Cellar Cool WM 2500 User manual

CWM 021014

CWM 021014
We manufacture, test and certify 100% of our wine cooling units in
the USA. By sourcing the best components and closely controlling our
manufacturing processes, we can assure the highest-quality, lowest
defect manufacturing rates in the industry.
Copyright © 2012. CellarCool. All rights reserved.
This manual, the product design, and the design concepts are copyrighted by CellarCool, with all rights reserved. Your rights with
regard to the hardware and manual are subject to the restrictions and limitations imposed by the copyright laws of the United
States of America. Under copyright laws, this manual may not be copied, reproduced, translated, transmitted, or reduced to any
printed or electronic medium or to any machine-readable form, for any purpose, in whole or in part, without the written consent
of CellarCool.
Every eort has been made to ensure that the information in this manual is accurate. CellarCool is not responsible for printing or
clerical errors.
CellarCool reserves the right to make corrections or improvements to the information provided and to the related hardware at any
time, without notice.
Vinothèque and CellarCool are registered trademarks, and ECE is a trademark of CellarCool. All rights reserved.
Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendtion.
CellarCool assumes no liability with regard to the performance or use of these products.
02.10.14

www.cellarcool.com | Page 1
TABLE OF CONTENTS
Quick Reference Guide
System ..................................................
Controller Layout & Specications ........................
Introduction ................................................
Receiving & Inspecting The System .........................
Before You Start ............................................
Preparing the Wine Cellar...................................
Unit Operation..............................................
Remote Controller Functions ...............................
Maintenance Schedule .....................................
Troubleshooting Guide .....................................
Technical Assistance & Accessories .........................
Installation Terms and Conditions ..........................
2
3
4
5
6
7
11
12
14
16
18
19

Page 2 | 1-855-235-5271 CWM 021014
QUICK REFERENCE GUIDE
Wall Mounted 2500 WM Evaporator Unit (Fan Coil Unit) Front / Side View
Evaporator Unit (Fan Coil Unit) Rear / Side View
Filter Grille
Evaporator Unit (Fan Coil Unit)
Circular Connection
Mounting Location
INSIDE CELLAR
Option 2
THROUGH THE WALL
Option 1
Knock Out For Wiring
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
Knock Out For Wiring
Mounting Key Hole (X4)
Knock Out For Suction Line
Knock Out For Liquid Line
Knock Out For Drain Line
Controller (optional)

www.cellarcool.com | Page 3
QUICK REFERENCE GUIDE
Controller Layout
Refer to page 12 for complete listing of buttons and symbols.
2500 WM SPECIFICATIONS
Model WM 2500-CR Unit
(Fan Coil Unit)
WM 2500-S Condenser
(Air Cooled Condensing Unit)
Cellar Size (cu. ft.) 500
Dimensions 20”w x 10.5”h x 13”d 11.5”w x 9.9”h x 16”d
BTUh with 90° air entering
the condenser coil. 1540
CFM 99 190
Refrigerant R-134a
Condensing Unit HP 1/5
Voltage Rating (20 amp
dedicated circuit required) 115V or 230V - 20 amp dedicated circuit required
Weight (lbs) 25 41
AMPS (Starting/Running) 2/1 11/3.8
dBA 51 65
Line Set Suction Line 3/8” od. Liquid Line 1/4”od
Drainline 1/2”
Installation
Evaporator Unit (Fan Coil Unit) is installed in the cellar. The Condensing Unit is installed up
to 100 line feet away and in accordance with the installation specications found in the Tech
Manual.
Thermostat Digital Control Display
Temp. Delta 55°F temperature dierential
(maintains proper cellar temperature when exhaust environment does not exceed 110°F)
Warranty 2 year parts and labor
Compressor On
Unit is in Anti-Frost Mode
Fans are On
Alarm is Present
Temperature Measurement
Menu Navigation
& Value Increase
*Press and hold
to manually enter
anti-frost mode.
Power On/O
(hold for approx. 3 seconds)
& Escape
Menu Navigation
& Value Decrease
Probe Values &
Alarm Folder
*Press and hold to
enter the parameter
menu.

