CITROEN DS4 DSign User guide

OWNER'S HANDBOOK

YOUR HANDBOOK
ON THE INTERNET!
CITROËN lets you view your vehicle's
documentation on line, to see earlier versions
and the latest information, simply and free of
charge.
Connect to http://service.citroen.com:
1 | Select your language and register,
click on the link in the "Private customer access" zone to consult the
vehicle documentation; a window opens providing access to all of
the handbooks,
select your vehicle, choose the body type then the date of issue of
the handbook,
finally, click on the heading of your choice.
2 |
3 |
4 |

CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Your vehicle is fitted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of your
vehicle's electronic system. Please note this
specific warning and contact a CITROËN
dealer to be shown the recommended
equipment and accessories.
At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.
Happy motoring!
We draw your attention to the following...

Contents
Contents
6FAMILIARISATION
34 ECO-DRIVING
380 VISUAL SEARCH
384 ALPHABETICAL
INDEX
MONITORING
38 Instrument panels
40 Rev counter
41 Warning and indicator lamps
52 Indicators
55 Manual test
58 Customisation
Key
safety warning
additional information
contributes to the protection of the environment
programming a function with the
configuration menu
001
001
refer to the page indicated

MULTIFUNCTION
SCREENS
COMFORT ACCESS VISIBILITY
62 Monochrome screen C
66 Colour screen and map
70 Trip computer
78 Ventilation
80 Manual air conditioning
82 Dual-zone digital air
conditioning
87 Rear screen demist - defrost
88 Front seats
93 Rear seats
94 Steering wheel adjustment
95 Mirrors
100 Remote control key
109 Alarm
112 Doors
114 Boot
115 Electric windows
117 Fuel tank
119 Misfuel prevention (Diesel)
122 Lighting controls
123 Daytime running lamps
126 Automatic illumination of
headlamps
127 Welcome lighting
128 Headlamp adjustment
129 Directional lighting
131 Wiper controls
132 Automatic rain sensitive
wipers
136 Courtesy lamps
137 Interior mood lighting
138 Boot lamp
004
004
005
005
002
002
003
003

SAFETY DRIVINGFITTINGS CHILD SAFETY
192 Electric parking brake
200 Manual parking brake
201 Manual gearbox
202 Gear shift indicator
203 6-speed electronic gearbox
system
207 Automatic gearbox
211 Hill start assist
212 Stop & Start
215 Lane departure warning
system
216 Blind spot sensors
220 Speed limiter
222 Cruise control
224 Parking space sensors
226 Parking sensors
172 Direction indicators
172 Hazard warning lamps
173 Horn
173 Emergency or assistance call
174 Tyre under-inflation detection
176 Braking assistance systems
177 Trajectory control systems
(ESP)
179 Front seat belts
183 Airbags
160 Child seats
166 ISOFIX child seats
169 Child lock
142 Interior fittings
148 Front armrest
153 Boot fittings
008
008
009
009
006
006
007
007

CHECKS PRACTICAL
INFORMATION
TECHNICAL DATA AUDIO AND
TELEMATICS
231 Bonnet
232 Running out of fuel (Diesel)
233 Petrol engines
234 Diesel engines
235 Checking levels
238 Checks
244 Temporary puncture repair
kit
249 Changing a wheel
256 Changing a bulb
263 Changing a fuse
269 Battery
272 Energy economy mode
273 Changing a wiper blade
273 Very cold climate screen
274 Towing the vehicle
276 Towing a trailer
278 Accessories
282 Petrol engines
283 Petrol weights
284 Diesel engines
285 Diesel weights
286 Dimensions
287 Identification markings
291 Emergency or assistance
293 eMyWay
345 Audio system
012
012
013
013
010
010
011
011

Familiarisation
Familiarisation

Exterior
Parking sensors
This system measures the size of a free
parking space between two vehicles or
obstacles.
Stop & Start system
This system puts the engine temporarily into standby during
stops in the traffic (traffic lights, traffic jams, etc...). The engine
restarts automatically as soon as you want to move off. The
Stop & Start system reduces fuel consumption and exhaust
emissions, as well as noise levels when stationary.
224
212
Directional lighting
This lighting automatically provides
additional visibility when cornering.
129
Panoramic windscreen
This large glazed area provides
incomparable visibility and light in the
passenger compartment.
12
Cornering lighting
At low speed, this lighting comes on
automatically to improve vision when
cornering, at intersections, when parking
parking... making use of the front foglamp on
the side in question.
130

9
Familiarisation
Exterior
Welcome lighting
This additional exterior and interior lighting,
controlled remotely, makes your approach to
the vehicle easier when the light is poor.
Temporary puncture repair kit
This kit is a complete system, consisting of a
compressor and a sealant cartridge, for the
temporary repair of a tyre.
127
244
Under-inflation detection
This system continuously monitors the pressure
in each tyre and warns you in the event of a
puncture or under-inflated tyre.
174
Blind spot sensors
In certain conditions, this system
detects the presence of a vehicle in
the blind spot. It informs you by means
of a warning lamp in the corresponding
door mirror.
216

