cec CD3300R User manual

Owner
’s M
Manual
CD3300R

2
Important Safety Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN THE UNIT. NO USER
SERVICABLE PARTS INSIDE: REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Precautions for use
•Check that the operating voltage of your unit is within the range of your local
power. Connecting to a too high voltage causes severe damage and may even
cause fire, electrical shock or explosion!
•Should any liquid or solid object fall into the cabinet, unplug the unit and have it
checked by qualified personnel before operating it any further.
•Sometimes in summer you have faults in your local power supply due to overloading.
Unplug the unit from the wall outlet when there is a thunderstorm.
•Unplug the unit from the wall outlet if it is not to be used for an extended period of
time. To disconnect the power cord, pull it out by grasping the plug. Never pull the
cord itself. Refer servicing to qualified personnel only.
•Unplug the unit from the wall outlet before connecting other units or opening the unit.
•If there is any break or cut in the AC-line cord, unplug it from the wall outlet and
replace it by a new one!
Location
•Do not install the unit in a location near heat sources such as radiators or air ducts, or
in a place subject to direct sunlight, excessive dust, mechanical vibration or shock.
Leave space around this unit for heat dissipation.
Condensation
•When this unit is brought into a warm room from previously cold surroundings or when
the room temperature rises sharply, condensation may form inside, and the unit may
not be able to attain its full performance. In cases like this, allow the unit to stand for
about an hour or raise the room temperature gradually.
Fuses
•The fuses are inside of the unit and should be changed by qualified personnel only.
Caution
•Changes or modifications to this equipment not expressly approved by CEC Co., Ltd.
for compliance will void the user’s warranty.

3
Introduction
Thank you for purchasing CD3300R!
Please read the manual carefully in order to use your CD3300R in the best possible way. CD3300R
is a high end sounding CD player, with several unique or special technical features, an outstanding
Digital to Analog Converter and Analog Output Stage without overall negative feedback loop (NFB):
x Most modern BB PCM1796, 24-bit DAC with balanced current output
x CI - Current Injection - Circuit for I/U Conversion without negative feedback (NFB)
x LEF Amplifier CC75 proceeding the whole signal in just one stage, NFB free
x Truly balanced, full differential signal proceeding
x RCA and balanced XLR analog output
x High Quality Headphone Amplifier, optimized for 15 to 150 Ohm Headphones
x Separate power supply for servo and DAC
x Transformerless synchronized digital outputs: Toslink, coaxial, AES/EBU
x CD, CD-R, CD-RW compatible
x Centre mounted mechanism
x Removable AC power cord
Maintaining Your CD3300R
•CD3300R requires no periodic maintenance and has no user serviceable parts inside.
•To keep it clean use only a soft cloth and never use any solvents or abrasives.
Dust and fingerprints may be removed with a soft cloth moistened only with a few drops of water.
•The power cord should be removed whenever the unit will be unused for an extended period.
Supplied Accessories
•The delivery includes a power cord, a remote control handset and spikes.
Repacking
•Keep the carton box and the packing material.

4
XPower - Power switch. Turns the unit on / off.
YPhones - 6.3mm standard headphone terminal and headphone volume control.
The outputs on the backside of the unit are not affected by the volume control.
ZOpen / Close - Tray open and close
[Music Skip - Jump to next or previous track
\Stop - Finish music play
]Play / Pause - Starts music reproduction. During play toggles between play and pause.
Two easy ways to play a CD:
1.: Open the tray by pressing Z, insert a CD and press ].
2.: Open the tray by pressing Z, insert a CD, close the tray by pressing Zagain, wait until the
display shows the content of the CD, then press ].
Front Panel Functions
XY Z[\]

5
ANALOG OUTPUT
XBALANCED - Balanced analog XLR output. Pinning: 1=Ground, 2=Hot, 3=Cold.
YRCA - Unbalanced standard analog output for connecting an amplifier.
Balanced XLR connections are first choice!
DIGITAL OUTPUT
ZTOSLINK - Optical digital output for Toslink optical fibre connection
[COAXIAL - Standard digital (SPDIF) output. The cable impedance should be 75 Ohm.
\AES/EBU - Balanced digital output according to the AES/EBU standard. The highest
quality link to connect CD3300R with other compatible digital audio device.
The cable impedance should be 110 Ohm.
Pinning: 1=Ground, 2=Hot, 3=Cold.
AC-POWER
]AC-POWER - AC Power connector.
Rear Panel Functions
BALANCED-R BALANCED-LRCA
L
R
AC-POWER
AES / EBU
COAXIALTOSLINK
DIGITAL OUTPUT
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLITE
KLASS 1 LASERAPPARAT
COMPACT DISC PLAYER
Model CD3300R
MANUFACTURED BY
CANDEIAS ENGINEERING
SHANGHAI, CHINA
ANALOG OUTPUT
CEC Co., Ltd.
Saitama Japan
Nur Sicherung 250V
Use Only With A 250V Fuse
Employer Uniquement Avec
Fusible De 250V
10A 250V ~
SERIAL NO.
XY Z[\ ]X

