Cce Mse-301 User manual

Service Manual

Model MSE-301

Customer: WalMart

CODE: 1.01.72274.51

__________________________

Approved Signature

MSE-301

INDEX

1. PRODUCT SPECIFICATION

2. PACKAGING BOX

3. TECHNICAL SPECIFICATION

4. TEST INSTRUCTION

5. MATERIAL LIST

6. ELECTRICAL SCHEME

6.1 MAIN PCB

7. SILKTOP AND SOLDERS

7.1 MAIN PCB

8. EXPLODED VIEW

PIPOCA

POTÊNCIA

CANCELAR INICIAR

POWER

DESCONG. RELÓGIO +1

MINUTO

ARROZ ENERGY

SAVING

MSE-301

DESCONG.DESCONG. BUZZER

DESLIG.

BUZZER

DESLIG.

TRAVATRAVA gg

S A V I N G

E ER Y

Esc. 1:2,5

Fl. 2/4

Dimensão do produto (L x A x P ): 530 x 320 x 430 mm - 900 Watts Potência

PAINEL DE CONTROLES

mec. 1.67.72204.05

acab. 1.67.72277.01

VISOR DO DISPLAY

mec. 1.67.72204.10

acab. 1.67.72358.01

PAINEL DA PORTA

mec. 1.67.72204.06

LOGOTIPO

acab. 1.67.72358.03

VISOR DA PORTA

mec. 1.67.72259.03

TECLADO DE FUNÇÕES

mec. 1.67.72204.09

TECLA POWER

mec. 1.67.22112.07

Acab. 1.67.72277.03

TECLA MULTI JOG

mec. 1.67.72204.08

ETIQUETA DE

IDENTIFICAÇÃO 120V

acab. 1.06.72358.01

ETIQUETA DE

IDENTIFICAÇÃO 220V

acab. 1.06.72360.01

CAIXA DE EMBALAGEM

acab. 1.05.72358.01

CAVIDADE MONTADA

acab. 1.53.72204.03

PORTA METÁLICA

acab. 1.67.72204.11

MÁSCARA DO PAINEL

mec. 1.67.72204.16

impressão

BRANCO

1.87.33701.28

impressão

CINZA

1.87.33701.09

impressão

VERMELHO CLARO

1.87.33701.40

EMBLEMA CCE

1.67.72358.03

visor do display=

SAN FUMÊ

1.86.91604.70

painel de controles

teclado de funções

tecla power

tecla multi jog=

ABS BRANCO

1.86.90018.90

painel da porta=

ABS BRANCO

1.86.90018.90

Porta metálica

Pintura Epoxi

PRETO

1.87.33686.00

MSE-301

Esc. 1:2,5

Fl. 3/4

210,0 mm

23,0 mm

MSE-301

Esc. 1:2,5

Fl. 4/4

1. Não ten te operar o forno de microondas se:

houver alg um objeto preso à porta;

a po rta do aparelho n ão estiver fechando

corretamente;

houver dan os na porta, n as dobradiças, nas

travas de segurança ou n a tela da p ort a. 4. N ão tampe as ab ert ura s de ventilação do a par elh o.

3. L imp e a parte i nte rna com um pan o umedecido c om

água o u com d ete rge nte líquido neutro. Não use

álcoo l ou pó de limpeza.

2. N ão deixe objetos met áli cos como colheres ou

garfo s na parte int ern a do forno.

PRECAU ÇÕ E S PARA EV ITA R PO S S Í V E L E X P O S IÇÃO A MICRO ONDA S.

CUI DADO !CUI DADO !

Não lig ue o forno de microondas quando

em s eu interior não h ouv er alimentos

ou l íqu ido s a serem p rep ara dos .

Se for necessário testar as funções do

produto, f aça -o operar com, pe lo menos,

um c opo com água e m seu interior.

Pintura

BRANCA

1.87.33630.00

Pintura

PRETO FOSCO

1.87.33800.01

Impressão

PRETO FOSCO

1.87.33675.00

Pintura

PRETO FOSCO

1.87.33800.01

POWER

CANCELAR INICIAR

S A V I N G

E ER Y

MSE_301

ARROZ ENERGY

SAVING

Retícula:

Produto: 10 linhas/cm, tipo redondo.

