CMX CD-6900-DM3 User manual

WARNING: To reduce
the risk of electric shock, do
not remove cover (or back).
No user-serviceable
parts inside. Refer
servicing to qualified
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation
point within the
triangle is a warning
sign alerting you of
important instructions
accompanying the
product.
The lightning flash
and arrowhead
within the triangle
is a warning
sign alerting you of
"dangerous voltage"
inside the product.
CAUTION
DO NOT EXPOSE TO DRIPPING OR SPLASHING LIQUIDS!
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS.
E-2
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LASER DE CLASSE
LASER DI PRIMA CLASSE
KLASSE 1 LASER
LASER PRIMERA CLASE
LASER CLASSE 1
KLASSE 1 LASER PRODUKT
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
VORSICHT: UNSICHTBARE LASERSTRAHLUNG TRITT AUS,
WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG
ÜBERBRÜCKT IST. NICHT DEM STRAHL AUSSETZENI.
VARNING: OSYNLIG LASERSTRÁLNING NÄR DENNA DEL ÄR ÖPPNAD OCH
SPÄRR ÄR URKOPPLAND. STRÁLEN ÄR FARLIG.
ADVARSEL: USYNLIG LASERSTRÁLING VED ÁBNING. NÁR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÁ UDS/ETTELSE FOR
STRÁLING.
ATTNENZIONE: RADIONS LASER INVISIDILE. NON GUARDARE
DIRETTAMENTE NELLA SORGENTE DEL LASER.
ACHTUNG: LASERLINSE NICHT BERÜHREN UNSICHTBARER LASERSTRAHL.
AVISO: A LENTE NUNCA DEVE SER TOCADA.
CAUTION: GROUNDING OR POLARIZATION. THE PRECAUTIONS
SHOULD BE TAKEN SO THAT THE WIDER BLADE OF THE AC PLUG
MUST MATCH THE SLOT IN RECEPTACLE "WALL SOCKET".
S-BASS
SUPER BASS
BOOSTER
MP3-CD-RADIO
WITH DIGITAL DISPLAY AM/FM TUNER
OPERATING INSTRUCTIONS
MODEL : CD-6900-DM3
6-WAY
SPEAKER
SYSTEM
DIGITAL
PLAYBACK
MP3

THE BUILT IN "SUPER BASS BOOSTER" CIRCUIT PROVIDES A POWERFUL
ENHANCEMENT TO LOW FREQUENCY MUSIC, GIVING A STRONGER BASS
SOUND WHICH IS IDEAL FOR "ROCK" OR "JAZZ" MUSIC.
SUPER BASS FUNCTION
POWER SUPPLY
BATTERY OPERATION
- OPEN THE BATTERY DOOR AND INSERT 6 PCS "C-CELL" (UM-2/ LR14 TYPE)
BATTERIES. PLEASE OBSERVE CORRECT BATTERY POLARITIES OR THE SET
WILL NOT WORK.
- IMPORTANT: WHEN THE SET IS ONLY USED WITH AC, OR IS NOT USED FOR
4 WEEKS OR MORE, PLEASE REMOVE THE BATTERIES, TO AVOID DAMAGE TO
THE SET FROM LEAKAGE OF BATTERIES.
E-4
AC OPERATION (BUILT-IN TRANSFORMER)
- MAKE SURE THE SET VOLTAGE OF THE UNIT MATCHES YOUR LOCAL
HOUSEHOLD VOLTAGE.
- THE AC-CORD IS LOCATED INSIDE THE BATTERY COMPARTMENT.
- INSERT THE PLUG OF THE AC-CORD INTO A WALL OUTLET WITH AC-POWER.
OPERATION OF RADIO
- SET THE FUNCTION SWITCH TO "RADIO" AND THE BAND SELECTOR SWITCH TO
THE DESIRED BAND.
- ROTATE TUNING KNOB TO TUNE-IN THE DESIRED STATION. AS DISPLAYED IN
THE LCD DIGITAL DISPLAY.
