CERLAND Jean 4920 User manual

Ref.004920
Vers.1.2
Carport Double Jean
604x513xH266 cm
Notice de montage - Building instructions - Handleiding - Montageanleitung
Istruzioni per il montaggio - Instrucciones de montaje - Instrukcja montażu

The essentials to enjoy your carport
1 Before assembly

You prepare the foundations of the carport. We recommend using type
“H” supports (not included) sealed in roughly 50cm foundations

You have made the inventory of the carport's components,

You store your carport in a covered, ventilated and flat place before
assembly in order to prevent mold and wood deformation,

In the event of a dispute, you send your dealer a service request
accompanied by a photo of the damaged item as well as the quality control
sheet attached to the instructions. Without these elements the dispute
cannot be taken into account.
2 During assembly

You do not screw any element without pre-drilling it first,
3 After assembly

You carefully keep all the documents attached to the product.
EN

Important! Please read this manual carefully before assembl y
Thank you for buying our product, we hope you will enjoy it.
Introduction:
This product is intended for private use to store materials, tools and gardening equipment.
Wood properties
: The product is made of natural wood. Its properties may vary depending on weather
conditions and exposure method. During winter season, it may slightly expand and shrink during summer season.
Such variations in dimensions are normal and do not affect the solidity, stability or functionality of the product. It
is best to unwrap the elements 48 hours before assembly and store them in a roofed area so that the wood can
adapt to the air humidity. (see paragraph "Warranty conditions")
Precaution before assembly
:
-
It is best to unwrap the elements 48 hours before assembly and store them in a roofed area so that the wood
can adapt to the air humidity.
-
Make a full inventory of the components before mounting the product and making a service request.
-
Before screwing screws to the shed parts, drill holes in them. Also, remember to ensure expansion gaps if the
shed shrinks in summer and expands in a rainy season : do not fix the planks together in order to allow the
movement of the boards (shelves, brackets, rails)
The shed is to be mounted by at least two people. The approximate time of assembly is one day.
Foundations:
Level the area where the shelter is to be placed. Flat, even surface will make work easier. Anchor the poles in the
ground (using H-shaped anchor bolts) and pour concrete when the structure is perfectly straight. We
recommend making foundations around 50 cm deep in the ground.
Maintenance :
-
If your carport has a shed, we recommend regular lubrication of door hinges and the lock. Do not leave the
door swinging in the wind.
-
During heavy snow, remove snow from the shed roof regularly if the snow layer is over 20 cm thick.
EN

Guarantee conditions: The guarantee is valid from the date of purchase. Proof of the date of purchase must be
provided for any warranty request. Our products are guaranteed for 2 years against any manufacturing defect.
Some features are acceptable, such as :
-
knots and stoppers in the wood,
-
non-adherent knots,
-
discoloration,
-
straight crack not open,
-
drying cracks (do not affect the quality of the product),
-
twists and torsion if assembly remains possible,
-
resin pockets,
-
any natural evolution relating to wood.
The warranty covers all defects in workmanship or material and is limited to repair or replacement of the
defective part. Any possible costs of assembly, disassembly and impregnation are not covered. The warranty
explicitly does not cover any claims or compensation.
In the case of supply at an address of residence, any complaints concerning the condition of the goods supplied
are accepted only in the form of a prepaid registered letter sent within 48 hours from the moment of supply of
the product to a given carrier (details of the carrier are given in the shipping document). We assume no liability
for any damage resulting from storage or transport on the distributor’s part. We are not obliged to accept any
new products returned for reasons outside the scope of our liability. If, as an exception, such products are
accepted, the client may be charged with any possible costs of repair or transport. We never accept already
assembled products. As far as wooden products are concerned, please remember that timber is a living material
that may naturally deform. Any claims regarding deformed elements must be accompanied by photographs of
such elements.
Warranty terms:
The following uses are excluded from the product warranty :
-
Misuse of the product or under "conditions of use not reasonably foreseeable”,
-
Non-compliance with the rules of the art of implementation of the product,
-
Use of the product for professional purposes not suited to the primary function of the product,
-
Modification of all or part of the product or one of its components,
-
Use of spare parts that are not original,
-
Use of cleaning and / or decoration products not recommended by Forest Style and / or not suitable,
-
Severe weather (wind> 100km / h and snow> 20cm) or natural disaster, flood, storm, fire etc.,
-
Use in the case of a place of residence,
-
Product degradation caused by foundations made outside of the state of the art,
-
Defects caused by poor ground levelness,
-
Storage and assembly defects as well as insufficient protective treatment.
Service:
For replacement parts, please contact the distributor and show the quality control sheet attached to this
manual. Service requests will not be considered without the above mentioned documents.
Please keep the quality control sheet attached to this assembly manual in a safe place. It is
required for the purpose of complaint consideration.

