Classique CL7FLWD1 User manual

CL7FLWD1

Safety Instructions
Safety Instructions ..................................................
Installation
Product Description ................................................
Installation ...........................................................
Operations
Quick Start .............................................................
Before Each Washing ..............................................
Detergent Dispenser ...............................................
Control Panel .........................................................
Option....................................................................
Other Functions ......................................................
Programmes.............................................................
Washing Programmes Table .....................................
Maintenances
Cleaning And Care .................................................
Trouble Shooting ....................................................
Technical Specifications .........................................
Testing methods .....................................................
2
9
10
13
14
15
16
17
19
22
23
24
27
28
29
1
CONTENTS

For your safety,the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
Explanation of the symbols:
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• If the supply cord is damaged, it must be replaced by the
Risk of Electric Shock!
2
SAFETY INSTRUCTIONS
Safety Instructions
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
Warning!
！
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Caution!
Warning!
！

3
• The new hose supplied with the appliance must be used
and any old hoses should be discarded.
• Before any maintenance on the device, unplug the
appliance from the mains.
• Always have the installation procedures carried out by
a competent and authorized person. The manufacturer
shall not be held liable for damages that may arise from
procedures carried out by unauthorized persons.
•
• Do not use any socket with a rated current less than that
of the appliance. Never pull out the power plug with wet
hands.
• Check carefully and make sure that your socket is
properly and reliably earthed.
• Make sure that the water and all electrical devices are
connected in accordance with the manufacturer's
instructions and local safety regulations.
The product should be unplugged from the power socket
during installation, before cleaning or maintenance and
when not in use.
Risk to children!
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children of less than 8 years should be supervised to
ensure that they do not play with appliance.
SAFETY INSTRUCTIONS

• Animals and children may climb into the machine. Check
the product before every operation.
• The glass door may become very hot during some wash
cycles and during the drying process. Make sure to keep
kids and pets far away from the machine during the
operation as well as away from rooms with explosive or
caustic gas.
• Important! Remove all packaging and transport bolts
before using the appliance. Otherwise, serious damage
may result!
Risk of explosion!
• Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances( such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in
fire or explosion.
.
• The washer dryer shouldn't be used if chemicals have
been used
• The exhaust air must not be discharged into a flue which is
also used for exhausting fumes from appliances, burning
gas or other fuels.
Installing the product!
4
• This appliance is for indoor use only and is not intended
to be built-in.
• A carpet must not obstruct the openings.
SAFETY INSTRUCTIONS
Caution!

5
• The appliance should not be installed in bathrooms, very
wet rooms or in rooms that may contain explosive or
caustic gases.
• Check to see if your appliance has a single inlet valve,
this can only can be connected to the cold water supply.
If the appliance has a double inlet valves then it should
be correctly connected to the hot water and cold water
supply.
• Please note: The plug must be accessible after installation
• The appliance must not be installed behind a lockable
door, a sliding door or a door with a hinge on the opposite
side to that of the washer dryer.
• The appliance shall not be installed at a humid place.
Risk of damaging appliance!
• This appliance is design for domestic use only. It is not
suitable for commercial use.
• This appliance designed for use with textiles marked as
suitable for machine washing, rinsing and drying of textile
products marked accordingly.
• Do not climb up and sit on top cover of the appliance.
• Do not lean against machine door.
• When transporting or handling the appliance make sure:
a)That the transport bolts have been reinstalled into the
machine by an authorized person.
b)Make sure that any water that has accumulated in the
machine has been drained out.
c)Please handle the appliance carefully. Never hold any
protruding part of the product whilst lifting and the door
cannot be used to handle or lift the appliance when
moving it.
SAFETY INSTRUCTIONS

6
d)This appliance is heavy. Transport with care.
e)That you do not place hands into any running water
extracting tub.
f)Please do not close the door with excessive forces. If it
is found difficult to close the door, please check if the
clothes are put in or distributed well.
• This appliance is not designed to wash carpets
Operating the appliance!
• Before washing the clothes for the first time, the appliance
should be operated for one cycle with no clothes in it.
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc. are not to be used as detergents.
Please only select the detergents suitable for machine
washing.
• Make sure that all pockets are emptied. Sharp and rigid
items such as coins, brooches, nails, screws or stones etc.
may cause serious damages to this machine.
• Please check whether the water inside the drum has
been drained before opening its door. Please do not
open the door if there is any water visible.
• Be careful not to burn yourself if you are draining hot
washing water from the appliance.
• Never refill the water by hand during washing or drying.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products must be washed in the appliance,they should
first be washed in hot water with extra detergent , this
will reduce, but not eliminate, any potential hazards.
SAFETY INSTRUCTIONS

