Contents
Before driving
Introduction 2
Instrumentation 4
Controls and features 14
Seating and safety restraints 44
Starting and driving
Starting 76
Driving 84
Roadside emergencies 107
Servicing
Maintenance and care 125
Capacities and specifications 183
Reporting safety defects (U. S. only) 189
Index 190
1
CDW I_IIImpr_Cont_en MM 5/15/97 7:41 PM Page 2

Introduction
2
ICONS
Indicates a warning. Read the
following section on Warnings for
a full explanation.
Indicates that vehicle information
related to recycling and other
environmental concerns will follow.
We must all play our part in
protecting the environment.
Correct vehicle usage and the
authorized disposal of waste
cleaning and lubrication materials
are significant steps toward this
aim.
BREAKING IN YOUR VEHICLE
There are no particular breaking-in
rules for your vehicle. Simply avoid
driving too fast during the first
1 600 km (1 000 miles). Vary
speeds frequently. This is
necessary to give the moving parts
a chance to break in.
WARNINGS
How can you reduce the risk of
personal injury and prevent
possible damage to others, your
vehicle and its equipment?
In this owner’s guide, answers to
such questions are contained in
comments highlighted by the
warning triangle symbol.
CDW II_A1_en MM 5/15/97 7:41 PM Page 2

Introduction
3
INFORMATION ABOUT THIS
GUIDE
The information found in this guide
was in effect at the time of
printing. Ford may change the
contents without notice and
without incurring obligation.
If possible, you should avoid hard
braking for the first 1 600 km
(1 000 miles).
From 1 600 km (1 000 miles)
onwards you can gradually increase
the performance of your vehicle up
to the permitted maximum speeds.
CDW II_A1_en MM 5/15/97 7:41 PM Page 3

4
Instrumentation
Page 27
Turn signal/high beam
Page 6
Instrument cluster
Page 26
Hazard flasher
control
Page 28
Windshield
wiper/washer
control
Page 129
Hood release
Page 14
Headlamp control/
Foglamp control*
Page 26
Horn
Page 25
Tilt steering
wheel lever
Page 16
Instrument panel
dimmer switch
Page 24
Ignition switch
Page 29
Speed control*
Page 17
Power mirrors
CHECK
ENGINE
O/D
OFF
Off
Res
Set
Acc
Coast
On
M
I
R
R
O
R
S
N
O
R
M
A
L
1
2
0
3
x 1000
456
7
8
000123
0000
10
20
30
4050 60 70 8090
100
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
E F
1/2
UNLEADED FUEL ONLY
BRAKE
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 4

5
Instrumentation
Page 18
Clock
Page 16
Rear window
defroster control*
On various models the
appearance and location of
some items may differ from
those shown here. However,
the page references given
still apply.
POWER AUDIO AM/FM SCAN
SEEK
31 2
64 5
ANS
SIDE 1-2
EJECT
VOLUME
DEF
LO
HI
OFF PNL/FLR
PANEL
A/C
FLOOR
FLR
DEF
MAX
A/C
:
I0 20
Page 19
Climate control system
Page 42
Anti-theft system status
indicator*
Electronic sound system;
refer to “Audio Guide”
* if equipped
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 5

High beams
Illuminates when the headlamp
high beams are on.
Instrumentation
6
Turn signal
Flashes when the left or right turn
signal or hazard lights are
activated.
Charging system
Briefly illuminates when the
ignition is turned on and the engine
is off. The light also illuminates
when the battery is not charging
properly and the vehicle may
require electrical system service.
000123
0 0 0 0
10
20
30
4050 60 70 8090
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
100
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
INSTRUMENT CLUSTER
LIGHTS AND CHIMES
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 6

