Clarion ProAudio DXZ545MP User manual

AM/FM CD/MP3/WMA PLAYER
•
RADIO AM/FM-LECTEUR CD/MP3/WMA
•
REPRODUCTOR DE AM/FM CD/MP3/WMA
Owner’s manual
Mode d’emploi
Manual de instrucciones
DXZ545MP
Clarion Co., Ltd.
All Rights Reserved. Copyright © 2003: Clarion Co., Ltd.
Printed in China / Imprimé en Chine / Impreso en China
2003/12
PE-2623B
280-8005-00
+DXZ545MP-001-cover 11/5/03, 5:03 PM1

2DXZ545MP
280-8005-00
1. FEATURES
•MP3 and WMA File Playable with ID3-TAG and WMA-TAG Display
•Visible Blue Negative LCD and White Illuminated Buttons
•Aluminum Detachable Faceplate
•Z-Enhancer Plus with 2 Band PEQ
•MAGNA BASS EX for Dynamic Bass Tuning
•4ch RCA Output and 2ch AUX Input with 3 Level Adjustments
•CeNET with Balanced Audio Line Transmission and Dynamic Noise Cancelling
•Sirius Control
280-8005-00
English
Contents
1. FEATURES ...................................................................................................................................... 2
2. PRECAUTIONS ............................................................................................................................... 3
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS ..................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major button operations when external equipment is connected to this unit ................................... 7
Display Items ................................................................................................................................... 8
LCD Screen ..................................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL ..................................................................................................................... 10
Inserting the Batteries ................................................................................................................... 10
Functions of Remote Control Unit Buttons .................................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
Radio Operations ........................................................................................................................... 14
CD/MP3/WMA Operations ............................................................................................................. 16
Different pieces of music heard by plural listeners (2-ZONE function) .......................................... 20
Operations Common to Each Mode .............................................................................................. 21
8. OPERATIONS OF ACCESSORIES .............................................................................................. 24
CD Changer Operations ................................................................................................................ 24
TV Operations ................................................................................................................................ 26
9. IN CASE OF DIFFICULTY ............................................................................................................ 28
10. ERROR DISPLAYS ....................................................................................................................... 29
11. SPECIFICATIONS ......................................................................................................................... 30
Thank you for purchasing this Clarion product.
∗Please read this owner’s manual in its entirety before operating this equipment.
∗After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗This manual includes the operating procedures of the CD changer, TV tuner connected via the
CeNET cable. The CD changer, TV tuner have their own manuals, but no explanations for operat-
ing them are described.
DXZ545MP 91
+DXZ545MP-001-cover 11/5/03, 5:03 PM2

280-8005-00
DXZ545MP 38 DXZ545MP
280-8005-00 280-8005-00
DXZ545MP 4
English English English
2. PRECAUTIONS
Be sure to unfold and read the next page. / Veuillez déplier et vous référer à la page suivante.
Cerciórese de desplegar y de leer la página siguiente.
1. When the inside of the car is very cold and the
player is used soon after switching on the
heater moisture may form on the disc or the
optical parts of the player and proper playback
may not be possible. If moisture forms on the
disc, wipe it off with a soft cloth. If moisture
forms on the optical parts of the player, do not
use the player for about one hour.The conden-
sation will disappear naturally allowing normal
operation.
2. Driving on extremely bumpy roads which cause
severe vibration may cause the sound to skip.
3. This unit uses a precision mechanism. Even in
the event that trouble arises, never open the
case, disassemble the unit, or lubricate the ro-
tating parts.
This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a resi-
dential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio communica-
tions. However, there is no guarantee that inter-
ference will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be de-
termined by turning the equipment off and on, the
user is encouraged to consult the dealer or an ex-
perienced radio/TV technician for help.
USE OF CONTROLS, ADJUSTMENTS,OR PER-
FORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN, MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER and MINI DISC
PLAYER SHOULD NOT BE ADJUSTED OR RE-
PAIRED BY ANYONE EXCEPT PROPERLY
QUALIFIED SERVICE PERSONNEL.