Page 4 | 1-855-235-5271 CWM 021014
WARRANTY REGISTRATION
In order to activate the warranty of your system, the Verication and Operational
Documentation must be completed by the certied refrigeration technician
installing your system and submit via mail, fax, or e-mail.
Mail to:
CellarCool
ATTN: Warranty Registration
1738 E. Alpine Avenue
Stockton, CA 95205-2505
USA
Fax to:
209.466.4606
Scan and email to:
[e-mail]
OR OR
INTRODUCTION
Customer Service
Thank you for purchasing a CellarCool cooling system. We strive to provide the highest quality products and the
best possible customer service. If you have any questions about your system, please call us at 1-800-343-9463 or visit
CellarCool.com.
Using the Manual
This Owners Manual is intended to assist in the proper maintenance of the cooling system. In order to ensure the
longevity of your cooling unit, the equipment should be installed as outlined in the Technician’s Manual. It is also vital
to establish a proper care and maintenance schedule. Please read and review this manual carefully and keep it for
future reference.
What Is the CellarCool Cooling System?
The CellarCool cooling system is a specialized refrigeration system designed for one purpose only: to maintain the
optimal temperature and humidity levels conducive to the proper storage and aging of ne wines. This system
produces minimal in-cellar noise and has the most lenient exhaust requirements. An exterior housing is required for
outdoor condensing unit installations.
How Does the Cooling System Work?
Similar to the air conditioning systems used for homes, the Evaporator Unit (Fan Coil Unit) and Condensing units
are installed in separate locations and are connected by a refrigerant line set. The evaporator portion is commonly
installed in the wine cellar, with the condensing unit located either outside or in a remote indoor location that is
ventilated. An exterior housing is required for outdoor condensing unit installations.
Temperature Setting
The CellarCool system can be set at any temperature within the acceptable wine-aging range of 45°F to 67°F. It
is designed to cool up to 55°F cooler than the ambient temperature of the space to which the condensing unit is
installed.

www.cellarcool.com | Page 5
Receiving and Inspecting the System
• Lift only at the designated hand hold locations on the shipping container or fully support the unit from
underneath. A shipment may include one or more boxes containing accessories.
• Before opening the container, inspect the packaging for any obvious signs of damage or mishandling.
• Write any discrepancy or visual damage on the Bill of Lading before signing.
• Allow the condensing unit to sit 24 hours prior to start up. The Condensing Unit can be placed in the
installation location, piped and evacuated during this time.
•
Note: CellarCool units are manufactured in the USA and tested prior to shipment.
Review the Packing Slip to Verify Contents
• Check the model number to ensure it is correct.
• Check that all factory options ordered are listed.
If any items listed on the packing slip do not match your order information,
contact CellarCool Customer Service immediately.
Check the Box for the following contents:
RECEIVING & INSPECTING THE SYSTEM
Please leave the unit in its original box until you are ready for installation. This will allow you to move the product
safely without damaging it. When you are ready to remove the product from the box, refer to the installation
instructions.
TIP: Save your box and all packaging materials. They provide the only safe means of transporting/shipping the unit.
(1) Condensing Unit
Main Evaporator Unit (Fan Coil Unit) Box
Main Condensing Unit Box:
(1) WM 2500-C or WM 2500-CR Evaporator Unit (Fan Coil Unit)
If the WM 2500-S was ordered the
Condensing Unit Box will be included
(4) 2” #8 Hex Head Screws
(1) 10 FT. 1/2” Drain Line
(1) ¼” Sight Glass
(1) ¼” Filter Drier
(1) 10” Piece of Cork Tape
(1) Split System Owner’s Manual
(1) Unit Specic Installation Guide
(1) Evaporator Mounting Template
(1) Split System Warranty Checklist