Outras Regiões: 10 linhas/cm, tipo geométrico.

MSE-301 Exp.

Fl. 3/3

Esc. S/E

MSE-301

3. TECHNICAL SPECIFICATION

Procedure to check up microwaves parameters

3.1 Product

Device Microwaves Oven

Model MSE-301

Capacity 30 liters

Frontal Panel

Lateral Panel -Material: Steel SAE 1010 ZCL Miniatured Crystals

(NBR 7008)

Back Panel -Weld by projections (capacitive and resistive)

Cavity

Chassis -Finishing: Painting the to the hot one–Epox

Cabinet -Color: ABS white euro

Product ≈530X320X430 mm

Dimensions Packing ≈612X376X477mm

Weight: Product ≈15,80 Kg

Packed

Product ≈18,10Kg

Display Led 7 segments.

Clock 12h

3.2 Specifications

a) Supply

UN. Nominal Min. Max.

Supply voltage V120 108 132

V220 209 231

Supply Frequency Hz 60 --

Microwaves Frequency (ISM) MHz 2450 2435 2465

Consumed Power MSE-301 W1340 --

Microwaves PowerMSE-301 W800 --

Nominal Current MSE-301 A13 --

b) PCB Voltage

point UN. Nominal Min. Max.

Trafo Primary Vac 120 --

Vac 220 --

Secondary Vac 10 --

12V + / -C05 Vdc 14 --

5V + / -C15 Vdc 5--

MSE-301

c) High Voltage

Magnetron voltageKV 4,25 --

Filament current A10 --

Diode current mA 300 --

d) General

−Resonance frequency (XTAL): 8,00MHz;

−Alarm frequency (Buzzer): 2,00KHz;

−Duration time of the sonorous alarm when pressed the key: 0,05 second;

−Duration time of the sonorous alarm when finished the process: 0,5

second/3 touches;

−Indication when the electric net: Access 4 segments / two points blink, to

indicate that the product is power on at the electric net.

3.3 Functions

01 Hot to maintain Cook wiht the 10% power.

02 Clock Clock function 12:00h.

03 +1 more Heat for 1 minute or add + 1 minute for the time.

04 Power on Execute the programed option.

05 Set Set the time and set the clock.

06 Power off / CancelStop the work or cancel the programming.

07 Cancel Cancel the programm

08 Defrost Execute the defrost pre programed function.

09 Power Set the level power desired.

10 Rice Execute the rice pre programed function.

11 Pop Corn Execute the pop corn pre programed function

3.4 Safety Requisites

a) Specification:

Accordance Product: IEC325-2-25 (1996).

b) Safety divices:

-Fuse of net: 20A/120V

10A/220V

-Monitored microwaves: 1st Monitored key of the door (otice the

microcontroler the door state).

2nd Monitored key of the electric net (em parallel

with AC, in case of relay fail and of the third key in

series with electric net, provoke the fuse burning.).

3rd Key in serires with the electric net (interrupt the

circuit supply at the moment when is opened the

door. ).

-Cavity thermostat: Temperature = 95ºC;

-Magnetron thermostat: Temperature = 135ºC;

MSE-301

4. TEST INSTRUCTION

4.1 Microwaves creepage

Specification: the microwaves creepage –a distance of 50mm of the external

surface of the device could not exceed 1miliwatts for squared centimeters.

Experience: a (275 +/-5) g load of potable water at (20 +/-2) ºC temperature

inside a recipient of thin walls of borosilicate glass with diameter upper 85mm

is places at the horizontal support center, the device supplied with nominal

voltage and operated with controls adjusted to maximim power. The

microwaves meter is moved over the device surface with objective the locate

microwaves creepage.

The maximum creepage colud not exceed 1 miliwatts per squared

centimeters.

4.2 Output power measurement of microwaves

It must be utilized borosilicate recipient with external diameter of

aproximately 190mm and height of 90mm and thickness of 3mm.

