CIE-Group WSR-1 User manual

B. WSR-1 Unit:
Interface:
•INPUT: 3.5mm socket provides the ability to Input an AUX Audio
Signal to the WSR-1. *Note: The wired input’s priority is
lower than WiFi audio input
• OUTPUT: 3.5mm socket provides audio output connection to
  audioamplierorHiFiunit
• MICRO-USB: Use supplied USB power lead to provide power via host
  amplierorviaoptionalplug-inPSU(USB-CHRGT)
•WPS/Reset: 1shortpresstooperateWPS
1 long press to operate reset function
C. Supported Software:
iOS Airplay,iTunes,SmartsonixAPP,otherAPPwhich
complies to DLNA like Spotify, BubbleUpnp
Android SmartsonixAPP,otherAPPwhichcompliestoDLNA
like Spotify, BubbleUpnp
Windows WindowsMediaPlayer12
• Search“Smartsonix”inGooglePlayoryourApple
 APPstoretodownloadtheAPPcontroller.
D. WSR-1 Schematic:
E. Specications:
Input Analogue Audio - 3.5mm Stereo Jack
Output Analogue Audio - 3.5mm Stereo Jack
Wireless Network IEEE802.11b/g/n
Wired Network RJ45
Power 5v/1ADCviaMicroUSB
Weight Gross:0.16kg/Net:0.08kg
Dimensions 116(W)x95(H)x22(D)mm
WSR-1 Quick Start Guide:
ThankyouforpurchasingthenewWSR-1StreamingReceiver.Pleasereadthroughthismanualcarefullybeforeusingyourdevicetoensureproperuse&installation.
ForanyfurtherqueriespleasecalltheCIE-GroupTeamon0115 9770075oremail: [email protected]
•1x3.5~3.5mmStereoAudioLead
•1xMiniUSB~USBAPowerLead
•1xUserManual
•Packaging
•1xWSR-1WiFiStreamingReceiverUnit
A. Package Contents:
WiFi Streaming Receiver
WSR-1 User Manual
www.cie-group.com

F. How to Connect & Stream:
WiFiStreamingReceiverallowsmusictobestreamedfromyourphone,iPadorPCandinputstoyourhostaudioamplierorHiFisystem.
MultipleUnitsmaybeusedtoprovideamulti-room/Zonecongurationwhereunitscanoperateindependentlyorcanbecombined(playingonesourceonmultiplereceivers).
The WSR-1 can be used in a number of ways to provide streaming capability in the following options:
Option 1: One to One connection
(Airplay etc….)
ThismodeisusedtoallowtheWSR-1toactasasingleonetoone
receiver,toplaymusicfromyourPhoneorTabletusingtheWSR-1’sown
internalWiFiconnection.
1. PlugintheMiniUSBandpoweruptheWSR-1usingthesupplied
USBcableoroptionalPSUandconnecttheAudioOutputfromthe
WSR-1toyourAmplierusingthe3.5mmjackcablesupplied.
2. OnyourPhoneorTabletsearchfortheWSR-1withintheWiFi
device menu.
3. TheWSR-1willshowupasLumiAudio_XXXX,selectandallowthe
connection.
4. ItshouldnowbepossibletoplayMusicstoredonyourPhoneor
TabletdirectlytotheWSR-1,andouttoyourconnectedAudio
Device.
Option 2: One to One via Smartsonix APP
1. DownloadtheSmartsonixAPPfromtheAndroidPlayorApple
Store to your device.
2. PlugintheMiniUSBandpoweruptheWSR-1usingthesupplied
USBcableoroptionalPSUandconnecttheAudioOutputfromthe
WSR-1toyourAmplierusingthe3.5mmjackcablesupplied.
3. OnyourPhoneorTabletsearchfortheWSR-1withintheWiFI
device menu.
4. TheWSR-1willshowupasLumiAudio_XXXX,selectandallowthe
connection.
5. OpentheSmartsonixAPPandusethistoselectandcontrolthe
Music/ContenttobebroadcastviatheWSR-1toyourconnected
Audio Device.
Option3: Network Broadcast (TuneIn Radio,
Spotify etc….)
1. DownloadtheSmartsonixAPPfromtheAndroidPlayorAppleStoreto
your device.
2. PlugintheMiniUSBandpoweruptheWSR-1usingthesuppliedUSB
cableoroptionalPSUandconnecttheAudioOutputfromtheWSR-1to
yourAmplierusingthe3.5mmjackcablesupplied.
3. OnyourPhoneorTabletconnecttoyourInstalledWiFINetwork.
4. OpentheSmartsonixAPP,themessageSearchingforSmartsonixWireless
HiFiSystemwillappear,followedbyAddDevice.
5. FollowtheOn-Screenprompts,thenpresstheWPSbuttonontheWSR-1,
themessageSearchingforWiFiconnectionisbroadcastfromtheWSR-1.
6. EntertheWiFipassword,andpressconnect,thismaytakeanumberof
minutestoconnect,themessageWiFiConnectedisbroadcastfromthe
WSR-1.
7. ConnectSuccessisshownonyourPhone/Tablet,pressNext.(ifFail
Messageappearsseesection‘IfWPSFailstoconnect’below).
8. TheSmartsonixAPPwillautomaticallyopen,selectthelocationintowhich
youwillbebroadcasting(oraddyourowndesignationviatheCustomeld)
andpressnish.
9. ThiswillopentheSmartsonixAPP,usethistoselectandcontrolthe
Music/ContenttobebroadcastviatheWSR-1andouttoyourconnected
Audio Device.
If WPS Fails to connect:
1. Select“Alternativewaytosetup”
2. GotothephonesettingsandselecttheWSR-1fromtheWiFiDeviceList,
onceconnectedreturntotheSmartsonixAPP.
3. SelectNext
4. SelectPreferedWiFiNetworkandenterPassword.
5. OnceconnectedselectDone
6. NametheWSR-1deviceandselectFinish.
PleaseNote:SomeAndroidbaseddevicesmaynotallowconnectionviaOption
1dependingonthecompatibilityofthedevicesMusicAPP.
WiFi Streaming Receiver
WSR-1 User Manual
www.cie-group.com
WSR-1 User Manual
CIE-Group Ltd 3 Widdowson Close Blenheim Ind Est Bulwell Not-
tingham NG6 8WB England
T: [phone] F: [phone]
E: [email protected] W: www.cie-group.com
