Coleman CVW20HD TrekHD2 User manual

i
Table of Contents
About this manual.............................................................v
Copyright...........................................................................v
Precautions.......................................................................vi
Waterproof..................................................................... viii
Before You Start ............................................................. xii
Copyright information................................................... xii
1Introducing the camcorder........................1
1.1 System requirements...............................................1
1.2 Features..................................................................1
1.3 Unpacking the camcorder......................................2
1.4 About the camcorder..............................................3
1.4.1 Front view...................................................3
1.4.2 Top view .....................................................3
1.4.3 Bottom view................................................4
1.4.4 Right view...................................................4
1.4.5 Left view .....................................................5
1.4.6 Back view....................................................5
1.4.7 Operating the camcorder ..........................6
2Getting started............................................9
2.1 Inserting a memory card........................................9
2.2 Inserting the battery.............................................10
2.3 Charging the battery.............................................12
2.4 Turning on/ off the camcorder.............................12

ii
2.5 Connecting to TV (AV Cable)...............................13
2.6 Connecting to TV (HDMI Cable).........................13
2.7 Connecting to PC (USB Cable)............................14
2.8 Changing modes...................................................14
2.9 Before you start ....................................................14
2.9.1 Setting the date and time ........................15
2.9.2 Setting the language ................................15
2.9.3 Setting the beep........................................16
3Using the camcorder................................17
3.1 Recording videos ..................................................17
3.2 Video menu...........................................................20
3.2.1 White balance ...........................................21
3.2.2 Size.............................................................22
3.2.3 Effect..........................................................23
3.2.4 Quality.......................................................23
3.2.5 Stabilizer....................................................24
3.2.6 Video Light ...............................................24
3.2.7 EV...............................................................25
3.2.8 Traffic mode .............................................26
3.2.9 Motion detect............................................27
3.2.10 Date stamp................................................28
3.2.11 Pre-recording............................................28
3.2.12 Lapse video...............................................29
3.3 Playing videos.......................................................30
3.4 Video playback menu............................................32

iii
3.4.1 Delete one .................................................33
3.4.2 Delete all ...................................................34
3.4.3 Lock one ....................................................35
3.4.4 Lock all ......................................................36
3.4.5 Autoplay ...................................................37
3.5 Shooting photos....................................................38
3.6 Camera mode menu..............................................41
3.6.1 White balance ...........................................42
3.6.2 Size.............................................................43
3.6.3 Effect..........................................................43
3.6.4 Quality.......................................................44
3.6.5 Stabilizer....................................................45
3.6.6 Continuous Shooting...............................45
3.6.7 Selftimer ....................................................46
3.6.8 Date stamp................................................47
3.6.9 Face detection...........................................47
3.7 Viewing photos......................................................49
3.8 Photo playback menu...........................................51
3.8.1 Delete one .................................................52
3.8.2 Delete all ...................................................53
3.8.3 Lock one ....................................................54
3.8.4 Lock all ......................................................55
3.8.5 Slideshow..................................................56
3.8.6 DPOF one..................................................56
3.8.7 DPOF all....................................................57

iv
3.9 System menu.........................................................59
3.9.1 Language...................................................60
3.9.2 Date / Time ..............................................60
3.9.3 Format .......................................................60
3.9.4 Default.......................................................61
3.9.5 Auto power off.........................................61
3.9.6 Frequency..................................................62
3.9.7 TV standard ..............................................62
3.9.8 Beep ...........................................................63
3.9.9 Information...............................................63
3.9.10 HDMI standard........................................64
3.10 USB mode.............................................................65
3.10.1 Using the mass storage feature ..............65
3.10.2 Using the Direct Print (DPS) feature .....66
3.11 Diving mode..........................................................67
Appendix............................................................68
Specifications..................................................................68
Troubleshooting..............................................................70

v
Preface
Congratulations on your purchase of this advanced camcorder.
Ensure that you read this manual carefully and keep it in a safe
place for future reference.
About this manual
Every effort has been made to ensure that the contents of this
manual are correct and up to date. However, no guarantee is made
regarding the accuracy of the contents. If the contents of this
manual do not tally with the camera, please take the camera as a
criterion, and our company reserves the right to change the contents
or technical rules without notice in advance. Also, the manufacturer
reserves the right to change the technical specification in advance
without notice.
If the accessories do not tally with the actual package, please take
the actual package as a criterion.