At the begining of the experience, the oven and the recipient must be at

environment temperature. And used to the experince potable water with 10

+/-1 ºC initial temperature. The water temperature is measured immediately

before to placed in recipient.

An amount of 1000 +/-5g of water is added in recipient. The recipient is

placed at plate center of the oven. The device is supplied with nominal

voltage at the adjustment of maximum power. It must be placed the needed

time for that the water reach 20 +/-2ºC. After the time finishing it leave the

recipient and it measured immediately.

Notas:

üThe water is mixed before your temperature be measured.

üDevice of mixing and measurement must have low capability of heating.

üSpecified power 800 Watts (IEC 705)

üPower tolerance +15-10%

The output power of the microwaves is calculated by formulation:

P = (1/T) x [4,187 x Mw x (T2 –T1) + 0,55 x Mc x (T2–T0)] / T

Where:

P = microwaves output in watts.

Mw = water mass in grammes.

Mc = recipient mass in grammes.

T0 = environment temperature in ºC.

T1 = water initial temperature in ºC.

T2 = water final temperature in ºC.

T= heating time in seconds, excluding the heating time of the magneton

filament.

MSE-301

4.3 Input power

The oven will have to be supplied with nominal voltage and a load of 1 liter of

water.

The measured input power could not present deviation more than 60W in

relation to the specified value, or either, the speficied value for consumed

power will be:

Consumed power = 1340 + 60W.

4.4 Oscillation frequency of the microwaves

The nominal frequency 2450MHz can vary +/-15MHz.

4.5 Creepage current and dielectric hardeness

Inicial experience: Submit a device to a climstic expereince during 72 hours

at the following conditions: 24 hours at the environment temperature and 48

hours a 30 +/-2ºC and 93 +/-2% of relative wetly.

Creepage current

The device creepage current could not exceed 0,5mA for class 01, when

submitted to a 1000V voltage.

4.5.1 Dielectric hardness

It could not occur anything spark ou fail when submitted to sinusoidal voltage

of 60Hz frequency, during 1 minute accordance the following description:

-beetwen the body and the poles of the supply cord, 1250V.

4.6 Heating

The device is placed as if was inlaid under of ceiling as

the following specifications.

a) minimum height in relation to device 150mm

b)depht of the ceiling 300mm, from the wall of the corner of experience.

c) minimum length 150mm more than the device width.

d) the device must be supplied with voltage 1,06 time the nominal voltage.

As the microwaves, the device is operated during 9 consutives periods of 10

minutes separated by an rest period of 1 minute.

It was adopted as load 1000g of water at 20ºC temperature. During the rest

period, the door is opened and replaced in the recipient.

During the heating experience, the temperature addition

could not exceed the specified values in the table A.

MSE-301

Measured points AB

1. Internal superior of the oven close of the thermostat cable. 160

2. Next the motor of the revolving. 60

3. Externallateral of the oven beside the transformer.60

4. Externalcentral superior of the oven 60

5. Insulation of white cable next the superior interlock. 65

6. Insulation of the black grey that come from the transformer primary

rolling. 65

4.7 Operation without load

The microwaves oven must be operated without load

during themost time permitted by timer.

The oven could not suffer no damage. Any device of

safety will have to act.

4.8 Supervision device

To curt-circuit the supervisor device of the door. Supply

the device with nominal voltage with the door closed. The

door opening will provoke the automatic power off of the

microwaves generator.

4.9 Protection against electric chock (miniature standard finger)

The standard finger miniature (figure 101 of the IEC 335 -

-25) cannot touch live parts when applied without

appreciable force in device parts that are accessible only

when the oven is operated in normal use.

4.10 Cutting parts

The device will not have present cutting partes that can

bring risk to the user during a normal operation or

maintans.

4.11 Insulation

Do not have be used as insulation the following materials:

üwood, cotton, silk, ,commom paper, with staple, hygroscopic.

MSE-301

4.12 Amianthus

Amianthus cannot be used in construction of devices.

4.13 Internal wiring

4.13.1 Internal wiring guide

The internal wiring guide must be smooth and free of

cutting parts.

