cec CD5 Manual

Installaton and Setup Gudie
for USB Driver on Windows PC
SOURCE
POWER
HEADPHONE
VOLUME
BELT DRIVE CD PLAYER CD5
Thank you for purchasing a CD5.
This guide book will show you how to install and setup the CD5 USB
driver at your Windows PC to playback music files through USB
connection.
CD5
Belt Drive CD Player
USB Sound System

CD PLAYER / USB SOUND SYSTEM CD5
2
Introduction …………………………………………………………………………………………… 2
USB Driver installation
1. Installation for BRAVO-HD …………………………………………………………………… 3
Installation and Setup to playback DSD les
2. Installation for foobar2000 …………………………………………………………………… 7
3. Installation for ASIO Driver on foobar2000 ………………………………………………… 9
4. Installation for ASIO Proxy on foobar2000 ……………………………………………… 11
5. Setup for foo_input_sacd.dll ……………………………………………………………… 13
BRAVO-HD Control Panel ……………………………………………………………………… 16
Contents
Introduction
The USB Interface equipped with CD5 is compatible to USB 2.0 audio device.
It is necessary for Windows PC users to install special driver for PCM music sources,
which is possible to download from the CEC home page.
When ASIO and DSD drivers are installed to the freeware pc-music player, foobar2000,
DSD les may be reproduced. This is to explain on how to install and set up those drivers
using foobar2000.
Compatible OS: Windows XP, Windows Vista, Windows 7, Windows 8
Mac PC (X10.6.8 or newer) are already equipped with a standard driver for USB 2.0 audio
device, and it is not necessary to install CEC specic driver.
Download site
Windows users may access to download this specic driver at CEC home page.
▷http://www.cec-web.co.jp/service/download/driver/index_ex.html
※It is not abnormal to see SECURITY WARNING upon downloading and/or installation. You may
continue to download and/or install according to the instructions by OS or Browser.
USB Driver (Your PC recognizes CD5 as a regular audio device.)
▷ 
BRAVO-HD (is the USB driver specialized in CD5, supplied by SAVITEC, USB Audio
IC manufacturer.)
Necessary components to reproduce DSD les at foobar2000
▷foo_out_asio_v2p1p2.fb2k-component (ASIO driver by foobar 2000)
▷ 
ASIOProxyInstall-0.6.0.exe (driver for the reasonable connection between ASIO and
DSD)
▷foo_input_sacd.fb2k-component (DSD driver by foobar 2000)
Note: The above are the possible components publicized on our internet. Up-dated version at CD5 might
not be assured.
Note: Free ware Music reproduction player foobar2000 can be downloaded at http://www.
foobar2000.org/

CD5 USB Driver Installation and Setup
3
USB Driver Installation
Install a USB driver, BRAVO-HD* on your Windows PC to recognize CD5 as USB audio device
and playback PCM music les.
*
BRAVO-HD is an exclusive USB driver that a USB Audio IC maker, SAVITEC company
provides for CD5.
1. Installation for BRAVO-HD
1.1. Melt (open) the "CD5_usb_win.zip" file downloaded from CEC download site and save the
melted folder at ex. desktop.
1.2. Double-click and open the saved "cd5_usb_win" folder.
1.3. Double-click "setup.exe" in the folder to start the installation.

CD PLAYER / USB SOUND SYSTEM CD5
4
1.4. BRAVO-HD install wizard will start. Click "Next" to continue.
1.5. Select an install folder and Windows user.
Click "Browse" to select an installation folder other than the default folder being showed.
Select "Everyone" for all Windows users to use BRAVO-HD or "Just me" only for the user
that is installing the driver now.
Click "Next" to continue.

CD5 USB Driver Installation and Setup
5
1.6. Click "Next" to start the installation.
1.7.
When the installation nishes a short-cut icon "BRAVO-HD Audio CPL" will be created on
desktop and the restart wizard will appear. Click "Yes(Y)" to restart the computer.

CD PLAYER / USB SOUND SYSTEM CD5
6
1.8. After the computer restarted connect with CD5 via USB cable.
1.9. Turning on CD5 the computer will recognize CD5 as CEC CD5 HS USB Audio and
automatically apply it to the output device. You can check the setting through control panel
- sound and audio device property. If not select CD5 as output device.
1.10. Starting a PC-music after selecting the USB input on CD5 you can listen to the playback
music through the analog or headphones output on CD5.
CD5 USB input is compatible with up to 32bit/384kHz PCM signal but the sampling frequency
may be limited by the system setting or PC-Music player.
Refer to "BRAVO-HD Control Panel" after completing "Installation and Setup to play DSD les"
Note: You can delete the downloaded "cd5_usb_win.zip" file and the saved "cd5_usb_win"
folder with files after the installation finished.
Sound property on WindowXP Sound property on Windows7

CD5 USB Driver Installation and Setup
7
Installation and Setup to play DSD les
Installing ASIO and DSD drivers to a freeware pc-music player foobar2000 for Windows
DSD64(2.8224MHz) and DSD128(5.6448MHz) les can be played through CD5.
Before starting these steps install foobar2000 to your Windows PC, which can be downloaded
from http://www.foobar2000.org/.
2. Installation for foobar2000 ASIO driver
2.1. Melt (open) the downloaded "cd5_dsd-plugin_fb2k.zip" le and save the melted folder at
ex. Desktop.
2.2. Double-click open the saved "cd5_dsd-plugin_fb2k" folder.
2.3. Double-click "foo_out_asio.fb2k-component" in the folder.
2.4.
foobar2000 Components Installer will start. Click "Yes(Y)" to continue.

