OPERATOR'S MANUAL
MODEL #200934
BACKPACK BLOWER
RE V 20211129 Champion Power Equipment, Inc., Santa Fe Springs, CA USA
or visit championpowerequipment.com
SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
WARNING
To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. If you do not
understand the warnings and instructions in the operator’s manual, do not use this product.
NOTICE
Do not use E15 or E85 fuel (fuel containing greater than 10% ethanol) in this product. It will damage the engine and void your warranty.
FUEL MIXTURE for this product is powered by a 2-cycle engine and requires pre-mixing gasoline and 2-cycle oil in a 50:1 ratio. Pre-mix
unleaded gasoline and 2-cycle engine oil in a clean container approved for gasoline. DO NOT mix quantities larger than usable in a 30-
day period.

200934 - BACKPACK BLOWER TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction................................................... 3
Safety Definitions .......................................... 3
Important Safety Instructions....................... 4
Fuel Safety .........................................................5
Safety Labels.......................................................6
Safety Symbols.....................................................7
Operation Symbols .................................................8
Quick Start Label Symbols.........................................8
Controls and Features ................................... 9
Backpack Blower...................................................9
Parts Included .................................................... 10
Assembly ..................................................... 11
Operation ......................................................... 12
Fueling and Refueling ............................................ 12
Filling the Fuel Tank.............................................. 12
Starting and Stopping............................................ 12
To Stop the Engine: .............................................. 14
Proper Blower Operation ........................................ 14
Cruise Control Feature ........................................... 15
Maintenance ................................................ 15
General Maintenance ............................................ 15
Cleaning the Air Filter ............................................ 15
Fuel Cap .......................................................... 16
Spark Plug ........................................................ 16
Maintenance Schedule........................................... 16
Storing The Blower............................................... 16
Specifications.............................................. 16
Backpack Blower Specifications ................................ 16
Troubleshooting........................................... 17

200934 - BACKPACK BLOWER INTRODUCTION
3
INTRODUCTION
Congratulations on your purchase of a Champion Power Equipment
(CPE) product. CPE designs, builds, and supports all of our
products to strict specifications and guidelines. With proper
product knowledge, safe use, and regular maintenance, this
product should bring years of satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the time of
publication, and we reserve the right to change, alter and/or
improve the product and this document at any time without prior
notice.
Since CPE highly values how our products are designed,
manufactured, operated and are serviced, and also highly value
your safety and the safety of others, we would like you to take the
time to review this product manual and other product materials
thoroughly and be fully aware and knowledgeable of the assembly,
operation, dangers and maintenance of the product before use.
Fully familiarize yourself, and make sure others who plan on
operating the product fully familiarize themselves too, with the
proper safety and operation procedures before each use. Please
always exercise common sense and always err on the side
of caution when operating the product to ensure no accident,
property damage, or injury occurs. We want you to continue to use
and be satisfied with your CPE product for years to come.
When contacting CPE about parts and/or service, you will need to
supply the complete model and serial numbers of your product.
Transcribe the information found on your product’s nameplate
label to the table below
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
200934
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
DANGER
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE indicates information considered important, but not
hazard-related (e.g., messages relating to property damage).

200934 - BACKPACK BLOWER IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
DANGER
The blower engine exhaust contains carbon monoxide,
a colorless, odorless, poison gas. Breathing carbon monoxide
will cause nausea, dizziness, fainting or death.
If you start to feel dizzy or weak, get to fresh air immediately.
Always operate the blower outdoors only in a well-ventilated
area.
NEVER operate the blower inside any building, including
garages, sheds or other confined spaces.
DO NOT allow exhaust fumes to enter a confined area through
windows, doors, vents or other openings while operating the
blower.
DANGER
Using an engine indoors CAN KILL YOU IN MINUTES. Engine
exhaust contains carbon monoxide. This is a poison you cannot
see or smell.
DANGER
Do not allow untrained individuals or children to use this
blower.
NOTICE
In some State and local jurisdictions and to comply with local
noise ordinances, operate your blower during established
hours of operation. For more information, contact your
State and local government for specific use of operation
requirements.
WARNING
–Clear the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
–Keep all bystanders, children, and pets at least
50 ft. (15.2 m) away, there is a risk of injury from thrown
objects. Bystanders should be encouraged to wear eye
protection.
–Never point the blower nozzle in the direction of people or
pets.
–Always wear sound protection (ear mufflers or ear plugs)
to protect your hearing to reduce the risk of hearing loss
associated with long term sound level(s).
–When wearing hearing protection be alert and cautious to
warnings such as shouts and other alarms.
–Always wear eye protection with side shields to comply
with ANSI Z87.1. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
–To reduce the risk of injury associated with objects being
drawn into rotating parts, do not wear loose clothing,
scarves, jewelry, neck chains, sandals or go barefoot.
–Always secure hair so it is above shoulder level to prevent
entanglement in any rotating parts.
–Keep all body parts away from any moving parts and all hot
surfaces of the blower.
–Do not operate this blower when you are tired, ill, or under
the influence of alcohol, drugs, or medication.
–Do not operate in poor lighting.