CHANGES OR MODIFICATIONS NOT EX-
PRESSLY APPROVED BY THE MANUFAC-
TURER FOR COMPLIANCE COULD VOID THE
USER’S AUTHORITYTO OPERATE THE EQUIP-
MENT.
INFORMATION FOR USERS:.
CHANGES OR MODIFICATIONSTOTHIS PROD-
UCT NOT APPROVED BY THE MANUFAC-
TURER WILL VOID THE WARRANTY AND WILL
VIOLATE FCC APPROVAL.
Bottom View of Source Unit
Handling Compact Discs
Use only compact discs bearing the or
mark.
Do not play heart-shaped, octagonal, or other
specially shaped compact discs.
Some CDs recorded in CD-R/CD-RW mode
may not be usable.
Handling
• Compared to ordinary music CDs, CD-R and
CD-RW discs are both easily affected by high
temperature and humidity and some of CD-R
and CD-RW discs may not be played. Therefore,
do not leave them for a long time in the car.
•New discs may have some roughness around
the edges. If such
discs are used, the
player may not work
or the sound may
skip. Use a ball-point
pen or the like to re-
move any roughness
from the edge of the
disc.
• Never stick labels on the surface of the compact
disc or mark the surface with a pencil or pen.
•Never play a compact disc with any cello-
phane tape or other glue on it or with peeling
off marks. If you try to play such a compact
disc, you may not be able to get it back out of
the CD player or it may damage the CD
player.
• Do not use compact discs that have large
scratches, are misshapen, cracked, etc. Use of
such discs may cause misoperation or damage.
• To remove a compact disc from its storage case,
press down on the center of the case and lift the
disc out, holding it carefully by the edges.
•Do not use commercially available CD protec-
tion sheets or discs equipped with stabilizers,
etc. These may damage the disc or cause
breakdown of the internal mechanism.
Storage
•Do not expose compact discs to direct sunlight
or any heat source.
•Do not expose compact discs to excess hu-
midity or dust.
•Do not expose compact discs to direct heat
from heaters.
Cleaning
•To remove fingermarks and dust, use a soft
cloth and wipe in a straight line from the center
of the compact disc to the circumference.
•Do not use any solvents, such as commercially
available cleaners, anti-static spray, or thinner
to clean compact discs.
•After using special compact disc cleaner, let
the compact disc dry off well before playing it.
Ball-point pen
Roughness
CAUTION
LCD Screen
In extreme cold, the screen movement may slow down and the screen may darken, but this is normal.
The screen will recover when it returns to normal temperature.
Z-Enhancer Plus indication
: Manual indication
: Stereo indication
: MAGNA BASS EXTEND indication
: MP3 indication
: WMA indication
: 2-ZONE indication
: Main indication
: Sub indication
: Satellite indication
: Disc folder indication
: Scan indication
: Repeat indication
: Random indication
Function mode indication
The names of modes being selected, etc.
are displayed.
: Mute indication
: Preset channel indication (1 to 6)
Disc number indication (1 to 12)
Operation status indication
Titles, clock, etc. are displays.
Display Items
+DXZ545MP-003-8 11/5/03, 5:01 PM1

280-8005-00
DXZ545MP 75 DXZ545MP
280-8005-00
6DXZ545MP
280-8005-00
English English Français Español English
●When the Sirius Satellite
Radio is connected
∗For details, refer to the Owner’s Manual
provided with the Sirius Satellite Radio.
[P/A] button
•Performs category scan while in the SIRIUS
mode. When the button is pressed and held,
preset scan is performed.
[DIRECT] buttons
•Stores a station into memory or recall it di-
rectly while in the SIRIUS mode.
[] button
•Select a category.
[a], [d] button
•Press the button to selects a station.
[FNC] button
•Press the button to switch the operation
mode among the SIRIUS mode, etc.
4. NOMENCLATURE
Note:
•Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
[RELEASE] button
•Deeply push in [RELEASE] button to unlock
DCP.
