cectek Kingcobra User manual

UNDERSTAND ALL MESSAGES IN THIS MANUAL 1
COORDINATION OF THE VEHICLE IN THIS MANUAL 2
IMPORTANT SAFETY MESSAGE 3
LOCATION OF THE IMPORTANT LABELS 5
WARNING FOR OPERATION 9
VEHICLE INFORMATION 20
VEHICLE SPECIFICATIONS 20
Dimension and Dry Mass 20
Engine 20
Drive Train 20
Chassis 20
Electrical 21
Capacity 21
IDENTIFICATION OF THE VEHICLE 21
Vehicle Identication Number (VIN) Location 22
Engine Identication Number (EIN) Location 23
Key 24
LIQUIDS 24
Fuel 24
Refuel and Fuel Level 25
Engine and Transmission Oil 26
Engine and Transmission Oil Level 27
Front and Rear Differential Gear Oil 29
Front and Rear Differential Gear Oil Level 29
Engine Coolant 30
Engine Coolant Solution Level 31
Brake Fluid 32
Brake Fluid Level 32
Battery 34
Remove Battery 34
Install Battery 34
BREAK-IN 35
Engine 35
Belt 35
10 HOUR / 30 DAYS INSPECTION 35
CONTROL AND ADJUSTMENT 36
LOCATION OF EQUIPMENTS AND PARTS 36
(1) MAIN SWITCH 41
(2) INSTRUMENT PANEL 43
a. Shift Position Indicators 45
b. Direction Light Indicator 45
c. Speedometer 45
d. Odometer (ODO) / Trip meter 45
e. Clock 45
f. High-Beam Headlight Indicator 45
g. 4WD Indicator 46
h. Rear Differential Lock Indicator 46
i. Both Differential Lock Indicator 46
j. Coolant Temperature Indicator 46
k. Engine Check Warning 46
l. Oil Pressure Warning Indicator 47

m. Fuel Meter 47
n. Tachometer 47
o. Hazard Warming Indicator / Engine Speed Limit Indictor 47
(3) TRANSMISSION GEAR SHIFT KNOB 48
(4) 2WD/ 4WD SELECTION KNOB (ONLY FOR 4WD) 49
(5) LEFT HANDLEBAR CONTROLS 50
a. Headlight Switch 51
b. Hazard Warning Switch 52
c. Direction Light Switch 52
d. Horn Button 52
e. Override Button 52
f. Engine Start Button 53
g. Parking Brake Lever 54
h. Rear Brake Lever 55
i. Parking Brake Lock 55
(6) RIGHT HANDLEBAR CONTROLS 56
a. Engine Stop Switch 56
b. Differential Lock Switch 57
Power Delivery Options 58
c. Throttle Lever 60
d. Throttle Cable Tension Adjuster 60
e. Front Brake Lever 61
f. Throttle Limiter 61
(7) 12Volt ACCESSORY SOCKET 62
(8) FOOT BRAKE PEDAL 63
(9) REWIND STARTER 63
(10) REAR BOX 64
(11) FRONT BOX 65
PRE-OPERATING CHECK 66
OPERATING YOUR ATV 67
YOU HAVE TO REMEMBER BEFORE OPERATION 67
INSPECTION BEFORE DRIVING 68
WHAT TO WEAR 70
STARTING THE ENGINE 72
BRAKING 73
TURNING 74
SKIDDING OR SLIDING 75
OPERATION ON HILLS 77
Climbing the Hill 78
Descending a Hill 80
TRAVERSING A SLOPE 81
DRIVING OVER OBSTACLES 82
DRIVING THROUGH WATER 83
DRIVING IN COLD WEATHER 85
Pre-ride Inspection 85
Dressing for Cold Weather Driving 86
Driving on Snow, Ice, or Any Slippery Surface 87

DRIVING IN REVERSE 88
MAINTENANCE 89
INSPECTION AND MAINTENANCE 89
TOOL KIT 91
ELECTRICAL HOUSING 92
BATTERY 93
SPARK PLUG 94
THROTTLE CABLE ADJUSTMENT 95
FUEL LINES 96
ENGINE OIL AND FILTER CHANGE 97
AIR CLEANER 98
AIR CLEANER DRAIN TUBES 101
ENGINE COOLANT CHANGE 101
GEAR OIL CHANGE 103
TIRES FOR OFF ROAD 104
Tire Thread Condition 105
TIRES FOR ON ROAD 105
Tire Thread Condition 106
Tire Pressure 106
TIRE REPLACEMENT 107
FRONT AND REAR WHEEL FREEMOVE 107
BRAKE PADS 108
BRAKE FLUID 109
FUSES 110
LIGHT BULB REPLACEMENT 111
HEADLIGHT 111
BRAKE / TAILLIGHT 113
TRAILER TOWING 114
VEHICLE/TRAILER LOAD 114
TROUBLESHOOTING 116
PREPARTION FOR WINTER DRIVING 118
TRANSPORTING 118
CLEANING PROCEDURE AND STORAGE PROCEDURE 118
PREPARATION FOR CLEANING 119
WASHING YOUR VEHCILE 119
INSPECTION AFTER CLEANING 120
STORAGE PROCEDURE 120
Vehicle 120
Fuel 120
Engine 121
Battery 121
Tire 121
External 121
PROCEDURE FOR RETURNING TO SERVICE 121
WARRANTY 122

