Converters.TV 475 User manual

Video to SXGA Converter Box
ID#475
Operation Manual

Introduction
The Video to SXGA Converter Box is a composite video
signal. S-Video signal and YCbCr signal format converter
for AV S stem (Such as DVD. VCD, VCR, Camcorder, CCD
etc.) to PC monitors with a DVI Cable or VGA single cable
and have high qualit SXGA resolution \ outputs. It is
connected between a standard personal computer (PC) and
PC monitor, or connected video game consoles (such as
Pla station 3, Pla station 2, WII, Game Cube , Microsoft
XBOX360, XBOX, Nintendo 64 etc.) at the same time.
Especiall , DVI out made to maximize the qualit for our
ultra-high-end video displa s such as HDTV, EDTV. Plasma
Displa .
Feature :
1. Compatible with multi-signal inputs : S-Video. AV,
YCbCr and PC
2. Provides a high qualit picture, it can reduce a sharp
and stable image output to VGA or DVI-D
3. Resolution : 640'480 / 800'600 / 1024'768 /
1280'1024 (VGA. SVGA, XGA. SXGA)
4. Compact bod and eas installation, no need uncover
PC case. No PC compatibilit problem.
5. Just Plug-and-pla can work on CRT or LCD-TFT
monitors. with or without a computer. It can provide
cheaper and better native picture solution than HDTV
and PDP media.
6. Support function (OSD) control and volume
adjustable in front plane

Connection
1 . Connect the VGA cable to the [Displa card] connecting
port on the PC s stem and the Video to SXGA Converter
Box [VGA-IN I To PC]
2.Connect the VGA cable with the monitor, another end to
the [VGA-OUT / To Monitor] on the Video to SXGA
Converter Box.
Video to SXGA
Converter Box

•If our Monitor possesses DVI-D IN, ou can use DVI
cable to connect the Video to SXGA Converter Box
[DVI-D OUT] with High qualit displa effect.
3. Connect the Stereo Pin Jack Cable to the [SPEAKER]
output port of the PC s stem and another end to (AUDIO-
IN) on the Video to SXGA Converter Box.
4. Connect the end of our earphone or speaker cable to
the [AUDIO-OUT] on the Video to SXGA Converter Box
5. Connect the AV. S-Video. Component cable from our
gaming console, DVD, VCR or other AV devices to either
the [RCA-IN, S-V IN or YPbPr IN] of the Video to SXGA
Converter Box.
•Please make sure our gaming console or AV device
is connected.
6. Connect the AC to DC adapter on to [DC +5V] Jack on
the Video to SXGA Converter Box and plug the adapter
into the electricit outlet.
•If ou loss our packaging adapter, please use high
qualit UL approval adapter with the same
specification as DC +5V 1A
Operation Control
and Function
The Video to SXGA Converter Box handles various formats
of traditional TV video, such as NTSC, PAL and also
accepts digital-analog video signal input such as AV, S-
Video and YCbCr. The Video to SXGA Converter Box
implements several proprietar video processing
technologies to improve video qualit , which includes input
mode detection, noise filtering, bandwidth expansion, de-
interlacing, anti-flickering, line-doubling, image scaling,
frame rate conversion and man other image enhancement
features.

1 VGA INPUT To PC
2 VGA OUTPUT To Monitor
3 RED LED displa Power indication
4 Standard Button action (UP / DOWN / LEFT / RIGHT) and OSD
Operation menu
A : TOP Button
Power control and video functions selection
button-used to turn
on the power to the VIDEO mode and turn
off power to the PC
mode. It is the function switch when the
device is under VIDEO mode
B : RIGHT Button Volume adjustable I ; use to increase
monitor function
C UNDER Button
OSD menu select when the device is under
VIDEO mode
Brightness, Contrast. Color, Hue,
Sharpness. Picture, Mode,
Resolution, Frequenc and Reset
D LEFT Button Volume adjustable - ; use to reduce
monitor function
5 DVI-D OUTPUT Connect our DVI-D cable to our monitor
6 AUDIO OUT Using our earphone or store cable to
connect
7 AUDIO IN Connect the store cable to Speaker output
port from our PC s stem
8 DC IN Power suppl input port
9 S-VIDEO INPUT Connect our S-Video cable from our
device
10 YPbPr INPUT Connect our Component cable from our
devices
11 RCA INPUT Connect our RCA cable from our devices

Specification
1. Proprietar scan rate conversion engine : 60 KHz and 75
KHz output signal specification selectable
2. Proprietar scaling engine :
●Programmable non-linear high order scaling engine
can be optimized for an diminution and expansion
ratio
●Independent expansion ratio in both horizontal
and vertical direction
●Support both down and up scaling
3. Advanced video enhancement processor
●Non-linear 16:9 conversion
●24 bit digital RGB/YCbCr
●Programmable sharpness and peaking
enhancement
●Color transient improvement
4. Color Processing
●Build-in color space converter
●Programmable gamma correction for different
color temperature and contrast
●Digital brightness. saturation and hue color
controls
5. INPUT port
●VGA in
●S-VIDEO in
●AUDIO in
●Y,Pb,Pr in
●RCA in
6. OUTPUT port
●VGA output
●AUDIO out
●DVI-D out
