Thank you for selecting the HYDRIM L110w G4 instrument washer. The HYDRIM
complements the STATIM®and BRAVO™ autoclaves by quickly and hygienically
preparing soiled instruments for sterilization. To ensure years of safe, trouble-free service,
carefully review this Operator’s Manual before operating the unit. The HYDRIM L110w G4
is suitable only for the applications listed in this manual. Using the HYDRIM for other
purposes may be dangerous. The manufacturer cannot be held responsible for damage
caused by improper use.
Operational, maintenance and replacement instructions must be followed for the product
to perform as designed. All trademarks referred to in this manual are the property of their
respective owners. Contents of this manual are subject to change without notice to reect
changes and improvements to the HYDRIM product.
The HYDRIM L110w G4 should only be installed and serviced by a qualied contractor
as it is an Installation Category 2 device. Before connecting the unit, the installer should
check that the voltage and frequency of the electrical supply correspond with the details
in the installation instructions. The unit must only be plugged into a grounded outlet.
Please note that this unit is completely isolated from the electrical supply only when it is
unplugged or the circuit breaker is turned OFF. This must be done before any repair work
is carried out.
The HYDRIM L110w G4 uses HIP™ Cleaning Solution exclusively. The unit will not
perform as described if other detergents / cleaning products are used. Other detergents /
cleaning products may damage the unit, the instruments, cause excessive foaming, and
void the warranty. Do not use solvents in this unit. Do not allow small children or
unauthorized personnel access to this unit or its controls.
1. Introduction
1

2. Important Information
The following symbols appear in this book.
Caution, there is a potential hazard to the operator.
This situation may lead to a mechanical failure.
This is important information.
2

Do not permit any person other than authorized personnel to supply parts for service or
maintenance for your HYDRIM. SciCan is not liable for incidental, special or consequential
damages caused by any maintenance or services performed on the HYDRIM by unauthorized
personnel, or for the use of equipment or parts manufactured by a third party, including lost prots,
any commercial loss, economic loss, or loss arising from personal injury.
Never remove any unit panels and never insert objects through holes or openings in the cabinetry.
Doing so may damage the unit and/or pose a hazard to the operator.
If the unit is used in a manner other than that specied, the protection provided by the equipment
may be impaired.
Cleaning solutions may irritate. Avoid contact with eyes, skin and mouth.
Never sit, stand or lean on the open door. The unit may tip forward causing injury.
Always turn the unit OFF before adding softener salt, adding solutions or performing routine
maintenance to the unit.
The owner shall not allow any personnel other than the trained and authorized personnel
to operate the unit.
SciCan recommends leaving the unit turned ON at all times, in particular over times when no staff
is in the ofce or when no water shut-off mechanism is installed. Leaving the unit turned ON will
activate the drain pump if water is leaking into the chamber as a result of any faulty circumstance.
For further information or questions about the HYDRIM L110w G4, contact your authorized dealer.
3. Disclaimers
3
