Coleman Powersports AT125UT User manual

READ THIS MANUAL CAREFULLY! It contains
important safety and service information.
AT125UT Owner’s Manual

chemicals including engine
exhaust , carbon monoxide,
phthalates, and lead, which are
known to the state of California to
cause cancer and birth defects or
other reproductive harm. To
minimize exposure, avoid
breathing exhaust, do not idle the
engine except as necessary, service
your vehicle in a well-ventilated
area and wear gloves or wash your
hands frequently when servicing
your vehicle. For more information
go to www.P65Warnings.ca.gov/-
passenger-vehicle
!WARNING
Operating, servicing and
maintaining a passenger vehicle or
off-road vehicle can expose you to

This vehicle should only be assembled and prepped by authorized
Coleman Powersports Dealer or professional motorcycle mechanic.
You should never to try to attempt assembly of this vehicle, it should
be done by professionals.
Death or serious injury could result from failure to follow these
warnings and instructions.
Please read carefully before operating this Vehicle!

INTRODUCTION
Thank you for purchasing the AT125UT. This ATV is designed for years of reliable use and family fun.
This manual will provide you with a good basic understanding of the features and operation of this ATV.
This manual includes important safety information. It also includes general riding techniques, maintenance
and inspection procedures. If you have any questions regarding the AT125UT, please contact Coleman
Powersports by visiting colemanpowersportsusa.com or call Customer Service at [phone]
AN IMPORTANT NOTE TO PARENTS:
THE AT125UT IS INTENDED FOR USE BY OPERATORS 10 YEARS OF AGE AND OLDER.
This ATV is not a toy. Before you let your child operate this ATV, you should understand
the instructions and warnings in this Owner’s Manual. Then be sure your child
understands and will follow them. Children differ in skills, physical abilities and
judgment. Some children may not be able to operate an ATV safely. Parents should
supervise their child’s use of the ATV at all times. Parents should permit continued use
only if they determine that the child has the ability to operate this ATV safely.
The AT125UT ATV has multiple safety features including an adjustable speed limiter. We recommend that all
beginners start with the slowest setting first. The speed adjusting screw may be gradually turned out as the
beginner becomes more familiar with operating this ATV. Parents should decide when to adjust for more power and
speed as the rider’s riding skills improve.
If your child is a beginner or is inexperienced, he or she should take a training course
free of charge. The free training course is available to purchasers of new AT125UT by
calling [phone] .
TIP

IMPORTANT MANUAL INFORMATION
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN
SERIOUS INJURY OR DEATH.
Important information is distinguished in this manual by the following notations:
Product and specific tions are subject to change without notice.
IMPORTANT NOTICE
The AT125UT ATV is designed and manufactured for off-road use only. It is illegal and
unsafe to operate this ATV on any public street, road or highway.
This ATV complies with all applicable off-road noise level and spark arrester laws and
regulations. Please check your local riding laws and regulations before operating the
AT125UT ATV.
This ATV should not be operated by anyone under 10 years of age.
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
A NOTICE indicates special
precautions that must be taken
to avoid damage to the vehicle
or other property.
A TIP provides key information
to make procedures easier
or clearer.
A WARNING indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
TIP
NOTICE
NOTICE

WARNING & SAFETY LABELS
Please read and understand all of the labels on your AT125UT ATV.
These labels contain important information for safe and proper operation. Never remove any labels from your ATV. If a label becomes
difficult to read or comes off, request a new replacement label from your Coleman Powersports dealer.

