Cookworks EM820CFD User manual

Model: EM820CFD
Read these instructions carefully before using your microwave oven. By following
these instructions carefully your oven will provide you with many years of excellent
service.
MICROWAVE OVEN
IMPORTANT
• WARNING: if the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person;
• WARNING: it is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy;
• WARNING: liquids and other food must not be heated in a sealed
container since they are liable to explode;
• WARNING: only allow children to use the oven without supervision when
adequate instruction have been given so that the child is able to use the
oven in a safe way and understands the hazards of improper use.
Specifications
Model:
Power Source:
Microwave Power Consumption:
Maximum Output:
Oven Capacity:
Turntable Diameter:
External Dimensions (L x W x H):
Net Weight:
EM820CFD
230V~50Hz
1270 Watt
800 Watt
20 litres
Ø 245 mm
440mm x 340mm x 258.5mm
Approx. 10.7 Kg
CAREFULLY RETAIN THESE INSTRUCTIONS
User Instructions - Please keep for future reference
User Instructions - Please keep for future reference
800W
E
1

SAFETY INSTRUCTIONS
1. The oven must be placed on a level surface.
2. The turntable and turntable ring assembly must always be used in the oven during cooking. Place the cookware gently on
the turntable and handle it carefully to avoid possible breakage.
3. Incorrect use of dish for browning food may cause turntable to break.
4. Use only the specified bag size when using pre-prepared popcorn.
5. The oven has several built-in safety switches to ensure that the power remains off when the door is open. Do not tamper
with these switches.
6. Do not operate the microwave oven when empty. Operating the oven with no food or food that is extremely low in moisture
can cause fire, charring or sparking.
7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause the turntable to break.
8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur which could cause scalding when
feeding the baby.
9. Do not heat narrow-necked containers, such as syrup or sauce bottles.
10. Do not attempt to deep-fry in your microwave oven.
11. Do not attempt home canning in this microwave oven as it is impossible to be sure all contents of the jar have reached
boiling temperature.
12. Do not use this microwave oven for commercial purpose. This microwave oven is made for household use only.
13. Caution : Stir the liquid prior to and during heating / reheating, let liquid stand for at least 10 seconds after cooking and always
take care when adding ingredients to hot liquids.
14. Check the food in the microwave oven frequently to avoid burning due to overheating.
15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface which could adversely affect the
life of the appliance and possibly result in a hazardous situation.
16. Stand at arm's length when opening the door to avoid scalding when steam or hot air is released.
17. ALWAYS allow an appropriate standing time after the oven has switched off according to the food being cooked to allow
heat to distribute evenly throughout the food.
18. Use oven gloves when removing any cookware from oven to reduce chance of being burned or scalded.
19. Read and follow the specific: "precautions for avoiding possible exposure to excessive microwave energy".
20. As with most cooking appliances, close supervision is necessary to reduce the risk of a fire in the oven cavity.
If a fire should start or smoke is observed:
a. Keep the oven door closed.
b. Turn the oven off and unplug the appliance.
21. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after
microwave heating has ended.
22. Do not overcook food. Regularly observe the oven if paper, plastic, or other combustible materials are used in the oven.
23. Do not use the oven cavity for storage purposes. Do not store items such as bread, cookies, paper products, etc. inside the
oven.
24. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.
25. This oven must be earthed. Connect only to properly earthed outlet. See "earthing installation".
26. Install or locate this oven in accordance with the installation instructions provided.
27. Use this appliance only for its intended uses as described in the manual. Do not use corrosive chemicals or vapours in this
appliance. This oven is specifically designed to heat or cook food. It is not designed for industrial or laboratory use.
28. Never allow children to use the oven without supervision unless adequate instructions have been given so that the children
are able to use the oven in a safe way and understand the hazards of improper use.
29. If the supply cord or plug is damaged, or if the oven is not working properly or has been dropped it must be replaced or
repaired by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
30. This appliance should be serviced only by qualified service technicians. Contact the nearest authorised service facility for
examination, repair or adjustment.
31.. Do not cover or block any vents on the oven.
32. Do not store or use this appliance outdoors.
33. Do not use this oven near water, near a kitchen sink, in a wet basement or near a swimming pool.
34. Do not immerse cord or plug in water.
35. Keep cord away from heated surfaces.
36. Do not let cord hang over edge of table or counter.
37. When cleaning door and oven surfaces use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.
38. There must be more than 30cm free or open space above the top surface of the oven.
39. Do not attempt to repair the oven yourself, please consult an authorised expert.
40. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be carefully
checked before consumption, in order to avoid burns.
41. Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to
microwave energy. It is important not to try and override or tamper with the safety interlocks.
42. Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no
damage to the, (1) door (i.e. door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door seals and
sealing surfaces.
43. Utensils should be checked to ensure that they are suitable for use in microwave ovens.
44. The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
45. The lamp holder must be serviced by an authorised service agent.
46. The oven should be cleaned regularly and any food deposits removed.
47. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
48. Do not use steam cleaners inside the cavity.
49. During use the appliance becomes hot. Care should be taken to avoid touching heating elemetns inside the oven.
50. This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
51. The appliances are not intended to be operated by means of an external timer or separate remote-control system.
2