[ROTARY] knob
•Adjust the volume by turning the knob clock-
wise or counterclockwise.
•Use the knob to perform various settings.
[CD SLOT]
•CD insertion slot.
[Q] button
•Eject a CD when it is loaded into the unit.
[] button
•Press and hold for 1 second or longer to turn
on or off the 2-ZONE mode.
•Press to switch the control zone between
main zone or sub zone while 2-ZONE mode
on.
[Z+] button
•Use the button to select one of the 4 types of
sound characteristics already stored in
memory.
[ISR] button
•Recall ISR radio station in memory.
•Press and hold for 2 seconds or longer: Store
current station into ISR memory (radio mode
only).
• Press and hold the button for 1 second or
longer to switch the main and sub zone sound
source. (only while 2-ZONE mode on)
[DISP] button
• Switch the display indication (Main display,
Clock display).
[T] button
•Use the button to input a title in the Tuner, CD
mode.
•Press and hold the button for 1 second or
longer to enter the adjust mode.
[P/A] button
•Perform preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
[UP], [DN] buttons
•Select the Folder. (MP3/WMA disc only)
[DIRECT] buttons
•Store a station into memory or recall it di-
rectly while in the radio mode.
Names of the Buttons and their Functions
[PLAY LIST] button
•Press and hold for 1 second or longer to turn
on or off the play list mode. (MP3/WMA disc
only)
[RDM] button
•Perform random play while in the CD mode.
•Press and hold the button for 1 second or
longer to perform folder random play while in
the MP3/WMA mode.
[RPT] button
•Repeat play while in the CD mode.
•Press and hold the button for 1 second or
longer to perform folder repeat play while in
the MP3/WMA mode.
[SCN] button
•Perform scan play for 10 seconds of each
track while in the CD mode.
•Press and hold the button for 1 second or
longer to perform folder scan play while in the
MP3/WMA mode.
[] button
•Play or pause a CD while in the CD mode.
[a], [d] buttons
•Select a station while in the radio mode or
select a track when listening to a CD. These
buttons are used to make various settings.
•Press and hold the button for 1 second or
longer to switch the fast-forward/fast-back-
ward.
[BND] button
•Switch the band, or seek tuning or manual
tuning while in the radio mode.
•Play a first track while in the CD mode.
[A-M] button
•Use the button to switch to the audio mode
(bass/treble, balance/fader Z-Enhancer Plus)
•Press and hold for 1 second or longer to turn
on or off the MAGNA BASS EXTENED.
[FNC] button
•Press the button to turn on the power.
Press and hold the button for 1second or
longer to turn off the power.
•Switches the operation mode among the ra-
dio mode, etc.
Major button operations when external equipment is
connected to this unit
3.CONTROLS / LES COMMANDES / CONTROLES
[ROTARY]
[a], [d]
[ ]
[SCN]
[RPT]
[RDM]
[PLAY LIST]
[DIRECT]
[DN], [UP]
[DISP]
[ISR]
Source unit / Appareil pilote / Unidad fuente
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
[RELEASE]
[P/A]
[T]
[FNC]
[A-M]
[BND]
[Z+]
[]
[Q]
[CD SLOT]
What is Sirius Satellite Radio?
Sirius is radio the way it was meant to be: Up to
100 new channels of digital quality programming
delivered to listeners coast to coast via satellite.
That means 50 channels of completely commer-
cial-free music. Plus up to 50 more channels of
news, sports, and entertainment from names like
CNBC, Discovery, SCI-FI Channel, A&E, House
of Blues, E!, NPR, Speedvision and ESPN.
Sirius is live, dynamic entertainment, completely
focused on listeners. Every minute of every day of
every week will be different. All 50 commercial-
free music channels are created in-house and
hosted by DJs who know and love the music. Do
you like Reggae? How about Classic Rock or New
Rock? Sirius has an array of choices spanning a
vast range of musical tastes including the hits of
the 50’s, 60’s, 70’s, & 80’s as well as Jazz, Coun-
try, Blues, Pop, Rap, R&B, Bluegrass, Alternative,
Classical, Heavy Metal, Dance and many others...