Page 6 | 1-855-235-5271 CWM 021014
BEFORE YOU START
1. Inspect all components prior to installation. If damage is found, please contact your distributor or CellarCool
Customer Service at 1.800.343.9463.
2. The Condensing Unit requires a dedicated 115-volt 20-amp circuit. Use a surge protector with the unit. Do not
use a GFI (Ground Fault Interrupter) line.
3. It is REQUIRED to install a drain line to remove condensation from the Evaporator Unit (Fan Coil Unit).
4. The system is intended for use in properly designed and constructed wine cellars. Hire a professional wine
storage consultant with a valid contractor’s license to build your wine cellar.
5. CellarCool requires that all Split Systems are installed by a certified HVAC-R technician only, Nate or equivalent is
recommended.
6. Warranty is not active until a Warranty Checklist has been received, reviewed, and approved.
If you encounter a problem with your CellarCool system, please refer to the Troubleshooting Guide on page 16.
If you have any further questions, concerns, or need assistance, please contact CellarCool’s Customer Service at
1.800.343.9463. Please be sure all testing has been completed prior to contacting Customer Service. Please have your
results ready for your representative.

www.cellarcool.com | Page 7
The performance and life of your system is contingent upon the
steps you take in preparing the wine cellar.
Note: Improperly preparing your enclosure or incorrectly installing your
unit may cause unit failure, leaking of condensation, and other negative side eects.
IT IS HIGHLY RECOMMENDED THAT YOU OBTAIN THE ASSISTANCE
OF A WINE STORAGE PROFESSIONAL.
Wine storage professionals work with licensed contractors, refrigeration technicians, and racking companies to build
well-insulated, beautiful, and protective wine cellars. CellarCool has put together some useful tips to assist in the
installation process. Our recommendations are meant to act as a guide in the process of building a proper enclosure.
Your intended location may have specic needs that we do not address.
Wall & Ceiling Framing
Build wine cellar walls using standard 2x4 or 2x6 construction methods and ceiling joists following the guidelines of
local and state codes in your area. As a general rule, the thicker the walls and the higher the insulation value in your
cellar, the better it will be at maintaining a consistent temperature.
Insulation
Insulation is REQUIRED with the use of the CellarCool product. Standard berglass or rigid foam insulation is normally
used in cellar construction or, in some cases, “blown-in” insulation is used. It is very important that all walls and
ceilings are insulated to keep the cellar temperature as consistent as possible during the summer and winter months.
The R-value, or quality of insulation, is determined by the rate at which heat passes through the insulation. The higher
the R-value, the more resistant the insulation is to conducting heat. Using higher R-values in insulation will lower your
operating costs and unit run time. (R-13 minimum, R-19 recommended, R-30 for ceiling and exterior walls.)
Vapor Barrier
Water vapor creates its own pressure, separate from the air pressure, and will intrude into colder/drier areas. A vapor
barrier is REQUIRED to prevent the intrusion of water vapor so that the cellar can be kept at the correct temperature
and humidity. 6 mm plastic sheeting (recommended) should be applied to the warm side of the cellar walls. The
vapor barrier must also be applied to the outside walls and ceiling. If it is impossible to reach the outside, then the
plastic must be applied from within the cellar. The most common method is to wrap the entire interior, leaving the
plastic loose in the stud cavity so the insulation can be placed between each stud. All of the walls and ceiling must be
wrapped in plastic for a complete vapor barrier.
In areas of high humidity, such as Southern and Gulf States, the vapor barrier will prevent inltration of warm moist
air. The moist air can cause mold to form, and standing water in drain pans promote microbial and fungal growth that
cause unpleasant odors and indoor air quality problems. If mold is found, remove it immediately and sanitize that
portion of the unit. Note: High humidity signicantly increases the heat load on the cooling system.
Any break in the vapor barriers (cut, nail hole, over-lapping, etc) will allow a moisture leak and must be sealed. Electric
conduit is a“duct” for vapor to travel in. The conduit should be caulked and sealed on the warm air end.
PREPARING THE WINE CELLAR

