Conrad SL1007 User manual

HUNTING CAMERA
INSTRUCTION MANUAL
Model #: SL1007 Hunting series
V1.2 2012. Dec

2
TABLE OF CONTENTS
Camera Kit Contents………………………………...…..3
Camera Overview…………….…………………………..4
General Information……………………………………..8
Definitions………….…………………………………………9
Quick Start Gui e………………………………………….12
Battery an Memory Installation……………….…13
Camera Setup an Program…………………….…..15
Using the Camera in PIR Detection Mo e….…27
Using the Camera in Time Lapse Mo e…….….29
Viewing an Deleting Files…………………..……...30
Technical Specifications……………………….….…..34
FCC Compliance…………………………………….…….38

3
Camera Kit Contents
1. Hunting Camera.
2. Instruction Manual.
3. Strap.
4. USB Cable.
5. AV Cable.
6. Wall Mounting Device.
7. Mounting screws.

4
Camera Overview
Front View

5
Back View

6
Top View (After Open Top Cover)
Bottom View

7
Open Bottom Cover Image with major parts
indication
•Follow below figure to turn the bottom cover to open .

8
General Information
Storing conditions
•Operating Environment: 14 to 104 eg F (-10 to 40 eg C).
20-85% relative humi ity, non-con ensing.
Specia care instructions!!
•The camera is esigne to be weather resistant. Never
attempt to immerse the unit in water or any other liqui .
This will amage the unit an voi the warranty.
•Use a soft lens cloth for cleaning lens. Avoi touching lens
with fingers. An remove irt or stains with a soft cloth
ampene with water or neutral etergent. Keep your
camera in a ry an cool ust-free environment or
container when it is NOT use .
•Take the batteries out, when camera is NOT to be use
over an exten e perio of time.
•Avoi ropping your camera on to a har surface.
•Do not isassemble your camera.
•Do not mix new an ol batteries.
•Do not open the camera for unauthorize service. This
coul cause serious amage to the unit an WILL voi the
warranty.
NOTE : This camera is a precision electronic evice. Do
not attempt to service this camera yourself, as opening
or removing covers may expose you to angerous
voltage points or other risks.

9
Definitions
Definitions of Front View parts
•Batteries Cover : Turn to open the cover to install the
batteries.
•Infrared LED : It is invisible light for night time capture.
•Camera Lens : It is to capture the image/vi eo.
•Test Laser Beam : It is to i entify the capture area an
count own in ication.
Please avoi the laser beam point to your eyes.
•Microphone : It is to pick up the soun s while vi eo in
recor ing.
•Passive Infrared Sensor : It is to etect the moving object.
•Bottom Cover : Turn to open the cover to set the camera.
Definitions of Back, Top and Bottom view parts
•Tripod Nut : It is to attach the wall mount evice.
•Strap Ho es : It is to attach the camera to pillar or tree by
provi e strap.
•Batteries Compartment : It is to install the C batteries.
•DC 6 Vo ts Port Cover : Open it to connect a DC 6V
external power. Tightly close to prevent the water leakage.
NOTE : Make sure the installe batteries or the external
power is in correct polarity.

10
Definitions of Bottom Open View parts
•LCD disp ay : It is to isplay the setting an camera status.
•USB port : It is to connect the camera to PC by provi e
USB cable for capture image/vi eo ownloa .
•AV out : It is to connect the camera to TV by provi e AV
cable to play the capture image/vi eo.
•Menu Button : Pressing into the camera mo e to change
the setting.
•Up and Down Button : Pressing to change the mo e an
a just the setting value.
•Switch : Switching to turn on/off the power or go into
test/Preset Mo e.
•SD Card S ot : It is to install the SD memory car .
•Confirm Button : Pressing to confirm the settings.
•DC 6V port : It is to connect the DC 6V external power
Definitions of LCD Disp ay

11
•CAM : It in icates the camera in still image mo e.
•VIDEO : It in icates the camera in vi e mo e.
• : It in icates the burst mo e or vi eo length.
• : It in icates the battery status.
> <
> <
> <
Fu (Icon on) Ha f (Icon b inking) Low (Icon off)
When batteries are low, the LCD isplay shows bAtLo.
Please replace with new batteries.
• : It in icates the still image/vi eo resolutions.
Image resolution is 8Mp.
Image resolution is 5Mp
or vi eo resolution is
HD 720P.
Image resolution is 3Mp or vi eo resolution is
VGA
•D : It indicates the camera in date setting.
•T : It in icates the camera in time setting.
•T-O : It in icates the camera in time out setting.
•PIR : It in icates the camera in PIR etection Mo e.
•TLS : It in icates the camera in Time Lapse Mo e.
• : It in icates the ate/time/time out value
uring setting or capture image/vi eo quality. The ate
an time will stamp to the still image an vi eo