From its state-of-the-art, digital broadcasting fa-
cility in Rockefeller Center, New York City, Sirius
will deliver the broadest, deepest mix of radio
entertainment from coast to coast.
Sirius will bring you music and entertainment
programming that is simply not available on tra-
ditional radio in any market across the country.
It’s radio like you’ve never heard before.
So Get Sirius and Listen Up! For more infor-
mation, visit siriusradio.com.
●When the CD/DVD changer is
connected
∗For details, see the section “CD changer
operations”. For the DVD changer, refer to
the Owner’s Manual provided with the
DVD changer.
[DISP] button
•When the button is pressed and held,
switches the user titles or track titles, etc.
while in the CD changer mode.
[T] button
•Use the button to input a title in the CD
changer mode.
• Use the button to scroll the title during CD-text play.
[UP], [DN] buttons
•Select the disc.
[RDM] button
• Perform random play. Also perform disc ran-
dom play when the button is pressed and held.
[RPT] button
• Perform repeat play. When this button is pressed
and held, disc repeat play is per-formed.
[SCN] button
•Perform scan play for 10 seconds of each
track. Disc scan play is performed when the
button is pressed and held.
[BND] button
•Move the next disc in increasing order.
[] button
•Play or pause a CD or DVD.
[a], [d] buttons
•Select a track when listening to a disc.
• Press and hold the button for 1 second or
longer to switch the fast-forward/fast-backward.
●When the TV is connected
∗ For details, see the section “TV operations”.
[P/A] button
•Perform preset scan while in the TV mode.
When the button is pressed and held, auto
store is performed.
[DIRECT] buttons
•Store a station into memory or recall it directly.
[] button
•Switch the TV picture mode or VTR (external)
picture mode.
[a], [d] buttons
•Select a station.
[BND] button
•Switch the band.
•When the button is pressed and held, switch
seek tuning or manual mode.
+DXZ545MP-003-8 11/5/03, 5:01 PM2

280-8005-00
DXZ545MP 9
English
5. DCP
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the DCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the DCP with you when
leaving the car.
Removing the DCP
1. Press the [FNC] button for 1 second or
longer to switch off the power.
2. Press in the [RELEASE] button.
3. Remove the DCP.
Attaching the DCP
1. Insert the right side of the DCP into the
Source unit.
2. Insert the left side of the DCP into the
Source unit.
Storing the DCP in the DCP Case
Hold the DCP, in the orientation as shown in the
figure below, and put it into the supplied DCP
case. (Ensure the DCP is in the correct orienta-
tion.)
DCP
DCP
2.
1.
Note:
•If the DCP is dirty, wipe off the dirt with a soft, dry
cloth only.
CAUTION
•The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
•When the Release button is pressed and
the DCP is unlocked, the car’s vibrations
may cause it to fall.To prevent damage to
the DCP, always store it in its case after de-
taching it. (ee figure below.)
•The connector connecting the Source unit
and the DCP is an extremely important
part. Be careful not to damage it by press-
ing on it with fingernails, screwdrivers, etc.
DCP
DCP case
DCP Rear Panel Source Unit Front
Source unit connector
DCP
connector
[RELEASE] button
+DXZ545MP-009-ENG 11/5/03, 5:01 PM9

10 DXZ545MP
280-8005-00
English
6. REMOTE CONTROL
[FUNC]
[],[ ]
[ISR]
[MUTE]
[SCN]
[RPT]
[]
[],[ ]
[BAND]
[DISP]
[RDM]
[2-ZONE]
Rear side
AA (SUM-3, IECR-6/1.5V)
Batteries
Rear cover
Remote control unit
Inserting the Batteries
1.Turn the remote control unit over, then slide the
rear cover in the direction of the arrow.