TABLE OF CONTENTS
Engine Stop, Lanyard Cord & Remote ..................................................1,2
Control Layout .............................................................................................. 5
Main Switch..................................................................................................... 6
Getting to know your ATV ................................................................ 32-42
Maintenance ................................................................................................. 31
Coleman Powersports Limited Warranty ...................................... 60-62
Instrument Cluster....................................................................................... 7
Speed Limiter ................................................................................................ 8
Parking Brake ................................................................................................. 9
Choke Lever ................................................................................................... 10
Fuel Tank Capacity ...................................................................................... 11
Fuel Tank Cap .............................................................................................. 12
Fuel Cock/Fuel Valve................................................................................... 13
Seat ................................................................................................................... 14
Under Seat Compartment ......................................................................... 15
Battery Charging & Changing Fuse ....................................................... 16
Pre-Ride Safety Checks.......................................................................... 17,18
Front & Rear Brakes ...................................................................................... 19
Tires & Wear Limit ........................................................................................ 20
Chassis Fasteners ......................................................................................... 15
Starting Engine ............................................................................................. 21
Engine Break-In ............................................................................................. 22
Parking, Accessories & Modifications, Rear Cargo Rack.................. 23
Gear Selector Lever...................................................................................... 24
Throttle cable & Throttle Cable Adjustment ...................................... 25
Brakes .............................................................................................................. 26
Front Brake Lever Freeplay Lower adjustment & Hydraulic Rear
Brake .......................................................................................................... 27,28
Engine Idle Adjustment .............................................................................. 29
Adjusting Suspension Spring Preload .................................................... 30
Specification Chart ...................................................................................... 43
Maintenance chart ................................................................................ 44-48
Engine Oil ................................................................................................. 49,50
Cleaning Air Filter Element ..................................................................... 51
Spark Plug ....................................................................................................... 52
Drive Chain & Adjustment ................................................................ 53-55
Lubricating Pivoting Joints ..................................................................... 56
Cleaning Spark Arrester ............................................................................. 57
Electrical Wiring Diagram .......................................................................... 58
Electrical Connector Wiring Diagram ................................................... 59
Transporting ................................................................................................. 3
Description .................................................................................................... 4
Emission Control System Warranty ............................................... 63-66

SAFETY INFORMATION
THE AT125UT ATV IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE.
MAKE SURE YOU UNDERSTAND ALL INSTRUCTIONS.
PAY CLOSE ATTENTION TO THE WARNING AND CAUTION LABELS ON THE ATV.
NEVER OPERATE THIS ATV WITHOUT PROPER TRAINING OR INSTRUCTION.
CHILDREN MAY NOT BE ABLE TO OPERATE THIS VEHICLE SAFELY DUE TO PHYSICAL OR MENTAL LIMITATION.
NOTICE The ATV you purchased may differ slightly from the illustrations in this Owner’s Manual.
Please consult your local Coleman Powersports dealer with any questions not covered in
this manual.

l
l
l
l
l
l
l
l
l
l
l
l
Always avoid operating an ATV on any paved surfaces, including sidewalks, driveways, parking lots
and streets.
This ATV is designed for operation by a single person at least 10 years of age, without passengers.
Never operate an ATV on any public street, road or highway, even a dirt or gravel road. This ATV is
designed and manufactured for use only off public roads.
Never operate an ATV without wearing an approved motorcycle helmet that ts properly. You should also
wear eye protection (goggles or face shield), gloves, boots, a long-sleeved shirt or a jacket, and long pants.
Never consume alcohol or drugs before or while operating this ATV.
Never operate the ATV on hills too steep for the ATV or for your abilities. Practice on smaller hills before
attempting larger hills.
Never modify an ATV through improper installation or use of accessories.
Never attempt wheelies, jumps, or other stunts.
Always inspect your ATV before you ride. Make sure it is in safe operating condition. Always follow the
inspection and maintenance procedures and schedules described in this manual.
Always keep both hands on the handlebars and both feet on the footrests of the ATV
during operation.
Always follow proper procedures for turning as described in this manual. Practice turning at low speeds
before attempting to turn faster speeds and never turn at excessive speeds.
Never let refueling be done by anyone other than an adult.
SAFETY INFORMATION

l
l
l
l
l
l
l
Never permit anyone other than an adult to start the ATV.
Drain gasoline from the fuel tank and carburetor prior to transporting the ATV.
Caution the child and others near the vehicle not to get close to or touch any moving parts or any heated areas
such as the engine and exhaust pipe.
Never let your child operate an ATV without close adult supervision (a child under 10 should not operate this
ATV even with adult supervision).
Promptly correct your child if he or she begins to ride beyond his or her abilities and, if necessary, intervene by
pulling the cord (lanyard) to stop the engine.
If the child rides beyond his or her abilities, or rides in terrain that is too dicult, he or she may lose control of
the ATV, causing an accident.
Introduce new riding situations slowly and make sure the riding areas do not exceed your child’s skill level.
SAFETY INFORMATION (continued)