Warming Up Heating 12
Microwave Auto Function 10
Defrost 10
Guarantee 18
Earthing Installation 17
Important Notes 16
Questions And Answers 16
Troubleshooting And Maintenance 15
Cleaning Your Microwave Oven 14
Child Safety Lock Function 13
Checking Stage Of Cooking 13
3
CONTENTS
PAGE
Specifications 1
Safety Instructions 2
Contents
Materials You Can Use In Microwave Oven 4
Materials To Avoid Using In Microwave Oven 4
Utensils 4
Oven Components And Accessories 5
Turntable Installation 5
Installing Your Oven 6
Microwave Cooking Principles 6
Microwave Food Packaging Symbols
Operating Your Microwave Oven 7
3
6
Microwave Cooking 7
Clock Setting 9
Speedy Microwave Cooking 8
Multi-stage Cooking 8
Pre-Set Function 9

CAUTION
Personal Injury Hazard
Tightly-closed containers could explode. Closed containers should be opened and plastic pouches pierced before cooking.
See above for further instructions "Materials you can use in microwave oven or to be avoided in microwave oven." There may be
certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question by following the
procedure below.
Utensil test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the utensil is warm, do not use if for microwave cooking.
4. Do not exceed 1 minute cooking time.
May cause arcing. Transfer food into microwave-safe dish.
Utensils Remarks
Aluminium tray
Food carton with metal handle
Metal or metal-trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may cause arcing.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Expanded polystyrene may melt or contaminate the liquid inside when exposed to high
temperature.
Wood will dry out when used in the microwave oven and may split or crack.
Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry
to prevent overcooking.
Remarks
Aluminium foil
Arcing can occur if foil is
too close to oven walls.
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking bags
Paper plates and cups
Paper towels
Parchment paper
Plastic
Plastic wrap
Thermometers
Wax paper
The foil should be a least 1 inch
(2.5cm) away from oven walls.
Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic
wrap to touch food.
Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage cause the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant
and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or
chipped dishes.
Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to
escape.
Use for short-term cooking/warming only. Do not leave oven unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for short-term cooking
only.
Use as a cover to prevent splattering or as a wrap during steaming.
Microwave-safe only. Follow the manufacturer's instructions. Should be labelled "Microwave Safe".
Some plastic containers soften as the food inside gets hot. "Boiling bags" and tightly closed
plastic bags should be slit, pierced or vented as directed by package.
Microwave-safe only (meat and sugar thermometers).
Use as a cover to prevent splattering and retain moisture.
4
MATERIALS YOU CAN USE IN MICROWAVE OVEN
UTENSILS
Utensils
MATERIALS TO AVOID USING IN THE MICROWAVE OVEN