200934 - BACKPACK BLOWER IMPORTANT SAFETY INSTRUCTIONS
5
WARNING
–Wear a face filter mask in dusty conditions to reduce the
risk of injury associated with the inhalation of dust.
–Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure to
hot contact surfaces.
–Do not use on a ladder, rooftop, tree, or other unstable
support. Stable footing on a solid surface enables better
control of the blower in unexpected situations.
–Never run the unit without the proper equipment attached.
Always ensure the blower tubes are installed.
–This engine is equipped with a spark arrestor screen.
Never operate the unit without a spark arrestor screen, this
screen is located inside the muffler.
–Always inspect the unit before each use for loose
fasteners, fuel leaks, etc. Replace damaged parts.
–Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard or
cause product damage and void your warranty.
–Before cleaning, repairing, or inspecting, shut off the
engine and make certain all moving parts have stopped.
Disconnect the spark plug wire and keep the wire away
from the spark plug to prevent starting.
–To reduce the risk of injury associated with contacting
rotating impeller blades, stop the engine before installing
or changing blower tubes.
–Service on the blower should be performed by qualified
repair personnel only. Service or maintenance performed
by unqualified personnel could result in injury to the user or
damage to the product.
–Always maintain the blower per the maintenance
instructions of this Operator’s Manual.
–Use only as directed per this operator’s manual
instructions.
Fuel Safety
DANGER
GASOLINE AND GASOLINE VAPORS ARE HIGHLY
FLAMMABLE AND EXPLOSIVE.
Fire or explosion can cause severe burns or death.
Gasoline and gasoline vapors:
–Gasoline is highly flammable and explosive.
–Harmful or fatal if swallowed.
–Gasoline can cause a fire or explosion if ignited.
–Gasoline is a liquid fuel but its vapors can ignite.
–Gasoline is a skin irritant and needs to be cleaned up
immediately if spilled on skin or clothes.
–Gasoline has a distinctive odor, this will help detect potential
leaks quickly.
–In any petroleum gas fire, flames should not be extinguished
unless by doing so the fuel supply valve can be turned OFF.
This is because if a fire is extinguished and a supply of fuel is
not turned OFF, then an explosion hazard could be created.
–Gasoline expands or contracts with ambient temperatures.
Never fill the gasoline tank to full capacity, as gasoline needs
room to expand if temperatures rise.
When adding or removing gasoline:
Do not light or smoke cigarettes while handling fuel.
Always mix, store or transfer gasoline in an EPA/CARB compliant
fuel tank.
Only mix and refuel outdoors where there are no sparks or flames.
Only drain gasoline outdoors in a well-ventilated area.
Always loosen fuel cap slowly to release pressure and to keep fuel
from escaping around the fuel cap and add fuel before starting the
engine.
Always replace and tighten the fuel cap securely after fueling.
Always stop engine and allow to cool before refueling.
Never remove the fuel cap or add fuel while the engine is running
or when the engine is hot.
In the event of spilled fuel, wipe the spilled fuel from the blower
and move 10’ ft. (3 m) away from refueling site before starting
engine to avoid potential ignition of fuel vapors.
Always store fuel in a cool, well-ventilated area, safely away from
spark and/or flame-producing equipment.
Save these instructions. Refer to them frequently and use them to
instruct others who may use this product. If you loan someone this
equipment, provide them these instructions also.
WARNING
NEVER use a gasoline container, gasoline tank, or any other
fuel item that is broken, cut, torn or damaged.