- ADJUST THE TELESCOPIC ANTENNA AND POSITION OF THE SET TO OBTAIN THE
BEST RECEPTION.
- ADJUST THE VOLUME KNOB TO THE DESIRED LEVEL.
- TO TURN OFF THE RADIO, SLIDE THE FUNCTION SWITCH TO "OFF" POSITION.
UM-2/"C"/LR14
(1.5V) SIZE x 6 PCS.
3
2
LOCATION OF CONTROLS
E-3
1. AC POWER CORD AND PLUG
2. TELESCOPIC ANTENNA
3. HANDLE
4. CD DOOR
5. CD DOOR FINGER GRIP
6. RADIO TUNING CONTROL KNOB
7. RADIO BAND SELECTOR SWITCH
8. FUNCTION SWITCH
[RADIO/ CD (MP3)/ OFF]
9. CD “PLAY” BUTTON
10. CD”NEXT” BUTTON
11. CD “BACK” BUTTON
12. VOLUME (+) BUTTON
13. SUPER BASS ON/ OFF SWITCH
14. VOLUME (-) BUTTON
15. “FM-STEREO” LED-LIGHT
16. SKIP + 10/ FOLDER BUTTON
17. CD “REPEAT/ PROGRAM” BUTTON
18. CD “STOP” BUTTON
19. MAIN SPEAKER (LEFT & RIGHT)
20. “DBBS” LED-LIGHT
21. TOP SPEAKER (LEFT & RIGHT)
22. CD/ RADIO DIGITAL DISPLAY
23. HEADPHONE (EARPHONE) SOCKET
(REAR OF UNIT)
24. BATTERY DOOR COMPARTMENT
(UNDER THE UNIT)
1
24 23
4
5
6
7
8
9
10
11
17
16
15
21
20
19 19
21
22
12
14
13
18

E-6
E-5
INSERTION & REMOVAL OF DISCS
- WHEN OPENING THE CD-DOOR, ALWAYS ENSURE THE DISC IS NOT IN MOTION
(NOT SPINNING) WHEN YOU OPEN THE CD-DOOR. ALWAYS PRESS "STOP"
BUTTON TO STOP THE DISC SPINNING FIRST.
- PLACE A CD INTO THE COMPARTMENT WITH THE LABEL-SIDE (PRINTED SIDE
OF DISC) FACING UPWARDS. PRESS DOWN IN THE CENTER PART OF DISC UNTIL
THE DISC "LOCKS" ONTO THE CENTER SPINDLE.
- WHEN THE CD HAS BEEN PLACED ONTO THE CENTER SPINDLE, GENTLY
LOWER THE CD-DOOR DOWNWARDS UNTIL IT LOCKS SHUT.
- THE CD IS NOW READY TO BE PLAYED.
- TO REMOVE A DISC, FOLLOW THE SAME PROCEDURE AS DESCRIBED ABOVE,
EXCEPT TO REMOVE THE CD INSTEAD OF INSERTING IT INTO THE
COMPARTMENT, BY PLACING ONE FINGER AT THE MIDDLE OF DISC
(CENTER SPINDLE) & THE OTHER AT THE EDGE OF THE DISC & GENTLY
PULLING UPWARDS.
- IMPORTANT : ALWAYS HOLD A CD BY ITS EDGES. AVOID GETTING ANY
FINGER PRINTS, SMUDGES OR DIRT ONTO THE SURFACE OF A DISC. IN CASE
THIS HAPPENS, USE A SPECIAL CD-CLEANING CLOTH OR CLEANING KIT TO
REMOVE THE DIRT OR SMUDGES.
NORMAL CD OPERATION
- INSERT A CD AS DESCRIBED.
- SLIDE THE FUNCTION SWITCH TO "CD".