2.Insert the AA (SUM-3, IECR-6/1.5V) batteries
that came with the remote control unit facing in
the directions shown in the figure, then close the
rear cover.
Notes:
Using batteries improperly can cause them to
explode. Take note of the following points:
•When replacing batteries, replace both batteries
with new ones.
• Do not short-circuit, disassemble or heat batteries.
• Do not dispose of batteries into fire or flames.
• Dispose of spent batteries properly.
Receiver for remote control unit
Operating range: 30˚ in all directions
Signal transmitter
+DXZ545MP-009-ENG 11/5/03, 5:01 PM10

280-8005-00
DXZ545MP 11
English
[FUNC]
[BAND]
[ ] , [ ]
[ ] , [ ]
[ ]
[MUTE]
[ISR]
[DISP]
[SCN]
[RPT]
[RDM]
[2-ZONE]
Functions of Remote Control Unit Buttons
Mode
Button
Radio/SIRIUS CD/MP3/WMA CD changer
DVD changer TV
Switches among radio, SIRIUS tuner, CD/MP3/WMA, CD changer, DVD changer, TV and
AUX.
Switches reception
band.
Plays the first track.
Top play.
Moves the next disc
in increasing order.
Switches reception
band.
Increases and decreases volume (in all modes).
Moves preset
channels up and
down.
No function.
Moves tracks up and down.
When pressed and held for 1 second:
Fast-forward/fast-backward.
Switches between playback and pause.
Moves preset
channels up and
down.
No function.
Tu r ns mute on and off.
Recalls ISR radio station in memory.
Press and hold for 2 seconds or longer: Stores current station into ISR memory (radio mode only).
Press and hold the button for 1 second or longer to switch the main and sub zone sound
source.(only while 2-ZONE mode on)
Switches among main display, clock display.
Press and hold for 1 second or longer to turn on or off the 2-ZONE mode.
Press to switch the control zone between main zone or sub zone while 2-ZONE mode on.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
No function.
No function.
Scan play.
Press and hold the
button for 1 second
or longer to perform
folder scan play while
in the MP3/WMA
mode.
Repeat play.
Press and hold the
button for 1 second
or longer to perform
folder Repeat play
while in the
MP3/WMA mode.
Random play.
Press and hold the
button for 1 second
or longer to perform
folder Random play
while in the
MP3/WMA mode.
Scan play.
When pressed and
held for 1 second:
Disc scan play.
Repeat play.
When pressed and
held for 1 second:
Disc repeat play.
Random play.
When pressed and
held for 1 second:
Disc random play.
Preset scan.
When pressed and
held for 2 seconds:
Auto store.
No function.
Switches between TV
and VTR.
∗Some of the corresponding buttons on the main unit and remote control unit have different functions.
+DXZ545MP-009-ENG 11/5/03, 5:01 PM11

12 DXZ545MP
280-8005-00
English
7. OPERATIONS
Basic Operations Note:Be sure to read this chapter referring to the front diagrams of
chapter “3. CONTROLS” on page 5 (unfold).
CAUTION
Be sure to lower the volume before switch-
ing off the unit power or the ignition key. The
unit remembers its last volume setting. If you
switch the power off with the volume up,
when you switch the power back on, the sud-
den loud volume may hurt your hearing and
damage the unit.
Turning on/off the power
Note:
•Be careful about using this unit for a long time
without running the engine. If you drain the car’s
battery too far, you may not be able to start the
engine and this can reduce the service life of the
battery.
1. Press the [FNC] button.
2. The illumination and display on the unit light
up. The unit automatically remembers its last
operation mode and will automatically switch
to display that mode.
3. Press and hold the [FNC] button for 1 second
or longer to turn off the power for the unit.
Note:
•System check
The first time this unit is turned on after the wire
connections are completed, it must be checked
what equipment is connected. When the power is
turned on, “SYSTEM CHK” and “Push POWER”
appear in the display alternately, so press the
[FNC] button. The system check starts within the
unit. When the system check is complete, press
the [FNC] button again.