ENGINE STOP LANYARD CORD & REMOTE
The AT125UT has two emergency-stop engine switches. The primary emergency engine shut off switch is the lanyard cord and
the secondary is the wireless engine shut off key fob.
The wireless engine shut off key fob has a limited range that varies in dierent conditions
DO NOT RELY solely on the key fob as the emergency engine shut off swich, especially
during operator training.
KEY FOB:
The wireless engine shut-off is desired for use by an adult supervising the child operating the ATV. The wireless engine
shut-o will work in the range of 50ft. If outside the range of the remote the remote will not stop the engine.
1. Test the range by turning on the ATV and walk 50 feet away and press the shut-off button on
the wireless remote. The engine should stop running, if the engine continues to run, you
may need to get closer or make sure there are no obstructions between the ATV and you.
2. Before using the wireless engine shut-off switch make sure the batteries in the remote are
new and have a full charge. Low or dead batteries in the wireless remote can prevent the it
from working properly.
3. The wireless engine shut-off key fob should not be used as a full-time engine stop switch by
the operator.
Supervising adults can use the wireless engine shut-off switch to turn the
engine off if the operator is riding recklessly or beyond his or her skill level. Once
corrective instructions have been given, the adult can restart the engine using the
wireless remote switch.
TIP
1

LANYARD CORD:
The lanyard cord is designed for use by an adult supervising the child operating the ATV. When using the engine
stop switch cord, be sure the speed limiter on the handlebar is adjusted and the engine speed limits the ATV to a
walking speed.
1. Install the cap on the end of the engine stop switch cord onto the engine shut-off switch
(Red button).
2. Put your fingers in the loop at the other end of the cord.
3. As your child is riding, walk behind the ATV, closely watching his or her actions as well
as the path ahead.
4. If there is a potential hazard ahead or if your child is not riding correctly, pull fimly on the cord (lanyard) to
stop the engine. Because the ATV will continue to roll for some distance,
allow extra time and distance to pull the cord before a potentially hazardous situation
might be encountered.
The ATV will not start without the cap in place.
NOTICE
1. Lanyard Cap
TIP The lanyard assembly can be attached on the left or right
side of the handle bar.
2

Avoid Carbon Monoxide Poisoning! All engine exhaust contains carbon monoxide, a
deadly gas. Breathing carbon monoxide can cause headaches, dizziness, drowsiness,
nausea, confusion, and eventually death. Carbon Monoxide is a colorless, odorless
tasteless gas which may be present even if you do not see or smell any engine exhaust.
Deadly levels of carbon monoxide can collect rapidly and you can quickly be overcome
and unable to save yourself. Also, deadly levels of carbon monoxide can linger for hours
or days in enclosed or poorly ventilated areas.
If you experience any symptoms of carbon monoxide poisoning, leave the area
Immediately, get fresh air, and SEEK MEDICAL TREATMENT.
Do not run engine indoors. Even if you try to ventilate engine exhaust with fans or open
windows and doors, carbon monoxide can rapidly reach dangerous levels.
When transporting the ATV in another vehicle, be sure it is kept upright and that the
fuel valve is in the off position. Fuel may leak out of the carburetor or fuel tank cap.
Fuel
Off
TRANSPORTING THE ATV
3

DESCRIPTION
RIGHT SIDE Air Filter
Fuse 10 Amp
Spark Arrester
Engine Oil
Dip Stick
Foot Rest
Spark Plug
Front Shock
Fuel Cap
Rear Cargo
Rack
Muffler
Rear Shock
Gear Shifter
Fuel On/Off Valve
Front Bumper
Cover
LEFT SIDE Front Cargo
Rack
Battery
4

CONTROL LAYOUT
CONTROLS & FUNCTIONS
IGNITION SWITCH
The positions of the main switch are as follows.
Ignition ON All electrical systems are supplied with power, and the engine can be started.
The key cannot be removed.
Ignition OFF All electrical systems are o. The key can be removed.
Ignition OFF Ignition ON
Rear Brake Lever
Speed Limiter
Front Brake Lever
Throttle Lever
Main Switch
Parking Brake
Start Button
Lanyard
Instrument Cluster
5

