Nest Protect (Battery)
Detects smoke and carbon monoxide (CO)
User’s Guide
ATTENTION: Please read carefully and save this User’s Guide in a safe place.

0086-CPR-599229
TABLE OF CONTENTS
Meet your Nest Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Location in your home. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Placement on the ceiling or wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Placement on a sloped ceiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup and installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Heads-Up and Emergency Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Wireless interconnect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Testing Nest Protect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
General maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Alarm limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installation code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Installation in Ireland. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Carbon monoxide (CO) precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Fire safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Mobile notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
WE TAKE YOUR PRIVACY SERIOUSLY
We’re committed to being open and honest about how we use data. We will always ask for
permission before sharing your personally identifiable information such as your email address.
We also keep your data safe with industry-standard security tools. To learn more about our
Privacy Policy, please go to nest.com/eu/privacy.
2

Nest Protect Backplate 4 mounting screws
MEET YOUR NEST PROTECT
Inside the box you’ll find:
Nest Protect is designed to detect smoke and carbon monoxide in a residential environment.
It has multiple sensors to help it understand what’s happening in your home and a photoelectric
sensor to detect slow, smoldering fires. Nest Protect can be used as a single station or multiple
station alarm.
The installation of this apparatus should be carried out by a competent person.
This guide covers the installation of Nest Protect (Battery) – Model number O5A-E.
REQUIREMENTS
Wi-Fi, an iOS or Android smartphone or tablet, and a free Nest Account are required for wireless
mobile notifications and software updates. During setup, Wi-Fi and a free Nest Account are
required for wireless interconnect and room naming. Once all the Nest Protects in your home are
connected, they can communicate with each other without Wi-Fi.
3

13.4 cm
(5.28")
4.1 cm
(1.63")
Horn enables Nest Protect
to alert you with a loud
emergency sound.
Speaker allows Nest Protect
to speak with a human voice.
Light ring changes
colour to alert you.
Push the Nest button to
silence alarms and run
a test.
Micro-USB connector
(for service only).
Battery compartment:
6 AA Energizer®Ultimate
Lithium batteries (L91).
4

BEDROOMMASTER
BEDROOM
LIVING/
FAMILY
ROOM
KITCHEN
GARAGECELLAR
HALL
AT TIC
MASTER BEDROOMLIVING/
FAMILY
ROOM
DINING
ROOM
KITCHEN
BEDROOMBEDROOM
LOCATION IN YOUR HOME
It is recommended that you place at least one smoke alarm on every floor of a dwelling,
and a carbon monoxide detector in at least every room with a fuel burning appliance.
The Nest Protect smoke and carbon monoxide alarm should be installed:
• On every floor (required by law for smoke alarms).
• In every room containing a fuel burning appliance (recommended for CO alarms).
• In every sleeping room.
• In remote rooms that are used often but may be too far away to hear an alarm.
• Outside of unused rooms, like the boiler room.
Nest Protect should be installed at least 3 m (10 ft) away from cooktops or cooking appliances.
Nest Protect should NOT be installed in unfinished attics or garages.
5

Figure 1
30 cm
(12")
Minimum
15 cm
(6")
Minimum
60 cm
(24")
Maximum
BEST
HERE
NOT IN
THIS AREA
CEILING
SIDE
WALL
OK
HERE
NE
ST LOGO
IS UPRIGHT
PLACEMENT ON THE CEILING OR WALL
Installing on the ceiling is recommended. Mark where the screws will go using the backplate as
a guide. Make sure it’s at least 30 cm (12 in) away from the wall.
6

Figure 4
Figure 2 Figure 3
NEST LOGO
IS UPRIGHT
ANYWHERE IN
THIS AREA
90 cm
(35")
ANYWHERE IN
THIS AREA
90 cm
(35")
PLACEMENT ON A SLOPED CEILING
If you have a sloped, pitched or cathedral ceiling, Nest Protect should be 90 cm (35 in)
fromthehighest peak.
7