Selecting a mode
1. Press the [FNC] button to change the opera-
tion mode.
2. Each time you press the [FNC] button, the
operation mode changes in the following or-
der:
Radio mode ➜SIRIUS mode ➜CD/MP3/
WMA mode ➜CD changer mode ➜DVD
changer mode ➜TV mode ➜AUX mode ➜
Radio mode...
∗External equipment not connected with
CeNET is not displayed.
Adjusting the volume
Tu r ning the [ROTARY] knob clockwise increases
the volume; turning it counterclockwise de-
creases the volume.
∗The volume level is from 0 (minimum) to 33 (maxi-
mum).
Switching the display
Press the [DISP] button to select the desired dis-
play.
Each time you press the [DISP] button, the dis-
play switches in the following order:
Main display ➜Clock display ➜Main display ...
∗Once selected, the preferred display becomes
the display default. When a function adjust-
ment such as volume is made, the screen will
momentarily switch to that function’s display,
then revert back to the preferred display sev-
eral seconds after the adjustment.
∗When you have entered a title in a CD, it ap-
pears in the main display. If you have not en-
tered a title, “NO TITLE” appears in the title
display instead. For information on how to en-
ter a title, refer to the subsection “Entering
titles” in section “Operations Common to
Each Mode”.
Setting the Z-Enhancer Plus
This unit are provided with 4 types of sound tone ef-
fects stored in memory. Select the one you prefer.
∗The factory default setting is “Z+ OFF”.
Each time you press the [Z+] button, the tone ef-
fect changes in the following order:
“Z+ OFF” ➜“BASS BOOST” ➜“IMPACT” ➜
“EXCITE” ➜“CUSTOM” ➜“Z+ OFF” ...
• BASS BOOST : bass emphasized
• IMPACT : bass and treble empha-
sized
• EXCITE : bass and treble empha-
sized mid de-emphasized
• CUSTOM : user custom
• Z+ OFF : no sound effect
Adjusting the Z-Enhancer Plus
1. Press the [Z+] button and select the Z-En-
hancer Plus mode to adjust.
+DXZ545MP-009-ENG 11/5/03, 5:01 PM12

280-8005-00
DXZ545MP 13
English
2. Press the [A-M] button and turning the
[ROTARY] knob clockwise adjusts in the +
direction; tuning it counterclockwise adjusts
in the – direction.
●When “B-BOOST 0” selected, you can ad-
just the bass in the range of –3 to 3.
●When “IMPACT 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
●When “EXCITE 0” selected, you can adjust
the bass and treble in the range of –3 to 3.
∗When Z-Enhancer Plus is selected, press and
hold the [Z+] button for 1 second or longer to
change to the “CUSTOM” mode.
Bass/treble characteristics become flat and
the indication “Z+ FLAT” is shown in the dis-
play.
Adjusting the tone
Press the [A-M] button and select the item to
adjust. Each time you press the [A-M] button,
the item changes as following order:
●When “BASS BOOST” is set
“SW-VOL 0” ➜“B-BOOST 0” ➜“BAL 0” ➜
“FADER 0” ➜Last function mode.
●When “IMPACT” is set
“SW-VOL 0” ➜“IMPACT 0” ➜“BAL 0” ➜
“FADER 0” ➜Last function mode.
●When “EXCITE” is set
“SW-VOL 0” ➜“EXCITE 0” ➜“BAL 0” ➜
“FADER 0” ➜Last function mode.
●When “CUSTOM” is set
“SW-VOL 0” ➜“BASS” ➜“TREBLE” ➜
“BAL 0” ➜“FADER 0” ➜Last function
mode.
●When “Z+ OFF” is set
“SW-VOL 0” ➜“BAL 0” ➜“FADER 0” ➜
Last function mode.
∗If subwoofer is effective, “SW-VOL 0” can be se-
lected.
Adjusting the subwoofer
When you default select one of mode (LPF50,
LPF80, LPF120)
1. Press the [A-M] button and select
“SW-VOL 0”.