5
fig. 2
TURNTABLE INSTALLATION
SETTING UP YOUR OVEN
OVEN COMPONENTS AND ACCESSORIES
fig.1

Microwave Symbols:
On the front of your oven there is a microwave symbol, as shown below. This
symbol has been introduced for your benefit when cooking or reheating
packaged food.
Packaged food is also increasingly using a microwave symbol similar to the one
below.
When you see this symbol on food packaging the cooking instructions are based
on either IEC Power Output Rating, on the Reheating Categories A,B,C,D or E.
1. The microwaves generated by the magnetron are evenly distributed through the food as the glass turntable revolves.
This ensures that the food is cooked uniformly.
2. The microwaves are absorbed by the food up to a depth of approximately 1 inch (2.5cm). Cooking continues as the heat is
dissipated through the food.
3. Cooking times will vary according to the recipe and the density, weight and water content of the food. The cooking time will
also vary according to the temperature at the start of cooking, i.e. depending on whether the food is frozen or not.
WARNING: Do not install microwave oven over a range
cooktop or other heat-producing appliance. If installed
above a heat producing appliance the microwave oven
could be damaged and the warranty would be void.
WARNING: Do not install microwave oven in a cupboard.
Carefully remove all packing materials and accessories.
Examine the oven for any damage such as dents or broken door.
Do not install if oven is damaged in any way.
Cabinate: Remove any protective film found on the on the outer surface.
Do not remove the light brown Mica cover that is attached to oven cavity
to protect the magnetron.
INSTALLATION
1. Select a level surface that provides enough clear space for the intake
and/or outlet vents (see Fig. 3).
A minimum clearance of 3.0 inch (7.5cm) is required between
the oven and any adjacent wall. One side must be clear.
1. Leave a minimum clearance of 12 inch (30cm) above the oven.
2. Do not remove the feet from the bottom of the oven.
3. Blocking the intake and/or outlet openings can damage the oven.
4. Place the oven as far away from radios and televisions as possible.
Operation of microwave oven may cause interference to your radio
or televisions reception.
5. Plug your oven into a standard household outlet. Be sure the voltage
and the frequency is the same as the voltage and the frequency on the
rating label.
E
800W
6
INSTALLING YOUR OVEN
Microwave cooking principles
MICROWAVE FOOD PACKAGING SYMBOLS
LESS HEATING TIME
MORE HEATING TIME
A, B, C, D or E

7
OPERATING YOUR MICROWAVE OVEN
1 . MICROWAVE COOKING
1) Press " " once to select the microwave cooking, continue to press " "
to select the required microwave power until the required power setting is reached.
2) Input the cooking time by pressing on the number buttons.
3) Press " " to start cooking.
1) Press " " twice to microwave power 80%.
2) Press "2", "0", "0", "0" to set the cooking time to 20 minutes.
3) Press " " to start cooking.
4) When the cooking is finished, the oven will beep 5 times.
No. of time to press
on " " button
1
2
3
4
5
Always remember that cooking instructions are intended only as a guide. If you have
followed the instructions and the food is still not piping not throughout, simply return it to the
oven and cook it until it is.
Display
P100
P 80
P 50
P 30
P 10
Microwave
power level
100%
80%
50%
30%
10%
Microwave power chart
Example: Setting cooking time of 20 minutes on power 80%.

2 . MULTI-STAGE COOKING
8
3 . SPEEDY MICROWAVE COOKING
This microwave can be set up to 2 stages cooking.
Example: cook with 100% microwave power for 10 minutes + 50% microwave power for
5 minutes.
The steps are as following:
1) Press " " once to choose 100% microwave power;
2) Press "1", "0", "0", "0" to set the cooking time of 10 minutes;
3) Press " " three times to choose 50% microwave power;
4) Press "5", "0", "0" to set cooking time of 5 minutes;
5) Press " " to start cooking.
Note : (1) If one of the stages is defrosting, the defrost cooking will be started at the 1st
stage automatically.
(2) The buzzer will ring once after each stage and the next stage will begin.
Example: Set 3 minutes speedy cooking:
1) Press " " once to start cooking, LED will display "0:30".
2) Press " " again for 4 times, the cooking time will be 3 minutes.
In standby, press " " to start cooking with 100% microwave power for 30 seconds.
If the remaining cooking time is less than one minute and 30 seconds, each press on
" " button will increase 30 seconds.
If the remaning cooking time is more than one minute and 30 seconds, each press on
" " button will increase 1 minute. The maximum cooking time is 12 minutes.