vi
Precautions
General precautions
Do not use or store the product in dusty, dirty, or sandy areas,
as its components may be damaged.
Do not store the product in a hot environment. High
temperatures can shorten the life of electronic devices, damage
batteries and warp or melt certain plastics.
Do not store the product in cold areas. When the product
warms up to its normal temperature, moisture can form inside,
which may damage the electronic circuits.
Do not attempt to open the casing or attempt your own repairs.
High-voltage internal components create the risk of electric
shock when exposed.
Do not drop or knock the product. Rough handling may
damage the internal components.
Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the product. Wipe the product with a
slightly damp soft cloth.
Do not open battery cover while an image is being recorded.
Doing so will not only make storage of the current image
impossible, it can also corrupt other image data already stored
in file.
If the product or any of its accessories are not working
properly, take them to your nearest qualified service center.
The personnel there will assist you and if necessary, arrange
for the product to be repaired.
Test for proper operation before using the camera.

vii
Notes on the LCD Screen
Be very careful to ensure the fluid contained in the LCD screen does
not escape if the screen becomes cracked or damaged. If this occurs,
follow these steps:
If the fluids make contact with skin, wipe it with a clean cloth
then rinse with a large amount of water.
If the fluid makes contact with eyes, wash eyes with clean
water for at least 15 minutes and go to the hospital as soon as
possible.
If the fluid is swallowed, first rinse mouth with water, then
drink a large amount of water and induce vomiting. Go to the
hospital as soon as possible.
Operation conditions
This camera is designed for use in temperatures ranging from
0°C to 40°C (32°F to 104°F).
Do not use or keep the camera in the following areas:
- In areas subject to direct sunlight
- In areas subject to high humidity or dust
- Near air conditioners, heaters, or other areas subject to
temperature extremes
- Inside of a closed vehicle, especially one parked in the sun.
- In areas subject to strong vibration
Power supply
Use only the type of battery that came with your camera.
Using any other type of battery may damage the equipment
and invalidate the warranty.
Ensure the battery is inserted correctly. Inserting the battery
incorrectly can cause damage to the product and possibly start
a fire.

viii
Remove the battery to avoid the fluid leakage if the camera is
not going to be used for a long time.
If the battery is crushed or damaged, remove it immediately to
avoid the battery fluid leakage and abnormal expansion.
Waterproof
Waterproof performance
The camera’s waterproof performance is equivalent IPX8
Underwater time limit: Do not use the camera underwater for
more than 60 minutes to ensure water resistance.
The camera is not dust-proof.
The supplied accessories are not waterproof.
Notes before going underwater:
(Do not do the following actions on sandy /dusty environment or
near the water’s edge, please check indoors)
Check if the area surrounding the battery/HDMI/USB port is
clean, do not allow dirt or sand or foreign objects around it.
Ensure that the battery/HDMI/USB compartment cover has
no cracks or scratches.
Ensure that the battery/HDMI/USB compartment cover is
closed.
Ensure that the camera has no cracks, if the camera has been
dropped; it is recommended to return it to your dealer.

ix
Notes for general use:
(If the USB cable is directly connected to a computer or if the AV
cable or HDMI cable is connected to a TV, be careful in plugging it,
do not allow it to touch the battery/HDMI/USB compartment
cover to avoid waterproof loss.)
Avoid opening or closing the battery, HDMI/USB
compartment cover near the water’s edge (sea, lake, beach,
lake, etc.). Do not open or close the cover with wet hands, or
hands with sand or dust.
If taking pictures near the water’s edge, pay attention not to
drop the front lens. If it is dropped, wipe off water drops using
a non-fiber clean cloth or a soft absorbent cotton cloth as soon
as possible so as not to leave water drop marks.
The accessories (batteries, etc.) used with the camera are not
water resistant, be careful in using them.
Do not drop the camera to ensure waterproof durability.
Do not place the camera in temperatures above 40°C or below
0°C to ensure waterproof durability.
Do not attempt to make the camera waterproof or seal the
vents yourself, doing so may damage the camera’s waterproof
ability.
When using the camera
The waterproof properties of the camera apply to fresh water
and saltwater only; they do not apply to cleaning substances,
chemicals, or water from spas, etc. Any such liquids should be
wiped off immediately.
Do not immerse in water at a depth greater than 3.0 m (10 ft).
Do not subject the camera to highly pressurized water.
Do not immerse in water for longer than 60 minutes. After 60
minutes of use in water, allow the camera to dry for at least 10
minutes.

x
Do not immerse in water warmer than 40°C (104°F).
Do not open or close the battery/HDMI/USB compartment
cover when the camera is wet or underwater.
Do not open or close the battery/ HDMI/USB compartment
cover with wet hands.
Do not open the battery/ HDMI/USB compartment cover next
to water or a pool.
The camera is not dust-proof.
Do not bump or knock the camera underwater, otherwise the
battery/ HDMI/USB compartment cover may open.
After using the camera
Be sure to come ashore within 60 minutes after going
underwater, this will maintain the appearance, quality and
water resistance of the camera.
After taking pictures underwater, clean the camera in a bucket
of water without salt. Ensure that the battery/HDMI/USB
compartment cover is closed; then soak the camera in the
bucket of water for about 10 minutes. After 10 minutes, wipe
the camera and the lens dry with absorbent cotton. Place the
camera in a well ventilated cool place to dry naturally (do not
place under direct sunlight or exposed areas). Be sure to wait
until the camera is completely dry before opening the
battery/HDMI/USB compartment cover (open the
compartment cover while holding an absorbent cotton to dry
off water or clean other impurities around the cover).
Wipe off water drops on the camera and the lens with a soft
lint-free cloth (to avoid fiber) and place it in a well-ventilated
place to dry. The cover at the battery/IO DOOR can be opened
only after dry to prevent water from entering the camera when
opening.

