CHALET TAKENA User manual

1

2
TABLE OF CONTENTS
WARRANTY STATEMENT PG. 3-4
IDENTIFICATION INFORMATION PG. 5
SAFETY PG. 6-7
WELCOME PG. 8-11
REPORTING SAFETY DEFECTS PG. 12
TRAILER AND TRUCK PG. 13-14
ELECTRICAL TO TRUCK PG. 15
LOADING WORKSHEET PG. 16
ON THE ROAD PG. 17-18
EFFECTS OF PROLONGED OCCUPANCY PG. 19
FIRE AND SAFETY PG. 20-22
EQUIPMENT PG. 23-24
ELECTRICAL SYSTEM PG. 25-27
PROPANE SYSTEM PG. 28-29
APPLIANCES PG. 30-31
FRESH WATER SYSTEM PG. 32-33
WASTE SYSTEM PG. 34-35
SLIDE OUT PG. 36
GENERAL MAINTENANCE PG. 37-40
WINTERIZATION / STORAGE PG. 41-43
SLIDE OUT TROUBLESHOOTING GUIDE PG. 44-47

3
LIMITED WARRANTY
FOR TRUCK CAMPERS MANUFACTURED BY CHALET RV MANUFACTURING CORPORATION
(CHALET RVS) SOLD IN THE UNITED STATES AND CANADA
Chalet warrants to the original end user purchaser (“Owner”) of this truck camper (“Camper”) to be free
of defects in materials and workmanship and for structural integrity, under normal use, with reasonable
care and maintenance, for one (1) year from the date of purchase (the “Warranty Period”), subject to the
exclusions given below.
COVERAGE PROVIDED
Within the Warranty Period, Chalet is obligated to repair or replace any part covered by this warranty
proven defective. In the event of such an occurrence, the Owner should contact the selling dealer for a
service appointment. If it is not possible to return to the selling dealer, call the Chalet factory Service
Department, and they will provide you with the location of the nearest authorized dealer or repair facility.
The cost of transporting the Camper to the dealer or service center shall be incurred and paid for by the
Owner.
This is the only warranty given with the purchase of the Camper other than express or implied warranties
given by the component manufacturers. Any warranties implied by law are limited to the Warranty Period.
Any other warranty, express or implied, not provided for in this Limited Warranty is waived by the Owner,
to the extent allowed by law.
OWNER’S OBLIGATION
The purchaser must notify Chalet RVs or a Chalet authorized dealer of any defect promptly upon
discovery.
Warranty repairs by a non-authorized Chalet RV Inc. dealer or service center must be
approved by the Chalet Factory Service Department prior to any work being started.
EXCLUSIONS
The scope of this warranty is expressly limited to only items actually constructed by Chalet. Chalet
therefore makes no warranty with respect to component parts constructed or assembled by other
manufacturers, including, but not limited to, all electrical devices (TV, sound systems, DVD player,
antennas, batteries, etc.), the propane appliances, electrical appliances, heaters, refrigerators, plumbing
fixtures, light fixtures, lights, entrance door and windows. Such component parts may be warranted by
their respective manufacturers, and copies of such warranties are included with the Camper.

4
This warranty does not cover damage caused by or related to (1) normal wear and tear, (2) accidents,
abuse, misuse or negligence, (3) failure to comply with instructions contained in the Owner’s Manual, (4)
any alteration or modification of the Camper, or (5) environmental conditions, including, but not limited
to, road salt, hail, or windstorm. Nor does this warranty apply to parts made out of cloth, leather, wood,
paint, or chrome, which have been affected by airborne fallout, including, but not limited to, chemicals
and tree sap.
No payment or other compensation will be made for incidental expenses, including, but not limited to,
towing, telephone, transportation, lodging, travel, gasoline, loss of pay or indirect or consequential
damage including, but not limited to, loss of use of the Camper, inconvenience, damage or injury to
person or property, or loss of revenue, which might be paid, incurred or sustained by reason of
manufacturer’s defect covered by this warranty. Chalet does not warranty equipment or accessories
installed at any dealership or other place of business, or by any other party.
As the manufacturer of the Camper that you purchased, Chalet does not know the purpose you have in
mind for your truck and camper, nor does Chalet know the Gross Vehicle Weight Rating (“GVWR”) of
your truck. Therefore,
Chalet makes no warranties or representations, express or implied, as to the performance of your truck
with the Camper or whether the match up of your truck and Camper exceeds the GVWR as specified by
your truck’s manufacturer. Specifically, there is no express or implied warranty of merchantability or of
fitness for the particular match of your truck to any particular camper.
This Limited Warranty is intended to comply with the requirements of both State and Federal laws. Any
part of this Limited Warranty in conflict with any law shall be ineffective to the extent of any such conflict.
This warranty gives you specific legal rights, and you may also have other rights, which may vary from
state to state.