CD PLAYER / USB SOUND SYSTEM CD5
8
2.5. The installing component "foo_out_asio" will be listed up marked with (unknown). Click
"Apply" to continue the installation.
2.6. Click "OK" to complete the installation and change. foobar2000 will restart.

CD5 USB Driver Installation and Setup
9
3. Installation for foobar2000 ASIO Proxy
3.1. Double-click "ASIOProxyInstall-0.6.0.exe" in the "cd5_dsd-plugin_fb2k" folder.
3.2. Click "Next" on ASIO Proxy for foobar2000 Setup wizard to continue.

CD PLAYER / USB SOUND SYSTEM CD5
10
3.3. Select an install folder.
Click "Browse" to select a folder other than the default folder being showed.
Click "Install" to start the installation.
4.2. Install will nish soon and click "Close" to complete the installation.

CD5 USB Driver Installation and Setup
11
4. Installation for foobar2000 DSD Driver
4.1. Double-click "foo_input_sacd.fb2k-component" in the "cd5_dsd-plugin_fb2k" folder.
4.2. foobar2000 Component Installer will start. Click "Yes(Y)" to continue.

CD PLAYER / USB SOUND SYSTEM CD5
12
4.3.
The installing component "foo_input_sacd" will be listed up marked with (unknown). Click
"Apply" to continue the installation.
2.6. Click "OK" to complete the installation and change. foobar2000 will restart.

CD5 USB Driver Installation and Setup
13
5. DSD Playback Setting on foobar2000
5.1. Click "File" on foobar2000 to open "Preferences".
5.2. Click "Tools - SACD" on the left side tree and select
"DSD" at ASIO Driver Mode.
5.3. Click "Playback - Output - ASIO" on the left side tree, and double-click "foo_dsd_asio"
listed at ASIO drivers.

CD PLAYER / USB SOUND SYSTEM CD5
14
5.4. Dialog for foo_dsd_asio v0.6.0 setting will appear.
Select "BRAVO-HD" at ASIO Driver.
Select "ASIO Native", "DoP marker" or "dCS Marker" at DSD Playback Method.
Note: ASIO Native is not compatible with DSD128.

CD5 USB Driver Installation and Setup
15
Select "DSD128" at Fs. Click "×" to close the foo_dsd_asio v0.6.0 setting dialog.
5.5. Click "Playback - Output" at the left side tree and select "ASIO:foo_dsd_asio" at Devices.
And click "OK" to nish the setup.
All the installation and setup have completed. Now foobar2000 is compatible with DSD64/128
and PCM up to 32bit/384kHz through CD5.

CD PLAYER / USB SOUND SYSTEM CD5
16
1. Start "BRAVO-HD Audio CPL" from the short-
cut on desktop or programs menu. BRAVO-
HD control panel will appear.
BRAVO-HD Control Panel
2. Turning on CD5 connected via USB cable the
BRAVO-HD control panel will change to show
a current setting.
In the area marked with Ⓐclick to change
the sample rate and/or bit rate to be used on
Windows sharing mode.
Note: WindowsXP does not have the sample
rate and bit rate settings for sharing
mode, thus Ⓐis not showed.
In the area marked with Ⓑthe current setting
and playback via ASIO like a foobar2000
output are displayed. And click to change the
bit rate and buffer size.
Note:
Ⓑdoes not work on playback via other
than ASIO.

CD5 USB Driver Installation and Setup
17
3. Changing the sample rate and bits per sample on BRAVO-HD control panel the Windows system
setting on "sound - digital output property" will change accordingly, and vice versa.
Note: Setting 352.8kHz or 384kHz the sound from ex. an internet browser may be unstable and noisy.
In that case set the sample rate 192kHz or lower and restart.

CD PLAYER / USB SOUND SYSTEM CD5
18
Ex. Playback after changing the bit rate and
buffer size during stop will show the new
settings.
Note: Bit rate setting should be the same as
or more than playback le. Otherwise the bit
rate for output is less than the original.
Note: By smaller buffer size setting against
a higher resolution music file a continuous
noise on music from the beginning, pop noise
or interruption may happen. In that case set
the buffer size bigger and restart.
4. PCM, bit rate, sampling frequency and buffer
size of a current PCM playback via ASIO like
a foobar2000 output setting are displayed.

CD5 USB Driver Installation and Setup
19
5. Displaying a DSD64/2.8MHz playback.
Note: When playing a DSD file set the bit
rate 24 or 32. 16 bits setting can not play any
DSD.
Ex. Playback after changing to 32 bits and
10ms buffer during stop will show the new
settings.
6. Displaying a DSD128/5.6MHz playback.
Note: Start BRAVO-HD Audio CPL to see a
current playback or change the settings. You
don't need to start it per playback.

1410-B
CEC Co., Ltd., Japan