ENGINE STOP SWITCH WITH LANYARD
Lanyard cap must be pushed in all the way for the engine to start.
THROTTLE
Once the engine is running, push the throttle lever to increase the engine speed. Regulate the speed of
the ATV by varying the throttle position. The throttle lever is spring-loaded to return to the start position when let go.
Before starting the engine, make sure the throttle lever is smooth in operation and will return to the start position. If
throttle lever is not smooth in operation or will not return to start position do not start engine.
NOTICE
1. Engine Run
2. Engine Stop
3. Start Button
4. Headlight Switch
HEADLIGHTS
This AT125UT ATV is equipped with High, Low, Strobe headlight features.
When ignition key is set to the " On " potion press the headlight switch to turn on headlights and to toggle through modes.
Never operate this ATV with headlights set to "Low" or Strobe mode.
Always ride this ATV with the headlights set in the "High" position.
MAIN SWITCH
Engine Start/Stop switch
Use this switch to stop the engine in an emergency situation.
The engine will not start when this switch is set to this position.
Set this switch to run position before starting the engine.
START BUTTON
Push start button to crank the engine with starter.
See the starting instructions on page 21 before starting the engine.
6

INSTRUMENT CLUSTER
The Instrument cluster displays many important information about the ATV. Make sure the rider is familiar with all the
information displayed before riding ATV.
Instrument panel icons
1. Engine RPM (multiplied by 1000r / min), with the change in engine RPM display will also change.
2. Vehicle speed displayed in MPH.
3. Gear indicator D,N,R.
4. Accumulative mileage total mileage.
5. Headlight on when shown.
1
2
3
45
7

The adjustable speed limiter screw must be installed for operation. Failure to install a speed limiter
screw may result in water or dirt ingestion and potential damage to the vehicle.
1. Loosen locknut (#1).
2. To increase the top speed of the ATV turn the adjustment screw counter clockwise. (#2).
3. Tighten the locknut to set adjustment screw in desired position(#1).
1. Loosen locknut (#1).
2. To decrease the top speed of the ATV turn the adjustment screw clockwise. (#2).
3. Tighten the locknut to set adjustment screw in desired position(#1).
FRONT BRAKE LEVER
The front brake lever is located on the right handlebar. To apply the front brake, pull the brake lever toward the
handlebar grip.
REAR BRAKE LEVER
The rear brake lever is located on the left handlebar. To apply the rear brake, pull the brake lever toward the
handlebar grip.
NOTICE
SPEED LIMITER ADJUSTMENT 1. Locknut
2. Adjustment Screw
3. Adjustment Range
Adults should always limit maximum restricted
speed within the ability and capacity of the child to
operate the ATV safely. Never allow the child to
adjust the speed limiter screw.
To decrease top speed
To increase top speed
SPEED LIMITER
The AT125UT ATV is equipped with a vehicle speed limiter adjusting screw. Beginning riders should start with slowest
setting to learn how to control this vehicle. Once the operator has demonstrated mastery of the ATV, the supervising
adult can adjust speed limiter screw to increase the top speed . The vehicle speed limiter keeps the throttle from fully
opening, even when the throttle lever is pushed to the maximum. The adjusting screw may be gradually turned out as the
beginner becomes more familiar with operating this ATV.
8

PARKING BRAKE
Use the parking brake before starting the engine or after parking the ATV, especially on a slope. This ATV is equipped with dual parking
brakes.
Rear Axle Parking Brake: Apply the rear brake lever and push down the lock button to apply the parking brake. Squeeze the rear brake lever to
release the parking brake.
Front Axle Parking Brake: Apply the front brake lever and push down the lock button to apply the parking brake. Squeeze the front brake lever
to release the parking brake.
Always set the parking brake before starting the engine. The ATV could start moving unexpectedly if
the parking brake is not applied. This could cause loss of control or a collision. Always be sure you
have released the parking brake before you begin riding. The brakes could overheat if you ride the
ATV without releasing the parking brake. You could lose control or cause an accident.
1. Rear Axle Parking Brake Button
2. Front Axle Parking Brake Button
Always set the parking brake before starting the engine. The ATV could start moving unexpectedly if
the parking brake is not applied. This could cause loss of control or a collision. Always be sure you
have released the parking brake before you begin riding. The brakes could overheat if you ride the
ATV without releasing the parking brake. You could lose control or cause an accident.
9

CHOKE LEVER
Starting a cold engine requires a richer air-fuel mixture. Move the choke lever all the way up when starting a cold engine. Once
the engine is warmed up return the choke lever all the way down in the running position.
Choke Lever
NOTICE For maximum engine life, never accelerate hard when the engine is cold or choke lever is in the
on position.
10