5
IDENTIFICATION INFORMATION
For identification purposes it is recommended that you write the trailer serial number inside your RV. Pick a
spot behind a drawer or inside a cabinet. Protect yourself from possible theft and be able to identify your
property.
You should keep a copy of this information at home. If the unit is ever stolen, the police can use the
appliance serial number to identify the unit. It is also handy to have when service is needed.
PLEASE TAKE A FEW MINUTES TO COMPLETE THE INFORMATION.
IT WILL BE A HANDY REFERENCE FOR YOU.
Your Name ______________________________________
Serial Name _____________________________________
Dealer Name ____________________________________
Address ________________________________________
Insurance Policy Number __________________________
Agent’s Phone Number ____________________________
Air Conditioner
Manufacturer _____________________________________
Model __________________________________________
Serial Number ____________________________________
Furnace
Manufacturer
Model __________________________________________
Serial Number ____________________________________
Generator
Manufacturer
Model
Serial Number ____________________________________
Convection or Microwave Oven
Manufacturer _____________________________________
Model __________________________________________
Serial Number ____________________________________
Camper Model ________________________
Purchase Date ________________________
Entry Door Key Number ________________
Agent’s Name ________________________
Air Conditioner
Manufacturer __________________
Model _______________________________
Serial Number _________________________
Range/Oven
Manufacturer __________________________
Model _______________________________
Serial Number _________________________
Stereo/DVD
Manufacturer __________________________
Model _______________________________
Serial Number _________________________
Water Heater
Manufacturer __________________________
Model ___________________
Serial Number _________________________

6
A FEW IMPORTANT
WORDS ON SAFETY
Your safety, and the safety of others, is very important.
Operating your truck and camper is an important
responsibility.
As you read this manual, statements preceded by the
following words are of special significance:
Indicates a potentially hazardous situation which,
if not avoided, may result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which,
if not avoided, may result in damage to the
component, camper or your truck.
This information is intended to help you reduce the risk
of personal injury and prevent possible damage to
others, your truck, camper and its equipment, or the
environment.
To help you make informed decisions about safety, we
have provided operating procedures and other
information on labels in your camper and in this manual.
There are also warnings in the appliance manuals in the
Owner’s Information Package. This information alerts
you to potential hazards that could hurt you or others.
Of course, it is not practical or possible to warn you
about all the hazards associated with operating or
maintaining your camper. You must use your own good
judgment.
This manual is filled with important safety information -
please read it carefully. If you have any questions
regarding operation, maintenance, or service, please
contact your dealer immediately so he can assist you.
Chalet RV is required to furnish the
following consumer information as provided by the
National Fire Protection Association and the American
National Standards Institute. The information and
warnings found here might also be found in other
chapters of this Owner’s Manual. Please see chapters
titled “PROPANE SYSTEM” and “APPLIANCES” for
other safety and operating information.
WARNING
Propane containers must not be placed or stored
inside the vehicle. Propane containers are equipped
with safety devices, which relieve excessive
pressure by discharging gas to the atmosphere.
The following label has been located in the cooking
area to remind you to provide an adequate supply of
fresh air for combustion.
DANGER
ALL PILOT LIGHTS, APPLIANCES AND THEIR
IGNITORS (SEE OPERATING INSTRUCTIONS)
SHALL BE TURNED OFF BEFORE REFUELING
OF
MOTOR FUEL TANKS AND/OR PROPANE
CONTAINERS. FAILURE TO COMPLY COULD
RESULT IN DEATH OR SERIOUS INJURY.
WARNING
Do not bring or store propane containers,
gasoline,
or other flammable liquids inside the camper.
Fire
or explosion may be the result.
WARNING
Portable fuel-burning equipment, including
wood
and charcoal grills and stoves shall not be
used
inside the recreational vehicle. The use of this
equipment inside the recreational vehicle may
cause fires or asphyxiation.
Unlike homes, the amount of oxygen supply is limited
due to the size of the recreational vehicle, and proper
ventilation when using cooking appliances will avoid
dangers of asphyxiation. It is especially important that
cooking appliances not be used for comfort heating as
the danger of asphyxiation is greater when the
appliance is used for long periods of time.
WARNING
IT IS NOT SAFE TO USE COOKING
APPLIANCES FOR COMFORT HEATING.
Cooking Appliances need fresh air for safe
operation.
BEFORE OPERATION:
Open overhead vent or turn on exhaust fan.
Open window.
FAILURE TO COMPLY COULD RESULT IN
DEATH
OR SERIOUS INJURY.

7
A warning label has been located near the propane
container. This label reads:
Overfilling the propane container can result in
uncontrolled gas flow, which can cause fire or explosion.
A properly filled container will contain approximately 80
percent of its volume as liquid
propane.
Overfilled Propane tanks must be bled.
This is different than purging the tanks. When the tanks are new,
they must be purged of the oxygen in the tanks used during the tank
manufacturer’s testing procedure prior to being filled with propane.
Overfilled tanks will emit liquid into the propane system,
which can cause problems/plugging with the regulators used on
the tanks, range and generator. A bathroom scale can be used to
weigh the tanks prior to reinstalling them in the camper.
A 5-gallon tank should not weigh more than 35 lbs. when filled.
A 7-gallon tank should not weigh more than 50 lbs. when filled.
Instructions for bleeding the tanks are located on a label on the tank.
WARNING
DO NOT FILL PROPANE CONTAINERS) TO MORE
THAN 80 PERCENT OF CAPACITY. FAILURE TO
COMPLY COULD RESULT IN A FIRE OR
PERSONAL INJURY.
CAUTION
THIS PROPANE PIPING SYSTEM IS DESIGNED
FOR USE WITH PROPANE ONLY. DO NOT
CONNECT NATURAL GAS TO THIS SYSTEM.
Securely cap inlet when not connected for use. After
turning on gas, except after normal cylinder
replacement, test propane piping and connections to
appliance for leakage with soapy water or bubble
solution. Do not use products that contain ammonia
or
chlorine.
DANGER
IF YOU SMELL PROPANE:
1. Extinguish any open flames, pilot
lights and all smoking materials.
2. Do not touch electrical switches.
3. Shut off the propane supply at the
container valve(s) or gas supply
connection.
4. Open doors and other ventilating
openings.
5. Leave the area until odor clears.
6. Have the gas system checked and
leakage source corrected before using
again.
FAILURE TO COMPLY COULD
RESULT IN EXPLOSION RESULTING
IN DEATH OR SERIOUS INJURY.
Propane regulators must always be
installed with the regulator vent facing
downward. Make sure the regulator
vent faces downward to minimize vent
blockage, which could result in
excessive gas pressure causing fire or
explosion.
WARNING
Carbon monoxide is toxic.
Breathing it can cause unconsciousness
and even kill you.
Avoid any enclosed areas or activities
that expose you to carbon monoxide.
High levels of carbon monoxide can collect
rapidly in enclosed areas, such as a garage
or family room.
The following label has been placed in the vehicle
near the range area:

8
WELCOME
Congratulations and welcome to the recreational
vehicle lifestyle and the ever-growing family of Chalet
owners. We sincerely thank you for
choosing Chalet. Your selection of a Chalet
was a wise investment. Chalet RV is confident that
it will give you years of camping pleasure.
At Chalet RV, we work hard to provide our
customers with safe and dependable travel trailers.
We constantly strive to produce a quality product to
meet your needs. Our customers are what are most
important. If you are satisfied, then we know we have
achieved what we set out to do. That is to be the best
truck camper manufacturer in the industry.
Your RV has been designed to conform with, or
exceed, the American National Standards Institute
(ANSI) 1192, National Fire Protection Association
(NFPA) 1192, Canadian Standards Association (CSA)
Z-240 (for Canadian built units), National Electric Code
(NEC), and applicable motor vehicle standards. These
standards establish the requirements for electrical,
plumbing, fuel systems and equipment, fire and life
safety provisions and other requirements for quality
and safety. Chalet RV is a member of the
Recreational Vehicle Industry Association (RVIA) and
the Canadian Recreational Vehicle Industry
Association (CRVIA) which oversees that our products
are in compliance with the above agencies and
organizations.
One of the best ways to enhance the enjoyment of
your new Chalet is to read this manual along
with the information provided in the Owner’s
Information Package. This information will help you
learn how to operate all the features of your new
Chalet. Afterwards, keep this Owner’s Manual along
with the Owner’s Information Package in your trailer
so you can refer to it at any time.
This Owner’s Manual covers all Chalet RV Takena
models. You may find descriptions of equipment and features
that are not on your particular model.
This Owner’s Manual, along with the Owners
Information Package should be considered a
permanent part of the camper, and should remain
with the camper when it is sold.
The information, specifications and photography
included in this publication were as accurate as
possible at the time of publication. For the most current
product information and changes, please visit our
website at www.chaletrv.com or contact your local
Chalet dealer.
Chalet RV reserves the right, however, to discontinue
or change specifications at any time without notice and
without incurring any obligation whatsoever. All
weights, fuel, liquid capacities, and dimensions are
approximate.
Before calling your Chalet dealer, we suggest that you
look for the answer to your problem in the Owner’s
Manual.
Several warranties protect your new Chalet.
Read each of the warranties thoroughly so you
understand the coverages and are aware of your rights
and responsibilities.
Chalet RV provides a limited warranty as defined at the
front of this manual. Please read that warranty
carefully. If you have any questions about the warranty
or what it does or does not cover, please contact your
Chalet dealer.
At the time of sale, your dealer will fill out and mail your
Chalet RV Warranty Registration Card to the factory.
Within three weeks you should receive, by mail, your
Owner Registration Card. Contact your dealer if it does
not arrive. The card will have your name, serial number
and model, date of purchase and dealer name. If your
trailer ever needs warranty service, present this card to
your dealer.
Your appliances and various other components in your
RV are warranted by their respective manufacturer and
their warranties are included in the Owner’s Information
Package. Be sure to fill out the warranty
registration cards for these items and mail them as
soon as possible after taking delivery of your trailer.

9
CUSTOMER RELATIONS
INFORMATION
It is best to return your trailer to the selling dealer for
warranty service. If this is not possible, you can find
the nearest dealer on our web site,
www.chaletrv.com, under the dealer locator heading,
or by contacting the Chalet RV Customer Service
Department at 541-791-4610, who can direct you to a
dealer in your area.
Service and maintenance on your RV is easily
accomplished by establishing a mutually agreeable
partnership between you and your Chalet RVdealership.
Take the time to get to know the people who will play
an important role in helping you keep your trailer in
prime working condition. Visit the dealer’s service
center to meet the service manager, technicians,
service writers, and those charged with ordering the
parts. Ask questions.
Following scheduled maintenance recommendations
will save you money in the long run. Carefully read all
operation manuals to obtain complete information on
prescribed service intervals. Don’t forget about your
truck. It too needs regular service.
If you prefer to perform general maintenance items on
your own, your Chalet dealer service department can
be a big help when it comes to making sure you obtain
the proper replacement parts.
Service and maintenance items may fall outside the
scope of your capability. In these instances you may
decide to seek the assistance of a qualified RV service
center to perform these tasks. Contact your Chalet RV
dealership’s service center in advance for a
scheduled appointment time. Advise the service
manager, in writing, the specific items needing repair
to give the service center an idea of what parts will be
required, and how long the work can be expected to
take. Keep in mind that seasonal maintenance needs
are a popular time of year at most service centers. Call
early to schedule annual tune-ups. Always include your
vehicle identification number when contacting your
Chalet dealer.
Chalet RV dealership personnel are trained professionals.
They should be able to answer all your questions.
If you encounter a problem that your dealership does not
solve to your satisfaction, please discuss it with the
dealership’s management. The Service Manager or
General Manager can help.
If you are dissatisfied with the decision made
by the dealership’s management, contact
Chalet RV’s Customer Service Center at:
Chalet RV
124 41st Ave. S.E.
Albany, OR. 97322
541-791-4610
E-mail inquiries to:
[e-mail]
www[email protected]
When you call or write, please give us this
information:
•Vehicle Identification Number
•Your name, address, and telephone
number
•Date of purchase
•Name and address of the dealer
where your camper was purchased.
This information will be on your Owner
Registration Card. The serial number is also
located on the identification tag located next to
the entry door.