Page 8 | 1-855-235-5271 CWM 021014
Unobstructed Airow
Unobstructed airflow to and from the system is critical for the Evaporator Unit (Fan Coil Unit) and Condensing
Unit overall performance and life-span. A minimum three-foot clearance (five foot is ideal) area is crucial. The air the
fans blow needs to circulate and either dissipate or absorb heat from the space, the more air to exchange the more
efficient the system will operate.
Note: Avoid attempting to camouflage the unit. This will restrict airflow and thus the systems’s ability to work
efficiently.
Mounting the Evaporator Unit (Fan Coil Unit)
The Evaporator Unit (Fan Coil Unit) must be mounted within 18“ of the top of the room in order to achieve
sucient cooling. As the room cools down, the warm air will rise to the ceiling. Mounting the unit high in the
room will contribute to consistently cool environment by capturing the warm air and replacing it with cool air.
Mounting the unit low in the room will result in a temperature variation in the room due to the unit’s inability to
draw warm air from the ceiling of the cellar to the unit itself, and cold air settling to the oor.
Door and Door Seal
An exterior grade (1 3/4”) door must be installed as a cellar
door. It is essential that weather stripping is attached to
all 4 sides of the doorjamb. A bottom “sweep” or threshold
is also required. The door must have a very good vapor
seal to prevent warmer moist air from leaking into the
cellar. One of the most common problems with cooling
systems running continually is due to the door not sealing
properly. In cases where glass doors are used and the
room size is close to the recommended system size,
the next larger size CellarCool system should be used.
This will compensate for the insulation loss due to the
lower insulating rating of glass.
Wine Cellar
Keep Clear

www.cellarcool.com | Page 9
Ambient Temperature Factor
The cooling system has the ability to cool a wine cellar eciently to 55°F as long as the ambient temperature of the
area that it is exhausting to does not exceed 110°F. Therefore, you want to exhaust the condensing unit in a space which
will not exceed 110°F. Otherwise the system will not have the capacity to keep the wine at a desirable 55°F.
Ventilation
The necessity of dissipating heat away from the condensing unit is critical to the performance and cannot be
overstated. As the system operates and cools, a greater amount of heat is generated on the condensing side of the
system. Adequate ventilation is required in order to dissipate heat away from the condensing unit. If ventilation is
inadequate, the exhaust will heat up the area or room and adversely aect the systems ability to cool. In some cases, it
may be advisable to install a vent fan to dissipate heat within the exhaust area on the condensing side of the system.
However, you must have a fresh air inlet as well.
Note: If you are unsure about having adequate ventilation in your install location, please
contact us to assess your specic installation at [e-mail] or 1.800.343.9463.
Warning, allowing your system to operate in high ambient temperatures for
extended periods of time will greatly decrease the life of your system and void
your warranty. The cooler the temperature of the air entering the condenser coil
the more cooling capacity the system has. The less heat gain through the common
wall, the less the electricity consumption.
BACK - EXHAUST SIDE
FRONT - WINE CELLAR
Exterior Cellar Wall
Evaporator Unit (Fan Coil Unit)
Condensing Unit

