Consonance Consonance Orfeo User manual

1
Orfeo CD PLAYER
USER GUIDE
Congratulations on your new Consonance !
Every Consonance product is based on a simple philosophy:
The audio reproduction instrument shall reproduce the original musical sound, purely and naturally.
It shall use Opera audio design reflecting natural music reproduction and styling to fit in with any interior.
The products shall be easy to operate and shall be manufactured according to the best quality principles.
All Consonance products are created with acoustical instruments in a concert situation as point of reference. The
music is reproduced exactly like the original and is limited only by the quality of the recording.
Our aim is to give you the best possible music experience!
CONTENTS
Sound Advice page 2
General use page 2
Remote Control page 3
Use & Placement page 5
Cleaning page 5
Technical specifications page 5
Note & Warning page 6
Warranty page6

2
SOUND ADVICE
The Consonance ORFEO High End CD-player is easy to connect and operate and requires no prior technical
knowledge. However, to get the most out of the player's superior sound and music quality, we have provided a
brief description of the connections and use of the player in order to provide a total music experience.
We recommend keeping this user guide for future reference.
GENERAL USE
The CD player has only six buttons. The buttons on the front panel have 6 functions.
NO.1 Power on / off
The CD-player is switched on by pushing the power button on the left hand side of the front panel. A flashing " --
-- --" blue light in the display indicates that power has been switched on.
By pushing the same button one more time the power is switched off.
NO.4 Open / close
Pushing the open/close button on the right hand side of the front panel will open the CD tray loader, and the CD
can be placed in the tray.
To close the CD tray loader push the same button one more time.
The CD tray loader can also be closed by pushing the tray loader gently inwards.
NO.2 Play
Pushing the play button on the right hand side of the front panel makes the player start playing.
Pause
If the play button is pushed when a track is playing the player will go into pause mode. One more push at the
button and the player will start playing again from the same position on the CD. The pause function is indicated by
the display flashing the track and time when the pause was selected.

3
NO.3 Stop
Pushing the stop button on the right hand side of the front panel makes the player stop playing the CD.
NO.6 Next track
Pushing the next track button on the left hand side of the front panel makes the player jump to the next track on
the CD. For every time this button is pushed the player will move one track forward.
The player will automatically start playing from the beginning of the selected track each time this button is pushed.
NO.5 Previous track
Pushing the prev. track button on the left hand side of the front panel makes the player jump to the beginning of
the track that is playing. For every time this button is pushed the track playing will move one track backwards. The
player will automatically start playing from the beginning of the selected track each time this button is pushed.
CONSONANCE REMOTE CONTROL
The Consonance ORFEO can be controlled by remote control. Like other Hi-End products, the number of buttons
on the remote is kept to a minimum.
The remote control uses two 1.5-volt LR03 AAA batteries.
Additional functions available on the remote control
By using the Consonance Remote control the functions search ( ) and repeat can be selected.
fast forward
Searching fast forward is selected by holding down the button on the remote control.

4
The search speed will start slow and will increase to high after some seconds.
fast backward
Searching fast backward is selected by holding down the button on the remote control.
The search speed will start slow and will increase to high after some seconds.
Repeat CD
To repeat the complete CD, press the button once. “r ALL” will be displayed on the screen.
Repeat track
To repeat the track playing, press the button twice. “r ONE” will be displayed for
two seconds on the screen.
.
Cancel repeat
To cancel repeat, press the repeat button third.
Dim display
To dim the display on the screen, press the FA button. The display will change from bright to dead on the screen.
Switch sampling
While the player in standby, press the FB button to switch the sampling 44.1/ 88.2kHz.
Track information
While the player in playing, press the FB button to show the track time, time left of the
playing track and time left of whole disc.
Back panel of CD-player
From left to right the connectors are :
AC Power connection 240V / 230V / 220V / 115V / 100V AC dependent on country.
Digital output Phono/RCA ,No.10
Unbalanced outputs Phono/RCA right/left

5
We recommend to connect signal cables to the CD-player when the CD-player and all the other units of the audio
system is switched off.
The CD-player has two types of analog audio outputs: unbalanced audio signal with RCA plugs (phono plugs)
The CD-player has got one RCA standard SPDIF digital audio output. Digital signal level is 0.5Vpp when
terminated in 75 ohm load. This is the standard load impedance of external DAC's and other recording equipment.
USE & PLACEMENT
The Consonance ORFEO should be placed on a flat, hard surface for proper isolation against vibrations. The CD-
player performs best after being switched on for about 30 minutes for heating upage A certain space is required
for air circulation above and below the CD-player. The CD-player must never be placed on a carpet or similar
surface that obstructs air circulation through the component. Nor must it be covered while in use or placed on a
narrow shelf or in another confined space.
CLEANING
The top cover , the front panel and side panels are made of brushed / blasted and anodized aluminum.
Fingerprints or stains on the front panel, knobs or top cover can be removed with a cloth moistened with warm
water.
We wish you good luck in setting up and connecting your new CD-player and hope that it will give you many years
of joyful natural sounding music experiences!
TECHNICAL SPECIFICATIONS
Consonance ORFEO High End CD-player
DAC resolution 16bit TDA1543
0dBFS signal output 2.35V RMS
Output Terminals Gold plated Tube RCA unbalanced
Frequency response Less than +/- 0.5 dB deviation 20Hz-20kHz
Phase response Less than 5 degrees deviation 20Hz-20kHz
Signal-to-noise ratio More than 100dB
Crosstalk Less than -100dB
Distortion (RCA) Less than 0.12 %
Remote Control Philips RC-5 compatible IR system 36kHz modulation frequency
Dimensions / Weight 11cm x 45cm x 40cm (HxWxD) / 18kg
NOTE & WARNING
Consonance products should only be opened and / or serviced by certified Consonance technicians. The device
contains electronic components that can cause severe electric shock. Work performed on Consonance products
by unqualified personnel can cause serious damage and personal injury.
Opening of the product by non-authorized personnel will void the guarantee.
The products must not be exposed to rain or moisture.

6
Warranty
Opera audio guarantees each product manufactured by us to be free from defects in materials and workmanship under normal
use. Our obligation under this warranty is limited to making good at our factory any part or parts thereof which shall, within 1 year
after delivery to the original purchaser, be returned to us with transportation charges prepaid, and which an examination shall
disclose to have been thus defective; this warranty being expressly in lieu of all other warranties expressed or implied and of all
other obligations or liabilities onour part. Thiswarranty shall not apply to any Opera audio product which shall have been repaired
or altered outside of our factory in any way so as to affect its stability, nor which has been subject to misuse, negligence or
accident. Warranties of the vacuum tubes are by the respective manufacturers, usually 90 days.
Please mail or e-mail the Registration Card to the address as follows:
Registration Card
Name
Address
City
State
Zip
Email
Telephone
Model
Serial Number
Purchase Date
Dealer
The Opera Audio Co., Ltd.
No.2 JianXianQiaoLu
ChaoYang District
Beijing, China
Tel: [phone]
Fax: [phone]
[email protected]
www.opera-consonance.com