xi
Before you open the cover at the battery/IO DOOR, always
wipe off water drops inside the cover. Note that it should face
down when opening.
Notes on maintenance
Be sure to wipe any dirt or sand off the waterproof sealing
material or its contraction surface. Dirt or sand may scratch the
material or the surface, making the camera less resistant to
water.
Do not use any soapy water, mild detergents, alcohol or
similar liquids to clean the camera. They may make the camera
less resistant to water.
The waterproof of sealing material is replaceable at cost. The
material should be replaced once a year to maintain the
camera water resistance.
Other Notes
If water accidentally enters the camera or any problem occurs
when it is in water, please get out of water immediately and
take proper actions. Dry the camera and send it to repair.
Information is subject to change without notice. Refer to the
important notes in the manual supplied with the camera.

xii
Before You Start
Take some test shots before performing a formal
recording.
Before taking pictures with this DV camera in any important
occasion (such as a wedding ceremony or an overseas trip), do test
the DV camera beforehand to ensure that it functions properly. Any
additional loss caused by the malfunction of this product (such as
costs of photography or any loss of benefit generated by the
photography) is not the responsibility of the manufacturer and no
compensation will be given for it.
Copyright information
Take care to observe "No Photography" notices in certain locations.
In these cases, you cannot record any live performance,
improvisation or exhibits, even for personal purposes. Any transfer
of pictures or memory card data must be conducted under the
constraints of copyright law.

1
1Introducing the camcorder
Read this section to learn about the features and functions of the
camcorder. This chapter also covers system requirements, package
contents, and descriptions of the hardware components.
1.1 System requirements
The camcorder requires a PC with the following specifications:
Windows®7 / Vista / XP (SP2) operating system
Intel®/ AMD Dual-Core CPU or higher
At least 1 GB of RAM or higher
At least DirectX 9 video card, DirectX 10 is recommended
Standard USB 1.1 port or higher
At least 2GB or greater available hard disk
1.2 Features
The camcorder offers a variety of features and functions including:
HD 1080p (30fps.)
Up to 16 Megapixels
3.0” TFT LCD Touch Display
8X Digital Zoom, 2X Advanced Zoom
Li-ion Battery NP40
Waterproof up to 3m (IPX8)
Note:
A USB 1.1 port will enable you to transfer files to and from
your host PC, but transfer speeds will be faster with a USB 2.0
port.

2
1.3 Unpacking the camcorder
The following items should be present in the package. If any item is
missing or appears damaged, contact your dealer immediately.
Camcorder
User’s Manual
CD Rom
Li-ion Battery
Charger
Power Cable
Pouch
USB AV Cable
HDMI Cable
(Optional)

3
1.4 About the camcorder
Refer to the following illustrations to familiarize yourself with the
buttons and controls of this camcorder.
1.4.1 Front view
Lens
LED light
1.4.2 Top view
Zoom
Button
Microphone

4
1.4.3 Bottom view
Tripod Socket
Battery
Compartment
Lock
1.4.4 Right view
Power Button
Playback
Button
Display
Button
Mode
Button
Menu
Button

5
1.4.5 Left view
Hand Strap
Macro Switch
1.4.6 Back view
Diving Mode Button
Record Button
Navigation Button
HDMI, USB AV Out

6
1.4.7 Operating the camcorder
To turn on the power, press the Power Button for one second or
open the LCD panel 90°.
Rotate the LCD panel can be rotated in both directions so you can
view pictures and movies.

7
See the table below for a description of each button’s function.
Name
Button
Function
Power
Button
Press and hold to turn the
camcorder on or off.
Macro
Switch
Turn to enable or disable the
Macro mode.
Zoom
Button
Press T to zoom in or press W
to zoom out when shooting
videos or photos.
Navigation
Button
Use the left/right
Navigation Button to
select items in the menu
and press the middle
Navigation Button to
confirm.
In Video/Camera
mode, use the up/down
Navigation Button to
adjust EV settings.
In Video/Camera
mode, press the right
Navigation Button to
select the desired
lighting mode.
Record
Button
In Video mode, press to
start recording a video.
Press it again to stop