Instrumentation
7
Safety belt
Illuminates when the ignition is
switched on as a reminder to fasten
the safety belts. For more
information, refer to Safety belt
indicator light and warning
chime in the Seating and safety
restraints chapter.
O/D Off indicator
(Automatic transaxle only)
Illuminates and remains
illuminated when the transaxle
control switch (TCS) on the end of
the gearshift lever is pressed and
overdrive is turned off.
Indicates the status of the
transaxle and will flash steadily if a
malfunction is detected. If the
flashing persists, have your
transaxle serviced by your dealer
or a qualified service technician as
soon as possible.
If the condition persists, your
transaxle may be damaged.
TRACTION
CONTROL
O/D
OFF
TRACTION
CONTROL
O/D
OFF
Low coolant (if equipped)
Briely illuminates when the ignition
is turned on and the engine is off.
Illuminates when the engine
coolant level is low. Refer to the
Maintenance and care chapter to
check the engine coolant level.
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 7

Instrumentation
8
Check engine
Illuminates when the ignition is
turned on and the engine is off.
Also illuminates when the engine’s
emission control system requires
service or if the fuel filler cap is
not fitted correctly.
CHECK
ENGINE
CHECK
ENGINE
Air bag readiness
Briefly illuminates when the
ignition is turned on. If the light
fails to illuminate, continues to
flash or remains on, have the
system serviced immediately.
000123
0 0 0 0
10
20
30
4050 60 70 8090
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
100
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
Low fuel
Illuminates when the fuel level is
low.
CHECK
ENGINE
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 8

Instrumentation
9
Front foglamps
Illuminates when foglamps are
switched on.
Refer to Foglamps control in the
Controls and features chapter for
notes on use.
CHECK
ENGINE
Brake system warning light
Extinguishes when the parking
brake is released. Illuminates after
releasing the parking brake to
indicate low brake fluid level.
Anti-lock brake system (ABS)
(if equipped)
Momentarily illuminates when the
ignition is turned on and the engine
is off. If the light stays on or
continues to flash, the ABS needs
to be serviced.
Engine oil pressure
Briefly illuminates when the
ignition is turned on and the engine
is off. The light also illuminates
when engine oil pressure has been
lost. Refer to the Maintenance
and care chapter to check the
engine oil level as soon as possible.
If the engine oil level is correct and
the light stays on, see your dealer
or qualified service technician.
BRAKE
BRAKE
BRAKE
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 9

Instrumentation
10
Testing the warning and
indicator lights and chimes
Turn the ignition key to the on
position without starting the
engine. The following warning and
indicator lights will illuminate
briefly: charging system, safety belt
(does not illuminate, if the driver’s
safety belt is fastened), low
coolant, low fuel, engine oil
pressure, check engine and air bag
readiness.
If any of these lights do not
illuminate, see your dealer or
qualified service technician.
000123
0 0 0 0
10
20
30
4050 60 70 8090
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
100
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 10

Instrumentation
11
Headlamps on warning chime
Sounds when the headlamps are
on, the ignition is off (and the key
is not in the ignition) and the
driver’s door is open.
Key-in-ignition warning chime
Sounds when the key is left in the
off/lock or accessory position and
the driver’s door is open.
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
Air bag supplemental restraint
system (SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 11

Instrumentation
12
N
O
R
M
A
L
Engine coolant temperature
gauge
Indicates the temperature of the
engine coolant. At normal
operating temperature, the needle
remains within the NORMAL area.
If it enters the red section, the
engine is overheating. Switch off
the ignition and determine the
source of the problem. Refer to
Checking and adding engine
coolant in the Maintenance and
care chapter.
000123
0 0 0 0
10
20
30
4050 60 70 8090
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
100
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
INSTRUMENT CLUSTER
GAUGES
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 12

Instrumentation
13
Trip odometer
The trip odometer can register the
mileage of individual journeys. To
reset, depress the button.
000123
0 0 0 0
10
20
30
4050 60 70 8090
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
100
Speedometer Odometer
Trip odometer Reset button
E F
1/2
UNLEADED FUEL ONLY
Fuel gauge
The fuel gauge displays the
approximate level of usable fuel left
in the fuel reservoir.
Tachometer
Indicates the engine speed in
revolutions per minute (rpm).
1
2
0
3
x 1000
456
7
8
Speedometer
Indicates the current vehicle
speed.
Odometer
Registers the total mileage of the
vehicle.
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 13