10
INFORMATION ABOUT THIS
MANUAL
This Owner’s Manual is of a general nature only and
does not cover every aspect of all models manufactured
by Chalet RV. Each owner should read this manual
thoroughly and heed the warnings given herein, as
well as those warnings given in the component instruction
manuals contained in the Owner’s Information Package.
PRODUCT CHANGES
Some equipment and features shown in this manual
may be optional or not available on some models.
Photographs or illustrations in this manual are
representative of function and may not be specific
in their depiction of actual equipment, fabrics,
interior or exterior decor or design options as installed
on or in your camper. For the most current product
information and changes please visit our website at
www.chaletrv.com or contact your local Chalet
dealer. Subsequent modifications may be evident in
the actual product. Specifications are subject to
change without notice. All weights, fuel, liquid
capacities and dimensions are approximate.
OWNER’S INFORMATION PACKAGE
The owner information package contains valuable
documents explaining details of operation for major
appliances, systems and equipment built into your
camper. Included in this package is warranty
information on various appliances and components in
your camper. Warranty registration cards for these
items should be filled out and mailed as soon as
possible after you take delivery of your camper. Since
this Owner’s Manual does not cover every possible
detail of equipment and options installed on or in your
camper, these booklets and instructional material in
this package will help you operate, maintain and
trouble-shoot those items. If you are missing any of
the component material, contact your Chalet dealer
and request the desired or missing information.
This information should be considered a
permanent part of the RV, and should remain
with the trailer when it is sold.
The Owner’s Information Package includes the
following items based on the standard features
and applicable options on your particular RV:
Owner’s Manual
•Consumer Information
•Refrigerator Manual
•Range/Oven Manual
•Convection Microwave Manual
•Furnace Manual
•Thermostat Manual
•Water Heater Manual
•Air Conditioner Manual
•Water Pump Manual
•Converter Manual
•Smoke, Propane and Carbon
Monoxide Detector Manuals
•Fantastic Vent Manual
•Awning Manual
•TV Antenna or Sat Dish Manual
•Stereo or DVD Manual
•LCD TV Manual

11
DEALER RESPONSIBILITY
Your RV has been thoroughly inspected at the
factory before shipment. However, your dealer is
responsible for performing a complete pre-delivery
inspection of all your trailer’s components. This
should assure you that all components are in proper
working order and free of defects prior to you taking
delivery.
During the delivery process, the dealer should have
taken you through the inside, as well as around the
exterior of the RV, to instruct and explain the
proper usage of all of the following items:
•Appliances
•Dinette Bed Conversions
•Electrical System
•Fresh Water System
•Propane Gas System
•Loading and Unloading
•Optional Equipment
•RV Park Hookup
•Waste System
•Slide-Out System
•Egress Exits
While the dealer has provided basic instructions on
how to use your RV, it is ultimately your
responsibility to make sure you fully understand how
to use the trailer prior to doing so. To fulfill this
responsibility, in addition to the instructions received
from the dealer, you must read all instructional
material furnished with the RV. If you do not
understand how to operate any appliance or
equipment, you should return to your dealer for
further instructions.
Your Chalet RV comes with applicable loose
items based on the standard features and options on
your particular trailer. Please make sure that you
have each of these items:
• Owner’s Information Package
• Two sets of keys for entry door, exterior access
doors
• Fire Extinguisher (mounted)
• Remote for TV/LCD & DVD (LCD/TV option)
• Propane Quick Disconnect Fitting for Low
Pressure Hookup (if equipped)
PLANNING AND
PREPARATION
Proper planning of your trip will ensure a
pleasurable experience. A thorough knowledge of
your RV is important if you are going to get the
most of the convenience and safety built into your
camper. You should become as familiar with your
camper as you are with your own personal car or
truck. If you have trouble or questions, you should
consult your dealer.
INSPECTION AND
MAINTENANCE
Maintaining your trailer according to the
maintenance schedules given in this manual helps
to keep your camping experiences trouble-free
while preserving your investment. When your trailer
needs maintenance, keep in mind that your Chalet
dealer’s staff is trained in servicing the many
systems in your trailer.
Your Chalet dealer is dedicated to your
satisfaction and will be pleased to answer any
questions and concerns.
The Maintenance Chart located at the rear of this
manual defines the minimum maintenance
intervals. Adherence to this schedule will
minimize the possibility of failure of important
systems of your camper. The time spent inspecting
and maintaining your trailer will provide you with
many years of trouble free recreational pleasure.
ALTERING OR MODIFYING YOUR RV MAY
VOID YOUR WARRANTY
Even doing something as simple as hanging a
picture. A drill, screw or nail could penetrate an
unseen gas line or electrical circuit, which would be
hazardous. If you are not sure, call your Chalet
dealer for help! Also alterations or modifications to
your trailer may void your warranty.

