Condor 92912 Quick reference guide

ASSEMBLY & OPERATING INSTRUCTIONS
CONDOR
Electric Remote
Control Airplane
92912
IMPORTANT:
If damage is caused due to a crash, your warranty is void.
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2005 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 05k, 09j, 09k

SKU 92912 For technical questions, please call 1-800-444-3353. Page 2
THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please
complete the owner’s record below:
Model______________ Serial No._____________ Purchase Date_______________
SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the
entire manual to become familiar with the unit BEFORE you begin assembly.
Technical Specifications
Safety Warnings and Precautions
WARNING: When using product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product!
1. Store idle equipment. When not in use, the Airplane must be stored in a dry location to inhibit
damage from moisture and salt air.
2. Check for damaged parts. Before using the Airplane, any part that appears damaged should
be carefully checked to determine that it will operate properly and perform its intended function.
Check for any broken or damaged parts and any other conditions that may affect its operation.
Replace or repair damaged or worn parts immediately. Do not use the Airplane if any part is
damaged or broken.
3. Replacement parts and accessories. When servicing, use only identical replacement parts.
Use of any other parts will void the warranty.
4. For ages 16 and over. Do not let children use the Airplane without adult supervision.
Failure to do so could result in personal injury and/or property damage.
5. Keep your work area clean and well lit. Cluttered benches and dark areas invite acci-
dents.
6. Always check hardware and assembled parts after assembling. All connections should
be tight and hardware tightened.
Wingspan .............................. 263/4”
Wing Area ............................. 96.1 sq. in.
Fuselage Length ................... 191/2”
Weight................................... ~41/4oz.
Battery .................................. 4.8V, 300 mAh, NiMh
Flight Time ............................ About 10-15 minutes
Remote Control..................... 2 Channel
Remote Power ...................... 6 “AA” Batteries (Not included)
Battery Charger Input ........... 120 VAC, 60 Hz
Rev 09j

SKU 92912 For technical questions, please call 1-800-444-3353. Page 3
7. Dress properly. Wear restrictive hair covering to contain long hair.
8. Use eye protection. Always wear ANSI approved impact safety goggles when assembling
and using this product.
9. Use the right Airplane and components. There are certain applications for which this Airplane
was designed. Do not modify this Airplane and do not use this Airplane for a purpose for which
it was not intended.
10. Do not use or assemble the Airplane if under the influence of alcohol or drugs. Read
warning labels on prescriptions to determine if your judgement or reflexes are impaired while
taking drugs. If there is any doubt, do not assemble or use the Airplane.
11. Do not pick up the Airplane while it is in motion.
12. Use only Batteries of the type recommended.
13. Do not mix old and new batteries.
14. Remove batteries if the Airplane is not used for a long period of time.
15. Make certain to use the Airplane in a large area free from interference from trees, electrical
power lines and other obstacles.
16. Never fly near buildings, cars or busy streets.
17. Do not fly the Airplane at or near other people or animals.
18. Keep this product away from small children; small parts can be easily swallowed.
WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by
the operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
Unpacking
When unpacking your Airplane with Radio Controller, check to make sure the parts listed on the
next page are included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS
at 1-800-444-3353.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE
PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR
HER INSTALLATION OF REPLACEMENT PARTS THERETO.

SKU 92912 For technical questions, please call 1-800-444-3353. Page 4
Assembly/ Operation
Your Airplane with Radio Controller will require complete assembly. It is important that you
read the entire manual to become familiar with the product BEFORE you use the Airplane. Before
assembling the Airplane be sure that you have all parts described in the Parts List and Assembly
Diagram, below.
NOTE: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
Assembly Diagram
Parts List
Part Description Qty Part Description Qty Part Description Qty
1 Fuselage 1 7 Tail Stabilizer 1 12 Charger 1
2 Windshield 1 8 Tail Fin 1 13 Antenna 1
3 Wings 1 9 Remote Control 1 14 Ribbon 1
4 Motor Cover (pair) 2 10 Receiver 1 15 Screw 5
5 Motor 2 11 Battery Pack 1 16 Motor Cover Screw 6
6 Propeller 2

SKU 92912 For technical questions, please call 1-800-444-3353. Page 5
Assembly
1. Connect the plug from the Motors (5) to the connector on the Receiver (10). See Figure 1.
Make sure that the plug is securely attached to the connector.
2. Place the Wings (3) on top of the Fuselage (1). Make sure that all wires fit within the Fuselage
without being pinched or kinked. Attach the Wings (3) to the Fuselage (1) using three Screws
(15) as shown in Figure 2.
Set out all parts on a clear and level surface prior to assembly.
3. Place the bracket on the Tail Fin (8) through the Tail Stabilizer (7) (shown in Figure 3) and into
the holes at the back of the Fuselage (1).
4. Secure the Tail Fin (8) to the Fuselage (1) using two screws from underneath as shown in
Figure 4.
Figure 3 Figure 4
Tail Fin (8)
Tail
Stabilizer
(7)
Screws
(15)
Tail Stabilizer
& Fin (7,8)
Figure 1 Figure 2
Wings (3)
Fuselage (1)
Screws
(15)
Fuselage (1)
Wings
(3)
IMPORTANT:
If damage is caused due to a crash, your warranty is void.
REV 05/06