2. Turning the [ROTARY] knob clockwise or
counterclockwise to adjust the subwoofer
volume.
∗The factory default setting is “SW-VOL 0”.
(Adjustment range: -6 to +6)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “BASS”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the bass; turning it counterclock-
wise attenuates the bass.
∗The factory default setting is “BÅÅ
ÅÅ
ÅGAIN 0ÎÎ
ÎÎ
Δ.
(Adjustment range: –6 to +8)
3. Press the [a] or [d] button to select
“BÅÅ
ÅÅ
ÅFREQ 50ÎÎ
ÎÎ
Δ.
Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗The factory default setting is “BÅÅ
ÅÅ
ÅFREQ 50ÎÎ
ÎÎ
Δ.
(Adjustment 50/80/120 Hz)
4. Press the [a] or [d] button to select “B
ÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Î
”.
Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the Q-curve.
∗The factory default setting is “BÅÅ
ÅÅ
Å
Q 1
ÎÎ
ÎÎ
Δ.
(Adjustment 1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can be performed when the Z-
Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “TREBLE”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the treble; turning it counterclock-
wise attenuates the treble.
∗The factory default setting is “TÅÅ
ÅÅ
ÅGAIN 0ÎÎ
ÎÎ
Δ.
(Adjustment range: –6 to +6)
3. Press the [a] or [d] button to select
“TÅÅ
ÅÅ
ÅFREQ 12kÎÎ
ÎÎ
Δ.
Tur ning the [ROTARY] knob clockwise or
counterclockwise to select the frequency.
∗The factory default setting is “TÅÅ
ÅÅ
ÅFREQ 12kÎÎ
ÎÎ
Δ.
(Adjustment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Basic Operations
+DXZ545MP-009-ENG 11/5/03, 5:01 PM13

14 DXZ545MP
280-8005-00
English
Radio Operations
FM reception
For enhanced FM performance the
®
tuner includes signal actuated stereo control,
Enhanced Multi AGC, Impulse noise reduction
curcuits and Multipath noise reduction circuits.
Listening to the radio
1. Press the [FNC] button and select the radio
mode. The frequency appears in the display.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the ra-
dio reception band changes in the following
order:
FM1 ➜FM2 ➜FM3 ➜AM ➜FM1...
3. Press the [a] or [d] button to tune in the
desired station.
Tuning
There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the de-
sired band (FM or AM).
∗If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek tun-
ing is now available.
2. Press the [a] or [d] button to automatically
seek a station.
When the [d] button is pressed, the station is
sought in the direction of higher frequencies; if
the [a] button is pressed, the station is sought
in the direction of lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the fre-
quency changes one step at a time. In the quick
tuning mode, you can quickly tune the desired
frequency.
1. Press the [BND] button and select the de-
sired band (FM or AM).
∗If “MANU” is not lit in the display, press and
hold the [BND] button for 1 second or longer.
“MANU” is lit in the display and manual tuning
is now available.
2. Tune into a station.
Basic Operations
Adjusting the balance
1. Press the [A-M] button and select “BAL 0”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the sound from the right speaker;
turning it counterclockwise emphasizes the
sound from the left speaker.
∗The factory default setting is “BAL 0”. (Adjust-
ment range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the fader
1. Press the [A-M] button and select “FADER 0”.
2. Turning the [ROTARY] knob clockwise em-
phasizes the sound from the front speakers;
turning it counterclockwise emphasizes the
sound from the rear speakers.
∗The factory default setting is “FADER 0”. (Ad-
justment range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound ad-
justment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
∗The factory default setting is off.
1. Press and hold the [A-M] button for 1 sec-
ond or longer to turn on the MAGNA BASS
EXTEND effect. “M-B EX” lights in the dis-
play.
2. Press and hold the [A-M] button for 1 second
or longer to turn off the MAGNA BASS EX-
TEND effect. “M-B EX” goes off from the dis-
play.
+DXZ545MP-009-ENG 11/5/03, 5:01 PM14