12
REPORTING SAFETY
DEFECTS
If you believe that your RV has a defect which
could cause a crash or could cause injury or death,
you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to
notifying Chalet RV.
If NHTSA receives similar complaints, it may open an
investigation, and if it finds that a safety defect exists,
it may order a recall and remedy campaign. However,
NHTSA cannot become involved in individual problems
between you, your dealer, or Chalet RV
To contact NHTSA, you may either call the Auto Safety
Hotline toll-free at 1-888-327-4236, or write to:
NHTSA, 400 Seventh St., S.W., Washington, D.C.
20590. You can also obtain other information about
motor vehicle safety from the Hotline. They are on the
web at www.safecar.gov.

13
TRAILER AND TRUCK
MATCHING TRAILER AND TRUCK
Selecting the right combination requires understanding
a few guidelines. Your Chalet dealer can be a valuable
source of information when matching a camper to your
truck.
A Federal Certification Label is required by law on all
trucks. It is usually located on the driver side door post.
It lists the Gross Vehicle Weight Rating (GVWR), the
maximum weight at which the vehicle may be operated.
It also provides a Gross Axle Weight Rating (GAWR),
the maximum weight allowed for each axle. The
GAWR, divided by two, is the maximum axle rating for
each end of an axle.
Trailers are considered “truck payload.” New trucks
have their payload capacity posted in the glove box or
on a specification sheet supplied with the truck
owner’s manual. Trucks that have many options and/or
a 4-wheel drive option have less payload. To calculate
payload, the truck manufacturers assume all seat
positions are filled with persons weighing 150 pounds.
One way to determine the actual payload available is
to weigh the truck full of fuel and with the number of
passengers you will normally be carrying and subtract
that weight from the GVWR.
RV’s become overloaded when people put too many
things into them. There is no easy way to determine
the weight you’ve loaded, so there’s a temptation to
keep loading until every available space if filled.
People are loading by volume, but weight is far more
important. Unfortunately, you may have exceeded the
load-carrying capacity of the tires before everything is
on board. The only way to tell if your truck/trailer is
overloaded is to weigh it fully loaded.
The most critical point about weighing a vehicle is that
it must be weighed with everything on board that will
be there while you’re traveling. That means you must
weigh the truck/trailerer with passengers, supplies,
food, water, propane and the truck full of fuel. Bear in
mind that water weighs 8.3 lbs per gallon and propane
weighs 4.2 lbs per gallon. These two items alone can
add over 400 lbs alone. Limiting your on-board water
until you arrive at your destination will lower your total
weight. You must know the actual load on the axles
and wheels, and there’s no other way to do it other
than on a commercial scale.
In addition to knowing the total weight, it is crucial to
know the weight on each end of each axle. That’s the
only way you can find out if the load is both within the
tire capacity, as well as whether or not the load is
properly distributed.
You should be able to find certified scales by looking
in your Yellow Pages for moving and storage
companies, farm suppliers, gravel pits, recycling
companies or commercial truck stops. Be sure to call
in advance to determine whether the facility offers
public weighing services, their hours of operation and
any fees that might be involved.
WARNING Failure to properly match trailer
And truck can result in undesirable handling
Characteristics and create a safety hazard.
Do not load your vehicle beyond its gross vehicle
weight rating (GVWR) and/or gross axle weight
ratings (GAWR). Both of these ratings are given on an
identification label normally located at the driver’s
door post area.
In addition to knowing the overall weight that can be
safely loaded in or attached to the truck, you should
know how to distribute the weight in the camper so
that correct amounts of weight are placed on each
truck axle. Proper weight distribution is required for
driving stability and will assure that the truck/camper
is not rear, front or side heavy. Heavy weights placed
at the rear end of the truck/camper may cause
undesirable handling characteristics
When loading the RV, store heavy gear first, keeping
it on or close to the trailer floor.
Store only light objects on high shelves. Distribute
weight to obtain even side-to-side balance of the
loaded vehicle.
Secure loose items to prevent weight shifts that could
affect the balance of your vehicle.

14
TIRES
Tires are available in a variety of load
ratings and sizes, and if the tires you currently
have cannot handle the load, it maybe possible
to replace your tires with tires of higher pound capacity.
Bear in mind, that the ultimate capacity of the truck is
determined by the weakest link in the system.
This could be the tires, wheels, suspension or brakes.
The maximum ratings are molded into the side of the tire.
The sidewall of the tire shows maximum and minimum
inflation pressure for that load.
Be sure you also know the load and inflation pressure
ratings for your wheels as well. Often, these are
stamped on the inside of the wheels, but if not, your
dealer can help you find out what they are.
Never exceed the maximum load or inflation pressure
of your wheels.
Driving on under-inflated tires can cause the tires
to overheat, which leads to the breakdown of the tire’s
internal structure. Improper inflation also can reduce
your ability to control your vehicle. Tire blowouts
occur more during summer months than any other
time of the year. Properly inflated tires last longer,
run quieter, grip better, increase fuel mileage and
safely support and control your vehicle.
Check your tire pressure once a month and each
time before you take a trip with your truck and camper.
Use a quality air pressure gauge to check the pressure.
Do not under-inflate or over-inflate your tires. Inspect your
tires for uneven or excessive wear.
Look for bulges, cuts, or blisters on the sidewalls.
When you’re traveling, do as professional commercial
drivers do: inspect your tires regularly and check and
adjust cold inflation pressure every day that you travel.
CAUTION Individual wheel position weights must not
exceed the maximum tire load capacity. Maximum tire
load capacity can only be achieved utilizing the
maximum allowable psi as listed on the sidewall of the
tire.