9
Your microwave oven is equipped with a clock. You must set the clock when you first install
your oven or after a power failure.
1) Press " ", "00:00" will be displayed and it is a 24 hours clock.
2) Press number buttons to set the hour and minute.
3) Finally, press " " and the time will be set.
For example: Set the time to 12:12pm.
1) Press " ";
2) Press "1", "2", "1", "2" to input the hour and minute and it displays "12:12";
3) Press " " and the time will be set.
Note: 1) ":" will flash when time has been set.
2) During the process of clock setting, if you press " ", the oven will go
back to the previous status automatically.
5 . PRE-SET FUNCTION
Please ensure the clock has been set. If the clock is not yet set, please follow the
section of "Clock Setting" to set the clock. The pre-set function cannot be activated if the
clock is not set.
Example: set cooking time at 12:12
1) Set cooking procedure;
To cook the food with 80% microwave power for 15 minutes.
a. Press " " twice to choose 80% microwave power and it displays "P80";
b. Press "1", "5", "0", "0" to set the cooking time to 15 minutes;
c. Be careful do not press " " to start the cooking;
2) Press " " and current time will display;
3) Press "1", "2", "1", "2" to set pre-set cooking time at 12:12.
4) Press " " to confirm the setting and the cooking will start at 12:12.
When the set time arrives, the buzzer sounds twice and cooking begins.
Note:
1) After the pre-set has been set, press " ", it will display the start time for the
pre-set cooking.
2) Press " " twice to cancel the preset function.
4 . CLOCK SETTING

6 . DEFROST
7 . MICROWAVE AUTO FUNCTION
This function help you to heat up the food under the microwave cooking.
A. Defrost By Weight
Example: Defrost beef of 500g:
(1) Press " ", LED will display "dEF1".
(2) Press "5", "0", "0" in order, "g" will light, the range of defrosting weight is 100g-2000g.
(3) Press " " to start defrosting.
B. Speedy Defrost
Example: Defrost beef of 500g
(1) Press " ", LED will display "dEF2".
(2) Press "5" "0" "0" in order, "g" will light, the range of defrosting weight is 100g-1200g.
(3) Press " " to start defrosting.
10
This auto function has nine pre-programmed cooking. You do not need to set either
cooking times or the power level. The table below shows the time taken to cook weight of
food.
1). In standby states, select auto setting by pressing number buttons "1 to 9". It will display
A-1 to A-9 respectively.
2). Continue to press the same number button to select the weight. i.e. portion / gram.
3). Press " " to start cooking
4). When the cooking is finished, the oven will beep 5 times.

Auto menu Chart
Menu Weight(g) Press Times Display
A-1
Auto Reheat
A-2
Vegetable
A-3
Fish
A-4
Meat
A-5
Pasta
A-6
Potato
A-7
Pizza
A-8
Soup
A-9
Sea Food
150
250
350
400
150
350
500
150
250
350
400
450
150
300
450
600
50(with cold water 450g)
100(with cold water 800g)
150(with cold water 1200g)
1 portion (230g)
2 portion (460g)
3 portion (690g)
1 portion (80g)
2 portion (160g)
3 portion 240g)
500
750
1000
550
1100
Once
Twice
Thrice
4 times
Once
Twice
Thrice
Once
Twice
Thrice
4 times
5 times
Once
Twice
Thrice
4 times
Once
Twice
Thrice
Once
Twice
Thrice
Once
Twice
Thrice
Once
Twice
Thrice
Once
Twice
150
250
350
400
150
350
500
150
250
350
400
450
150
300
450
600
50
100
150
1
2
3
1
2
3
500
750
1000
550
1100
Power
100%
100%
80%
100%
80%
100%
100%
80%
100%/50%
11