The wiring cannot have contact with wings barbs of

cooling or similar.

The metallic orifice must be smooth and corners without

tips except if have bushings.

The wiring must not have contact with mobile parts.

4.14 Internal wiring insulation

The internal wiring insilation must resiste at the voltage

experience applied of 2000V, 60Hz during 15 minutes if

have not marking equivalent to IEC227, IEC245, NBR

13249 and NBR 9374.

4.15 Wire heart identification

The supply cord of class 01 devices must have a wire

heart that connect the earthing terminal of the device to

the earthing terminal of the electric net.

MSE-301

5. MATERIAL LIST

MAIN PCB

CAPACITORS

CODE DESCRIPTION POSITION

1380109622 ELCO 1UF/100V M 5x11mm C18

1380100524 ELCO 10UF/50V M 5X11MM C22

1380109622 ELCO 1UF/100V M 5x11mm C21

1363103601 C.C.D. Y5U 10KPF/500V Z C1

1363103601 C.C.D. Y5U 10KPF/500V Z C2

1363103601 C.C.D. Y5U 10KPF/500V Z C3

1363103601 C.C.D. Y5U 10KPF/500V Z C4

1363103300 C.C.D. Y5U 10KPF/50V Z C14

1363103300 C.C.D. Y5U 10KPF/50V Z C20

1363103300 C.C.D. Y5U 10KPF/50V Z C8

1364104102 C.C.D. Y5V 100NF/25V Z C10

1364104102 C.C.D. Y5V 100NF/25V Z C6

1360330300 C.C.D. SL 33PF/100V K C11

1360330300 C.C.D. SL 33PF/100V K C12

1380101328 ELCO 100UF/25V M 6,3X11MM C9

1291222422 ELCO 2200UF/25V M 16X20MM C5

1291222422 ELCO 2200UF/25V M 16X20MM CX

1259995898 CAPACITOR DE ALTA TENSAO 7(B11)

RESISTORS

CODE DESCRIPTION POSITION

1183510392 RES.METAL.FILME 1/2W 10K 5% N R12

1183510392 RES.METAL.FILME 1/2W 10K 5% N R17

1183510392 RES.METAL.FILME 1/2W 10K 5% N R42

1183510392 RES.METAL.FILME 1/2W 10K 5% N R43

1183510392 RES.METAL.FILME 1/2W 10K 5% N R44

1183510392 RES.METAL.FILME 1/2W 10K 5% N R47

1183510392 RES.METAL.FILME 1/2W 10K 5% N R57

1183510392 RES.METAL.FILME 1/2W 10K 5% N R58

1183510392 RES.METAL.FILME 1/2W 10K 5% N R59

1183510392 RES.METAL.FILME 1/2W 10K 5% N R6

1183510392 RES.METAL.FILME 1/2W 10K 5% N R60

1183510492 RES.METAL FILME 1/2W 100K 5% N D8

1183510492 RES.METAL FILME 1/2W 100K 5% N R63

1183515192 RES.METAL FILME 1/2W 150R 5% N R45

1183522392 RES.METAL FILME 1/2W 22K 5% N R41

1183522392 RES.METAL FILME 1/2W 22K 5% N R46

1183522392 RES.METAL FILME 1/2W 22K 5% N R61

1183522392 RES.METAL FILME 1/2W 22K 5% N R8

1183510292 RES.METAL FILME 1/2W 1K 5% N R1

1183510292 RES.METAL FILME 1/2W 1K 5% N R21

1183510292 RES.METAL FILME 1/2W 1K 5% N R22

1183510292 RES.METAL FILME 1/2W 1K 5% N R23

1183510292 RES.METAL FILME 1/2W 1K 5% N R24

1183510292 RES.METAL FILME 1/2W 1K 5% N R25

1183510292 RES.METAL FILME 1/2W 1K 5% N R26

MSE-301

CODE DESCRIPTION POSITION

1183510292 RES.METAL FILME 1/2W 1K 5% N R27

1183510292 RES.METAL FILME 1/2W 1K 5% N R28

1183510292 RES.METAL FILME 1/2W 1K 5% N R29

1183510292 RES.METAL FILME 1/2W 1K 5% N R50

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R52

