Comica LINKFLEX AD2 User manual

XLR/6.35mm--3.5mm Audio Preamp
Adapter / Interface for Camera and Smartphone
User Manual

Thanks for purchasing COMICA LINKFLEX AD2 XLR / 6.35mm -- 3.5mm
Audio Preamp Adapter / Interface for Camera and Smartphone
The COMICA LINKFLEX AD2 is a XLR/6.35mm--3.5mm Audio Preamp
Adapter / Interface for shooting videos with any camera and
smartphone. It is designed with functions of 'Mic/Phone Two Way
Audio Monitor', 'Audio Preamp and Gain Control', '48V Phantom
Power Output', 'Belt-clamp and Magic-tape Design', etc.,
It provides a compact audio mixing solution.
Please read this manual carefully before using. This product has
been precisely calibrated at the factory, do not assemble and
disassemble parts by yourself.
. XLR/6.35mm (For Instrument like Guitar etc.,) Audio
Adapter Interface;
. Universal for Camera and Smartphone;
. Support 48V Phantom Power Output;
. Audio Preamp and Gain Control ;
. Mic/Phone Two Way Audio Monitor;
. Belt-clamp and Magic-tape Design at the Bottom;
Gain-Control Two-way
Audio Monitor
Support 48V Phantom
Power Output
Universal for
Camera & Smartphone
Multi-interface
Audio Adapter
Foreword
Main Features
1

When the adapter/interface works with iPhone with lightning
audio input, you need to use the original adapter cable;
For the Android system smartphone, the adapter/interface
works well in audio mode, but video mode will happen with
incompatibility trouble while working with some smartphone;
(Then we suggest that you try the 3rd party’s video APP);
For the iOS system phone, the adapter/interface works well
in all audio mode, video mode, and 3rd party’s APP;
This product belongs to high-precision instruments, please
avoid falling, collision or pounding;
Do not use this equipment in the vicinity of heat source or
interference source, such as radiator, oven, refrigerator or
air conditioner;
Please keep the product in a dry environment;
Do not use the equipment in rain or in a damp environment,
otherwise there will be a risk of the circuit;
Notice
Package Contents
XLR/6.35mm--3.5mmAudio Preamp
Adapter/ Interface for Camera and Smartphone
User Manual
Audio Adapter / Interface Belt Clamp Magic-tape
User Manual Warranty Card
2

Components and Instruction
XLR Audio Input Jack
6.35mm Audio Input Jack
Gain-Control Knob
Power / Phantom Power Switch
Phone/Camera Audio Output Switch
Phone/Mic Monitor Switch
3.5mm Audio Output Plug
Power Indicator Light
Phantom Power Indicator Light
3.5mm Audio Monitor Output Jack
Battery Cover
Magic-tape Fixing Slot
Belt Clamp
1
2
3
4
5
6
7
8
9
10
11
12
13
1
89
11
12
2
3
4
5
6
7
10
13
3

Installation and Usage
Please note that the positive and negative poles
of the battery should corresponding to the positive
and negative poles of the product
9V Battery
Negative Pole
Positive Pole
Battery Cover
1.Battery installation
Press the battery cover and open it in the direction of the
arrow.Install the 9V battery according to the corresponding
positive and negative poles
4

2. Usage method
Hang the belt clamp on the belt to use;
Pass the Magic-tape through the Magic-tape Fixing Slot
and attach it to the fixer for use;
5

The 6.35mm and XLR are in the same jack
and cannot be used at the same time
3. Audio input
This product supports XLR/6.35mm audio jack, please
insert the microphone plug into the corresponding jack
when using
XLR Audio Plug
6.35mm Audio Plug
6

1. After installing the recording
device, adjust the output
mode according to the
device
2. After installing the monitor
headphones, please adjust
the monitor mode according
to the requirements
Step 1:
Install the microphone
Step 3:
Install the recording device
(smartphone or camera)
Step 2:
Install the monitor
headphone
:Smartphone Mode
:Camera Mode
:Smartphone Playback
Monitoring Mode
:Microphone Real-time
Monitoring Mode
4.Installation method (Take XLR audio plug for example.)
7

Audio Gain-Control Knob
(Adjust the gain of the Audio Input)
Audio Input
Smartphone Playback Monitoring
Microphone Real-time Monitoring
5. Gain-control knob
Rotate the audio gain-control knob to adjust the gain of the
audio input
6.MIC/Smartphone monitoring switch
:Smartphone Playback Monitoring Mode
:Microphone Real-time Monitoring Mode
In the camera output mode, the switch does
not work and only the microphone real-time
monitoring works
8

Without the correct switch to
the corresponding output
mode will result in an
unsuccessful recording.
If your microphone requires phantom power to work,
please set the switch to PH
Smartphone Output Mode
Turn on
Camera Output Mode
Turn o Phantom Power
8.Power/ Phantom power switch
OFF: Turn o;
ON: Turn on;
PH: Phantom Power
7.Smartphone/Camera output mode switch
:Smartphone Output Mode; :Camera Output Mode
9

Tech Parameters
Input
Output
Frequency Response
Gain Range
THD+Noise
Battery
Size
Net Weight
Working Temperature
Storage Temperature
XLR , 6.35mm
3.5mm audio output, 3.5mm headphone output
20Hz~20kHz, ±1dB
Maximum increase +20dB
<0.02%, RL=2KΩ, f=20Hz~20kHz, Vo=1Vrms
9V 6LR61/6F22 x 1
53x43x102mm
109g
0℃~ +50℃
-20℃~ +60℃
10
