GROUP 2 - Front Suspension & Drive
Illustration Title Group-Fig. No.
Front Suspension
Front Suspension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 002-105
January 8, 2003

1 6502 697 4 NUT, Hex Flange Lock, M12x1.75
2 6504 800 4 SCREW
3 ARM, Control
4865 320AA 1 Upper Right
4865 321AA 1 Upper Left
-4 4815 306 2 BUSHING, Pivot, Upper Control Arm
-5 6030 099 1 FITTING, Ball Joint, Zirc, Upper
Control Arm
-6 4695 673 1 SEAL, Upper Control Arm
7 ARM, Control
4865 322AA 1 Lower Right
4865 323AA 1 Lower Left
-8 4786 580 1 BUSHING, Lower control Arm to
Pushrod Lower
9 6101 994 4 SCREW
10 6504 751 2 NUT AND RETAINER, Hex Flange
Locking, M14 x 2.00
11 6504 751 4 NUT AND RETAINER, Hex Flange
Locking, M14 x 2.00
12 6502 698 2 NUT, Hex Flange Lock
13 4786 578 2 PUSH ROD, FRONT SUSPENSION
14 6101 993 2 SCREW, and Washer Hex Hd Wa
Hd Pt M14x2.00x85.00
15 ROCKER ARM, front suspension
4865 284AA 1 Right
4865 285AA 1 Left
16 4897 344AA 2 BUSHING PKG, FRONT SHOCK
UPPER, CONTROL ARM
17 4815 307 1 BUSHING, Rocker, Arm to Pushrod
Front Suspension
18 4865 031AA 2 CAP, Ball Joint
19 6101 994 4 SCREW, and Washer Hex Hd Cone
Wa Hd Pt M14x2.00x110.00
20 6504 843AA 2 NUT AND RETAINER, m8x1.25
21 6504 989AA 2 SCREW AND WASHER, Hex Head,
M14-2x95
22 6101 993 2 SCREW, and Washer Hex Hd Wa
Hd Pt M14x2.00x85.00
23 4626 762AB 2 CLAMP, Stabilizer Bar
24 6101 980 2 SCREW AND WASHER, Hex Head,
M8x1.25x45
25 4626 368 2 CUSHION, Sway Eliminator
26 6505 593AA 2 NUT, Hex Flange
27 6504 668 2 NUT
Front Suspension
Figure 002-105
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX »

28 6504 378 2 SCREW, Hex Flg Hd Full body Hd Pt
M10x1.5x170.00
29 6504 271 2 NUT, M10x1.50
30 KNUCKLE, Front
4865 282AA 1 Right
4865 283AA 1 Left
31 6504 989AA 2 SCREW AND WASHER, Hex Head,
M14-2x95
32 6504 751 2 NUT AND RETAINER, Hex Flange
Locking, M14 x 2.00
33 4786 590AB 1 BAR, Front Sway
34 4786 592AB 2 LINK, Sway Eliminator
35 6505 291AA 2 NUT AND WASHER, Hex, M12x1.
75, Sway Bar Link to Sway Bar
36 5290 906AB 2 SHOCK ABSORBER, Suspension
37 5264 894AA 2 SPRING
Front Suspension
Figure 002-105
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX «

GROUP 3 - Rear Axle
Illustration Title Group-Fig. No.
Rear Axle Shafts
Shaft, Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 003-410
January 8, 2003

1 SHAFT, Axle Half
4882 522AC 1 Right
4882 521AC 1 Left
2 4728 262 1 BOOT KIT, Half Shaft, Inner
3 4863 722 1 BOOT KIT, Half Shaft, Outer
4 6502 541 2 NUT, Hex Flange Lock, M27x2
-5 4593 012 2 CIRCLIP, Half Shaft
-6 6502 363 2 O RING, CV Joint
Shaft, Rear Axle
Figure 003-410
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

GROUP 4 - Parking Brake
Illustration Title Group-Fig. No.
Parking Brake Lever and Cables
Lever and Cables, Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 004-110
January 8, 2003

1 4786 521 1 LEVER, Park Brake, with Output
Cable,Equalizer and Switch
-2 5209 922 1 SWITCH, Parking Brake
-3 4815 677 1 REINFORCEMENT, Parking Brake
4 4815 634 1 CABLE, Parking Brake, Right
5 6502 691 4 NUT, Hex Flange Lock, M6x1, Cable
Clip to Rivet Stud Mounting
6 4616 248 4 CLIP, Parking Brake Cable
7 4815 635 1 CABLE, Parking Brake, Left
8 6502 691 4 NUT, Hex Flange Lock, M6x1, Cable
Clip to Rivet Stud Mounting
9 4616 248 4 CLIP, Parking Brake Cable
10 6101 467 2 NUT, Hex Flange, M8x1.25, Parking
Brake Lever Mounting
Lever and Cables, Parking Brake
Figure 004-110
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

GROUP 5 - Service Brakes
Illustration Title Group-Fig. No.
Front Brakes
Brakes, Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-110
Rear Brakes
Brakes, Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-210
Power Brake Booster
Booster, Power Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-310
Brake Master Cylinder
Master Cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-410
Brake Lines and Hoses
Front,to Proportioning Valve and to Chassis Brake Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-510
Front,to Caliper and to Chassis Brake Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-520
Rear Lines and Hoses and Chassis Brake Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-530
Brake Pedals
Pedal, Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fig. 005-610
January 8, 2003

