COOL HEAD VRX 18/38S/S User manual

P2M005STD-Ver1.2
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manual de instrucciones
Manual de instruções
Istruzioni d’uso
GB
DE
FR
ES
PT
IT

1 P2M005STD-Ver1.2
GB

P2M005STD-Ver1.2 2
GB
Dear Customer,
Congratulations on your purchase of this product.
Please take a few minutes before starting operation of the appliance and read the following operating
instructions.
Table of Contents
Product Overview ............................................................................................................... 3
Safety Tips........................................................................................................................... 4
Intended Use ...................................................................................................................... 5
Location and Installation .................................................................................................... 6
Operation............................................................................................................................ 7
Cleaning, Care & Maintenance......................................................................................... 10
Optional Accessory ........................................................................................................... 11
Troubleshooting................................................................................................................ 12
Disposal............................................................................................................................. 13
Technical data................................................................................................................... 14
Warranty........................................................................................................................... 14

3 P2M005STD-Ver1.2
GB
Product Overview
Article Description
Horizontal Showcase –Glass Top
Horizontal Showcase –Lids Top

P2M005STD-Ver1.2 4
GB
Safety Tips
IMPORTANT: For your safety read the manual
carefully before installing or using this product. Save
this manual for future reference.
Consult Local and National Standards to comply with the following:
1. Health and Safety at Work Legislation
2. Fire Precautions
3. IEE Wiring Regulations
4. Building Regulations
5. DO NOT use the appliance outside.
6. DO NOT attempt to service the item yourself.
7. DO NOT use damaged appliances. If you are in any doubt, consult service
agent.
8. DO NOT use electrical appliances inside the appliance (e.g. heaters, ice-
cream makers etc.), unless they are of the type recommended by the
manufacturer.
9. Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
10.DO NOT use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
11.DO NOT damage the refrigerant circuit.
12.DO NOT stand or support yourself on the base, drawers or doors.
13.DO NOT allow oil or fat to come into contact with the plastic components
or door seal. Clean immediately if contact occurs.
14.This unit can be used by children aged above 8 years and persons with
reduced physical, sensory or mental capabilities or lacking of experience
and knowledge who have been given supervision or using instruction of
the device and understand the resulting risks (for European market).
15.Do not let children play with the appliance.
16.Cleaning and user maintenance must not be carried out by children
without supervision.
17.DO NOT place combustible, explosive or volatile articles, corrosive acids
or alkalis or liquids in the appliance.

5 P2M005STD-Ver1.2
GB
Safety Tips
18.DO NOT use this appliance to store medical supplies.
19.DO NOT use jet/pressure washers to clean the appliance.
20.DO NOT allow children to play with the packaging, and dispose plastic
bags safely.
21.Bottles that contain a high percentage of alcohol must be sealed and
placed vertically in the refrigerator.
22.Always carry, store and handle the appliance in a upright orientation and
move by holding the base of the appliance.
23.Always switch off and disconnect the power supply to the unit before
cleaning.
24.If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
25.This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety
(for market beyond European).
26.Children should be supervised to ensure that they do not play with the
appliance.
27.For indoor use only. Not suitable for installation in an area where a water
jet could be used. Shall not be cleaned by a water jet.
28.To guarantee safe operation, ensure that the appliance is set up and
connected as described in the instruction manual.
29.Any repairs and work on the appliance should only be carried out by the
customer service department/ qualified technician.
30.The key to the electrical cabinet should be kept out of the reach of
children and users.
31.Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
Intended Use
Only use this appliance for cooling and storage of food for commercial purposes.

P2M005STD-Ver1.2 6
GB
Location and Installation
Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are
thoroughly removed from all surfaces. To prevent injury or damage to the unit, we recommend that the
appliance should be unpacked and set up by two people.
The climatic class can be found on the rating plate. It specifies the ambient temperatures at which the
appliance may be operated. The rating plate can be found inside the appliance.
Climate Class
Max. Ambient Temperature
Relative Humidity
3
25
60%
4
30
55%
5
40
40%
Maintain a distance of 20 cm (7 inches) between the appliance and walls or other objects for ventilation.
Increase this distance if the obstacle is a heat source.
The appliance should be placed on a solid flat and stable floor to reduce noise and vibration. Level the
appliance by adjusting the feet.
Avoid locating the unit in direct sunlight or near heat sources such as ovens or radiators.
Please make sure the appliance is properly ventilated.
Check that the power supply and voltage used comply with the details on the rating plate. The plug
must be accessible after installation.
Correctly connect and disconnect the plug. When inserting ensure the plug is fully engaged. While
unplugging hold the body of the plug. Never pull the supply cord directly.
If the unit is to be shut down for long period, switch it off and disconnect the plug from socket outlet.
Clean the appliance and leave the door open to prevent odour.
Important! For your personal safety, this appliance must be properly grounded (earthed). This
appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be
inserted into an outlet that is properly grounded and installed. Consult a qualified electrician or service
centre if you do not completely understand the grounding instructions. If doubt exits whether the
appliance is properly grounded, have a qualified electrician check the circuit to make sure the outlet is
properly grounded.
If the cable does not reach the nearest socket, either rearrange your store layout or ask a qualified
electrician to fix a new socket.
If power is cut off, wait for at least 3 minutes before restarting the appliance to avoid damaging the
compressor.
Slide the shelf/drawer into place.
Note: If the unit has not been stored or moved in an upright position, let it stand upright for
approximately 12 hours before operation.
Note: Before using the appliance for the first time, clean the shelves and interior with soapy water.

