Convergent COHO 801 User manual

Convergent Manufacturing Technologies Inc.
6190 Agronomy Road, Suite 403, Vancouver, British Columbia, Canada, V6T 1Z3
Tel: [phone], Fax: [phone], [e-mail], www.convergent.ca
COHO 801
List of Components
Setup Instructions
Start-up Instructions
Shut-down Instructions

Fixed Display
Battery Charger
Valves
Inclinometers
Frontend
Roamers (iPads)
Backend
Computer
Computer
Filters
(Optional)
Pressure Gauges
Smart Manifolds
COHO 801
Convergent Manufacturing Technologies Inc. 604.822.9682 [e-mail]
List of Components
Front View (Hoses and cables not shown)

COHO 801
Convergent Manufacturing Technologies Inc. 604.822.9682 [e-mail]
24
Back View
7
13
19
2
8
14
20
3
9
15
21
456
10 11 12
16 17 18
22 23
List of Components
Vacuum Inlets
Vacuum Outlet
Power Switches
1

COHO 801
Convergent Manufacturing Technologies Inc. 604.822.9682 [e-mail]
Setup Instructions
1
2
3
Step 1: Connect Power Cables
There are two power cables, both must be plugged in• Connect each power cable directly to a power source, do not use a power bar or other splitters•
Step 2: Connect Inlet Hoses
Connect each of the vacuum ports on the part to one of the inlet connections• There are 24 available inlet connections• Refer to the relevant activity for hose numbering•
Step 3: Connect the Outlet Hose
Connect the vacuum source to the outlet connection•

COHO 801
Convergent Manufacturing Technologies Inc. 604.822.9682 [e-mail]
Start-up Instructions
Step 1: Turn on the cart power supplies
Both power switches on the back of the cart must be turned on•
Step 2: Check that the backend computer is on
If the blue light on the front face of the backend computer does not turn on with the• cart power, press the computer power button
Step 3: Turn on the frontend computer
Press the power button on the computer docking station• If the computer does not start, lift the screen and press the computer power button•
Step 4: Turn on the smart manifolds
All smart manifolds should be turned on•
Step 5: Turn on the inclinometers
Ensure that the inclinometers have charged batteries•
Step 6: Open all of the valves
All valve handles should point towards the front of the cart•
2
4
3
5
6
1

6
COHO 801
Convergent Manufacturing Technologies Inc. 604.822.9682 [e-mail]
Shut-down Instructions
Step 1: Close all of the valves
All valve handles should point towards the side of the cart•
Step 2: Turn off the inclinometers
To conserve bettery power, all inclinometers should be turned off•
Step 3: Turn off the smart manifolds
All smart manifolds should be turned off•
Step 4: Turn off the frontend computer
Press the power button on the computer docking station•
Step 5: Turn off the backend computer
Press the power button on the front face of the backend computer•
Step 6: Turn off the cart power supply
Both switches on the back of the cart must be turned off•
4
3
5
2
1