7
• Adequate ventilation has to be provided and avoid the
back flow of gases into the room from appliances
burning other fuels, including open fires.
• Do not dry unwashed items in the appliance.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers,turpentine,waxes and wax removers should be
washed in hot water first with an extra amount of
detergent before being dried in the appliance.
• Items such as foam rubber (latex foam), shower caps,
water proof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the machine.
• Fabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
• The final part of a washer dryer cycle occurs without
heat (cool down cycle) to ensure that the items are left
at a temperature that ensures that the items will not be
damaged.
• Remove all objects from pockets such as lighters and
matches before use the appliance.
• WARNING: Never stop a washer dryer before the end of
the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
SAFETY INSTRUCTIONS

This marking indicates that this product should not be
disposed with other household wastes throughout the
EU.To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of
material resources.To return your used device, please use
the collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.
Packaging/Old appliance
8
SAFETY INSTRUCTIONS

9
INSTALLATION
Accessories
Product Description
Transport
plughole
Supply hose hot
water (optional)
Supply hose
cold water
Drain hose
(optional
support
)
• The product line chart is for reference only, please refer to real product as
standard.
Note!
Drum
Power supply cord
Control panel
Detergent dispenser
Service filter
Door
Water supply hose
Top cover
Drain hose
Owner’s manual

10
Installation
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0℃
5.Keep far away from the heat resources such as coal or gas.
as
Unpacking the washer dryer
1. Remove the cardboard box and styrofoam packing.
2. Lift the washer dryer and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Stop the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Remove transport bolts
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
！
•
•
Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
Warning!
！
•
• product
you
You must remove the transport bolts from the backside before using the product.
You’ll need the transport bolts again if you move the , so make sure
keep them in a safe place.
Warning!
！
INSTALLATION
w
w
W> 20mm
Installation area

9
11
1.Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions tighten the nuts.
2.Loosen the lock nut turn the feet until it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Levelling the washer dryer
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Supply Hose
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1.Connection between ordinary tap and inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter
Do not kink, crush, modify or sever .
!
• water inlet hose
• For the model equips hot valve,connect it to hot water tap with hot water supply
hose. Energy consumption will decrease automatically for some program.
234 1
Raise Lower
Lock nut
foot
Warning!
！
Warning!
！
INSTALLATION
Loosen clamp nut and
four bolts
Tighten clamp nut Press slide bushing,
insert inlet hose into
connecting base
slide bushing
2341
Connection finished
clamp nut
Tap with threads and inlet hose Special tap for washing machine
2.Connection between screw tap and inlet hose.
slide bushing

10
12
Warning!
！
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Min.60cm
100cm
Max.
Trough
Hose Retainer
Bind
Max.100cm
Min.60cm
Min.60cm
Max.100cm
If the machine has • drain hose support, please install it like the following .
Warning!
！Warning! ！
Note!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.

10
13
Before using, please make sure the appliance is installed properly.
Before washing the clothes for the first time, the appliance should be operated
for one cycle with no clothes in it.
•
•
1. Before Washing
Buzzer beep or “End” on display.
Open tap
Load
Close door
Plug in
Add detergent
II
Main wash
Prewash
I
Softener
Quick Start
3. After Washing
• Detergent only need to be added in "case I “after selecting pre-washing for
product with this function.
1 2 3 4 5
2. Washing
Power On
Select Programme Select function or
default
Start up
1 2 3 4
• 1.
2.The function button line chart is for reference only, please refer to real product
as standard.
If default is selected, step 3 can be skipped.
Note!
Note!
Caution!
OPERATIONS

10
14
Knot the long strips,zip or
button
• Washing single items of clothes may cause an imbalance when the drum
rotates, especially during the spin cycle, which may cause the appliance to
shudder. To avoid this, it is suggested multiple items of clothing to be washed
together.
• Do not wash or dry clothes which have been exposed to kerosene, gasoline,
alcohol and other flammable materials
• The working condition of the washer should be(0-40)℃.If used under 0℃,the
inlet valve and draining system may be damaged. If the machine is placed under
condition of 0℃or less, then it should be transferred to normal ambient
temperature to ensure the water supply hose and drain hose are not frozen
before use.
• Please check the labels and the explanation of using detergent before wash. Use
non-foaming or less-foaming detergent suitable for machine washing properly.
Take out the items out of
the pockets
Put small clothes into the
pillow slip
Check the label
Before Each Washing
Turn easy-pilling and
long-pile fabric inside out
Separate clothes with
different textures
Warning!
！
OPERATIONS

10
15
Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
II
I
Pull out the dispenser
Liquid detergent Powder detergent
Caution!
• Detergent only need to be added in "case I “after selecting pre-washing
for machines with this function.
OPERATIONS
Dam-board Dam-board
Programme
Cotton ECO
Sport Wear
Quick
Delicate
Wool
Colours
Jeans
Spin Only
Programme
Rinse&Spin
Dry Only
Mix
Baby Care
Synthetic
Cotton
1Hour W/D
Model:CL7FLWD1
=Required ○ =optional
• If you are using a thick or gelatinous detergent or additive, before they are
added into the detergent box, it is suggested to use water to dilute the
detergent, to prevent the inlet of the detergent box from being blocked and
overflowing while filling with water.
• Please make sure you choose a suitable type of detergent for the various
washing temperature to get the best washing performance with less water
and energy consumption.
Note!

