Cino SD112 User manual

Bluetooth Smart Dongle
Quick Start Guide
SD112

1
Getting Familiar with Your Bluetooth
Smart Dongle
Cino’s smart dongle is an instant plug-and-play solution that connects
FuzzyScan Bluetooth imagers with a host device that lacks Bluetooth
capabilities. Incorporating a Bluetooth® v4.0 radio, the smart dongle delivers
a wireless communication range of over 100 meters. It is compatible with
most operating systems and no separate driver installation is required when
the imager is used in USB HID Standard mode.
This document serves as a quick reference guide for the dongle’s installation
and operation. Please visit www.cino.com.tw for details.
Installation
Pairing Bluetooth Imager with Dongle
Turn on your FuzzyScan Bluetooth imager. Make sure it is in an unpaired
state: its status indicator should emit alternating red-green flashes.
Otherwise, scan the “Uninstall” command barcode to release any prior
pairing.
Initiate the dongle-imager pairing process by scanning the dongle’s
“Quick Pair” barcode label. Your imager will then produce clicking sounds,
and its link indicator will flash blue rapidly. During this process, your
dongle will continue to emit red and green lights.
Upon successful pairing, the scanner will beep 4 times in ascending tone,
and its link indicator will flash blue every 2.5 seconds. The dongle’s
power/pairing indicator will be a steady blue.
The Quick Pair barcode on your dongle is designed for “Pair Mode”,
i.e. the dongle can only pair with one imager at a time.
The dongle's default host interface setting is USB HID. To change this
setting to USB COM, please first install the USB2COM driver on your
host device.
Status Indicator
Power/Pairing Indicator
Quick Pair Command Barcode
Cap
Remove the dongle’s cap.
Plug the dongle into your host device’s USB port.
Supply power to the dongle by turning on your host
device. The power/pairing indicator will flash blue once
and its status indicator will emit alternating red-green
flashes (“unpaired state”) when powered on.

2
Unpairing Bluetooth Imager from Dongle
To unpair the imager from a dongle, scan the “Uninstall” barcode with such
imager. If unpairing is successful, the imager will beep 4 times in descending
tone. Both the dongle and the imager will also emit red-green flashes to
reflect their unpaired state.
UNINSTALL
Creating a Barcode for PICO Mode
Under PICO mode, multiple imagers (up to 7) can be paired with a smart
dongle simultaneously. To establish pairings under this mode, you must
create a pairing barcode for this purpose with a barcode generator.
Pair your dongle with an imager using the Quick Pair barcode.
Thereafter, scan the “System Information” command barcode. The
dongle’s MAC addresses will be displayed on your host device.
SYSTEM INFORMATION
When using your barcode generator to create the pairing barcode for
PICO mode, the barcode’s symbology should be Code 128, and its
format ought to be as follows:
<Fnc 3>Mxxxxxx
M is the prefix. xxxxxx represents the last 6 characters of the smart
dongle’s MAC address.
For example, if the dongle’s MAC address is “00 25 14 11 11 11”, the
pairing barcode will be: M111111
To pair or unpair a scanner under PICO mode, please follow the
instructions provided above.
Indications
Event
Power/Pairing Indicator
Status Indicator
Power on
1 blue blink
Off
Dongle Upgrading State
Off
Steady red
Uninstall state
Off
Alternative red-green blinks
PICO Mode
Radio Connected
Steady blue
Steady Green
Radio Disconnected
Off
Steady red
PAIR Mode
Radio Connected
Steady blue
Off
Radio Disconnected
Off
Steady red

P/N: YMAUBB001000100
SD112 Quick Start Guide
International Edition, Rev. A1
www.cino.com.tw
Cino makes no warranty of any kind with regard to this publication, including, but not limited to, the
implied warranty of merchantability and tness for any particular purpose. Cino shall not be liable for
technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material. Cino disclaims all responsibility for the
selection and use of software and/or hardware to achieve intended results. Cino reserves the right to make
changes in specications and other information contained in this document without prior notice, and the
reader should in all cases consult Cino to determine whether any such changes have been made. The
information in this publication does not represent a commitment on the part of Cino.
Disclaimer
© COPYRIGHT CINO GROUP • PC WORTH INT’L CO., LTD. ALL RIGHT RESERVED.
Regulatory
FCC part 15B, FCC part 15C
EN55022 EN55024
EN301 489-1 & 489-17, EN300 32B
EN61000-3-2, EN61000-3-3, EN60950-1