1
UNDERSTAND ALL MESSAGES IN THIS MANUAL
Many important safety messages are printed in this manual and on the vehicle. Before
operating the vehicle, realize all contents and special messages labeled with the ALERT symbol
and the words WARNING, CAUTION and NOTE which have special meanings. Fail to
follow the contents and special messages when operating this vehicle can cause the SEVERE
INJURY AND DEATH.
WARNING is as below:
Indication of highly potential hazard which
may cause SEVERE INJURY or DEATH.
Warning
CAUTION is as below:
Indication of highly potential hazard which
may cause VEHICLE DAMAGE.
CAUTION
NOTE is arranged as below:
NOTE: Indication of specic information for user to maintain or operate the vehicle easier.
WARNING and CAUTION are arranged as below format:
This rst part will describe the POTENTIAL HAZARD.
This second part will state WHAT CAN HAPPEN If you ignore the message.
The third part will state HOW TO PREVENT THE HAZARD.
WARNING or CAUTION

2
COORDINATION OF THE VEHICLE IN THIS MANUAL
Front
(FWD)
Left Hand Side
(LHS)
Right Hand Side
(RHS)
Rear
(BACK)
Top View of the Vehicle

3
IMPORTANT SAFETY MESSAGE
•
THIS VEHICLE IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE: The maneuver
of this vehicle is different form other types of vehicles including motorbikes and cars.
Improper operation without taking proper precautions, a collision or rollover can
occur quickly. If the rider does not follow the instructions in this manual, it can cause
SEVERE INJURY OR DEATH.
•
Read this manual carefully before operating the vehicle. This manual contains important
safety information. Please read carefully and fully understand all of the contents in this
manual before operating the vehicle.
•
Always follow the instructions in this manual when operating the vehicle. Improper
operation of this vehicle may cause SEVERE INJURY OR DEATH.
•
Take a training course before operating this vehicle. Beginners should attend the training
course provide by specic instructor licensed by local authorities. Please contact a authorized
ATV dealer or organization to nd out the training course available in your area.
•
Never allow any person under 16 years old to operate this vehicle.
•
Follow the instruction in this manual to carry a passenger on this vehicle.
•
Not for SPORTS or RACE use, never attempt jumps, wheelies, or stunts. This vehicle is
designed and manufactured under the instructions of EU DIRECTIVES ON TWO OR THREE-
WHEEL MOTOR VEHICLES. This vehicle is NOT designed and manufactured for SPORTS
OR RACE use. This vehicle complies with all applicable EU directives, regulations, and laws
in effect at the time of manufacture.
•
Operating this vehicle on any public street, road, or landscape should follow the instructions,
directives, regulations, and laws of the local authorities. Please check any applicable local
instructions, directives, regulations, and laws and consult with the local authorities before
operating this vehicle.
•
Never operate this vehicle on highway. This vehicle is NOT designed and manufactured
for highway use.
•
Always operating this vehicle with proper protection: Rider and Passenger on this
vehicle should always wear approved helmet and protection gears (goggles or face shield,
gloves, boots, long sleeved shirt, jacket, and long pants).
•
Never consume drugs, alcohol, food, or drinks which can affect your physical
capability before or while operating this vehicle.
•
Always operate this vehicle at a speed which is proper for the operating condition,
terrain, visibility, weather, environment, your skill and experience. Improper operation
at excessive speed can cause SEVER INJURY or DEATH.
•
Always follow the inspection and maintenance procedures and schedules stated in
this manual. Always inspect this vehicle each time and conrm it is safe for operation
before operating.
•
Always keep both feet on the footrests and hands on the handlebars to operate this
vehicle.
•
Always ride this vehicle slowly and be extremely careful when passing unfamiliar
terrain especially the changing terrain.

