CITROEN C4 PICASSO User manual

CITROËN C4

2

CONTENTS: 3ALIVE WITH TECHNOLOGY 4ELEGANT DESIGN 6THE PERFECT LAYOUT 8DRIVING PLEASURE 10 INTELLIGENT
TECHNOLOGY 12 ENVIRONMENTAL 14 SAFETY 16 RANGE OVERVIEW 20 OPTIONS 22 COLOUR, TRIM & WHEEL OPTIONS
24 EQUIPMENT SPECIFICATION 26 TECHNICAL SPECIFICATION 28 ACCESSORIES 30 ENVIRONMENTAL COMMITMENT
32 FINANCE 33 CARE & INSURANCE 34 GLOSSARY 35 DIMENSIONS
3
CITROËN
C4
ALIVE WITH
TECHNOLOGY
ALIVE WITH TECHNOLOGY,
MOVING WITH STYLE. THE
CITROËN C4 IS MORE ALIVE
THAN EVER.
A SEDUCTIVE BALANCE OF ADVANCED TECHNOLOGY AND UNIQUE STYLE, BOTH HATCHBACK AND COUPÉ FEATURE STRIKING
NEW DESIGN ELEMENTS, SUCH AS THE RAISED BONNET PROFILE, REDESIGNED GRILLE AND BUMPER. THE MESSAGE IS CLEAR
AT A GLANCE: THIS IS A DYNAMIC AND DESIRABLE CAR THAT’S PACKED WITH CITROËN INSPIRATION. LIFE JUST MOVED ON.

ELEGANCE WORKING BEAUTIFULLY. THE CITROËN
C4 DOESN’T LOOK LIKE AN ORDINARY CAR. AND ITS
UNIQUE CHARMS ARE FAR FROM JUST AESTHETIC.
THEY WORK, BEAUTIFULLY.
COUPÉ. SPORTS
PERSONALITY
The ground hugging prole of the Citroën
C4 Coupé sends a clear message. This is
very far from ordinary. Low, aerodynamically
efcient and charismatic, there is a sporty
aura about the Citroën C4 Coupé,
balanced with the no-compromise comfort
and sheer usability of a true Citroën.
4

CITROËN
C4
ELEGANT DESIGN
AT THE FRONT, YOUR EYE WILL BE DRAWN TO THE UNIQUE ‘BOOMERANG’ CURVE OF THE HEADLAMPS. BOLDLY
DESIGNED AND INSTANTLY RECOGNISED, THEY SWEEP ELEGANTLY INTO THE FRONT WINGS. SMOOTHLY INTEGRATED
INTO A NEW GRILLE DESIGN, THE CHROME DOUBLE CHEVRON LOGO HELPS TO CREATE A SHARPER, MORE DYNAMIC
FRONT END. MOST STRIKING OF ALL IS THE FACT THAT THE CITROËN C4 IS NOT A CAR; IT’S A CHOICE OF TWO
ExCITING MODELS WITH DISTINCT AND DIFFERENT CHARACTERS.
HATCHBACK. COMFORTABLY
CUTTING EDGE
From that unmistakable ‘arc of steel’
protective rooine to those subtly curved
sides and sensational rear lights, the
Citroën C4 Hatchback redenes what a
comfortable, space-efcient 5-door hatch
can be. This is both soothing and razor
sharp, safe and exhilarating.
5

THE PERFECT LAYOUT. EVERYTHING IS
WHEREITNEEDSTOBE,FORSAFETY,FOR
COMFORT, FOR SHEER ENJOYMENT. THE
UNIQUE, INTELLIGENT SIMPLICITY OF THE
INTERIOR LAYOUT MAKES THE CITROËN
C4 A TRAVELLING ENVIRONMENT LIKE
NO OTHER.
6