15
ELECTRICAL CONNECTION TO TRUCK
Your Chalet RV comes equipped with a 12-volt
electrical cord with a molded camper connector.
The truck electrical connector will be installed by your
Chalet Dealer to your truck wiring system. With the
wiring and connectors hooked-up, your truck will
supply 12-volt DC power to charge your trailer’s
battery and provide power for the 12-volt power needs
while the truck is operating.
Under no circumstances should the plug be altered or
changed to another type.
COLOR GAUGE FUNCTION
•Black 8 12-volt power
•White 8 Ground (-)
•Green 14 Running Lights
•Red 16 Left Turn Signal
•Brown 16 Right Turn Signal
•Yellow 16 Back-up Lights
NOTE: Do not use less than 8 gauge wire size for
charge lines. Also, do not attach them to smaller
gauge wires. Your RV maybe equipped with a 3-
way refrigerator which uses 120v, 12v or LP gas to
operate. Selecting the 12v operation requires a large
amount of amperage. This selection should only be
used while traveling when your truck alternator can
produce this amount of amperage. Using an 8 gauge
wire from your truck battery to the trailer will ensure
that adequate amperage will be supplied to the
refrigerator.
To protect your truck’s 12-volt system from overload, a
40-amp circuit breaker should be installed at the power
source under the hood. A Battery Separator may be
necessary to install on your . Its purpose is to
protect your truck’s starting battery from discharge. To
handle the trailer’s electrical requirements and to
charge the trailer’s battery, 8 gauge hot and ground
wires must be run from the power source under the
truck hood to the 12-volt camper electrical connector
location in the truck bed.

16
TRUCK/TRAILER LOAD
WORKSHEET
The truck must be weighed with occupants and full of
fuel. Drive onto the scales and get the weight of the
total truck. Next pull forward until the front axle is off
the scale and get the weight on the rear axle. Subtract
the weight on the rear axle from the total truck weight
to get the weight on the front axle.
With the RV loaded and ready for a camp outing,
pull on the scales as before and get the weight of the
total truck and trailerer. Next pull forward until the front
axle is off the scale and get the weight on the rear
axle. Subtract the weight on the rear axle from the total
truck and trailer weight to arrive at the weight on the
front axle. Subtract the truck weights from the total
truck and trailer weight for each axle. This amount
should be less then the truck manufacturer’s GAWR
rating as shown on the Federal Certification Label. If
you are over the GAWR rating, you will need to
remove or shift weight accordingly.
Once you are less then the GAWR, you need to weigh
each individual wheel to insure you are not overweight
from side to side. Again pull on to the scales, but with
only the right front tire on the scales. Pull forward and
get the weight of the right rear tire. Do the same for
the left side tires. First the front and then the rear. Take
the GAWR rating of the front axle and divide by 2. Do
the same for the rear. This is the GAWR for each axle
end. Now subtract the individual wheel weights from
the individual GAWR for each wheel. If the amount is
less you are within the GAWR for that axle end. If the
amount is more, you are over the GAWR for that axle
end and you will need to adjust how your unit is loaded
to bring the weight down within the GAWR.
Proper weight distribution, load management and
operating within established limitations will aid in
safe and enjoyable travel.

17
ON THE ROAD
LOADING
When loading camping gear, store heavy items first and
place down low. Distribute weight as evenly as
possible from side to side. REMEMBER: overloading
or uneven loading can create a serious safety hazard.
Do not load upper cabinets with heavy items.
Secure and brace stored items so they won’t
move during travel, thereby shifting the load in the
trailer. Do not load heavy items near the end of the
RV. Carry only as much water as needed for
travel use or to balance the load.
Whenever possible, empty the waste water holding
tanks before traveling.
STORAGE
All cabinets and storage areas should have the
heaviest items on the bottom and lighter items
overhead. After loading you should have the skillets
and can goods on the floor or bottom shelf, and the
cereals and crackers in the overheads. Use the
unbreakable type plates and saucers, and consider
storing your dishtowels around them.
Clothing hung in wardrobes should be kept on hangers
that snap over the clothes rods to keep them from
“jumping” off on rough roads.
PREPARING FOR TRAVEL
Properly preparing for a trip before you leave can
make things more enjoyable. Make a list of items you
will need or wish to take. Keep in mind the following
categories:
•Bathroom supplies
•Bedding
•Cleaning items
•Clothing
•Fire Extinguisher
•First aid items
•Food
•Holding tank chemical
•Kitchenware
•Personal items
•Road flares
•Tools
PRE TRIP CHECKS
(Exterior)
1. Connect battery(s) and check condition.
2. Check for fluid leaks.
3. Check tires and wheels for damage and proper
inflation. Check tires for cuts or other damage.
4. Check tires for unusual tread wear that may
indicate a balance or suspension problem.
5. Always keep tires in good condition and when
replacing, be certain that the new tires have the
load carrying capacity of your truck’s G.V.W.R.
6. Check that access doors are securely closed.
7. Check engine and power plant oil levels.
8. Check engine coolant level, windshield washer
reservoir, and batteries.
9. Check all running lights, taillights and electrical system.
10.Be sure to have a stable and adequately rated
heavy-duty jack that will lift both the truck and
trailer weight.
(Interior)
1. Secure all loose items.
2. Close all drawers and cabinets.
3. Secure range and refrigerator doors.
4. Check that entry door is locked.
(Systems)
1. Fill fresh water tank.
2. Drain holding tanks and secure drain cap.
3. Check operation of interior lights and appliances.
4. Check propane gas level. Check for kinked
propane lines and possible leaks.
POST-TRIP CLEAN-UP
1. Clean unit and check for damage.
2. Drain waste-holding tanks.
3. Clean waste drain hose and secure drain cap.
4. Drain fresh water tank and rinse.
5. Close outlet valve on propane tank.
6. Disconnect the battery cables or turn off battery
disconnect switch if equipped.
SAFE DRIVING RULES
Your truck will have different handling and stopping
characteristics when it is carrying the trailer. The
following rules will help you develop needed skills for
safe truck camper driving.
Travel slowly with your new truck/trailer
combination, until you have learned the handling and
stopping characteristics of the combination. Practice
turning, stopping, and backing in a secluded place
away from traffic.
Do not permit a driver who is inexperienced to
operate your truck/trailer combination without your
direct supervision. REMEMBER it’s slow speed for
beginners.
Drive at moderate speeds allowing for adverse
highway and wind conditions. Even under the best of
conditions, do not exceed 55 miles per hour. As speed