WARMING UP, HEATING
Times stated are approximate and can vary depending on the quality, size of the chopped pieces, storage temperature and moisture
content of the foodstuff. It is advisable to set a shorter cooking time at first, and then if necessary continue the cooking process, until
the food is cooked to your satisfaction.
Foodstuff Quantity Output Level Time (Mins) Remarks
Liquids
Milk, 1 cup 150g P100 (=100%)
Water/Coffee/Milk 1 cup 150g P100 (=100%)
0.5 - 1
2. - 1
Caution: Stir the liquid prior to and during heating/
reheating, let liquid stand for at least 10 seconds
after cooking and always take care when adding
ingredients to hot liquids.
Caution: Stir the liquid prior to and during heating/
reheating, let liquid stand for at least 10 seconds
after cooking and always take care when adding
ingredients to hot liquids.
One-course meals/ 450g P100 (=100%) Cover.
Ready-to-serve meals
Soups 250g P100 (=100%) Stir.
Stews 500g P100 (=100%) Stir between times.
Meat / Poultry
Roast 250g P100 (=100%)
Rissoles/Meatballs 500g P100 (=100%)
1/2 Chicken 450g P100 (=100%) Lightly brush with oil.
Vegetables
Portion x 1 150g P100 (=100%) Cover, stir.
Portions x 2 300g P100 (=100%) Cover, stir.
Side Dishes
Noodles 150g P100 (=100%) Dampen slightly beforehand, cover, stir.
Rice 150g P100 (=100%) Dampen slightly beforehand, cover, stir.
Potatoes 500g P100 (=100%) Cover.
Baby Food approx, 200g P100 (=100%) Stir well, check the temperature.
Meat
Beef, Pork in one piece 500g P80 (= 70%) Cover, turn halfway through cooking, leave to stand.
for 3-5 minutes.
Lightly smoked pork loin 500g P80 (= 70%)
Meatloaf P100 (=100%)
Sausages 200g P80 (= 70%) Pierce skin with fork.
Poultry
Chicken 1000g P100 (=100%) Cover, turn once, leave to stand for 5 minutes.
Pieces of Chicken 250g P80 (=70%)
Fish
Fresh fish 300g P80 (= 70%) Cover, turn once, leave to stand for 3 minutes.
Fillet of fish 300g P80 (= 70%) Cover, turn once, leave to stand for 3 minutes.
Frozen fish 400g P100 (=100%) Cover, leave to stand for 3 minutes.
Vegetables, fresh
Cauliflower, broccoli, fennel 150g P100 (=100%) Chop vegetables into small pieces, cook with liquid,
(3-5 tablespoons), stir in between times leave to stand
for 3-5 minutes, add spices, (salt before serving).
French beans 500g P100 (=100%)
Potatoes, boiled potatoes 500g P100 (=100%)
Jacket potatoes 500g P100 (=100%) Prick the jacket for boiling potatoes.
Carrots 500g P100 (=100%)
Vegetables, deep frozen Take note of details on the packaging.
Leaf spinach 300g P100 (=100%) Cover, add some liquid, stir in between times, leave to
stand for 3 - 3 minutes.
Peas 300g P100 (=100%)
Leeks 200g P100 (=100%)
Carrots 200g P100 (=100%)
Brussel sprouts 250g P100 (=100%)
Spinach 150g P100 (=100%)+
P 30 (= 30%)
Deserts
Pudding/Flummery 500g P100 (=100%)
2 - 3
4 - 5
5 - 7
4 - 5
8 - 10
8 - 10
10 - 12
8 - 10
10 - 12
8 - 10
10 - 12
7 - 9
10 - 12
6 - 8
6 - 8
3 - 4
20 - 22
6 - 8
4 - 6
1 - 2
3 - 5
2 - 3
3 - 4
3 - 4
1 - 2
2 - 4
1 - 2
1 - 2
3 - 4
1 - 2
11 - 14
12 - 15
12 - 15
20 - 25
Caution: Stir the liquid prior to and during heating/
reheating, let liquid stand for at least 10 seconds
after cooking and always take care when adding
ingredients to hot liquids.
Water 500g P100 (=100%) 3 - 5
12

11 . CHECKING STAGE OF COOKING
12 . CHILD SAFETY LOCK FUNCTION
(1) While cooking press " ", it will display the current power, i.e. P100, after three
seconds, it will revert to the former time count down.
(2) While in standby with pre-set cooking, press " ", it will display the start time
for the pre-set cooking, i.e. 12:00, after 3 seconds, it will revert to current time display.
(3) While cooking press " ", it will display the current time, i.e. 15:12, after 3
seconds, it will revert to the former time count down.
Lock: In waiting state, press " " for 3 seconds, a long "beep" will be heard
denoting entering into the children-lock state and " " will be displayed.
Unlock: In locked state, press " " for 3 seconds, a long "beep" will be heard
denoting that the lock is released and the " " will go out.
13