1 CALIPER, Disc Brake
4897 654AA 1 Right
4897 655AA 1 Left
2 4728 121 1 PISTON PACKAGE, Disc Brake,
Right And Left
3 4364 781 1 BOOT AND SEAL, Disc Brake, Right
And Left
4 3780 788 1 BLEEDER SCREW, Brake
5 4238 717 1 CAP, Bleeder
6 4423 573 1 SLEEVE, Disc Brake Caliper
7 6502 527 2 BOLT, Hex Flange Head, M8-1.
25x68.50, Caliper Mounting
8 4383 471 1 BUSHING, Disc Brake Caliper
9 4897 664AA 1 PAD KIT, Front Disc Brake
10 4815 797 1 ROTOR, Brake, Right or Left
11 4641 517 1 HUB AND BEARING, Brake, with
Seal, Right or Left
12 4815 594 1 BOLT, Hub/Bearing Clamp
13 6502 311 5 STUD, Wheel
14 KNUCKLE, Front
4865 282AA 1 Right
4865 283AA 1 Left
15 4786 750 1 ADAPTER, Disc Brake Caliper, Right
or Left
16 6101 702 4 BOLT, M10x1.50x70, Hub To
Knuckle Mounting
17 6502 294 1 NUT, Hex Flange, M22x1.25, Hub/
Bearing Clamp
Brakes, Front
Figure 005-110
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

1 5066 701AA 1 PAD KIT, Rear Disc Brake
2 4728 121 1 PISTON PACKAGE, Disc Brake
3 CALIPER, Disc Brake
5011 072AA 1 Right
5011 073AA 1 Left
4 4383 471 1 BUSHING, Disc Brake Caliper
5 3780 788 1 BLEEDER SCREW, Brake
6 4238 717 1 CAP, Bleeder
7 4423 573 1 SLEEVE, Disc Brake Caliper
8 4886 493AA 1 SHOE AND LINING KIT, Parking
Brake
9 4383 543 1 CLIP, Brake Shoe Hold Down
-10 4762 536 1 PIN, Brake Shoe Hold Down
11 4509 504 1 SOCKET, Brake Adjusting Screw
12 4383 539 1 NUT, Parking Brake Adjusting
13 4886 496AA 1 SPRING, Park Brake Shoe Return
14 4509 503 1 SCREW, Parking Brake
15 KNUCKLE, Rear
4865 288AA 1 Right
4865 289AA 1 Left
16 6101 662 3 SCREW AND WASHER, Hex Head,
M12x1.75x70, Hub To Knuckle
Mounting
17 4593 450AA 1 HUB AND BEARING, Brake
18 6505 519AA 5 STUD, Hub
19 4815 750 1 ROTOR, Brake
20 6502 541 2 NUT, Hex Flange Lock, M27x2
-21 4897 343AA 1 LEVER KIT, Rear Wheel Brake
Adjust Pivot
-22 ADAPTER, Parking Brake
4886 490AA 1 Right
4886 491AA 1 Left
-23 6502 527 2 BOLT, Hex Flange Head, M8-1.
25x68.50, Caliper Mounting
-24 4897 342AA 1 BOOT, Parking Brake Lever
-25 4886 497AA 1 SPRING, Adjusting Shoe
Brakes, Rear
Figure 005-210
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

1 4865 624AA 1 HOSE, Brake Booster Vacuum
2 2448 761 2 CLAMP, Hose
3 4723 391 1 VALVE, Brake Booster Check
4 4883 813AA 1 GROMMET, Brake Booster Check
Valve
5 4723 642 1 SEAL, Brake Booster To Dash,
Mounting
6 4882 873 1 BOOSTER, Power Brake
7 6101 467 4 NUT, Hex Flange, M8x1.25, Brake
Booster Mounting
Booster, Power Brake
Figure 005-310
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

1 4683 656 1 CAP, Master Cylinder Reservoir
2 4761 942 1 RESERVOIR, Brake Master Cylinder
-3 4723 389 1 GROMMET, Master Cylinder
Reservoir, Mounting
4 4882 872 1 MASTER CYLINDER, Brake
-5 4723 395 1 SEAL, Master Cylinder To Booster,
to Booster, Mounting
-6 6101 467 4 NUT, Hex Flange, M8x1.25, Booster,
Mounting
Master Cylinder
Figure 005-410
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX

1 4786 506 1 TUBE, Brake Master Cylinder,
Master Cylinder to Proportioning
Valve, Secondary
2 4786 507 1 TUBE, Brake Master Cylinder,
Master Cylinder to Proportioning
Valve, Primary
3 5290 961AA 1 VALVE, Proportioning, with Bracket
4 4786 504AB 1 TUBE, Brake, Proportioning Valve to
Right Front Hose
5 4815 559 1 TUBE, Brake, Proportioning Valve to
Chassis Brake Tube
6 0154 780 4 SCREW, Tapping, .25-20x1.25, PDC
Bracket, Mounting
7 6506 053AA 1 SCREW, Hex Head, M8x1.25x50,
Proportioning Valve Attaching
8 4786 505AB 1 TUBE, Brake, Proportioning Valve to
Right Front Hose
9 4688 934 1 BRACKET, Power Distribution Center
-10 4683 556 2 CLIP, Tube, Mounts to Engine
Crossmember, Dual
Front,to Proportioning Valve and to Chassis Brake Tube
Figure 005-510
January 8, 2003
CHRYSLER PROWLER (PR)————————————————————————————————————————————————————————————
SERIES LINE BODY ENGINE TRANSMISSION
S = Special P = Premium 27=Convertible EGG = 3.5L 6 cyl 24V DGX = 4 spd. Automatic
PART
ITEM NUMBER QTY LINE SERIES BODY ENGINE TRANS TRIM DESCRIPTION
AR = Use as required - = Non illustrated part # = New this model year
«
RETURN TO GROUP INDEX