CITROËN
C4
THE PERFECT
LAYOUT
BEYOND THE COMFORT ZONE
Every new Citroën cossets you with real long distance comfort. Driver’s
seats are height-adjustable and VTR+ and Exclusive models also
include lumbar adjustment. The added indulgence of the optional
Leather Pack brings tactile soft leather trim and the all-weather comfort
of heated front sport seats.
THE NERVE CENTRE
Stylish and ever more practical, the distinctive centred translucent
instrument display has been carefully thought out. All the vital driving
information needed is included and clear to see at a glance. Especially
as there is no sun reection on the screen.
THE WHEEL REINVENTED
A Citroën C4 trademark, the steering wheel has a centre that remains
xed at all times. This means that all the important controls and lights
positioned there remain quickly and easily accessible, all the time. It
means that a driver’s hands can stay on the wheel and eyes can stay on
the road. Amongst the ngertip functions there are the cruise control
and radio/Hi-Fi buttons. Also designed for class-dening safety, the
xed-centred controls steering wheel ensures that the driver’s airbag
always deploys at the optimum angle.
7
77

THE DYNAMICS OF PLEASURE.
UNDENIABLY STYLISH AND ORIGINAL,
PACKED WITH SAFETY AND COMFORT
FEATURES, THE CITROËN C4 IS ALSO
ALIVE WITH TECHNOLOGY THAT
DELIVERS A THRILLING DRIVE.
CLIMB IN AND GET COMFORTABLE. FROM THE FIRST TURN OF THE
WHEELS YOU’LL APPRECIATE LIGHT, ACCURATE STEERING THAT
COMMUNICATES WITH YOU – SUPPLYING PLENTY OF FEEDBACK
FROM THE ROAD BELOW. FROM THE FIRST CORNER YOU’LL SENSE A
POISED CHASSIS THAT FLOWS WITH PRECISION AND GRIPS HARD, YET
SACRIFICES NONE OF THE TRADEMARK CITROËN RIDE COMFORT,
GLIDING OVER EVERY POTHOLE AND BUMP...
8

CITROËN
C4
DRIVING PLEASURE
PERFECTLY POISED
Maintaining the Citroën C4’s no-compromise balance between sharp handling and silky
ride is a no-compromise suspension design. At the front are MacPherson struts and
coil springs, while at the rear, independent trailing arms and torsion bars keep things
perfectly composed.
HEARTS WITH MINDS
A well balanced front wheel drive car needs a great engine to exploit its potential. The
Citroën C4 offers a choice of two petrol engines and three brilliant diesels, all bristling with
the technology that provides exible performance, economy and low emissions. Try the
muscular 1.6HDi 16V 110hp diesel or the enterprising 1.6 16V VTi 120hp petrol engine
to discover what we mean by the dynamics of pleasure.
SHIFTING PRIORITIES
A highly capable car needs a gearbox to match. In addition to the smooth,
well-judged ratios of the 5-speed manual there is the best-of-both-worlds high technology
of the Electronic Gearbox System (EGS). Essentially two transmissions in one, allowing fast,
precise manual changes to be made using the steering column mounted paddles, or let the
efcient and seamless automatic mode do the work.
CONFIDENCE INSPIRING
The Citroën C4 can be driven safe in the knowledge that its talents include advanced
stopping power. With powerful discs all round, ventilated discs at the front, ABS, Emergency
Braking Assistance (EBA) and Electronic Brakeforce Distribution (EBD), the Citroën C4
knows that excitement and safety are both part of a great dynamic balance. Electronic
Stability Programme (ESP) also features on VTR+ and Exclusive models.
9

INTELLIGENT TECHNOLOGY. IN THE CITROËN C4, INNOVATION
IS HARNESSED TO DELIVER AN ExTRAORDINARY CHOICE OF
TECHNOLOGY, FROM NAVIGATION, COMMUNICATION AND
ENTERTAINMENT, TO SAFETY AND CLEVER STORAGE. WELCOME
TO THE CAR THAT THINKS OF EVERYTHING.
10