- THE CD WILL SPIN MOMENTARILY AND THEN THE DISPLAY WILL SHOW THE
TOTAL NUMBER OF TRACKS (SONGS) OF THE DISC.
- PRESS THE PLAY/PAUSE BUTTON . THE DISC WILL START SPINNING
& THE FIRST SONG (TRACK) WILL START PLAYING. THE DISPLAY WILL INDICATE
THE CURRENT TRACK NO. ("1" IF IT IS THE FIRST TRACK).
- AT ANYTIME DURING PLAYBACK, PRESS THE "STOP" BUTTON TO STOP
OPERATION OF THE SET. THIS WILL RESET THE CD PLAYER TO THE FIRST
TRACK (IF YOU PRESS PLAY AFTER STOP, THE FIRST TRACK WILL ALWAYS
START PLAYING).
- AT ANYTIME DURING PLAYBACK, PRESS THE "PLAY/PAUSE" BUTTON
TO PAUSE OPERATION OF THE UNIT. PRESS PLAY/PAUSE BUTTON TO RESUME
OPERATION AT THE SAME TRACK & POSITION.
- AT ANYTIME DURING PLAYBACK, "PRESS AND RELEASE" THE BACK/NEXT
BUTTONS : OR TO SKIP BACKWARDS OR FORWARDS BY ONE
TRACK, AS DESIRED.
- AT ANYTIME DURING PLAYBACK, "PRESS AND HOLD" THE BACK/NEXT
BUTTONS : OR TO FAST-REVERSE (REVIEW) OR FAST-FORWARD
(CUE) THE SPECIFIC TRACK, WHICH IS CURRENTLY PLAYING.
- AT ANYTIME DURING PLAYBACK, PRESS THE "CD REPEAT BUTTON" AS
FOLLOWS:
PRESS ONCE = DISPLAY IS FLASHING,
PRESS TWICE =
TO REPEAT THE CURRENT TRACK
TO REPEAT ALL TRACKS (FULL CD)
PROGRAMMING THE CD PLAYER
- THE CD PLAYER CAN BE PROGRAMMED TO PLAY ANY SEQUENCE OF UP TO
20 TRACKS, AS DESIRED.
- ALWAYS PRESS THE STOP SWITCH BEFORE STARTING THE PROGRAMMING.
- PRESS THE PROGRAM BUTTON ,THE DISPLAY WILL SHOW "P01" AND THE
"PROGRAM"SYMBOL WILL BE SHOWN, TO INDICATE THAT THE SET IS NOW IN
"MEMORY PROGRAMMING MODE", AT THE FIRST MEMORY POSITION.
- REPEAT THE PREVIOUS 2 STEPS, EACH TIME SELECTING ANY TRACK NUMBER
OF YOUR CHOICE TO BE STORED IN THE SUCCESSIVE MEMORY (PROGRAM)
POSITIONS.
- WHEN YOU PRESS THE DISPLAY WILL ADVANCE TO
THE NEXT MEMORY POSITION (eg. "P02").
THE PROGRAM BUTTON
- PRESS THE BACK/NEXT SWITCHES OR TO SELECT THE TRACK (SONG)
NUMBER YOU WISH TO BE STORED IN THE FIRST MEMORY (PROGRAM)
POSITION, AND PRESS THE PROGRAM BUTTON TO CONFIRM YOUR SELECTION.
- AFTER EACH TRACK NUMBER, REMEMBER TO PRESS THE PROGRAM BUTTON.
- AFTER A MAXIMUM OF 20 SONGS (OR LESS) HAVE BEEN SELECTED AS
DESCRIBED ABOVE, PRESS THE PLAY BUTTON.
P
HOW TO PLAY MP3 DISCS
- INSERT A MP3 CD DISC, CLOSE THE DOOR.
- SLIDE THE FUNCTION SWITCH TO CD (MP3) POSITION.