200934 - BACKPACK BLOWER IMPORTANT SAFETY INSTRUCTIONS
6
Safety Labels
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.
LABEL DESCRIPTION
A
1858-L-SF-B
DO NOT TOUCH! Hot surface.
WARNING
¡NO TOCAR! Superficie caliente.
ADVERTENCIA
AVERTISSEMENT
NE TOUCHEZ PAS! Surface chaude.
K485 152 --- ---
ColorsLPN 1858-L-SF
Rev B
Size 51 x 63mm
Artwork Notes
2mm safe margin.
Revision Changes
rev B: dieline changed
This ar twork belongs to Champion Power Equipment. The contents are confidential and pr ivileged and shall not be disclo sed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Hot Surface
B
3091-L-SF-A
K109 2945 --- ---
ColorsAPN 3091-L-SF
Rev A Size 23 x 97.5 mm
Artwork Notes
2mm safe margin;
to be printed on
white
substrate.
Revision Changes
---
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for outside parties without the explicit consent of Champion Power Equipment.
Safety Symbols
C
1514-L-SF-B
K109 2945 485 ---
ColorsLPN 1514-L-SF
Rev B
Size 60 x 20 mm
Artwork Notes
2mm safe margin; to be printed on white substrate
Revision Changes
B:change the size from 75X20 mm to 60X 20mm
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
A
B
C

200934 - BACKPACK BLOWER IMPORTANT SAFETY INSTRUCTIONS
7
Safety Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
Read Operator’s Manual. To reduce the risk of injury, user must read and understand operator’s manual
before using this product.
Eye and Ear Protection. Always wear safety goggles or safety glasses with side shields, and as
necessary a full face-shield as well as full ear protection when operating this product.
Safety Alert. Precautions that involve your safety.
Risk of Fire/Explosion. Fuel and its vapors are extremely flammable and explosive. Fire can cause
severe burns or death. Do not add fuel while the product is operating or still hot.
Open Flame alert. Fuel and its vapors are extremely flammable and explosive. Keep fuel away from
smoking, open flames, sparks, pilot lights, heat, and other ignition sources.
Toxic Fumes. The engine exhaust from this product contains chemicals known to the state of California
to cause cancer and birth defects and other reproductive harm.
Risk of Asphyxiation. This engine emits carbon monoxide, an odorless, colorless poison gas. Breathing
carbon monoxide can cause nausea, fainting or death. Use only in a well ventilated area.
Thrown Objects. Beware of thrown objects.
Clearance. Keep all objects including others at least 50' (15.2 m) from this machine.
Hot Surface. To reduce the risk of injury or damage, avoid contact with any hot surface.
Rotating Impeller. Keep clear of blower outlet. Never point the blower at yourself or others.
Rotating Blades. Never put your hand in the chute. Contact with rotating parts can amputate fingers and
hands.

200934 - BACKPACK BLOWER IMPORTANT SAFETY INSTRUCTIONS
8
Operation Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
Choke. Move choke lever to “RUN”
position. See Starting and Stopping
Section.
Choke. Move choke lever to “CHOKE”
position. See Starting and Stopping
Section.
Quick Start Label Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
Starting the Engine
1. Check fuel. Make sure fuel-to-oil mixture is 50:1 and add if
necessary.
2. Move choke knob to CHOKE position.
3. Primer bulb:
3a. For cold starts, press primer bulb 7-14 times.
3b. For warm starts, DO NOT press primer bulb.
4. Set cruise control lever to about 1/2 throttle position.
3092-L-OP-C
1
50 : 1
2
4
7-14X
3
6 8
30 s
5
1-6X
5
1-6X
2945 485
ColorsAPN 3092-L-OP
Rev C
Size 60 x 40 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
B-Changed choke direction
C-Changed the label size
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
KK:50 152
5. Pull recoil handle 1-6 times.
6. Move choke knob to RUN position.
7. Pull recoil handle 1-6 times.
8. Allow the engine to idle for 30 seconds.

200934 - BACKPACK BLOWER CONTROLS AND FEATURES
9
CONTROLS AND FEATURES
Read this operator’s manual before operating your backpack blower. Familiarize yourself with the location and function of the controls and
features. Save this manual for future reference.
Backpack Blower
1. Lower blower tube
2. Middle blower tube
3. Upper blower tube
4. Throttle trigger
5. Cruise control lever
6. STOP switch
7. Flex tube
8. Spark plug
9. Carry handle
10. Muffler
11. Fuel Tank
12. Fuel cap
13. Starter grip
14. Air filter
15. Primer bulb
16. Choke
1
2
10
89
11
12
14
13
16
15
3
7
4
5
6

200934 - BACKPACK BLOWER CONTROLS AND FEATURES
10
Parts Included
Accessories
Spark plug wrench ................................................................... 1
Reversible flathead and cross-head screwdriver ....................... 1
2-cycle oil ......................................................... 2.6 fl .oz.(76 ml)
Assembly Parts
Blower body ............................................................................. 1
Clamps..................................................................................... 2
Flex tube .................................................................................. 1
Blower tubes ............................................................................ 3
Upper
Lower
Middle