T20
T25
x2

V01
6x100mm (x24)
V02
6x60mm (x42)
Blister ref. S05426
V03
6x70mm (x24)
V04
M10x100mm + washer 10 + nut M10
(x12)
V05
4,8x35mm (x280)
V06
(x1)
V07
6x160mm (x14)
Vis / Screw /
schraube / Tornillo
Percage/ Drilling /
Bohrung/ Perforacion
6 ( V01, V02, V03,
V07 )
4
10 ( V04 ) 12
Pré-perçage / Pre-drilling / Vorbohren / Perforacion previa

S05540
S05541
S05542
S05548
S05549
S05545
2345x90x90
2242x90x90
2140x90x90
2570x160x45
6000x160x45
2600x120x20
M01
M02
M03
M04
M05
M06
x2
x2
x2
x4
x7
x8

S05550
S05551
757x90x45
3040x120x20
S03151
2600x798
M07
M08
M09
x18
x4
x16

M06
M04
M09
M01
M02
M03
M08
M05
M07
Global View

400
400
90
90
600
90
90
90°
90°
5780mm
1600mm 1600mm
90
90
1
/8
Fondations / Fundations
Plot Beton: 400x400x600 mm
Concrete block: 400x400x600 mm
Recommended
(not included)

M01 (x2)
M02 (x2)
M03 (x2)
2A
/8
No. Dimensions Qty
M01 2345x90x90
2
M02 2242x90x90
2
M02 2140x90x90
2

801mm
M04 (x2)
D
V06 (x1)
93
93
V06
2B-D
/8
x2
B
C
No. Dimensions Qty
M04 2570x160x45
4

x6
V04 (x2)
2E-F
/8
12mm
E
F
No. Dimensions Qty
V04 M10x100mm +washer 10 + nut M10
12

4mm
V01 (x1)
V03 (x4)
V03 (x2)
~480mm
M07 (x2)
3A-B
/8
A
B
x12
x12
No. Dimensions Qty
M07 757x90x45
12
V01
6x100mm
12
V03
6x70mm
24

M05 (x2)
V07 (x2)/M05
4
/8
4mm
No. Dimensions Qty
M05 6000x160x45
2
V07
6x160mm
4

787mm
802
802
802
802 762
M05 (x5)
V07 (x2)/M05
5
/8
4mm
No. Dimensions Qty
M05 6000x160x45
5
V07
6x160mm
10

M07 (x1)
V01 (x2)
6
/8
No. Dimensions Qty
M07 757x90x45
6
V01
6x100mm
12

V05 (x12)
1
M09 (x1)
30mm
SZCZEGÓŁ CN
SKALA 1 : 15
V06
7A
/8
No. Dimensions Qty
M09 2600x798
1
V05
4,8x35
12

V05 (3x5=15)
2
M09 (x1)
7B
/8
1 screw every 2 waves
1 vis toute les 2 ondes
min. 1 wave
min. 1 onde
No. Dimensions Qty
M09 2600x798
1
V05
4,8x35
15

V05
3
4
9
10
11
12
M09 (x14)
5
6
7
8
13
14
15
16
min.100mm
7C
/8
No. Dimensions Qty
M09 2600x798
14
V05
4,8x35
253
