1
Do not use unless all screws are tight. At least every six months, check all screws to be sure
they are tight. If parts are missing, broken, damaged, or worn, stop use of the product
until repairs are made by your dealer using factory authorized parts.
#34552 Circulation Chair
Don’t Sweat ItTM
The productyouhavepurchasedisguaranteedagainstmaterialandworkmanshipdefects. This
guaranteeextends1yearfromdateofpurchase. Shouldthisproductfailtofunction satisfactorily under normal
usedueto defect or imperfection,thedefective part or productwillbe replaced. Damage caused bycommon
carriersduringshipmentisnotincludedinthisguarantee.
This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed
orimpliedshallapply. Failuretofollowinstructionsfound inImportantInformationSectionof Owner
Sheetshall void theguarantee. Consequential orincidentaldamages andor costs arenot refundable.
Important
Important

2
#34552 Circulation Chair
Don’t Sweat It
34552 _3-25-14
TM
A
H
G
F
E
D
B
CA Chair Back 1 EA
B Backpost Plug 2 EA
C Back Push Pin 4 EA
D SeatAssembly 1 EA
E Lever Control 1 EA
F Lock Washer 4 EA
G Bolt 4 EA
H Cylinder Cover 1 EA
I Pneumatic Cylinder 1 EA
J Base 1 EA
K Caster 5 EA
Part Drawing Description Qnty
Part / Hardware List
1.
2.
3.
4.
5.
6.
7.
8.
SeperateandIdentify allparts.
Place Chair Back (A) on backpost tubes of SeatAssembly (D).
Alignholes in ChairBack with holes in the backpost tubes and insert 4
BackPush Pins(C) into the holes.
Boltthe LeverControl (E) to the bottomof theSeatAssembly (D) using4 Bolts(G)
with4 LockWashers (F).
Pushin 5 Casters (K) into the holes inthe bottom ofBase (J).
InsertthePneumatic Cylinder (I)intothe Base(J).
SlidetheCylinder Cover(H)down thePneumaticCylinder (I).
Placethe Seatand Backassembly fromStep#4 ontothe PneumaticCylinder (I).
Assembly Instructions
I
J
K