Attention
Your microwave oven should be cleaned regularly to prevent grease and food particles from building up on the inside
surface. The accumulated grease / food particles may cause a fire hazard.
It is important to clean the interior of your microwave oven after each use.
To clean the oven interior, use a mild detergent solution, such as washing-up liquid, with warm water on a soft cloth.
It is suggested to place half a lemon in a bowl and add 300ml water inside the oven. Then heat it on 100% microwave
power setting for 10 minutes. Wipe the oven clean with a soft, dry cloth.
IMPORTANT:
ALWAYS switch off oven and unplug from power supply.
ALWAYS use a branded cleaning spray, and for stubborn spots inside the oven, spray a small amount of cleaner onto a damp cloth.
DO NOT SPRAY DIRECTLY INSIDE THE OVEN.
Removable Parts
1. The turntable may be cleaned at the sink. Be careful not to chip or scratch the edges as this may cause the turntable to break during
use.
2. The turntable roller rest should be cleaned regularly.
3. Do not immerse the turntable glass in cold water.
Special Care
For best performance and safety, the inner door panel and the oven front frame should be free of food residue. To prevent damage to
the operating parts inside the oven, water should not be allowed to seep into the ventilation openings.
14
CLEANING YOUR MICROWAVE OVEN

NORMAL CONDITION
Microwave oven interfering with TV reception.
Radio and TV reception may be interfered with when microwave oven is in operation. It is similar to the interference of small electrical
appliances such as food mixers, vacuum cleaners and electric fans. This is normal.
Oven light dim.
In low power microwave cooking, oven light may become dim. This is normal.
Steam accumulating on door, hot air out of vents.
In cooking, steam may come out of food. Most will come out from vents but some may condense on cool places such as the oven door.
This is normal.
Oven started accidentally with no food in.
Although starting the oven with no food in it should be avoided, it does no damage to the oven provided it is only operated empty for a
very short time. It is advised that a glass or microwave safe container of water is always left in the oven to absorb any heat should the
oven be turned on accidentally.
MAINTENANCE
Troubleshooting
Check for problems by using the chart below. If the microwave oven still does not work properly, contact the nearest authorised service
centre.
15
TROUBLESHOOTING AND MAINTENANCE
PROBLEM
Oven will not start
POSSIBLE CAUSE
a. Plug not secure in power socket, or not switched on.
b. Door is open.
c. Wrong operation is set.
Arcing or sparking a. Materials which should be avoided in microwave oven are used.
b. The oven is operated when empty .
c. Spilled food remains in the cavity.
Unevenly cooked food a. Materials which should be avoided in microwave oven are used.
b. F ood is not defrosted completely.
c. Power setting for cooking time is incorrect.
d. Food is not turned or stirred.
Overcooked food Power setting for cooking time is incorrect.
Undercooked food
a. Materials to be avoided in microwave oven are used.
b. F ood is not defrosted completely.
c. Oven ventilation ports are restricted.
d. Power setting for cooking time is incorrect.
Incomplete defrosting
Noise comes from
turntable when oven
is turned on
Oven light does not
glow
a. Materials to be avoided in microwave oven are used.
b. P ower setting for cooking time is incorrect.
c. Food is not turned or stirred.
a. Food residue exists between the turntable roller rest and
cavity bottom.
a. The light bulb has burned out, a new bulb must be fitted by
a qualified service engineer .
b. START has not been pressed.