18
increases, driving stability, stopping ability, and ability
to make emergency maneuvers are greatly reduced.
Reduce speed before starting down hills - even
short ones - and avoid heavy braking on downgrades.
Truck stability is reduced when traveling downhill.
Slow down before entering turns and avoid heavy
braking in turns. Truck stability is reduced in turns, and
the weight of the trailer on the truck will affect the
way the truck handles. Avoid quick steering
movements that can reduce truck stability.
Maintain at least twice the normal stopping distance
while towing your trailer. The increased weight of
the trailer on the truck requires greater stopping
distance.
Use lower gears on long grades. Downshift on
upgrades to avoid overheating or undue engine loads.
Downshift on downgrades to allow engine braking to
assist in controlling vehicle speed. Avoid continuous or
frequent brake application.
Allow ample time for passing. Your acceleration will
be much slower when you are towing the trailer.
Become familiar with the position of the trailer in
traffic, and be cautious when maneuvering to allow for
its length and width. Always allow extra room to corner
and to change lanes. Learn to use the side mirrors to
view the road behind and to the sides. Check them
often.
Allow for extra height of your trailer. Check for
low hanging tree branches or other obstructions
whenever you drive, park, or when pulling in for fuel or
service. Always check overhead clearance of
overpasses and bridges, especially if you drive with
the roof vents slightly open or if the RV is
equipped with a roof air conditioner, roof rack,
TV/radio antenna, or a satellite dish.
Measure your height from the ground to the highest
point on the roof. Write it down on a piece of tape and
put it in a visible place in your truck. This will help you
when you get to that “low overpass”.
NOTE: Be sure to lower TV antenna before driving.
RIDING IN CAMPER WHILE TRAVELING
For the safety of passengers, it is not advisable to ride
in the RV while traveling. In some states it may be
illegal.
CARBON MONOXIDE GAS
Safety Precautions
Carbon monoxide gas is colorless, tasteless, and
odor-less. It is a combustion by-product of fuel burning
engines. The engines in your truck and generator
system (if installed) produce it constantly while they
are running. Carbon monoxide gas is deadly. Please
read and understand the following warnings and
precautions to protect yourself and others from the
effects of carbon monoxide gas.
WARNINGExhaust gases are deadly. Do
not block the tailpipes or situate the vehicle in a place
where the exhaust gases have any possibility of
accumulating either outside, underneath, or inside your
vehicle or any nearby vehicles.
WARNING Outside air movement can carry
exhaust gases inside the vehicle through windows or
other openings remote from the exhaust outlets.
WARNING Operate the engine(s) only
when safe dispersion of exhaust gases can be assured,
and monitor outside conditions to be sure that exhaust
continues to be dispersed safely.
WARNINGDo not under any circumstances
operate any engine while sleeping.
Beware of exhaust gas (carbon monoxide) poisoning
Symptoms include:
Dizziness
Headache
Weakness and sleepiness
Nausea
Vomiting
Muscular twitching
Throbbing in temples
Inability to think coherently
If symptoms indicate the possibility of monoxide gas
poisoning: Turn off engine(s) immediately. Get out into
fresh air at once. Summon medical assistance
Check the exhaust systems during routine
maintenance and repair any leaks, damage, or
obstruction before further operations. Do not modify
any exhaust system in any way.