Page 10 | 1-855-235-5271 CWM 021014
NOTES

www.cellarcool.com | Page 11
Initial Start-Up:
When power is applied to the unit, the control will briey
display all symbols, and the Compressor symbol will be
displayed (if unit is calling for cooling). There may be a brief
delay prior to the evaporator fans turning on.
Set Point:
The set point is set from the factory (CellarCool) at 55°. It
can be adjusted by the customer between 50° and 70° in
one degree increments.
Cooling Operation:
Cooling is activated once the Air Sensing Probe senses
a temperature that is 4° greater than the set point. The
controller then energizes the solenoid relay which activates
the solenoid. The evaporator fans operate with the
compressor. The unit provides cooling until the Air Sensing
Probe senses the set point. At this point the solenoid relay
is de-energized which stops the ow of refrigerant through
the evaporator coil. The compressor will continue to run
until the low side pressure reaches 5 psi. The evaporator
fans will continue to run for 1 minute to re-evaporate any
moisture from the evaporator coil.
Humidity Features:
The FDC parameter can be increased to allow the evaporator
fans to run for a longer period of time after the compressor
turns o, allowing more moisture to be re-evaporated into
the cellar.
Defrost/Anti-frost:
When the evaporator probe senses a temperature of
26 degrees for 5 minutes, the unit will go into Anti-frost
mode. This will shut down the compressor and allow the
evaporator fans to run to evaporate any frost accumulation
on the coil. The compressor will remain o until the
evaporator coil reaches 40°, or for a maximum of 10 minutes.
The unit will then return to normal operation.
If the evaporator is not above 26 degrees after the anti-frost
sequence has ended, the red error light will display in the
upper right corner. Alarm “Ad3”will be recorded in the alarm
folder, meaning that the anti-frost sequence ended based
on time. The unit will run for 5 minutes and then enter
another Anti-Frost cycle. This sequence will continue until
the evaporator temperature increases above 26°.
“Def” will be displayed during anti-frost. If the anti-frost
sequence is less than 5 minutes, the control will not allow
the compressor to start until 5 minutes has elapsed. This is
to prevent short cycling of the compressor.
Holding down the up button for approximately ve seconds
manually starts the Anti-frost sequence, but only if the
evaporator is below 40 degrees (defrost end temperature).
If the evaporator is above 40 degrees, the display will blink
three times and continue normal operation.
Display:
The Air Sensing Probe temperature is displayed by default.
“Def” is displayed during anti-frost. The Air Sensing Probe
and evaporator probe temperatures can all be accessed
by pushing the set button and scrolling through PB1 (Air
Sensing Probe) and PB2 (evaporator probe).
Safety Features:
Once the solenoid relay is de-energized the controller must
wait 5 minutes before re-energizing the relay. This prevents
the compressor from repeatedly turning o and on. If the
unit is calling for cooling during this time, the compressor
symbol will blink indicating that cooling is needed but the
control is waiting for the anti-short cycle delay.
In the event of a faulty Air Sensing Probe, the compressor
will cycle o for 10 minutes and on for 40 minutes. E1 will
will be displayed on the screen.
Alarms:
If the air temperature reaches 10 degrees above the set
point, a red light will blink in the upper right corner of the
display. The set button can then be pressed to reach the
alarm menu. The menu will display “AH1” indicating a high
bottle temperature. The same thing will happen if the air
temperature reaches 10 degrees below the set point, except
the alarm will read“AL1”. These alarms will not display for the
rst 10 hours after the unit is turned on to allow the cellar
to reach temperature. They will also wait one hour after an
anti-frost cycle before displaying.
In the event of a faulty evaporator probe E2 will ash on the
screen intermittently. The red alarm light will be displayed
in the upper right corner. The unit will go through one anti-
frost sequence every 24 hours.
Press the set button and enter the Al folder to view any
current alarms that are not ashing on the display.
UNIT OPERATION

