INSTALLATION INSTRUCTION -- ‘’CL’’ HEATING CABLE
READ CAREFULLY BEFORE BEGINNING INSTALLATION
1. Clean the room.
2. Make sure that the floor surface is free of any irregularities
3. The heating cable length must not be altered, cutted or shortened . However the cold lead
can be cut to desired length. The identification label must be reattached for future identification.
4. All Copal’s Heating Cables are fabricated of high quality materials and have been tested prior to
shipping. Refer to the identification label at the end of the cold lead concerning the voltage and
the cable type. It is recommended making a reading with an ohmmeter. The ohmmeter reading
should match the resistance printed on the identification label.
Installation
The installation needs two (2) concrete casting. Install prepunched strapping as per Drawing #1.
Provide enough prepunched strapping to ensure that the cables remain in place during the casting. It
is recommended to cover the cables with 1½ ‘’ to 2’’ of concrete.
The cables must never cross an expansion joint.
Drawing #1
6. Connections
Use cable at voltage specified on the Identification label. Copal’s heating cable is an electrical
appliance and should be installed by a professional electrician. Its installation is under strict
standards issued by electrical and building codes (national and/or local)
The heating cable must be control by an electronic thermostat which sensor install in a ½’’ diameter
flexible PVC conduct at the floor level. The Electrical Code requires a Ground Fault Circuit Interrupter
(GFCI) be used on the branch supply circuit for shock safety and fire protection.




Caution :
 The cables cannot be crisscrossed or overlapped.
 Avoid twisting the heating cable during the installation .
 Avoid shocks and injuries on the cable duct.
 Keep an 8" space in front of existing heating sources.
 Do not install under furniture that would prevent air dispersion.
 It is important that each cable be grounded properly ( see drawing #2).
 Do not energize heating cables until concrete has thoroughly cured.
 Do not used rubber or vinyl backing carpets.
 Wrong voltage, even brief, applied on the heating cable would damage it.
Testing :
Verify heating cable continuity BEFORE and AFTER concrete pour. Using a minimum 1000 volts
insulation meter.
*Available sizes
THE CL TYPE HEATING CABLES
# Câble Linear feet WATTS VOLTS
CL100 59 299 240
CL140 76 389 240
CL175 98 490 240
CL450 145 725 240
CL850 186 938 240
CL700 215 1072 240
CL800 245 1237 240
CL1100 325 1626 240
CL1500 445 2232 240
CL1550 470 2357 240
CL1800 500 2560 240
CL2050 636 3235 240
CL2800 845 4260 240
* Also avalable in 208volts et 347volts
Drawing #2
WARRANTY :
COPAL warrants to the original purchaser its heating cables against all defects relative to parts or labour for a
10-year period from the date of purchase for installation.
COPAL commits itself to replace any cable that could be found defective relative to parts or labour during the
said period of 10 years provided that a written notice to this effect is forwarded to Copal within the prescribed
delay. Such repair or replacement is and will be COPAL’S SOLE OBLIGATION. Distribution and regulation
equipment is subject to manufacturer’s warranty rules and is normally not covered by this present warranty.
Please follow manufacturer’s recommendations to install such equipment.