19
EFFECTS OF PROLONGED
OCCUPANCY
Your RV was designed primarily for recreational
use and short-term occupancy. If you expect to occupy
the trailer for an extended period, be prepared to
deal with condensation and the humid conditions that
may be encountered.
The relatively small volume of space and air tight
construction of a modern recreational vehicle means
that the normal living activities of even a few
occupants will lead to rapid moisture saturation of the
air contained in the trailer and the appearance of
visible moisture, especially in cold weather.
Just as moisture collects on the outside of a glass of
cold water during humid weather, moisture can
condense on the inside surfaces of your RV
during use in cold weather when the relative humidity
of interior air is high. This condition is increased
because the insulated walls of the trailer are much
thinner than house walls.
Estimates indicate that a family of four can vaporize up
to three gallons of water daily through breathing,
cooking, bathing, and washing. Unless this water
vapor is carried outside by ventilation, or condensed
by a dehumidifier, it will condense on the inside of the
windows and walls as moisture, or in cold weather as
frost or ice. It may also condense out of sight within
the walls or the ceiling where it will manifest itself as
warped or stained panels.
Appearance of these conditions may indicate a serious
condensation problem. When you recognize the signs
of excessive moisture and condensation in your
trailer, you should take action to minimize their
effects.
NOTE: Your RV is not designed to be used as
permanent housing. Use of this product for long term
or permanent occupancy may lead to premature
deterioration of the structure, interior finishes, fabrics,
carpeting and drapes. Damage or deterioration due to
long-term occupancy may not be considered normal,
and may under the terms of the warranty constitute
misuse, abuse or neglect, and may therefore reduce
your warranty protection.
VENTILATION AND MOISTURE CONTROL
You can reduce interior moisture condensation by
taking the following steps:
Ventilate with outside air. Partially open one or more
roof vents and one or more windows to provide
circulation of outside air into the interior. While this
ventilation may increase furnace-heating load during
cold weather, it will greatly reduce water
condensation.
Even when it is raining or snowing, ventilation air from
outside will be far drier than interior air and will
effectively reduce condensation inside the camper.
Minimize moisture release inside the trailer. Run
the range vent fan when cooking and the bath vent
fan (or open the bath vent) when bathing to carry
water vapor out of the RV. Avoid making steam from
excessive boiling or use of hot water. Remove water
or snow from shoes before entering to avoid soaking
the carpet. Avoid drying overcoats or other clothes
inside the camper.
DO NOT HEAT THE INTERIOR WITH THE
RANGE OR OVEN!!
In addition to the hazards of toxic fumes and oxygen
depletion, open flames add moisture to the interior air,
increasing condensation. Do not use an air humidifier
inside the trailer. Water put into the air by the
humidifier will greatly increase condensation.
Ventilate closets and cabinets. During prolonged
use in very cold weather, leave cabinets and closet
doors partially open to warm and ventilate the interior
of storage compartments built against exterior walls.
The airflow will warm the exterior wall surface,
reducing or eliminating condensation and minimizing
possible ice formation.
Install a dehumidifier. During prolonged, continuous
use, a dehumidifying appliance may be more
comfortable and effective in removing excess
moisture from the interior air. While use of a
dehumidifier is not a “cure-all”, ventilation, and
moisture reduction continue to be important, operation
of the dehumidifier will reduce the amount of outside
air needed for ventilation. Heating load on the furnace
will be reduced, and the interior will be less drafty.
INTERIOR ODOR
New units may have a strong odor and even cause
eye and lung irritation when closed up in hot weather.
This is due to glues used in production of forest
products (plywood, paneling, etc.). This condition
passes with time, but in an extreme condition, open
the door, windows, and vents to allow the interior to
“air out” for several hours.

20
FIRE AND SAFETY
The hazard and possibility of fire exists in all areas of
life, and the recreational lifestyle is no exception. Your
trailer is a complex device made up of many
materials - some of them flammable. But like most
hazards, the possibility of fire can be virtually
eliminated by recognizing the danger and practicing
common sense safety and maintenance habits.
Recreational vehicle fires are generally caused by
unattended food cooking on the stove or in the oven,
faulty or damaged wiring and electrical devices, fuel
leaks (both gasoline and propane), or carelessness.
The most common careless acts include smoking in
bed, leaving children unattended and cleaning with
flammable liquids.
Consider These Fire Safety Suggestions:
Before refueling your truck or any fuel tank in the
vicinity of your RV, be sure to turn off all pilots and
appliances in your trailer.
Consider the cause and severity of the fire and the risk
involved before trying to put it out. If the fire is major or
is fed by gasoline, propane or any type of oil product,
stand clear of the vehicle and wait for the fire
department or other emergency assistance.
If your RV is damaged by fire, do not use it
until it has been thoroughly examined and the
cause of the fire is found and fixed.
All occupants of the trailer should become familiar
with the audible sound of the smoke, propane leak and
CO detectors. If an alarm sounds, investigate the
cause. Do not remove the detector in an attempt to
silence the alarm.
Teach everyone in the RV how to use the entry
door locking system and emergency exits. Occasionally
open the emergency exit to prevent the seal from
sticking. Always keep the dead bolt on the entry door in
working condition.
FIRE EXTINGUISHER
The fire extinguisher in your trailer is located near the
main entry door. Your fire extinguisher should be
replaced immediately after use or discharge.
The fire extinguisher furnished with your camper is
rated for Class B (gasoline, grease, flammable liquids)
and Class C (electrical) fires since these are the most
common types of fires in recreational vehicles. Read
the instructions on the fire extinguisher. Know how and
when to use it. You and your family should be familiar
with its operation. If you find it necessary to use the
fire extinguisher, stand 45 degrees from the flame and
spray side to side, starting at the top of the flame. Use
caution to avoid standing upwind or uphill. If flames are
climbing, spray vertical and work the retardant
downwards. Dry chemical flame retardant should be
cleaned away as soon as possible.
SMOKE DETECTOR
Most fire casualties are caused by inhalation of toxic
fumes (smoke) from a fire and not by flame. The smoke
detector responds to smoke that enters the sensing
chamber. It does not sense gas, heat or flame.
A ceiling mounted, battery powered smoke detector is
located in the living /cooking area of your RV. Please
read the smoke detector Owner’s Manual for details on
testing and caring for this important safety device.
Test the smoke detector after the RV has been in
storage, before each trip, and at least once a week
during use.
The smoke detector should never be disabled due to
nuisance or false alarm from cooking smoke, a dusty
furnace, etc. Ventilate your trailer with fresh air and
the alarm will turn off. Do not disconnect the battery.
Replace the battery once a year or immediately when
the low battery “beep” signal sounds once a minute.
The detector uses a standard 9-volt battery.
Test smoke detector operation after replacing the
battery. If the smoke detector fails to operate with a
new battery, replace the detector with a new unit.