12
Quick Start Gui e
This gui e is esigne to get you up an running in a matter of
moments. To get the most out of this HUNTING CAMERA tools,
please rea the manual thoroughly before operating. If you
woul like to mo ify any of the factory Default Settings, except
for the Time & Date, please see manual for instructions.
Factory Defau t Settings:
Time Out: 30 Sec Burst Mode: 3 Still Image
Reso ution: 3M Operation Mode: PIR
Video Mode: 10 Seconds (VGA Resolution)
Time apse setting: 19:00 7:00 (Next day)
Initia Camera Set-up:
1. Install 4 “C” cell batteries in correct polarity (+/-) as in icate in
battery compartment.
2. Insert SD car into the camera.
3. Turn switch to CAM to a just the Time an Date.
4. The internal LCD screen isplays T blinking.
5. Press the [OK] button to start the Time settings.
6. Press the [UP] or [DN] button to a just the Minute setting an
press [OK] to confirm an move to the Hour setting.
7. Repeat to set the Hour an then press [OK] to confirm an
move to Date.
8. A just the Month, Day, an Year by using [UP] or [DN] button.
Each time you finish an a justment you MUST press the [OK]
button to confirm an move to the next fiel for a justment.
9. Once one, the wor - EL - will be blinking, this stan s for
Delete menu an will allow you to format your SD Car . (This
will elete ALL images). Press the [M] button to exit.

13
Battery an Memory Installation
WARNING : Do not use ifferent Voltage lea aci
battery other than the one specifie in this section.
Doing so will amage the camera an will voi the
warranty.
WARNING : ALWAYS have the camera in the OFF position
when installing or removing batteries an memory car .
Removing batteries or memory car while the camera is
ON may amage the camera.
Your HUNTING CAMERA is esigne to operate using two ifferent
types of battery power options.
Batteries “C” ce
The internal battery compartment accepts 4 “C” cell batteries.
Be sure to use high quality bran name alkaline batteries. Install
batteries with correct polarity (+/-) as note insi e the battery
compartment.
DC 6V externa power
The camera is equippe with an external power jack esigne to
accept a barrel plug cable of DC 6V a aptor (Sol separately).
•Make sure camera is in the OFF position.
•Insert the external AC to DC power a aptor barrel plug
into the DC 6V jack on the bottom of camera housing.
•Turn the switch to a CAM or PSET.

14
Memory Options
The camera is also equippe with an expan able me ia car slot
capable of accepting up to 32GB SD car with Class 6 or below
spee rating (sol separately). The LCD isplay will show the
number of images store on the SD car . If no SD car is
inserte the front counter isplay will show “NOSd”.
Inserting SD memory card
NOTE: Make sure camera is in the OFF position
whenever a ing or removing memory.
•Insert SD memory car in to the SD car slot completely
an in the correct irection as shown by the sticker
locate at the si e of the housing.
•To remove the SD memory car , epress the SD car an
pull out the car gently.
•SD car s must be clean (no images from other sources). If
you are using the SD car from other cameras, please
make sure to format the SD car in your computer prior
to use in your camera. New car s are goo to use straight
from the package.
FORMAT – Definition : When you format a SD memory card, the
operating system erases all information and files on the card.
Then it creates an internal address tables that it later uses to
locate information and files. Formatting also removes all Hidden
System files as well. Basically it cleans your SD memory card just
like if it was brand new.
DO NOT USE File System type: “NTFS” or “exFAT”, these formats
are not supported.

15
Camera Setup an Program
When the camera switch is first turne in the CAM location, the
internal LCD isplay shows the camera status. The following
information is present on this screen.
Passive Infrare Mo e Time-Lapse / PIR Mo e
If no buttons are presse after 30 secon s the LCD isplay will
go to sleep mo e an LCD isplay switch to show the capture
quality an enter 1-minute count own for user leave the
capture area, then camera enter PIR etection mo e or Time
lapse mo e. To wake up the camera by press UP or DOWN
button once, the LCD isplay will resume the status of camera.
Setting the Preset Program Se ection Mode:
This camera is equippe with 2 Program selection toggle switch
settings. Make sure camera switch is in the OFF position
BEFORE changing any toggle switches.
NOTE: If you choose one of the Preset settings, your
camera will only function in PIR mo e not Time Lapse
mo e
•CAM - This allows the user to efine what setting the
camera will use.