Page 12 | 1-855-235-5271 CWM 021014
CONTROLLER FUNCTIONS
Button/Symbol Normal Functions
ON/OFF • Press and hold the on/o button for approximately 3 seconds to turn the unit on or o.
Note: This does not disconnect power from the unit. In order for the power to be shut o from
the unit, the power cord must be unplugged from the wall receptacle.
• This button also serves as an escape button.
Up and Down • Use these buttons to scroll up or down a menu.
• Press and hold the up button for approximately ve seconds to manually start the Anti-
frost sequence. The Anti-frost sequence will begin, but only if the evaporator is below 40
degrees. If the evaporator is above 40 degrees, the display will blink three times, signal-
ling that an Anti-frost cycle is not needed, and the unit will continue normal operation.
SET • Press the set button once to view the set point, temperature of the evaporator and actual
air temperature as well as any alarms.
• Once the set button is pressed“SEt” will be displayed. Press the up or down arrows to
scroll through Pb1 & Pb2.
SEt Set Point
Pb1 Air Temperature
Pb2 Evaporator Coil Temperature
• Press the set button again to view any of these values.
• To change the set point, press the SET button. When“SEt” is displayed on the screen,
press the SET button once more. Use the up and down arrow buttons in order to change
the value until the desired set point is reached.
• Hold the set button for approximately 5 seconds to enter the CPSM (Customer Preference
Selection Mode) menu. (CPSM detail on next page)
Snowake Constant - Unit is in cooling mode and the compressor is running.
Blinking - The unit is calling for cooling, but must wait 5 minutes before restarting the com-
pressor. This 5 minute delay serves as an anti-short cycle for the compressors protection.
Dripping Snowake Unit is in Anti-frost mode. The evaporator and condenser fans are running to evaporate any
frost which may have formed on the evaporator coil.
Fan The evaporator fan is on.

www.cellarcool.com | Page 13
Alarm Codes
Message Cause Solution
“E1”
Faulty Air Sensing Probe
Connection
1. Check Air Sensing Probe attachment at circular connector.
2. Check Air Sensing Probe connection at the back of controller.
Defective Air Sensing Probe Replace the Air Sensing Probe.
“E2”
Faulty Evaporator Probe
Connection
Check Evaporator Probe connection at the back of controller.
Defective Evaporator Probe Replace the Evaporator Probe.
“AH1”
The Air Sensing Probe is
sensing a temperature that is
10° above the set point
1. Allow time for the wine to reach the desired temperature.
2. Make sure all windows and doors are closed and have a proper seal.
3. Follow the procedures in the pre-installation instructions to test the unit for proper
cooling.
“AL1”
The Air Sensing Probe is
sensing a temperature that is
10° below the set point
1. Make sure unit is not in cooling mode. (the snowake symbol will not be lit)
2. Add heat to the room until the wine reaches the desired temperature.
“Ad3”
Anti-frost ended on time-out 1. Check the evaporator coil for ice buildup. Unplug the unit and allow coil to thaw
before re-starting.
2. Make sure the room to which the unit is exhausting is not less than 60°.
3. If unit continues to go into continuous anti-frost cycles (every 5 minutes), call cus-
tomer service for more troubleshooting information.
Alarm The Alarm symbol is shown and a audible buzzer will sound when the unit encounters an issue that
needs attention, the displayed alarm codes are explained below. To silence the buzzer press any but-
ton, the alarm code will remain displayed until corrected.
CPSM (Customer Preference Selection Mode)
Press and hold the set button for approximately 5 seconds to enter the CPSM menu.
“Fdc”will be displayed on the screen. Use the down arrow to access the following parameters.
Fdc
Humidity Management/
Enhancement
This parameter is set to 1 from the factory which should provide adequate relative humidity for the
cellar. An increase in this parameter will increase the Humidity Enhancement (%RH). This parameter
should not be adjusted below 1. Adjustments should be made in increments of 5, with a maximum of
15 and a minimum of 1. After any adjustment to Humidity Enhancement you should wait a minimum
of three days before making any additional adjustments. This will allow the cellar sucient time to ac-
climate to the new setting.
PA2 No adjustable settings in this parameter.
tab No adjustable settings in this parameter.
Rel No adjustable settings in this parameter.
loc Change this parameter from“n”to“y”to lock the keyboard from changes to the set point.
ddd Select one of these numbers to display your preference:
0 = Set Point
1 = Air Sensing Probe Temperature
2 = Evaporator Probe Temperature
“CA1” Use this parameter to calibrate the Air Sensing Probe to a known temperature. This parameter can be
adjusted between -12°F and 12°F.
Example: Bottle temperature reading = 58°F
Known temperature reading = 55°F
CA1 parameter setting to match known temperature = -3