100
Opening
A. Folding/unfolding the key
(first press this button).
3-button remote
control
When a sensor detects a low level of light,
the remote switching on of the dipped beam
headlamps, the sidelamps and the side spotlamps
makes your approach to the vehicle easier.
Welcome lighting
Complete or selective unlocking of
the vehicle
(rapid flashing of the direction
indicators).
Opening the windows
(hold until the desired position is reached).
Selective unlocking of the boot.
Normal locking
(press once; fixed lighting of the
direction indicators).
Closing the windows
(hold until the desired position is reached).
127
In the same way, the passenger compartment
lighting, such as the courtesy lamps and the
footwell lamps, comes on.

11
Familiarisation
117, 119
A. Opening the fuel filler flap.
Capacity of the fuel tank: approximately 60 litres.
Fuel tank
Opening
101, 114
1. Selective unlocking of the boot.
2. Opening the boot.
Boot

Panoramic windscreen
Blind
)To open it, take the blind by its central
grip A, and pull it rearwards, guiding it to
the desired position.
)To close it, take the blind by its central
grip A, and pull it forwards, guiding it to
the desired position.
The sun visor should be in the folded position
before moving the blind.
This includes a panoramic area in tinted glass to increase lighting and vision in the passenger compartment.
Fitted with a blind on each side to improve temperature control and a sun visor to avoid dazzle.
Sun visor
Fitted with a courtesy mirror and a ticket holder.
)To avoid dazzle from the front, lower the
sun visor.
)To avoid dazzle from the side, disengage
the sun visor from its central fixing and turn
it towards the side window.
Do not attach to or suspend heavy
objects from the blind and its guide rails.

13
Familiarisation
Interior
6-speed electronic gearbox
system
This system offers driving combining a fully
automatic mode and a manual mode.
Interior mood lighting
This dimmed lighting of the passenger
compartment improves visibility inside the
vehicle when the light is poor.
Audio and communication
systems
These systems benefit from the following
technologies: radio, CD player, USB player,
Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets.
Radio
203
137
345
293
Electric parking brake
It combines the functions of automatic
application on switching off the engine and
automatic release when moving off.
Manual application and release remains
possible.
192
eMyWay satellite navigation system
Massage function
This system gives a lumbar massage for a
period of 60 minutes. The massage is done in
6 cycles of 10 minutes each.
91

Instruments and controls
1. Cruise control/speed limiter controls.
2. Controls for optional functions.
3. Steering wheel adjustment control.
4. Lighting and direction indicator control
stalk.
5. Instrument panel.
6. Driver's airbag.
Horn.
7. Controls for audio and telematic system.
8. Controls for Bluetooth system or telephone.
9. Bonnet release.
10. Door mirror controls.
Electric window controls.
11. Fusebox.
12. Manual headlamp height adjustment
Lower side switch panel.
13. Fuel filler flap opening switch.
Upper side switch panel.
14. Side adjustable air vent.
15. Front side window demisting vent.

15
Familiarisation
Instruments and controls
1. Steering lock and ignition.
2. Steering mounted control paddles for the
6-speed electronic gearbox system.
3. Wiper/screenwash/trip computer
control stalk.
4. Speaker (tweeter).
5. Windscreen demisting vent.
6. Sunshine sensor.
7. Passenger's airbag.
8. Glove box/Audio/video sockets/
Passenger's airbag deactivation switch.
9. Heated seat control.
10. Lumbar massage control.
11. Electric parking brake.
12. Gear lever, 6-speed electronic gearbox
system.
13. Large multifunctional storage unit.

Roof consoles - Centre consoles
A. Rear view mirror.
B. Microphone for audio and telematic
system.
C. Interior mood lighting.
D. Emergency call/Assistance call.
E. Courtesy lamp/Map reading lamps.
1. Central adjustable air vents.
2. Monochrome screen and seat belt and
front airbag warning lamp screen or colour
and mapping screen.
3. eMyWay Audio or satellite navigation
system.
4. Central switch panel.
5. Heating/air conditioning controls.
6. USB port/auxiliary Jack socket and
cigarette lighter/12 V accessory socket.
7. Gear lever, manual or electronic gearbox
system.
8. Manual or electric parking brake
9. Portable ashtray.
10. Front armrest.

17
Familiarisation
Sitting comfortably
Manual adjustment 88
Driver's seat
Forwards-backwards Height
Electric adjustment
Seat back angle
89

Sitting comfortably
Head restraint height and angle
Front seats
Other functions available...
Lumbar massage.
Storing driving positions
(driver's electric seat).
Heated seats.
90
1. Release the steering wheel.
2. Adjust for height and reach.
3. Lock the steering wheel.
Steering wheel adjustment
94
As a safety precaution, these
operations must only be carried out
when stationary.
Lumbar
91