16
•PSET - This bypasses all user efine settings an uses the
following settings: (PIR mo e / Resolution: 3MP / Burst:
3P / Time out: 30 secon s).
Program HUNTING CAMERA using CAM mode
Setting the CAM Operation Mode:
Your HUNTING CAMERA can be programme to operation either in
PIR Detection mo e or Time Lapse / PIR mo e.
•Sli e the switch to the CAM position.
•LCD isplay will show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e, the wor PIR or TLS will be blinking.
•Press the [UP] or [DN] button to select PIR mo e.
•Press [OK] to save your selection.
•Press [M] button to exit.

17
Setting the Image Reso ution in PIR mode:
Your HUNTING CAMERA can be programme to 3 ifferent image
resolutions: 3 Stars is 8Mp, 2 Stars is 5Mp an 1 Star is 3Mp.
•Sli e the switch to the CAM position, LCD isplay will
show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e.
•The wor PIR will be blinking, press [OK] to confirm the
camera’s operation is PIR etection.
•Press [UP] or [DN] button until the wor CAM is blinking.
•Press the [OK] button ONCE to confirm the camera into
CAM mo e, the STARTS will be blinking.
•Press the [UP] or [DN] button to select the esire
resolution.
•Press [OK] to save your selection, then current number of
burst shoot will blinking. Press [OK] to enter the burst
shoot setting or press [M] button to exit.
Setting the Image burst shoot in PIR mode:
Your HUNTING CAMERA can be programme to shoot 1-9 pictures
per triggering.
•Sli e the switch to the CAM position, LCD isplay will
show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e.
•The wor PIR will be blinking, press [OK] to confirm the
camera’s operation is PIR etection.

18
•Press [UP] or [DN] button until the wor CAM is blinking.
•Press [OK] button ONCE to confirm camera into CAM
mo e.
•Press [UP] button ONCE to enter burst shoot setting, the
current number of burst shoot will blink.
•Press [OK] then press the [UP] or [DN] button to select
the esire burst mo e setting or number of pictures per
triggering.
•Press [OK] to save your selection, then the time out T-O
will blinking. Press [OK] button to enter time out setting
or press [M] button to exit.
Setting the Video Reso ution in PIR mode:
Your HUNTING CAMERA can be programme to 2 ifferent vi eo
resolutions: 2 Stars is HD 720, 1 Star is VGA 640 x 480 pixels.
•Sli e the switch to the CAM position, LCD isplay will
show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e.
•The wor PIR will be blinking, press [OK] to confirm the
camera’s operation is PIR etection.
•Press [UP] or [DN] button until the wor VIDEO is blinking.
•Press the [OK] button ONCE to confirm the camera in
VIDEO mo e, the STARS will be blinking.
•Press the [UP] or [DN] button to select the esire
resolution.

19
•Press [OK] to save your selection, then current number of
vi eo length will blinking. Press [OK] button to enter
vi eo length setting or press [M] to exit.
Setting the Video ength in PIR mode:
Your HUNTING CAMERA can be programme to recor 5-300
secon s of vi eo per triggering. The Vi eo mo e is only
workable un er PIR mo e.
•Sli e the switch to the CAM position, LCD isplay will
show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e.
•The wor PIR will be blinking, press [OK] to confirm the
camera’s operation is PIR etection.
•Press [UP] or [DN] button until the wor VIDEO is blinking.
•Press the [OK] button ONCE to confirm the camera in
VIDEO mo e.
•Press [UP] button ONCE an the vi eo length in secon s
will be blinking.
•Press [UP] or [DN] button to select the esire vi eo
length from 5 to 300 secon s in 5-secon increments.
•Press [OK] to save your selection then the time out T-O
will blinking. Press [OK] button to enter time out setting
or press [M] button to exit.

20
Setting the Time Out in PIR mode:
Your HUNTING CAMERA can be programme to set the amount of
time in secon s or minutes the camera will sleep between PIR
triggers .
•Sli e the switch to the CAM position, LCD isplay will
show the camera status screen.
•Press the [M] button once within 30 secon s to enter the
programming mo e.
•The wor PIR will be blinking, press [OK] to confirm the
camera’s operation is PIR etection.
•Press [UP] or [DN] button until the wor T-O (Time Out) is
blinking.
•Press [OK] button an the MINUTES igits will be blinking.
•Press [UP] or [DN] button to increase or ecrease the
time value in minutes from 00 to 10 minutes in 1-minute
increments.
•Press [OK] to save the minute setting an the SECONDS
igits will be blinking.
•Press [UP] or [DN] button to increase or ecrease the
time value in secon s from 05 to 55 secon s in 5-secon
increments.
•Press [OK] to save the secon setting.
•You’ll then see the wor T (Time) blinking. Press [OK]
button to enter time setting or press [M] button to exit.