Page 14 | 1-855-235-5271 CWM 021014
MAINTENANCE SCHEDULE
Monthly 1. Check for debris surrounding condensing unit(i.e. leaves, branches, trash ect).
Remove all obstructions.
2. Check for unusual noise or vibration
3. Check the drain line to see if it is above the waterline if draining into a vessel.
Quarterly 1. Use a vacuum with brush attachment to clean the evaporator coil. Be careful not to
crush coil ns when cleaning.
2. Remove the evaporator lter and clean with warm water.
3. Ensure the condensing unit is free of debris and dust.
4. Have a certied HVAC Technician service the condensing unit/clean the condenser
coil.
Annually 1. Inspect for corrosion.
2. Check wiring connections and integrity of cords.
3. Pour a 50/50 bleach solution into the drain line every spring.

www.cellarcool.com | Page 15
NOTES

Page 16 | 1-855-235-5271 CWM 021014
TROUBLESHOOTING GUIDE
Unit has ice forming on the Evaporator Unit (Fan Coil Unit)
Possible Cause Solution
Evaporator lter or coil is dirty. Remove the lter and wash, then clean the coil with a vacuum.
If coil is very dirty, use a spray bottle with a small amount of
liquid dish washing detergent or coil cleaner. Spray coil, let set
for 5 min, then ush with fresh water.
There is something blocking the supply and or return air Remove blockage
The evaporator fan is not turning on. Call a service tech to troubleshoot
The Evaporator Unit (Fan Coil Unit) has not gone through
its anti-frost sequence, yet.
Check for ice in the depth of the coil. Melt with blow drier
until coil is warm to the touch. Soak up water with a towel.
If Evaporator Unit (Fan Coil Unit) continues to ice. Observe ice formation pattern. If only part way up the coil
face, the system could be low on refrigerant. If all the way
up, the coil may be dirty or airow is blocked.
Unit does not run/power up
Possible Cause Solution
Evaporator Unit (Fan Coil Unit) is not plugged in Make sure the unit is plugged into an outlet
Power switch not on Turn unit on by pressing the power button on the control
Line voltage is incorrect rating for the system Check line voltage to make sure there is 110v/120v
Bottle at set point Lower set point
Thermostat not calling for cooling Lower set point
Faulty thermostat or wiring Call Customer Service at 1-800-343-9463
Cellar Temperature is to Warm
Possible Cause Solution
The temperature or the room condensing unit is
exhausting to has exceeded 110°F Intake temperature needs to drop below 85°.
The system is undersized for the cellar. Order correct size system
There is something blocking the supply and/or return air,
on the Evaporator Unit (Fan Coil Unit) or the Condensing
Unit.
Remove air ow obstruction
Evaporator Unit (Fan Coil Unit) is mounted too low in the
cellar Re-Locate unit so the distance from the ceiling and top of
the unit is no more than 18”
One or more of the fans are not turning on. Please contact the installing technician to troubleshoot.
Compressor is not turning on. Please contact the installing technician to troubleshoot.
Compressor keeps cycling on overload Make sure all fans are working and there are no airow
obstruction.
Poor seal around door or other areas requiring a seal
(around the unit, wall joints, etc)
Make sure there are no air gaps around the door. If door
seal is damaged, replace it.
Controller set too high Lower the set point.
Evaporator coil is frosted or iced up Observe ice formation pattern. If only part way up the
coil face, Evaporator Unit (Fan Coil Unit) could be low on
refrigerant. If so, contact your installing technician to assist
with troubleshooting.
System Runs Constantly
Possible Cause Solution
Leaky door seal or poorly insulated cellar. Fix leaky door seal and insulate cellar in accordance with
this manual. (Page 9)