10
16
1
1
1
2
4 3
1
5
On/Off
Product is switched on or off.
Start/Pause
Press the button to start or pause the
washing cycle.
Programmes
Available according to the laundry type.
Option
This allows you to select an additional
function and will light when selected.
1
1
3
1
2
4
Display
The display shows the settings, estimated time remaining, options, and status messages
for your washer. The display will remain on through the cycle.
5
RB
A
K
MLJ
C
D
O
P
Mute the buzzer
J
Remain
A
Speed Wash
D
Extra Rinse
E
Pre Wash
F
Soak
I
Anti-crease
H
Extra Wash
G
Reload
K
Wash Time Delay Time
Error End
Q
Child Lock
L
E
F
G
I H
MDoor Lock
NSpin Speed
N
Model:CL7FLWD1
Q
Delay
B
Dry level(Extra Dry-Normal Dry-Gentle
Dry-Air Dry)
C
OTemp.
Rate Of Progress(Pre wash- Wash
-Rinse-Spin)
P
OPERATIONS
Note!
Programmes with the Speed Wash symbol can be used with the Speed
Wash function
•
Colours

10
17
OPERATIONS
Pre Wash
The Prewash function can get an extra wash before main wash,it is suitable for
washing the dust rises to surface of the clothes;You need to put detergent into
the Case (I) when select it.
Extra Rinse
The laundry will undergo extra rinse once after you select it.
Speed Wash
The function can decrease the washing time.
Option
Delay
Set the Delay function:
1. Select a programme
2.Press the Delay button to choose the time(the delaying time is 0-24 H.)
3.Press [Start/Pause] to commence the delay operation
Choose the Programme Start
On/Off Setting time
Delay
Cancel the Delay function:
Press the [Delay] button until the display be 0H.It should be pressed before
starting the programme. If the programme already started, should press the
[On/Off] button to reset the programme.
Caution!
• If there is any break in the power supply while the machine is operating, a
special memory stores the selected programme and when the power is
restarted, press the [On/Off]button the program is continues.
Extra Wash
For use with very dirty clothes. The Extra Wash Function will increase the washing
time and intensity to provide an intense washing effect.
Anti-Crease
It can be used to reduce the wrinkles of clothes.
Soak
When water reaches the target level,sock for 20 minutes and then the motor do
not rotate.
/

10
18
OPERATIONS
Programme Option Programme Option
Rinse&Spin
Dry Only
Mix
Baby Care
Synthetic
Cotton
1Hour W/D
Cotton ECO
Sport Wear
Quick
Delicate
Wool
Colours
Jeans
Spin Only
Anti-
crease
Speed
wash Extra
rinse
Delay
Extra
wash
Model:CL7FLWD1
Soak Anti-
crease
Speed
wash Extra
rinse
Delay
Extra
wash Soak
○ =optional

10
19
My Cycle
Programmes the machine to memorise frequently used programmes.
Press [Spin]([Dry]/[Temp.]) 3sec. to memorise the running programme. The
default is cotton.
• Don't use the Reload function when the water level is over the edge of the
inner tub or the temperature is higher.
Reload
This operation can be executed during the washing progress. When the drum is
still rolling and there is large amount of water with high temperature in the drum.
The state is unsafe and the door cannot be opened forcefully. To press
[Start/Pause] for 3 sec. to reload, and start the clothes adding in the midway
function. Please follow the steps as bellow:
1.Wait until the drum stops rotation.
2.The door lock is unlocked.
3.Close the door when the clothes are reloaded and press the [Start/Pause]
button.
Start
P 3sress[Start/Pause]ec.
Clothes
Reload the clothes
Caution!
Other functions
( )
OPERATIONS
Spin
Press the button to change the spin speed.
1400: 0-600-800-1000-1200-1400
• When the lights of spin speed (600,800,1000,1200,1400) are off, it means
the spin speed is 0.
Caution!
Temp.
℃,Press the button to change the temperature(Cold,20 30℃, 40℃,60℃,90℃)