SKU 92912 For technical questions, please call 1-800-444-3353. Page 6
Battery Charging/Installation
1. If the Battery Pack (11) is inside the Fuselage (1), pull the tab on the Windshield (2) toward
the nose of the plane and lift the Windshield off - see Figure 5. Underneath, press the latch
on the side of the connector, gently disconnect the plug, and remove the Battery Pack (11).
2. Plug the Battery Pack (11) into the Charger (12). Plug the Charger (12) into a 120V electrical
outlet. Allow up to one and a half hours for the initial charge. Do not leave unattended when
charging. Disconnect the Battery Pack (11) from the Charger (12) when the charge is complete.
The batteries will become warm when they are ready for use. If you feel them becoming overly
hot, immediately disconnect the Charger (12).
3. Make certain that the “ON/OFF” Switch for the Airplane is in the “OFF” position. Plug the Bat-
tery Pack’s (11) plug into the connector located underneath the Windshield (2) - see Figure
6. Insert the Battery Pack (11) into the Fuselage (1) and hold the tab on the Windshield (2)
forward while putting it back in place.
Setting up The Controls
1. Insert the Antenna (13), threaded end first, into
the Remote Control (9) and tighten it until it is
secure. Tie the Ribbon (14) to the end of the
Antenna (13), as shown in Figure 8.
2. The direction control stick controls the motors
to turn the plane right or left.
3. The motor control button activates the motors.
The motors operate while the button is pressed
and stop when both the button and the stick are
released.
4. Switch “OFF” the “ON/ OFF” Switch on the Re-
mote Control (9). Remove the two screws at
the base of the remote and slide the cover off.
Insert six “AA” batteries (not included) into the
Remote Control (9) in the orientation shown in
Figure 7 and close the cover.
IMPORTANT: The Remote (9) is shown face down
in Figure 7. If the batteries are installed im-
properly, DAMAGE may result to the Remote
and the batteries.
Figure 8 Ribbon
(14)
Channel 1 (CH1)
-direction
control stick
Channel 2 (CH2)
-motor
control button
ON/OFF
switch
Antenna
(13)
Power LED
(GREEN)
Low Battery
LED (RED)
Figure 7
IMPORTANT:
Remote (9) is
face down.
Remote
battery
cover
Remote (9)
Figure 5 Figure 6
Windshield (2)
Fuselage (1)

SKU 92912 For technical questions, please call 1-800-444-3353. Page 7
Flying the Airplane
FAMILIARIZE YOURSELF WITH ALL INSTRUCTIONS BELOW
BEFORE ATTEMPTING TO LAUNCH OR FLY THIS PLANE.
1. Choose a day when the wind is light. The Ribbon (14) attached to the Antenna (13) should be
blowing slightly (not greater than 30 degrees) and not be blowing straight out. Find a wide-open
field.
2. Switch the Remote Control (9) “ON”, the green Power LED on the remote should illuminate- see
Figure 8. If the red Low Battery LED illuminates, change the batteries in the remote before
use. Turn the switch on the Fuselage (1) to “ON”, also.
3. Face the Airplane into the wind. Hold the motor control button down so that the motor is running
at full power.
Note: It is recommended that two people work together to hand launch the Airplane. One
should control the Remote Control and one will launch the Airplane.
4. With the Airplane tilted at about 10 degrees upward, propel and release it into the wind.
5. Hold the motor control button down until the Airplane climbs to about 100 to 150 feet high.
6. If the Airplane does not climb smoothly, follow the following steps until the problem is
corrected:
a. If the Airplane rises too slowly or dives, land the plane immediately and adjust the entire
back edge of the Tail Stabilizer (8) up (no more than 1/16” at a time). Adjust the entire back
edge evenly.
b. If the Airplane continually rises then dives, land the plane immediately and adjust the entire
back edge of the Tail Stabilizer (7) down (no more than 1/16” at a time). Adjust the entire
back edge evenly.
7. Move the direction control stick to the left to steer to the left, and right to steer it right.
8. If the airplane drifts to the right or left excessively, land the plane and adjust the Tail Fin (8)
accordingly. If the plane drifts right, adjust the Fin to the left (no more than 1/16” at a time). If
the plane drifts left, adjust the Fin to the right (no more than 1/16” at a time).
9. Note that letting go of the control stick and the button will automatically bring them to a neutral
position. This will cause the Airplane to glide, unpowered.
10. Normal flight time for one full charge is about ten (10) minutes. If the plane appears to be losing
power or climbs with difficulty, the batteries are low. Land the plane.
11. When the remote control’s battery begins to reach the end of its power, the red indicator light
will illuminate or blink. When this occurs, IMMEDIATELY LANDTHE AIRPLANE. If the remote
control’s battery is allowed to die completely, the plane will be uncontrolled and may
cause damage to property or SEVERE PERSONAL INJURY.
12. To bring in the Airplane for landing, release the motor control button and glide the Airplane
down against the wind. If airplane descends too quickly, briefly press the motor control button
to compensate.