SETUP AND INSTALLATION
2.Set up Nest Protect with
the Nest app
The Nest app will guide you through each step:
scanning the Nest Protect QR code, connecting
it to the Internet, and connecting it to other
Nest Protects in your home.
Watch the video at nest.com/eu/installprotect.
1. Get the Nest app
Before you install your Nest Protect on the
ceiling or wall, you’ll need to set it up with
the Nest app. Download the app from the
Apple App Store, Google Play or the Amazon
App Store and create a free Nest Account.
4.Test before you install
Once you’re done setting up all of your Nest
Protects, test they’re added to your Nest Account
by pushing the Nest button on one Nest Protect
and follow the instructions to test. If they’re all
added, every Nest Protect will speak up.
Now you can install them on the ceiling or wall.
Already Added New
3.Have more Nest Protects?
The Nest app will ask you if you have additional
Nest Protects to set up. If so, it’ll take you
through a shorter setup. Make sure to keep
track of which Protects you’ve already set up
and where you’re going to install them.
8

5.Remove the old smoke alarm
Just remove it safely from the wall or ceiling.
Ifithad a backplate, unscrew it.
6.Install Nest Protect backplate
Screw the backplate to the ceiling or wall using
the included screws. Use two to four screws.
Choose the slots to support Nest Protect
evenly. Make sure the backplate is squared up
to the wall.
Tabs face away from
the ceiling or wall.
7. Mount and test your Nest Protect
Push Nest Protect onto the backplate tabs
and give it a slight twist clockwise. It’ll CLICK
into place.
Once you’ve installed all your Nest Protects,
press the Nest button on one Nest Protect and
follow the instructions to test. They should all
speak to you, confirming that they’re in range of
each other.
WARNING
Be sure to prevent dust from getting into
Nest Protect. Put the dust cover back on,
or keep it in a separate room while you
drill and install the backplate. Clean
any remaining dust before you mount
Nest Protect.
9

SETUPALERTS
WHAT YOU HEAR WHAT YOU SEE ON
NEST PROTECT
WHAT IT MEANSWHAT TO DO
To set up or run a
manual test.
Smoke levels are rising.
Carbon monoxide levels are
rising. This Heads-Up will
occur if carbon monoxide
levels stay at 70 ppm for
1 to 4 hours.
The smoke in the room has
reached emergency levels.
The carbon monoxide in
the room has now reached
emergency levels.
“READY. PRESS TO TEST.”
“BE AWARE, THERE’S
SMOKE IN THE (ROOM
NAME). THE ALARM
MAY SOUND.”
“BE AWARE, THERE’S
CARBON MONOXIDE
IN THE (ROOM NAME).
THE ALARM MAY
SOUND.”
(ALARM SOUND)
“EMERGENCY. THERE’S
SMOKE IN (ROOM NAME).”
(ALARM SOUND)
“EMERGENCY. THERE’S
CARBON MONOXIDE IN
(ROOM NAME). MOVE
TO FRESH AIR NOW.”
BLUE rotates.
YELLOW pulses.
YELLOW pulses.
RED pulses.
RED pulses.
Press the Nest button.
Nest Protect will walk you
through next steps.
Stand under Nest Protect
and press the Nest button
to silence the alert. Then
put out the source of
the smoke.
Stand under Nest Protect
and press the Nest button
to silence the alarm. Open
a window or door to get
fresh air, then find the CO
leak and stop it.
Get out of the
house immediately.
1) Keep calm and open all
doors and windows.
2) Stop using all
fuel-burning appliances
and ensure that they are
turned off.
3) Evacuate the premises
if the CO alarm
continues to sound.
4) Call 999 or the fire
brigade from outside.
OPERATING INSTRUCTIONS
When the Nest Protect smoke and carbon monoxide (CO) alarm has something to say, it will speak to you
in words and colours instead of just beeping. It has two kinds of alerts: Heads-Up and Emergency Alarms.
• Nest Protect can see smoke or carbon monoxide levels rising. So before it turns on an Emergency
Alarm, Nest Protect gives you a friendly spoken Heads-Up to warn you in advance. It pulses yellow
and speaks to you, telling you what and where the danger is.
• When smoke or carbon monoxide reach dangerous levels, Nest Protect tells you where the
emergency is and pulses red, in addition to making a loud alarm sound. This is an Emergency Alarm.