Controls and features
14
POWER AUDIO AM/FM SCAN
SEEK
31 2
64 5
ANS
SIDE 1-2
EJECT
VOLUME
M
I
R
R
O
R
S
DEF
LO
HI
OFF PNL/FLR
PANEL
A/C
FLOOR
FLR
DEF
MAX
A/C
T/C OFF
000123
0000
10
20
30
4050 60 70 8090
100
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
:
I0 20
Off
Res
Set
Acc
Coast
On
INSTRUMENT PANEL
CONTROLS
Headlamp control
Lamps off.
Turn one position clockwise:
Parking lamps, instrument panel
lamps, license plate lamps and tail
lamps on
Turn two positions clockwise:
Headlamps on.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 14

Controls and features
15
Daytime running light (DRL)
(Canadian vehicles only)
The DRL system turns on the
highbeam headlamps, with a
reduced light output, when:
• the vehicle is running and the
ignition is in the on position,
• the vehicle has a fully released
parking brake, and
• the headlamp system is in the off
position.
Foglamp control (if equipped)
Pull out the control while the
headlamps are on to turn the
foglamps on.
Push the control in to deactivate
the foglamps.
The daytime running light
(DRL) system will not
illuminate the tail lamps and
parking lamps. Turn on your
headlamps at dusk. Failure to do
so may result in a collision.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 15

Controls and features
16
Panel dimmer control
Adjust the control to vary the
intensity of the panel lighting.
Operates only when the exterior
lights are switched on.
Rear window defroster
(if equipped)
Press the defroster control to clear
the rear window of thin ice and fog.
The ignition must be in the on
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
off position. To manually turn off
the defroster, push the control
again.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 16

Controls and features
17
Power mirrors
The control can be swivelled and
turned.
Turn the control counterclockwise
to adjust the driver’s side mirror,
clockwise to adjust the passenger’s
side mirror. Adjust the selected
mirror by moving the center
control in the desired direction.
Then turn the control back to the
center position.
M
I
R
R
O
R
S
M
I
R
R
O
R
S
POWER AUDIO AM/FM SCAN
SEEK
31 2
64 5
ANS
SIDE 1-2
EJECT
VOLUME
DEF
LO
HI
OFF PNL/FLR
PANEL
A/C
FLOOR
FLR
DEF
MAX
A/C
000123
0000
10
20
30
4050 60 70 8090
100
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
:
I0 20
Off
Res
Set
Acc
Coast
On
M
I
R
R
O
R
S
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 17

To toggle between 12 or 24 hour
format, depress the H button and
the M button simultaneously and
then release them.
To advance the hours, press the H
button; to advance the minutes
press the M button. To advance
rapidly, depress and hold the
corresponding button.
Hours Minutes
:
I0 20
Audio system
For information on the audio
system, refer to the “Audio Guide”.
Digital clock
Switch the ignition on: The clock
can be set to either 12 or 24 hour
format.
Controls and features
18
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 18

Controls and features
19
POWER AUDIO AM/FM SCAN
SEEK
31 2
64 5
ANS
SIDE 1-2
EJECT
VOLUME
M
I
R
R
O
R
S
DEF
LO
HI
OFF PNL/FLR
PANEL
A/C
FLOOR
FLR
DEF
MAX
A/C
000123
0000
10
20
30
4050 60 70 8090
100
110
120
130
MPH
20
40
60
55
80 120
100 140
160
180
200
E F
1/2
UNLEADED FUEL ONLY
1
2
0
3
x 1000
456
7
8
N
O
R
M
A
L
BRAKE
CHECK
ENGINE
TRACTION
CONTROL
O/D
OFF
:
I0 20
Off
Res
Set
Acc
Coast
On
Climate controls
Vents
Airflow from the vents may be
adjusted by moving the horizontal
control or vertically adjusting the
vent according to your airflow
preference.
Your vehicle has one of the
following climate control systems:
• Manual heating system
• Manual heating and air
conditioning system
In some modes, the two systems
function similarly. In modes where
the systems do not function
similarly, the different functions
are noted.
CDW IIIC3Cont en MM 5/15/97 7:45 PM Page 19