7 P2M005STD-Ver1.2
GB
Operation
Storing food
To get the best results from your appliance, follow these instructions:
Only store foodstuffs in the appliance when it has reached the correct operating temperature.
Ensure GN container bays are full at all times, even if the GN containers are unused or empty.
Empty bays will greatly reduce efficiency of the appliance.
Always close the door, lid or drawer when not in use.
Do not place uncovered hot food or liquid inside the appliance.
Wrap or cover food where possible.
Do not obstruct the fan inside the appliance.
Avoid opening the doors for prolonged periods of time.
The food must be put into container before placed into cabinet or on the shelf. Food must not be
placed into food cabinet directly.
Turn on
Close the door of the appliance.
Ensure the power switch is set to [O] then connect to the power outlet.
Switch on the Power [I]. The current temperature within the appliance is displayed.
The on the control panel will flash to indicate a delay to compressor start.
Open/ Close the lid or drawer
Lift the lid up and back so the hinge settles into the support slot.
Lift the lid up and completely back so the GN container trays are completely exposed.
WARNING: The sliding lid does not have a locking mechanism. Always make sure that the lid is in the ‘half-
open’ position before opening.
WARNING: Do not pull the drawer out of its full open position to avoid any hurt.

P2M005STD-Ver1.2 8
GB
Operation
Temperature Setting and Control (Dixell)
The front panel of the thermostat display:
1. Defrost indicator
2. Compressor operation indicator
3. SET key
4. Temperature modification keys
5. Defrost button
How to see the set point
• Push and immediately release the SET key, the set point will be showed;
• Push and immediately release the SET key or wait about 15s to return to normal visualisation.
How to change the set point
• Push the SET key for more than 2 seconds to change the set point value;
• The value of the set point will be displayed and the “°C” starts blinking;
• To change the set value push the „ “ (up) or “ ” (down) arrows within 15s.
• To memorise the new set point value push the SET key again or wait 15s.
Automatic defrost
• The appliance will automatically run defrost cycles.
Note: The cycle starts from the time the appliance is initially powered up.
Manual Defrost:
• Press and hold the DEFROST button for 5 seconds.
• The defrost cycle will start immediately and the Defrost LED illuminates.
Note: Starting a manual defrost also resets the automatic defrost timer.

9 P2M005STD-Ver1.2
GB
Operation
Temperature Setting and Control (Dixell)
The front panel of the thermostat
display:
1. Defrost-/ Light Key (Light key only
active in glass door models)
2. SET Key
3. UP- Key
4. Stand By-/ DOWN Key
LED
Mode
Function/ Explanation
ON
Compressor Operation Indicator
Flashing
Compressor Start Delay Indicator
ON
Defrost enabled
Flashing
Drip time in progress
ON
Fan Operation Indicator
Flashing
Fan Delay Indicator (After Defrost)
ON
Alarm Indicator
ON
Light Indicator (active on glass door)
ON
Measurement Unit Indicator
Flashing
Programming Mode
ON
Stand By Mode (Compressor OFF, Light and
fan function with normal operation)
How to switch the unit from Stand By Mode to ON mode / How to switch the unit from ON Mode to Stand By mode
• Press and hold the Standby key for 3s.
How to see the set point
• Push and immediately release the key, the set point is displayed.
• Push and immediately release the key or wait about 15s to return to normal visualisation.
How to change the set point
• Push the key for more than 2 seconds to change the set point value
• The value of the set point will be displayed and the “ ” starts blinking
• To change the set value push the “ “ (up) or “ ” (down) arrows within 15s.
• To memorise the new set point push the key again or wait for 15s.
Automatic defrost
• The appliance will automatically run defrost cycles.
Note: The defrost timer starts from the time the appliance is initially powered up.
Manual Defrost:
• Press and hold the “ ” DEFROST button for 5s.
• The defrost cycle will start immediately and the Defrost LED illuminates.
Note: Starting a manual defrost resets as well the automatic defrost timer.
How to turn ON / OFF the light
• Press and release the key, to switch the light ON or OFF.
Note: Light function is active only for glass door models.
How to see recorded MINIMUM and MAXIMUM temperatures
• Press and release the “ “ or “ ” key. The recorded MIN (“Lo”)/MAX (“Hi”) temperature of the last 24h is displayed.
• To reset the record press for 3s while the MIN or MAX temperature is displayed.
How to Lock and Unlock the keyboard
• Press both “ “ and “ ” key at the same time for more than 3s. The display shows “PoF”/ “Pon” to indicate that the keyboard is
locked/ unlocked.
Alarm Code Description:
• P1 –Room probe failure, P2 –Evaporator probe failure, HA –Max.temperature alarm, LA –Min. temperature Alarm, H2 –Max.
temperature alarm 3rd Probe, L2 –Min temperature alarm 3rd probe, EA –External Alarm, CA –Serious external alarm, dA –Door open
alarm, HF –Defrost alarm.