CITROËN
C4
INTELLIGENT
TECHNOLOGY
BLUETOOTH®SYSTEM WITH USB BOx
Combining two outstanding features in one clever option, the USB socket
allows you to connect an MP3 player to play and browse its content using
steering-mounted and dashboard radio controls. At the same time, the
Bluetooth® system allows you to make safe hands-free calls, and browse
through your phone’s Contacts or Call Log.
AUTOMATICALLY DARK
Using light sensors, the Citroën C4’s electrochrome rear view mirror on Exclusive
models automatically darkens to prevent dazzle from following headlamps.
AUTOMATICALLY LIGHT
As night falls, deep shade covers the road or a tunnel appears, the Citroën C4’s
automatic headlamps activate to illuminate the way ahead on Exclusive models.
AIR AS YOU LIKE IT
The air conditioning standard on all
models has an advanced lter and
a recycling system which can be
controlled from the centre console
or the xed-centred controls steering
wheel. The automatic digital system
on Exclusive models has dual-zone
adjustment, so front passengers can
choose their own temperature setting.
PERFECT SCENTS
The Citroën C4’s fresh air system goes
further. Carefully integrated into the
dashboard vents, is a scented air freshener
system that distributes a choice of soothing
aromas around the cabin. Citroën C4
appeals to all the senses!
STORE MORE
Intelligent use of interior space is a Citroën
signature. The Citroën C4 proves the point
with a spacious drawer under the passenger’s
seat and a ventilated and illuminated glove
box on all models.
MYWAY
The MyWay colour satellite navigation system, standard on Exclusive models,
includes Bluetooth® and live trafc information for maximum convenience. It also
features a 7” 16/9 screen, and its SD card integrated European mapping brings
you voice guidance and graphics in 2D or aerial perspective.
11

CITROËN
C4
ENVIRONMENTAL
12

THE ENVIRONMENTAL BENCHMARK. A TRULY
ADVANCED CAR MUST TREAD SOFTLY WHEN IT
COMES TO THE ENVIRONMENT. THE CITROËN
C4 IS DESIGNED TO SET BENCHMARKS FOR
LOW EMISSIONS AND FUEL EFFICIENCY.
AIMING LOW
The 1.6HDi 16V engine with 90hp or 110hp has incredibly low CO2 outputs. The
110hp version with Diesel Particulate Filter System (DPFS) produces an extraordinary
118g/km when combined with the Electronic Gearbox System (EGS) on VTR+ and
120g/km CO2 on Exclusive models. And remember it still delivers smooth, punchy
performance and a combined fuel consumption gure of 64.2mpg on VTR+ and 62.8mpg
on Exclusive models.
ANYTHING PARTICULAR
Available on most of the diesel range, the Diesel Particulate Filter System (DPFS) uses
advanced anti-pollution technology to remove harmful carbon particles from the exhaust
gases, before they reach the great outdoors. Smoky diesels are history.
EFFICIENCY ENGINEERED IN
All Citroën C4 engines make a more environmentally sound choice, from the ultra-low
emissions diesels to rened, efcient petrol. Each engine has been carefully engineered to
meet Euro IV emissions standards, providing maximum enjoyment and minimal waste. Even
the powerful 1.6 16V 120hp petrol engine can return 54.3mpg on the extra urban cycle.
EGS MEANS LESS CO2
The revolutionary Electronic Gearbox System (EGS) is essentially two gearboxes in one, for
rapid and responsive manual changes, or a seamless automatic. And it’s even cleverer still.
Choose EGS and you will produce even less CO2 than with a conventional manual!
ENERGY SAVER®TYRES
With a reduction in rolling resistance of 20%, Michelin’s Energy Saver® tyres, tted on
1.6HDi 90hp and 1.6HDi 110hp DPFS EGS VTR+ models, reduce the amount of energy
needed to propel the car along the road which results in a reduction in fuel consumption.
This is achieved with no loss of grip or stability, with shorter stopping distances in wet
conditions. The tyre’s innovative architecture generates fuel savings of nearly 0.2litres per
100km (in combined cycle), resulting in a reduction in CO2 emissions of nearly 4g/km and
around one tonne less CO2 over the entire life of a Citroën C4.
13

SAFETY TO THE POWER OF CITROËN C4. THE SHEER DEPTH OF
SAFETY TECHNOLOGY THROUGHOUT THE CITROËN C4 MAKES
IT A VERY WELL PROTECTED PLACE TO BE, FROM ITS TYRE
PRESSURE MONITOR AND MULTIPLE AIRBAGS, TO ITS
ELECTRONIC STABILITY PROGRAMME.
TYRE PRESSURE MONITOR
Included with the optional Xenon Dual-Function Directional headlamps available
on Exclusive models, the Citroën C4’s tyre pressure monitor regularly checks each
tyre and gives the driver a visual and audible warning if a problem is detected – it’s
a very reassuring safety feature.
14