200934 - BACKPACK BLOWER ASSEMBLY
11
ASSEMBLY
Your blower requires some assembly. If you have any
questions regarding the assembly of your blower, call our
Technical Support Team at 1-877-338-0999. Please have your
serial number and model number available.
1. Attach flex tube to elbow on blower body. Tighten the clamp
fully.
Flex tube Clamp
Elbow
2. Install flex tube to upper blower tube (with the throttle handle
guide). Tighten the clamp fully.
Throttle
handle guide
Upper blower
tube
Clamp
Clamp
Elbow
Flex tube
3. Loosen wing nut completely on throttle handle clamp. Align
notches in throttle handle clamp with guide on the upper
blower tube and slide on as shown. When the throttle handle
is at the desired length, tighten the wing nut fully to secure.
4. Assemble upper blower tube to middle blower tube by
aligning the arrow of the peg of tube with the arrow of the
locking groove of tube. Slide the peg into the locking groove
and rotate clockwise to lock in place.
5. Assemble middle blower tube to lower blower tube by aligning
the arrow of the peg of tube with the arrow of the locking
groove of tube. Slide the peg into the locking groove and
rotate clockwise to lock in place.

200934 - BACKPACK BLOWER ASSEMBLY
12
OPERATION
Fueling and Refueling
Fuel Mixture
This product is powered by a 2-cycle engine and requires pre-
mixing gasoline and 2-cycle oil in a 50:1 ratio. Pre-mix unleaded
gasoline and 2-cycle engine oil in a clean container approved for
gasoline. DO NOT mix quantities larger than usable in a 30-day
period. Recommended fuel: This engine is certified to operate on
unleaded gasoline intended for automotive use.
When mixing fuel, always use clean, fresh, regular unleaded
gasoline with minimum octane rating of 85 and an ethanol
content of 10% or less by volume. DO NOT USE E15 or E85.
Recommended oil: Use premium 2-cycle oil, or an equivalent high-
quality synthetic 2-cycle oil. Do not use automotive oil or 2-cycle
outboard oil.
Gasoline (US gal.) Oil (oz.)
12.6
2.5 6.4
3.0 7.7
4.0 10.2
5.0 12.8
Gasoline (L) Oil (ml)
3.8 76
9.5 190
11.4 228
15.1 302
18.9 378
Filling the Fuel Tank
1. Do not smoke while fueling or mixing fuel.
2. Mix and pour fuel outdoors where there are no sparks and
flames.
3. Place the blower on a flat stable surface, with the fuel tank
cap facing upwards.
4. Clean the surface around the fuel cap to prevent
contamination.
5. Loosen the fuel cap slowly by turning counterclockwise.
6. Pour the fuel mixture carefully into the tank.
7. Only fill the fuel tank to 80% of the full capacity. Fuel level
can be seen via the clear fuel tank.
8. Clean and inspect the fuel cap gasket before replacing the
fuel cap.
9. Replace the fuel cap and tighten it by turning it clockwise.
10. Wipe spilled fuel from the product.
11. If you spill fuel on the unit, wait 10 minutes after wiping
before starting.
12. Move at least 10 ft. (3 m) away from refueling area before
starting the product.
NOTE: It is normal for smoke to be emitted from a new engine
during first use.
WARNING
Always shut off engine before fueling. Never add fuel to a
machine with a running or hot engine. Wait at least 15 minutes
to allow for cool down before refueling. Move at least
10 ft. (3 m) from refueling site before starting engine. Do not
smoke and stay away from open flames and sparks. Failure to
safely handle fuel could result in serious personal injury.
NOTICE
Do not use E15 or E85 fuel (fuel containing greater than 10%
ethanol) in this product. The use of E15 will damage the engine
and void your warranty.
Starting and Stopping
NOTICE
To avoid breaking the starter rope, do not pull the whole length or
let it slide along the edge of the rope guide. Allow the starter rope
to rewind gradually.

