Certa CTODSTRCBDA User manual

OUTDOOR STORAGE
CUPBOARD
CTODSTRCBDA

ATop door
panel (x2)
BBottom door
panel (x2)
CBack plate (x2) DSide plate (x4)
EDividing panel
(x2)
FShort shelf (x3) G Top and bottom
panel (x2)
HLong shelf (x1)
I Back connecting
plate (x1)
JSide connecting
plate (x2)
KHandle (x2) LTop left side
connecting
plate (x2)
COMPONENTS

MTop right side
connecting
plate (x2)
NTop left back
connecting
plate (x2)
OTop right back
connecting plate (x2)
PRight leg (x2)
QLeft leg (x2) RDecorative cover
(x22)
SLarge hanger (x2) TSmall hanger (x2)

Step 1:
Insert the top connecting plates (L,M,N, O) into the top and bottom panels (G).All
components should click into place.
Step 2:
Insert the legs (P, Q) into the bottom panel (G).
M
O
G
L
N
Q
P
G
P
Q
ASSEMBLY
x2

Step 3:
Insert one back plate (C) into the base plate assembly.
Step 4:
Insert two side plates (D) into the base plate assembly.
C
D

Step 5:
Insert the back connecting plate (I) into the assembly.
Step 6:
Insert the side connecting plates (J) into the assembly.
I
J

Step 7:
Insert one back plate (C) and two side plates (D) into the assembly.
C
D

Step 8:
Partially insert the top plate assembly onto the cupboard assembly. Ensure to leave a gap
between the top plate and cupboard assemblies.
Step 9:
Connect one top door panel (A) to one handle (K) and bottom door panel (B). Repeat this
process to create two door assemblies.
G
Gap
x2
A
K
B

Step 10:
Align and insert the bottom of the door assembly into the hole on the bottom plate (G).
Fasten the middle of the door assembly onto the hinge holder.
Align and insert the top of the door assembly into the hole on the top plate (G).
Press the top plate assembly into the door assembly to secure.
Repeat this process with the other door assembly.
G
G
x2

Step 11:
Insert the long shelf (H) into the cupboard.
H

Step 12:
Secure the dividing panels (E) to each other. This will create the dividing panel assembly.
E

Step 13:
Insert the bottom of the dividing panel assembly into the bottom panel (G).
Insert the top of the dividing panel assembly into the long shelf (H).
Push the long shelf (H) down to ensure the dividing panel assembly is secure.
G
H

Step 14:
Insert and press down the three short shelves (F) into the cupboard.
F

Step 15:
Vertically attach the large hangers (S) onto the dividing panel assembly, then twist it down
to secure.
Insert the small hangers (T) onto the dividing panel assembly.
Step 16:
Place the decorative covers (R) over the marked areas on the cupboard.
S
S
T
R
S

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