4
•
Never operate this vehicle on unfamiliar terrain without learning and practice before in
the training course.
•
Always operate this vehicle by proper procedures described in this manual and check
if you can handle the operation on the terrain before entering.
•
Never open the throttle suddenly, go high speed, and make sudden gear changes
when operating this vehicle in difcult terrain, hill, valley, or any not level status.
•
Never operate an ATV through fast owing water or in deep water. Be aware of that
stop capability of brake may be reduced by water. Always test the brake and conrm
the brake force sufcient when the brake could be wet.
•
Always conrm that there is no obstacle, person, or animal behind the vehicle before
operate the vehicle in reverse. When go reverse, always go slowly.
•
Always use tires in specication of this manual and inate the tire with right air and
maintain the tire pressure in specication.
•
Never attempt to modify an ATV via installing not genuine parts, improper installation,
or equipping improper accessories.
•
Never put the payload over the loading capacity stated in this manual and labels
on the vehicle. Always conrm the payload is proper distributed on the vehicle and
attached securely. Reduce speed, increase safety clearance for stopping the vehicle,
and follow the instructions in this manual for carrying payload, passenger, towing, or
any material increasing the total gross weight of the vehicle.
•
Always follow the instructions in this manual when you are taking a passenger.
•
You should install specific genuine components for the passenger sitting on the
vehicle securely. Conrm with your local authorities if it is legal to carry a passenger
on the vehicle in the area.
•
FOR MORE INFORMATION ABOUT ATV SAFETY, please consult with the distributors
of CECTEK in your country.
REMEMBER:
Indication of highly potential hazard which
may cause SEVERE INJURY or DEATH.
Warning
All information and content in this manual are based on the latest product information
available at the time of publication. Due to improvement, optimize, or changes, there may be
discrepancies in this manual. CECTEK reserves the right to make change at any time without
notice and without incurring any obligation.

5
LOCATION OF THE IMPORTANT LABELS
WARNING AND SPECIFICATION LABELS ON THE VEHICLE
Carefully read all labels on the vehicle. If you could not exactly understand all of the labels,
please consult with your local dealer. Those labels contain very important safety information
and notes for operation of the vehicle.
Those labels should be a permanent part of the vehicle and should be always clear for
reading. If the labels are too dirty to be read or come off, please contact your local dealer for
replacement.
1
3
4

6
5
2
6

7
6

8
Label 1
Label 2
Label 3
Label 4 (for 4WD only)
Label 4 (for 2WD only)
Label 5 (for OFF ROAD only)
Label 5 (for ON ROAD only)
Label 6

9
Warning
•
Operating this Vehicle without proper training can be hazardous.
•
If you do not know how to operate this vehicle properly in different situations and on
different type of terrain, accident can be happen.
•
Beginnings and inexperienced operators should complete the certified training
course. They should regularly practice the skills learned in course and the operating
techniques in this owner’s manual. For more information about the training course,
contact CECTEK authorized dealers.
•
Always operate the vehicle at low speed until you are thoroughly familiar with the
operation of the vehicle.
•
Take the time to learn the basic techniques well before attempting more difficult
operate.
WARNING FOR OPERATION
You should read all of the following information before DRIVING . If you are NOT properly
prepared, NEVER try to operate this vehicle.

10
Warning
•
Operating this vehicle by children under age 16 can be hazardous.
•
Operated by children under age 16 can result in their sever injury or death. Children
under age 16 do not have the physical capability, skills, abilities, or judgment needed to
operate this vehicle safely.
•
Never allow any children under age 16 to operate this vehicle.
UNDER
16

11
Warning
•
Operating this vehicle after consuming alcohol or drugs can be hazardous.
•
Alcohol and drugs can
1.Seriously affect your judgment.
2.Cause you to react more slowly.
3.Affect your balance and perception.
•
Operating this vehicle after consuming alcohol or drugs can result in an accident or
death.
•
Never consume alcohol or drugs before or while DRIVING this vehicle.

12
Warning
•
Operating this vehicle on paved surface, including sidewalk, paths, parking lots
driveways, and streets can be hazardous.
•
This vehicle tires are designed for off-road use only. DRIVING on paved surfaces may
seriously affect handling and control of this vehicle, and may cause the vehicle to go out
of control.
•
Avoid operating the vehicle on any paved surfaces whenever possible.
•
If you must ride on paved surface, ride slowly and do not make turns or stops suddenly.

13
Warning
•
Operating this vehicle on public streets, roads, or highways without following the law
and regulations can be hazardous.
•
Always follow your local laws and regulations when you are DRIVING on the roads.

14
Warning
•
Operating this vehicle at excessive speeds can be hazardous.
•
Speeding could increase the chances of losing control the vehicle, which can result in an
accident.
•
Always travel at a speed that is proper for the terrain, visibility and operating conditions,
and your skills or experience.

15
Warning
•
Attempting wheelies, jumps, and other stunts can be hazardous.
•
Never attempt stunts, such as wheelies or jumps.

16
Warning
•
Removing hands from the handlebars or feet from the footrest when operating the
vehicle can be hazardous.
•
Removing any hand or foot when operating the vehicle can reduce your ability to control
the vehicle or lose your balance and fall off the ATV. If you remove a foot from the
footrest, your foot or leg may come into contact with the rear wheels, which could injure
you or cause an accident.
•
Always keep both hands on the handlebars and both feet on the footrest during the
operation.