200934 - BACKPACK BLOWER ASSEMBLY
13
To Start a Cold Engine:
1. Blower should be on a flat, bare surface for starting.
2. Set the choke knob to the CHOKE position.
3. Slowly press the primer bulb 7-14 times or until fuel is visible
and flows freely into the clear tank return line.
4. Set the cruise control lever to the half throttle position.
Throttle trigger
Cruise control
5. Holding the unit firmly, pull starter grip until engine starts.
Use short pulls and do not allow the rope to snap back.
Do not pull more than 6 times.
6. Move choke knob to the RUN position and pull recoil starter
handle until engine starts. Do not pull more than 6 times.
NOTICE
Allow engine to warm at least 30-60 seconds depending on
ambient temperature. The colder the temperature, the longer the
warm up required.
To Start a Warm Engine:
1. Set the cruise control lever to the half throttle position.
Throttle trigger
Cruise control

200934 - BACKPACK BLOWER ASSEMBLY
14
2. Holding the unit firmly, pull starter grip until engine starts.
Use short pulls and do not allow the rope to snap back.
Do not pull more than 5 times.
NOTICE
If the engine does not start, return to the “Start a Cold Engine”
and repeat the steps that follow.
To Stop the Engine:
1. To stop the engine, ensure cruise control is off and let go of
the throttle trigger.
2. Depress and hold the STOP switch to the STOP position until
engine completely dies.
Proper Blower Operation
SAFETY:
–Fully familiarize yourself with the IMPORTANT SAFETY
INSTRUCTIONS section of this manual.
–To keep from scattering debris, blow around the outer edges of
a debris pile. Never blow directly into the center of a pile.
–Watch out for children, pets, open windows, or freshly washed
cars, and blow debris safely away.
OPERATION:
–Check your equipment before operation, especially the muffler,
air intakes, and air filters.
–Install the blower tube. Refer to the ASSEMBLY section earlier
in this manual.
–Start the blower. Refer to Starting and Stopping earlier in this
manual.
–Hold the upper handle in your right hand.
–Move the blower from side to side along outer edge of the
debris.
–Operate blower at the lowest possible throttle speed to do the
job.
GENERAL TIPS:
–To reduce sound levels, limit the number of pieces of
equipment used at any one time.
–Use rakes and brooms to loosen debris before blowing.
–In dusty conditions, slightly dampen surfaces when water is
available.
–Hold blower so the air stream can work close to the ground.
–After using blowers or other equipment, CLEAN UP! Dispose of
debris properly.
WARNING
Never run the unit without the blower tubes installed. Use of
an improperly assembled unit could result in serious personal
injury.
WARNING
Do not place blower on top of or near loose debris or gravel.
Debris may be sucked into blower intake vent resulting in
damage to the unit and could result in serious personal injury.
WARNING
Always wear sound protection (ear mufflers or ear plugs)
to protect your hearing to reduce the risk of hearing loss
associated with long term sound level(s).
WARNING
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in objects
being thrown into your eyes and other possible serious injuries.

200934 - BACKPACK BLOWER MAINTENANCE
15
Cruise Control Feature
The cruise control lever can be used to operate the blower at
desired speed without holding the throttle trigger.
–To engage, squeeze the throttle trigger and move the cruise
control lever to the desired speed.
Throttle trigger
Cruise control
–To release, move the cruise control lever back to the original
low position.
MAINTENANCE
WARNING
Never operate a damaged or defective blower.
WARNING
Improper maintenance will void your warranty.
NOTICE
For Emission control devices and systems, read and
understand your responsibilities for service as stated in the
Emission Control Warranty Statement of this manual.
The owner/operator is responsible for all periodic maintenance.
Complete all scheduled maintenance in a timely manner.
Correct any issue before operating the trimmer.
For service or parts assistance, contact our
Technical Support Team at 1-877-338-0999.
General Maintenance
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to damage from various types of commercial
solvents and may be damaged by their use. Use a clean cloth to
remove dirt, dust, lubricant, grease, etc.
WARNING
Before inspecting, cleaning, or servicing the machine, shut off
engine, wait for all moving parts to stop, and disconnect spark
plug wire and move it away from spark plug. Failure to follow
these instructions could result in personal injury or damage to
your blower.
WARNING
When servicing, use only identical replacement parts. Use
of any other parts could create a hazard or cause product
damage.
WARNING
Do not let brake fluids, gasoline, petroleum based products,
penetrating oils, etc., come in contact with plastic parts.
Chemicals can damage, weaken, or destroy plastic which
could result in serious personal injury.
WARNING
Tampering or adjusting the factory set carburetor is a Federal
Violation and will void your warranty coverage.
Cleaning the Air Filter
For proper performance and long life, keep the air filter clean.
1. Move choke knob to CHOKE position (See Cold Start
section of manual) to prevent dirt and debris from entering
carburetor.
2. Remove the air cleaner cover by turning the cover fasteners
counter-clockwise. Brush away any accumulated dirt from the
air filter cover area.

