Appliance Operation
Connect the appliance lead to the 3 pin socket in the rear of the appliance and
plug the appliance into a suitable supply and switch on the ON/OFF switch situated on
the rear of the appliance. The ON/OFF switch is illuminated and will light up. The
appliance should be positioned for easy access to the ON/OFF switch and mains plug
to facilitate rapid switch off and appliance isolation when required.
The appliance may bleep several times whilst internal components that may have
moved during transportation reset themselves. If this does happen the bleeping should
last no longer than 20 seconds. If bleeping continues for a longer period pull the Water
Tank and the Ice Cube Drawer out slightly and re-insert them ensuring that they are
fully home in their recesses. When the Water Tank is withdrawn the WATER TANK
indicator on the Function Display should change colour from green to red or red/orange,
and when re-inserted it should go back to green. If the indicator stays red or red/orange
this could indicate that the appliance internal water level detector is not operating
correctly. Remove the Water Tank and check that the black float inside the transparent
water level indicator on the right hand side of the rear of the Water Tank is free. If the
float is stuck gently tap the indicator to free the float and the re-insert the Water Tank
fully into its recess.
Ice cube size S (small) of the SELECT display should be illuminated red as this is the
default setting. If it isn’t depress the S button to illuminate it.
Press the START button on the Function Display and keep it pressed for a couple of
seconds. The appliance will start with the water pump, cooling fan and compressor
starting to operate. Looking through the right hand side of the clear Window in the top of
the appliance water will be seen entering the water tray.
After approximately 12 minutes ice cubes will be deposited in the Ice Cube Drawer and
the appliance will bleep four times. Do not attempt to remove ice cubes until after the
four bleeps have finished otherwise the appliance will bleep continuously and the cubes
may be deposited into the Ice Drawer recess rather than the Ice Drawer itself. If the
appliance does bleep continuously ensure the Ice Cube Drawer is fully in its recess.
The appliance will continue to produce ice cubes at approximately 12 minute intervals.
Some variation in ice cube size should be expected on initial switch on however
variation should be minimised once the appliance has stabilised. Other variables such
as water temperature and ambient operating temperature can affect ice cube size.
When the Ice Cube Drawer is full the appliance will detect this and bleep 10 times. The
S, M and L lights will flash for 5 minutes and, if the Ice Cube Drawer is not emptied, the
appliance will go into sleep mode. Emptying the Ice Cube Drawer and replacing it into
its recess will re-start the ice cube making process.
.