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R53

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R54

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R55

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R56

1183547392 RES.METAL.FILME 1/2W 47K 5% N R49

1183547392 RES.METAL.FILME 1/2W 47K 5% N R5

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R13

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R14

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R19

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R4

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R48

1183547292 RES.METAL FILME 1/2W 4,7K 5% N R62

1183547292 RES.METAL FILME 1/2W 4,7K 5% N RX

1183510192 RES.METAL FILME 1/2W 100R 5% N R10

1183522292 RES.METAL FILME 1/2W 2,2K 5% N R11

1183522292 RES.METAL FILME 1/2W 2,2K 5% N R18

1183522292 RES.METAL FILME 1/2W 2,2K 5% N R9

1183533392 RES.METAL FILME 1/2W 33K 5% N R2

1183533392 RES.METAL FILME 1/2W 33K 5% N R3

1183556292 RES.METAL FILME 1/2W 5,6K 5% N R51

1182510632 RES.CARBONO 1/4W 10M 5% N R40

1183510192 RES.METAL FILME 1/2W 100R 5% N R32

1183510192 RES.METAL FILME 1/2W 100R 5% N R33

1183510192 RES.METAL FILME 1/2W 100R 5% N R34

1183510192 RES.METAL FILME 1/2W 100R 5% N R35

1183510192 RES.METAL FILME 1/2W 100R 5% N R36

1183510192 RES.METAL FILME 1/2W 100R 5% N R37

1183510192 RES.METAL FILME 1/2W 100R 5% N R38

1183510192 RES.METAL FILME 1/2W 100R 5% N R39

1183547192 RES.METAL FILME 1/2W 470R 5% N R20

1183547192 RES.METAL FILME 1/2W 470R 5% N R30

SEMICONDUCTORS

CODE DESCRIPTION POSITION

1320020102 TRANSISTOR BC-547B Q1

1320020102 TRANSISTOR BC-547B Q10

1320020102 TRANSISTOR BC-547B Q11

1320020102 TRANSISTOR BC-547B Q12

1320020102 TRANSISTOR BC-547B Q13

1320020102 TRANSISTOR BC-547B Q14

1320020102 TRANSISTOR BC-547B Q15

1320020102 TRANSISTOR BC-547B Q16

1320020102 TRANSISTOR BC-547B Q17

1320020102 TRANSISTOR BC-547B Q2

1320020102 TRANSISTOR BC-547B Q3

MSE-301

CODE DESCRIPTION POSITION

1320020102 TRANSISTOR BC-547B Q5

1320020102 TRANSISTOR BC-547B Q7

1320020102 TRANSISTOR BC-547B Q8

1320020102 TRANSISTOR BC-547B Q9

1415168901 DIODO ZENER BZX79C3V3 D11

1415166401 DIODO MTZ-JT77-3,3A D11

1415168901 DIODO ZENER BZX79C3V3 D11

1414621902 DIODO 1N4148 75V SINAL D10

1414621902 DIODO 1N4148 75V SINAL D9

1124500200 DIODO RETIFICADOR 1N4002 D1

1124500200 DIODO RETIFICADOR 1N4002 D2

1124500200 DIODO RETIFICADOR 1N4002 D3

1124500200 DIODO RETIFICADOR 1N4002 D4

1124500200 DIODO RETIFICADOR 1N4002 D5

1124500200 DIODO RETIFICADOR 1N4002 D7

1127613200 DIODO ALTA TENSAO ESJC13-12BX 10(F11)

1146100353 I.C. 7805 (METAL) IC1

1149376899 I.C. 7805 (PLASTICO) IC1

MISCELLANEOUS

CODE DESCRIPTION POSITION

1027220501 CJT.PCI MANUAL/MONTADO

1027220411 CJT.PCI AUTOMATICO MONT

1107220401 PEPCI PRINCIPAL 4PECAS

1169100010 JUMPER 10MM R31