200934 - BACKPACK BLOWER SPECIFICATIONS
16
3. Inspect and replace or clean the air filter. To reassemble
make sure the filter fits in the cavity and reinstall the filter
as shown. Fasten the air filter cover by turning the fasteners
clockwise.
Fuel Cap
WARNING
Check for fuel leaks. If you find any leaks, correct the problem
before using the product. A leaking fuel cap is a fire hazard
and must be replaced immediately. Failure to do so could
result in a fire that could cause serious personal injury.
Spark Plug
1. Remove spark plug and check for worn and rounded center
electrode.
2. Clean, adjust or replace with a new spark plug per the gap
specifications below.
OEM Type NGK-BPMR7A
Replacement Type TORCH-L8RTC
Gap 0.024" - 0.028" (0.6 - 0.7 mm)
Maintenance Schedule
Follow the service intervals indicated in the schedule below.
Service your blower more frequently when operating in adverse
conditions. Contact our help line authorized service dealer. Time
intervals shown are maximum. Actual use and your experience will
determine the frequency of required maintenance.
BEFORE USE
Wipe up fuel leaks, fuel spillage.
Inspect and clean fuel tank.
EVERY 25 HOURS
Clean cylinder fins and intake cooling vent.
Inspect and clean the air filter.
EVERY 50 HOURS
Clean and readjust spark plug gap (gap: 0.6 - 0.7 mm
[0.024 - 0.028"]), and replace if necessary.
Clean exhaust port.
Inspect and clean the air filter.
ANNUALLY
Replace spark plug.
Storing The Blower
–Clean all foreign material from the blower. Store unit indoors in
a dry, well-ventilated area that is inaccessible to children. Keep
away from corrosive agents such as garden chemicals and
deicing salts.
–Abide by all local regulations for the safe storage and handling
of gasoline.
When storing 1 month or shorter:
–Fuel stabilizer is an acceptable alternative in minimizing the
formation of fuel gum deposits during storage. Add stabilizer
to your fuel container (not the fuel tank on the blower). Run
engine at least 3 minutes after adding stabilizer.
When storing longer than a month:
–Drain all fuel from tank into a container approved for gasoline.
Run engine until it stops.
SPECIFICATIONS
Backpack Blower Specifications
Model ...................................................... 200934
Displacement..................................................42 cc
Type........................................................ 2-Stroke
Air Velocity* ............................MAX 190 MPH (306 km/h)
............................................. MAX 529 CFM (ft³/min)
Sound Pressure* ...................... 75 dB(A) @ 50 ft. (15.2 m)
Effective Fuel Tank Capacity.................33.8 fl. oz. (1000 ml)
Fuel to Oil Mix Ratio............................................50:1
* Rated per ANSI/OPEI B175.2-2012

200934 - BACKPACK BLOWER TROUBLESHOOTING
17
TROUBLESHOOTING
Problem Cause Solution
Engine does not start.
Fuel mixture is too rich. Open choke.
Fuel strainer clogged. Clean fuel strainer.
Fuel line clogged. Clean fuel line.
Flooded engine. Let unit sit for 15 minutes or remove spark plug
and clean per manual.
Spark plug gap is incorrect. Replace or adjust spark plug per instructions.
Engine dies or accelerates poorly.
Air filter dirty. Clean air filter.
Incorrect fuel. Drain and fill with correct fuel/new fuel.
Exhaust port / spark arrestor screen
blocked. Clean exhaust port / Spark arrestor screen.
Blower is weak or uneven. Blower pipe is clogged or loose. Inspect and make sure blower tubes are clear and
clamps are installed tight and properly.
For further technical support:
Technical Support Team
Toll Free 1-877-338-0999
[e-mail]