6
Remote Control
• Avoid exposure of the remote sensor to direct sunlight or other light sources as such exposure can
cause malfunction.
• When operating the remote control unit, pay attention to a free way to the CD3300R, otherwise
control may not be possible.
• When operating the remote control unit, point the unit’s infrared signal transmitter at the remote
control receiver behind the window on the front panel of the CD3300R.
• When the batteries are exhausted, the remote commander will not operate the unit. In this case,
replace the batteries with new ones. Use only batteries of same type.
If you should have any further question or problem concerning your unit, please contact your CEC dealer.
The included remote control is for the use with CEC CD transport, CD player, digital to analog
converter and amplifier. This manual just describes the functions concerning the CD3300R.
MEMO, CHECK and CLEAR for programmed playback,
see next page.
TIME to show 1. elapsed time of the actual track
2. remaining time of the actual track
3. remaining time of the whole CD
1...9; +10; 0 - Direct access play.
Press the numeric button corresponding the required track. The
player starts from the specified track directly.
Example to play track 28: Press +10 >+10 >8.
SHUFFLE: This function plays the tracks of a CD randomly.
SEARCH: High speed music search.
SKIP: Jump to next or previous track.
PLAY / PAUSE
STOP
INTRO: Plays the beginning of each track for 10 seconds.
1/ALL: To repeat a CD press 1/ALL once, for a track twice.
A-B: To repeat a designated section :
1. Press PLAY to start playback.
2. Designate the point where the repeat play-back
should start (point A) by pressing A-B -
The Repeat and A indicators light.
3. Press A-B again at the ending point (point B).
The portion will be played repeatedly until
pressing A-B again to terminate the function.

7
Programmed Playback
1. In stop mode, press MEMO.
The player enters the program mode. The memory
indicator lights on the display. The TRACK No. and
STEP No. indicators blink.
2. Press numeric buttons
They are automatically stored in the program memo-
ry order.
Example to program tracks in the order 3 - 15:
Press 3with the numeric button of the remote
control. 3 appears in the Music Calender, TRACK 3
and STEP 2 blink in the display. Then press +10
and 5.
3. Press the play button Ź
•The same track can be programmed repeatedly.
•Playback stops when the last programmed track
has finished playing.
•The programmed contents will be held in memory
even after program playback has been completed or
when playback is stopped be pressing STOP.
•To terminate the program mode, press MEMO. in
Stop mode.
Checking the programmed contents:
The programmed contents can be easily checked
using the CHECK button in STOP mode. Each time
the button is pressed, the track number and STEP
number appear in the programmed order.
Clearing the program memory
• In STOP mode press CLEAR for more than 2 se-
conds to clear the program memory.
• The program is also cleared by opening the tray.
• Once the CD player has been powered off, any
program content is cleared.
Changing the program:
1. In STOP mode, press CHECK to indicate the
desired STEP number in the display
2. Press CLEAR. The track number displayed will be
deleted and the next track advance up.
Repeat the same steps to delete other track num-
bers.
Renewing a track:
1. In STOP mode, press CHECK to indicate the
desired STEP number in the display
2. To modify the program, input the desired TRACK
No. using the numeric buttons. The indicated track
which was previously programmed is modified.
Adding a track:
To add new track to the program, input the track
number using the numeric buttons in the STOP
mode. The track is added to the end of the program.
CHECK
5
3
+10
CLEAR
MEMO

8
Specifications
• Laser: 3 beam semiconductor laser
• Frequency response: 20 Hz to 20 kHz: +/- 0.3 dB
• Output voltage RCA: 2 V rms
• Output voltage XLR: 4 V rms
• Total harmonic distortion: 0.008 % at XLR Output, 0.01 % at RCA Output
• Signal / Noise: 106 dB at XLR Output, 97 dB at RCA Output
• Channel separation: >95 dB
• Power consumption: 10W
• External dimensions (w / h / d): approx.: 435 x 115 x 310 mm
• Weight: approx.: 4.6 kg
Note:
• Specifications and design subject to possible modification without notice, due to improvements.
Errors excepted.
CEC Co., Ltd.
Saitama, Japan