CITROËN
C4
SAFETY
SLOW DOWN FAST AND
BE SEEN
The hazard warning lights activate
automatically in the event of rapid
deceleration to warn other drivers.
They switch off when the Citroën C4
accelerates away.
STABILITY = SAFETY
A Citroën is inherently stable and secure,
thanks to its sophisticated suspension
design, but the Electronic Stability
Programme (ESP), standard on VTR+
and Exclusive models, adds another
level of protection. By monitoring
progress through a bend, it can sense
if oversteer or understeer is developing,
modify engine torque and apply one or
more of the brakes to maintain stability
and control.
MAxIMUM BRAKING
The standard Emergency Braking
Assistance (EBA) automatically maximises
brake effort when it detects strong braking
input. This compensates for the fact that
many of us don’t brake with enough force
in an emergency situation.
15
COME RAIN…
The rear wiper operates automatically when the reverse gear is engaged.
Exclusive models benet from rain-sensitive windscreen wipers that activate
to clear your view at the rst sign of a downpour. The automatically
illuminating headlamps also turn on during a rain shower.
AIRBAGS EVERYWHERE
The Citroën C4 features an army of airbags
for maximum passenger protection. Front
airbags are adaptive, so that they deploy
with exactly the right power and speed
for every kind of impact. Thanks to the
innovative xed-centred controls steering
wheel, the driver is also protected by a
torso-shaped airbag that always deploys
at the optimal angle. Curtain airbags built
into the roof protect the heads of front and
rear passengers should a side impact occur,
while lateral airbags integrated into the front
seats also protect against side impacts,
and move occupants towards the centre of
the passenger cell, away from the force of
the collision.
Euro NCAP for adult occupant protection for the Citroën
C4 5-door Hatchback, date assessed: November 2004

CITROËN
C4
RANGE OVERVIEW
16
DIVERSITY DEFINED. THE CITROËN C4 IS NOT A
CAR.IT’S A DIVERSERANGE OF HATCHBACKSAND
COUPÉS, EACH ALIVE WITH A DIFFERENT CHOICE
OF TECHNOLOGY, EQUIPMENT AND STYLE.

• ABS with Electronic Brakeforce
Distribution (EBD)
• Emergency Braking Assistance (EBA)
• Driver’s, front passenger’s, front lateral
and curtain airbags
• High-frequency multi-function remote
control central locking with deadlocks
• Front seat belts pre-tensioners with
force-limiters
• Body colour painted front and rear
bumper inserts
• Body colour painted door handles
(Hatchback only)
• 16” steel wheels with ‘Azzana’ wheel
covers (set of four)
• Fixed-centred controls steering wheel
• ‘Guide-me-home’ headlamp function
• Front fog lights
• Variable power assisted steering
• Cruise control with speed limiter
• Electrically adjustable door mirrors
• Front electric windows with ‘one-touch’
operation and anti-pinch
• Laminated windscreen
• Air conditioning
• Scented air freshener
• Multi-function on-board trip computer
• RDS stereo radio/MP3 compatible
CD player
CITROËN C4 VTR SPECIFICATION INCLUDES:
CITROËN
C4
V T R
CO2 EMISSIONS (G/KM)
HATCHBACK COUPÉ
PETROL ENGINE AVAILABILITY
1.4i 16V 90hp 153 153
1.6 16V VTi 120hp 159 159
DIESEL ENGINE AVAILABILITY
1.6HDi 16V 90hp 115 115
THE DIFFERENT CHARACTERS OF THE CITROËN C4 VTR – HATCHBACK AND COUPÉ – ARE SHARPLY DEFINED. THE HATCHBACK BRISTLES WITH
ADVANCED FEATURES FOR YOUR COMFORT, ENJOYMENT AND SAFETY. IT TAKES REFINEMENT TO ANOTHER LEVEL, LETTING THE CORE CITROËN
BALANCE OF DYNAMIC PROWESS AND PEERLESS RIDE COMFORT SHINE THROUGH. THE COUPÉ IS PACKED WITH THE KIND OF FOCUSED, DYNAMIC
FEATURES THAT KEEN DRIVERS WILL LOVE. A CAR TO SUIT YOUR CHARACTER? WHATEVER NEXT!
17
EXPECT THE UNEXPECTED WITH THE CITROËN C4.
AND ExPECT MORE.