WARRANTY*
CHAMPION POWER EQUIPMENT
2 YEAR LIMITED WARRANTY
Warranty Qualifications
To register your product for warranty and FREE lifetime call center
technical support please visit:
https://www.championpowerequipment.com/register
To complete registration you will need to include a copy of the
purchase receipt as proof of original purchase. Proof of purchase
is required for warranty service. Please register within ten (10)
days from date of purchase.
Repair/Replacement Warranty
CPE warrants to the original purchaser that the mechanical and
electrical components will be free of defects in material and
workmanship for a period of two years (parts and labor) from
the original date of purchase and 180 days (parts and labor) for
commercial and industrial use. Transportation charges on product
submitted for repair or replacement under this warranty are the
sole responsibility of the purchaser. This warranty only applies to
the original purchaser and is not transferable.
Do Not Return The Unit To The Place Of
Purchase
Contact CPE’s Technical Service and CPE will troubleshoot any
issue via phone or e-mail. If the problem is not corrected by
this method, CPE will, at its option, authorize evaluation, repair
or replacement of the defective part or component at a CPE
Service Center. CPE will provide you with a case number for
warranty service. Please keep it for future reference. Repairs or
replacements without prior authorization, or at an unauthorized
repair facility, will not be covered by this warranty.
Warranty Exclusions
This warranty does not cover the following:
Normal Wear
Products with mechanical and electrical components need
periodic parts and service to perform well. This warranty does not
cover repair when normal use has exhausted the life of a part or
the equipment as a whole.
Installation, Use and Maintenance
This warranty will not apply to parts and/or labor if the product is
deemed to have been misused, neglected, involved in an accident,
abused, loaded beyond the product’s limits or modified. Normal
maintenance is not covered by this warranty and is not required to
be performed at a facility or by a person authorized by CPE.
Other Exclusions
This warranty excludes:
–Cosmetic defects such as paint, decals, etc.
–Wear items such as starter pulleys, starter ropes, filter
elements, belts, blower fans, impeller blades, blower and/or
vacuum tubes, vacuum bag and straps (where applicable), etc.
–Failures due to acts of God and other force majeure events
beyond the manufacturer’s control.
–Problems caused by parts that are not original Champion
Power Equipment parts.
Limits of Implied Warranty and
Consequential Damage
Champion Power Equipment disclaims any obligation to cover
any loss of time, use of this product, freight, or any incidental
or consequential claim by anyone from using this product.
THIS WARRANTY AND THE ATTACHED U.S. EPA and/or CARB
EMISSION CONTROL SYSTEM WARRANTIES (WHEN APPLICABLE)
ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
A unit provided as an exchange will be subject to the warranty
of the original unit. The length of the warranty governing the
exchanged unit will remain calculated by reference to the purchase
date of the original unit.
This warranty gives you certain legal rights which may change
from state to state or province to province. Your state or province
may also have other rights you may be entitled to that are not
listed within this warranty.
Contact Information
Address
Champion Power Equipment, Inc.
12039 Smith Ave.
Santa Fe Springs, CA 90670 USA
www.championpowerequipment.com
Customer Service
Toll Free: 1-877-338-0999
[e-mail]
Fax no.: 1-562-236-9429
Technical Service
Toll Free: 1-877-338-0999
[e-mail]
 EMERGENCY 24 HOUR SUPPORT: 1-562-204-1188
*Except as otherwise stipulated in any of the following enclosed Emission Control System Warranties (when applicable) for the Emission Control System: U.S. Environment Protection Agency
(EPA) and/or California Air Resources Board (CARB).

CHAMPION POWER EQUIPMENT, INC. (CPE) AND
THE UNITED STATES ENVIRONMENTAL PROTECTION AGENCY (U.S. EPA)
EMISSION CONTROL SYSTEM WARRANTY
Your Champion Power Equipment (CPE) engine complies with U.S. EPA emissions regulations.
YOUR WARRANTY RIGHTS AND OBLIGATIONS:
The U.S. EPA and CPE are pleased to explain the Federal Emission Control System’s Warranty on your 2021 small off-road engine and
engine powered equipment. In the United States new equipment that use small off-road engines shall be designed, built and equipped to
meet U.S. EPA regulations. CPE shall warrant the emission control system on your small off-road engine and equipment for the period of
listed below, provided there has been no abuse, neglect, unapproved modification or improper maintenance of your equipment.
Your emission control system may include parts such as: carburetor, fuel tanks, fuel lines (for liquid fuel and fuel vapors), fuel caps, valves,
canisters, filters, clamps, connectors, and other associated components. Where a warrantable condition exits, CPE will repair your small
off-road engine at no cost to you including diagnosis, parts and labor.
MANUFACTURER’S WARRANTY COVERAGE:
This emission control system is warranted for two years. If any emission related part on your engine or equipment is defective, the part will
be repaired or replaced by CPE.
OWNER’S WARRANTY RESPONSIBILITIES:
As the small off-road engine owner, you are responsible for the performance of the required maintenance listed in your Owner’s Manual.
CPE recommends that you retain all your receipts covering maintenance on your small off-road engine, but CPE cannot deny warranty
solely for the lack of receipts.
As the small off-road engine owner, you should be aware that CPE may deny you warranty coverage if your small off-road engine or a part
has failed due to abuse, neglect, or improper maintenance or unapproved modifications.
You are responsible for presenting your small off-road engine to an Authorized CPE distribution center or service center or alternate service
outlet as soon as a problem exists. The warranty repairs shall be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty coverage, you should contact:
Champion Power Equipment, Inc.
Customer Service
12039 Smith Ave.
Santa Fe Springs, CA 90670
1-877-338-0999
[e-mail]