1. Before first using this oven please read this instruction manual and keep it carefully.
2. Do not attempt to repair the oven yourself, please consult an authorised expert.
3. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature should be carefully checked
before consumption, in order to avoid burns.
4. Check the oven and the cable regularly for damage. If there is any kind of damage, the oven should not be used.
Warning:
a. It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any
cover which gives protection against exposure to microwave energy.
b. Never allow children to use the oven without supervision unless adequate instructions have been given so that the children are able
to use the oven in a safe way and understand the hazards of improper use.
c. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to
avoid a hazard.
NOTE
• Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave
energy. It is important not to try and override or tamper with the safety interlocks.
• Carefully clean door seals and sealing surfaces.
• Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to
the, (1) door (i.e. door is not bent or dented), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces.
• Utensils should be checked to ensure that they are suitable for use in microwave ovens.
• When heating food in plastic or paper containers, check the oven frequently to avoid any possibility of ignition.
• Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.
• If smoke is observed, switch off or unplug the appliance immediately and keep the door closed in order to stifle any flames.
• Eggs in their shells and whole hard-boiled eggs should not be heated in microwave ovens since they may explode.
• If the door or door seals are damaged the oven must not be operated until it has been repaired by a trained person.
• Liquids or other foods must not be heated in sealed containers since they are liable to explode.
• Warning: Children should only use this oven under adult supervision.
• When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
• The temperature of accessible surfaces may be high when the appliance is operating. The surfaces are liable to get hot during use.
Keep cord away from heated surface, and do not cover any events on the oven.
• Children should be supervised to ensure that they do not play with the appliance.
• The appliances are not intended to be operated by means of an external timer or separate remote-control system.
BULB REPLACEMENT
If the interior light bulb fails, it can be easily replaced by a qualified service engineer. Do not attempt to remove
the outercasing, as this will expose live components. Please consult a qualified service engineer.
Q: When the oven is plugged into a wall outlet for the first time, it does not work properly. What's wrong?
A: The microcomputer used in the oven control may temporarily become scrambled and fail to function as programmed. Unplug the
oven from the wall outlet and then plug it back in. The microcomputer will then reset for proper functioning.
Q: Why is there noise coming from the oven when using a lower power level?
A: When cooking with power other than 100%, the oven automatically switches on and off to obtain the correct power output. The
clicking noise can be heard when the oven switches on and off. This is normal
Q: Why is there steam coming out of the air exhaust vent?
A: Steam is produced during cooking. The microwave oven has been made to vent this steam.
Q: What is wrong when the oven light will not glow?
A: There may be several reasons why the oven light will not glow. The light bulb has burned out or START has not been pressed.
Q: Why do eggs sometimes burst?
A: The egg yolk may burst because of steam build-up inside the membrane. Pierce the membrane with a toothpick before cooking it.
Never microwave eggs in the the shell as they may explode.
Q: How is boiling over avoided?
A: Use a larger utensil than usual for cooking. If you open the oven door or touch STOP/CLEAR, the food will stop boiling.
16
IMPORTANT NOTES
QUESTIONS AND ANSWERS

This appliance must be earthed. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for
the electric current. This appliance is equipped with a cord having a
grounding wire with a earthing plug. The plug must be plugged into an outlet
that is properly installed and earthed.
Consult a qualified electrician or serviceman if the earthing instructions are not
completely understood or if doubt exists as to whether the appliance is
properly earthed. If it is necessary to use an extension cord, use only a 3-wire
extension cord that has a 3 pin earthing plug, and a 3-slot socket which will
accept the plug.
1. A short power -supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
2. If an extension cord is used:
a. The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
b. The extension cord must be earthed, a 3-wire cord.
c. The extension cord should be arranged so that it will not drape over the
worktop or tabletop where it can be pulled on by children or tripped over
accidentally.
Check that the voltage marked on the product corresponds with your
supply voltage.
This product is fitted with a 13 A plug complying with BS1363. If this plug
is unsuitable or needs to be replaced, please note the following:
Important: The wires in the mains lead are coloured in accordance with
the following code:
GREEN / YELLOW – EARTH,
BLUE – NEUTRAL, BROWN – LIVE
For UK use only
Plug fitting details (where applicable):
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug proceed as follows:
The GREEN/YELLOW wire is the EARTH and must be connected to the
terminal which is marked with the letter (E) or by the earth symbol or
coloured GREEN or GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to the terminal
marked with the letter (N) or coloured BLACK.
The BROWN wire is the LIVE and must be connected to the terminal
marked with the letter(L) or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 13A fuse
conforming to BS1362 and be ASTA approved.
If in doubt contact a qualified electrician.
DANGER
Electric Shock Hazard
Touching some of the internal components
can cause serious personal injury or death.
Do not disassemble this appliance.
WARNING
Electric Shock Hazard
Improper earthing can result in electric shock.
Do not plug into an outlet until appliance is
properly installed and earthed.
Three pin earthed plug
Properly polarised and earthed outlet.
17
EARTHING INSTALLATION

PRODUCT GUARANTEE
This product is guaranteed against manufacturing defects for a period of
This product is guaranteed for twelve months from the date of original purchase. Any
defect that arises due to faulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer
from whom you purchased the unit.
The guarantee is subject to the following provisions:
-  The guarantee does not cover accidental damage, misuse, cabinet parts, knobs
or consumable items.
-  The product must be correctly installed and operated in accordance with the
instructions contained in this manual.
-  It must be used solely for domestic purpose.
-  The guarantee will be rendered invalided if the product is re-sold or has been
damaged by inexpert repair.
-  Specifications are subject to change without notice.
-  The manufacturer disclaims any liability for the incidental or consequential damages.
-  The guarantee is in addition to, and does not diminish your statutory or legal rights.
Guarantor: Argos Ltd
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
Year