CITROËN
C4
VTR+
CO2 EMISSIONS (G/KM)
HATCHBACK COUPÉ
PETROL ENGINE AVAILABILITY
1.6 16V VTi 120hp 159 159
1.6 16V VTi 120hp Auto 165 –
DIESEL ENGINE AVAILABILITY
1.6HDi 16V 90hp 115 115
1.6HDi 16V 110hp 128 128
1.6HDi 16V 110hp DPFS†EGS†† 118 118
THE CITROËN C4 VTR+ MODELS ARE SUPERBLY
EQUIPPED AND ENGINEERED TO INSPIRE YOU.
EVEN A BRIEF GLANCE AT THE SPECIFICATION BELOW WILL GIVE YOU AN IDEA OF WHAT THE ‘+’ MEANS IN VTR+. WITH SUCH
AN ARMOURY OF FEATURES THERE REALLY IS ONLY ONE FUNDAMENTAL CHOICE TO MAKE – HATCHBACK OR COUPÉ?
• ‘Black panel’ night-time
instrument lighting
• Front sport seats with lumbar
adjustment on driver’s side
• Front armrest with storage
• Electronic Stability Programme (ESP)
with traction control
• 16” ‘Olympie’ alloy wheels (set of four)
• Leather steering wheel
• Front fog lights with chrome inserts
• Rear electric windows with
‘one-touch’ operation and
anti-pinch (Hatchback only)
• Body colour painted bumper
inserts and door handles
• Cigarette lighter
CITROËN C4 VTR+ SPECIFICATION IN ADDITION TO VTR INCLUDES:
†Diesel Particulate Filter System †† Electronic Gearbox System
18

CO2 EMISSIONS (G/KM)
HATCHBACK COUPÉ
PETROL ENGINE AVAILABILITY
1.6 16V VTi 120hp 159 159
DIESEL ENGINE AVAILABILITY
1.6HDi 16V 110hp 128 128
1.6HDi 16V 110hp DPFS†EGS†† 120 120
LAUGH OUT LOUD PERFORMANCE?
INDULGENT LUxURIES? EVERYTHING?
THE CITROËN C4 ExCLUSIVE DELIVERS YOUR HEART’S DESIRE, WHICH PROBABLY INCLUDES MYWAY
COLOUR SATELLITE NAVIGATION, AUTOMATIC DIGITAL AIR CONDITIONING AND BLUETOOTH®. THESE
MODELS LEAVE NOTHING OUT ExCEPT COMPROMISE. PREPARE FOR UNDILUTED, DYNAMIC ENJOYMENT.
• MyWay – colour satellite
navigation, auxiliary socket,
live trafc information, European
mapping and Bluetooth® system
• Dark tinted tailgate window
• Anti-theft alarm
• Electrochrome rear view mirror
• 17” ‘Volubilis’ alloy wheels
(set of four – Hatchback models only)
• 17” ‘Ribalta’ alloy wheels
(set of four – Coupé models only)
• Automatic digital air conditioning with
dual-zone temperature setting
• Heat-reecting acoustic windscreen
• Automatic rain-sensitive windscreen
wipers and automatic illumination
of headlamps
CITROËN C4 EXCLUSIVE SPECIFICATION IN ADDITION TO VTR+ INCLUDES:
†Diesel Particulate Filter System †† Electronic Gearbox System
CITROËN
C4
ExCLUSIVE
19

CITROËN
C4
OPTIONS
OPTIONS ARE ABOUT FREEDOM OF CHOICE. FREEDOM IS
ABOUT GOING WHERE YOU WANT AND DOING AS YOU
PLEASE. THE CITROËN C4 OPTIONS INVITE YOU TO DO SO IN
STYLE AND IN SAFETY.
LEATHER PACK
For pure luxury, choose the tactile quality and comfort of the Leather Pack, trimmed
in soft leather and featuring heated front sport seats.
HI-FI PACK
Want more ‘punch’ from your punk or extra clarity from your classical music? Choose
the JBL Hi-Fi system with an amplier and nine loudspeakers including a subwoofer.
20