- THE DISK WILL SPIN AND PERFORM A FULL CHECK OF THE DISC TO COUNT THE TOTAL
NUMBER OF SONGS. THEN PLAYBACK OF THE FIRST SONG (TRACK) WILL BEGIN AND
THE DISPLAY WILL INDICATE THE CURRENT TRACK NO: (001).
- AT ANY TIME DURING PLAYBACK, PRESS AND RELEASE OR TO SKIP
BACKWARDS OR FORWARDS BY ONE TRACK.
- MP3 DISCS OFTEN HAVE “FOLDER” (SUB-DIRECTORIES) WHICH CONTAIN GROUPS
OF SONGS.
- IF YOUR MP3-CD HAS NO FOLDERS, YOU CAN USE THE BUTTON TO
JUMP 10 SONGS AHEAD. THIS IS USEFUL IF YOU HAVE MANY SONGS ON YOU WANT TO
QUICKLY JUMP TO A PARTICULAR SONG.
- PRESS SEVERAL TIMES UNTIL YOU REACH A SONG NUMBER NEAR
TO YOUR DESIRED SONG, AND THEN PRESS "BACK" OR "NEXT" REPEATEDLY
TO ARRIVE AND THE EXACT SONG YOU DESIRE.
(NOTE: THE "SKIP +10" FUNCTION ONLY WORKS ON MP3-DISCS WHICH HAVE NO FOLDERS).
- IF YOUR MP3-CD HAS FOLDERS, YOU CAN SELECT THE FOLDER TO PLAYBACK BY
PRESSING THE BUTTON.
- EACH TIME YOU PRESS THE BUTTON, THE PLAYER JUMPS TO THE
FIRST SONG IN THE NEXT FOLDER.
(NOTE: THE "FOLDER" FUNCTION ONLY WORKS ON MP3-DISCS WHICH HAVE FOLDERS.
IF YOUR DISC HAS NO FOLDERS, PRESSING WILL PERFORM THE
"SKIP +10" FUNCTION).
SKIP + 10/ FOLDER
SKIP + 10/ FOLDER
SKIP + 10/ FOLDER
SKIP + 10/ FOLDER
SKIP + 10/ FOLDER

- THE "PROGRAM" SYMBOL WILL REMAIN "ON" TO INDICATE THAT YOU
HAVE SAVED A PROGRAM-MEMORY (SEQUENCE).
- PRESSING PLAY STARTS PLAY BACK OF THE "SAVED SEQUENCE" IN
THE PROGRAM MEMORY.
- TO CLEAR (CANCEL) THE ENTIRE PROGRAM WHICH IS STORED IN THE MEMORY,
SIMPLY PRESS "STOP" , OR SWITCH "OFF" THE SET.
(NOTE: THE "SKIP +10" & "FOLDER" FUNCTIONS ARE DISABLE DURING
"PROGRAMMING MODE".
P
E-8
POWER SUPPLY : ..................................... AC 230V , 50/60Hz
DC 9V (6 x C-CELL/ UM-2/ LR14 SIZE)
(BATTERIES NOT INCLUDED)
POWER CONSUMPTION : ........................ 15W
FREQUENCY : .......................................... AM 530 - 1600 kHz
FM 88 - 108 MHz
SPECIFICATIONS
~
- - -- - -
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING
AND NO OBJECTS FILLED WITH LIQUIDS SHOULD BE PLACED ON THE
APPARATUS.
THE MAINS PLUG IS USED AS THE DISCONNECT DEVICE
IMPORTANT
MP3 FILE NAME FORMAT
PLEASE TAKE CARE TO USE ONLY REGULAR ENGLISH
ALPHABETS (A TO Z) & NUMERALS (0 TO 9) IN THE
FILE NAMES OF MP3 SONGS. CHARACTERS SUCH AS
" _ " (UNDERSCORE) & " " (SPACE) MAY RESULT IN THE
FILES BEING UNREADABLE OR INCONSISTENTLY
UNRECOGNIZABLE BY THE PLAYER.