EMISSION CONTROL SYSTEM WARRANTY
1. APPLICABILITY: This section applies to Emissions Control Systems on small off-road engines or equipment that use small off-road
engines subject to the emission standards in this Article. The warranty period begins on the date the new engine or equipment is
delivered to an ultimate purchaser and shall continue for 24 consecutive months thereafter.
2. GENERAL EMISSIONS WARRANTY COVERAGE
CPE warrants to the ultimate purchaser of the new engine or equipment and to each subsequent owner that the Emissions Control
System when installed is:
2a. Designed, built and equipped to conform to U.S. EPA emissions standards for spark-ignited engines at or below 19 kilowatts;
2b. Free from defects in materials and workmanship that cause the failure of a warranted part to be identical in all material respects
to the part as described in the engine manufacturer’s application for certification for a period of two years.
3. THE WARRANTY ON EXHAUST AND EVAPORATIVE EMISSION-RELATED PARTS WILL BE INTERPRETED AS FOLLOWS:
3a. Any warranted part that is not scheduled for replacement as required maintenance in the Operators Manual required by subsection
(e) must be warranted for the warranty period defined in subsection (b)(2). If any such part fails during the period of warranty
coverage, it must be repaired or replaced by CPE according to subsection (3)(3d) below. Any such part repaired or replaced under
the warranty must be warranted for a time not less than the any remaining warranty period.
3b. Any warranted emissions-related part that is scheduled only for regular inspection in the Operators Manual shall be warranted
for the warranty period defined in subsection (b)(2). A statement in such written instructions to the effect of “repair or replace as
necessary” shall advise owners of the warranty coverage for emissions related parts. Replacement within the warranty period is
covered by the warranty and will not reduce the period of warranty coverage. Any such emission-related part repaired replaced
under warranty shall be warranted for a time not less than the remaining warranty period.
3c. Any warranted emissions-related part that is scheduled for replacement as required maintenance in the Operators Manual shall
be warranted for the period of time prior to the first scheduled replacement point for that part. If the part fails prior to the first
scheduled replacement, the part shall be repaired or replaced by CPE according to Subsection (3)(3d) below. Any such emissions-
related part repaired or replaced under warranty shall be warranted for a time not less than the remainder of the period prior to
the first scheduled replacement point for such emissions-related part.
3d. Repair or replacement of any warranted emissions-related part under the Warranty provisions of this article shall be performed at
no charge to the owner at a CPE Authorized Service Outlet.
3e. The owner of the small off-road engine shall not be charged for diagnostic labor that leads to the determination that a warranted
part is in fact defective, provided that such diagnostic work is performed at a CPE Authorized Service Outlet.
3f. CPE shall pay for covered emissions warranty repairs at non-authorized service outlets under the following circumstances:
i. The service is required in a population center with a population over 100,000 according to U.S. Census 2000 without a CPE
Authorized Service Outlet AND
ii.The service is required more than 100 miles from a CPE Authorized Service Outlet. The 100-mile limitation does not apply in the
following states: Alaska, Arizona, Colorado, Hawaii, Idaho, Montana, Nebraska, Nevada, New Mexico, Oregon, Texas, Utah and
Wyoming.
3g. CPE shall be liable for damages to other original engine components or approved modifications proximately caused by a failure
under warranty of an emission-related part covered by the ECS Warranty.
3h. Throughout the Emissions Control Systems Warranty period, CPE shall maintain a supply of warranted emission-related parts
sufficient to meet the expected demand for such emission-related parts.
3i. Any CPE Authorized, and approved emission-related replacement part may be used in the performance of any ECS Warranty
maintenance or repair and will be provided without charge to the owner. Such use shall not reduce CPE’s warranty obligation.
3j. Unapproved add-on or modified parts may not be used to modify or repair a CPE engine. Such use voids this Warranty and shall
be grounds for disallowing a warranty claim. CPE shall not be liable hereunder for failures of any warranted parts of a CPE engine
caused by the use of such an unapproved add-on or modified part.