www.cellarcool.com | Page 17
TROUBLESHOOTING GUIDE
Unit leaks water
Possible Cause Solution
Evaporator Unit (Fan Coil Unit) is not level Evaporator Unit (Fan Coil Unit) should be level on the wall to
prevent leaking.
Drain line clogged or kinked Check drain line to make sure water can ow freely.
Drain is clogged preventing water form escaping Disconnect drain and clear out, open access door and check
drain for blockage
Drain line does not have a downward slope Fix Drain line so there is a downward slope from the unit to the
drain.
Coil is iced causing drain pan ice and water overowing Melt ice with blow drier. Soak up with a towel
Unit runs but does not cool
Possible Cause Solution
Lack of air ow Make sure fan is unobstructed; Make sure the evaporator lter,
evaporator coil, and condenser coil are clean and free of debris.
System undersized Contact Customer Service at 800-343-9463
Compressor is overheating Shut system o for 1 hour to allow compressor to cool. Turn back
on and check for cooler air ow out. If compressor runs, check
for and clean condenser coil as possible cause of compressor
overheating. If problem repeats, contact you installing technician
to assist with troubleshooting.
Evaporator fan runs but compressor does not
Possible Cause Solution
Running an Anti-Frost Cycle 1) If the system is maintaining the correct cellar temperature
and there is a dripping snowake symbol illuminated on the
control, the system is going through an anti frost cycle. No action
Required. 2) If the system is not maintaining the correct cellar
temperature this may be caused by a dirty evaporator lter or
coil. 3) Call installing technician to troubleshoot as the system
may be low on charge or an adjustment to the TXV.
Compressor and/or starting components faulty Please contact the installing technician to troubleshoot.
System may be performing the WHM function Allow cooling system to revert back to cooling mode.
Compressor may have overheated. Shut system o for 1 hour to allow compressor to cool. Turn back
on and check for cooler air ow out. If compressor runs, check
for and clean condenser coil as possible cause of compressor
overheating. If problem repeats, contact you installing technician
to assist with troubleshooting.
Compressor runs but evaporator fan does not
Possible Cause Solution
Faulty fan motor Please contact the installing technician to troubleshoot.
Faulty Controller Please contact the installing technician to troubleshoot.
Compressor short cycles
Possible Cause Solution
System low on refrigerant charge Please contact the installing technician to troubleshoot.
Condensing fan motor/capacitor faulty Please contact the installing technician to troubleshoot.
Compressor and /or starting components faulty Please contact the installing technician to troubleshoot.
Humidity in cellar too low
Possible Cause Solution
Not enough moisture Raise the Fon setting to increase the humidity level

Page 18 | 1-855-235-5271 CWM 021014
TECHNICAL ASSISTANCE
CellarCool Customer Service is available Monday through Friday from 8:00 a.m. to 4:00 p.m. Pacic Time.
The customer service representative will be able to assist you with your questions and warranty information more
eectively if you provide them with the following:
• The model and serial number of your CellarCool systems.
• Location of unit and installation details, such as ventilation, ducting, construction of your wine cellar, and
room size. Photos of the cellar and installation location may be needed.
Contact CellarCool Customer Service
1738 E. Alpine Ave
Stockton, CA 95205
www.CellarCool.com
Email: [e-mail]
Phone: [phone]
US Toll Free 1(855) 235-5271
Fax [phone]
CellarCool offers accessories to enhance and customize your wine cooling unit.
Condensate Pump Kit
The condensate pump kit is designed as an automatic condensate removal pump for water dripping out of our
evaporator units’ drain line. The pump is controlled by a float/switch mechanism that turns the pump on when
approximately 2-1/4”of water collects in the tank, and automatically switches off when the tank drains to approximately
1-1/4”. The condensate pump kit allows the excess condensate to be pumped up to 20ft away from the unit.
Accessories can be purchased at www.cellarcool.com
ACCESSORIES FOR COOLING UNITS
