Staubli PV-KST4 UR Series User manual

1/12
PV-KST4/2.5...-UR
PV-KST4/6...-UR
PV-KST4/10...
PV-KBT4/2.5...-UR
PV-KBT4/6...-UR
PV-KBT4/10...
PV-KBT4/5...-UR
PV-KBT4/8II-UR
PV-KST4/5...-UR
PV-KST4/8II-UR
PV-SVK4
32.0717
PV-BVK4
32.0716
MA000 (de_en)
Montageanleitung
MA000 (de_en)
Assembly instructions
MA231 (cn_en)
安装说明
MA231 (cn_en)
Assembly instructions
PV 公电缆连接器 PV-KST4/...-UR
PV 母电缆连接器 PV-KBT4/...-UR
PV male cable coupler PV-KST4/...-UR
PV female cable coupler PV-KBT4/...-UR
目录
安全须知2
所需工具3
存放注意事项4
连接器选型指南 ......................................................................... 5
电缆准备5
压接7
安装检查9
插入和拔出
- 无安全锁扣PV-SSH4 10
- 有安全锁扣PV-SSH4 10
安装注意事项��������������������������������������������������������������������������������������������11
技术参数12
Content
Safety Instructions �����������������������������������������������������������������������2
Tools required............................................................................. 3
Notes on storage........................................................................ 4
Guideline for connector configuration.......................................... 5
Cable preparation ....................................................................... 5
Crimping..................................................................................... 7
Assembly check ......................................................................... 9
Mating and disconnecting the cable coupler
- without safety lock clip PV-SSH4 ........................................... 10
- with safety lock clip PV-SSH4 ................................................ 10
Notes on installation ..................................................................11
Technical data .......................................................................... 12
公电缆连接器/Male cable coupler
母电缆连接器/Female cable coupler
可选件/Optional
PV-SSH4
安全锁扣/Safety lock clip
(见/see www.staubli.com/electrical --> MA252)
保护帽/Sealing caps

2/12
安全须知 Safety instructions
安装说明的重要性
不遵守安装说明和安全须知可能会导致因电击、电弧、火灾或系
统故障而危及生命的人身伤害。
• 请完全按照安装说明的要求进行操作。
• 只可按照本安装说明和技术参数使用和安装产品。
• 安全妥善地保管安装说明，并将其移交给后续用户。
Importance of the assembly instructions
NOT following the assembly and safety instructions could result
in life-threatening injuries due to electric shock, electric arcs, fire,
or failure of the system.
•Follow the entire assembly instructions.
•Use and install the product only according to this assembly
instructions and the technical data.
•Safely store the assembly instructions and pass them on to
subsequent users.
应用范围
该连接器对光伏阵列直流 (DC) 电路中的部件进行电气连接。
该连接器可用于光伏阵列以外的用途，例如，可作为低压直流
(LVDC) 部件。如果该部件被用于其他用途，则要求和规格可能与
本文件中描述的有所不同。
• 要了解更多信息，请联系史陶比尔。www.staubli.com/electrical
Intended use
The connector electrically connects components within the DC
circuits of a photovoltaic array.
The connector can be used for purposes other than those in
a photovoltaic array, e.g., as a LVDC component. If the com-
ponent is used for other purposes, then the requirements and
specifications may be different from the ones described in this
document.
•For more information, contact Stäubli
www.staubli.com/electrical
对人员的要求
仅电工或接受过电气指导的人员可以装配、安装和调试该系统。
• 电工是指接受过适当的专业培训，并具有适当的知识和经验的
人员，能够识别和避免可能来自电力的危险。电工能够选择和
使用合适的个人防护设备。
• 受过电气指导人员是指在电工的指导或监督下，能够识别和避
免可能来自电力的危险的人员。
Requirements for personnel
Only an electrician or electrically instructed person may assem-
ble, install, and commission the system.
•An electrician is a person with appropriate professional
training, knowledge, and experience to identify and avoid the
dangers that may originate from electricity. An electrician is
able to choose and use suitable personal protective equip-
ment.
•An electrically instructed person is a person who is instructed
or supervised by an electrician and can identify and avoid the
dangers that may originate from electricity.
安装和装配的先决条件
• 切勿使用有明显损坏的产品。
• 仅应使用史陶比尔认可的工具和程序。
• 仅经过认证的光伏电缆才可装配到连接器上。
Prerequisites for installation and assembly
•NEVER use an obviously damaged product.
•ONLY tools and procedures approved by Stäubli shall be
used.
•ONLY approved PV-cables shall be assembled to the connec-
tor.
安全装配和安装
隔离或断开连接后，带电部件仍然通电
• 只有在光伏阵列或光伏组串断电的情况下才能安装本产品。
Safe assembly and mounting
Live parts can remain energized after isolation or disconnection
•ONLY Install the product when the photovoltaic-array or -string
is de-energized.
连接或断开连接
• 在连接或断开连接器之前，一定要切断光伏系统的电源。
• 切勿切断有负载的连接器。
• 切勿将史陶比尔连接器的公端或母端与其他制造商的连接器
相连接。
Mating and disconnecting
•ALWAYS de-energize the photovoltaic system before mating
and disconnecting the connectors.
•NEVER disconnect the connectors under load.
•NEVER connect male or female part of Stäubli connector with
connectors of other manufacturers.
切勿调整或修理部件。
• 连接器仅可安装一次。
• 切勿在连接器装配好后进行调整。
• 更换有缺陷的部件。
Do NOT modify NOR repair component
•Mount connector only once.
•Do NOT modify connectors after assembly.
•Replace defective connectors.

3/12
1
2
PV-MS-PLS PV-MS
3
Tab. 1
所需工具 Tools required
（图 1）
剥线钳 PV-AZM
(ill. 1)
Stripping pliers PV-AZM...
导线截面积
Conductor cross section
型号
Type
订货号
Order No.
mm2AWG
1.5/2.5/4/6 – PV-AZM-156 32.6027-156
4/6/10 – PV-AZM-410 32.6027-410
注意： 操作说明 MA267，
wwwstaublicom/electrical
Note:
Operating instructions MA267,
www.staubli.com/electrical
（图 2）
组装和解锁工具
PV-MS-PLS，订货号 326058
或
开口扳手套件 PV-MS
订货号 326024
(ill. 2)
Assembly and unlocking tool
PV-MS-PLS, Order No. 32.6058
or
Open-end spanner set PV-MS,
Order No. 32.6024
注意： 操作说明 MA270，
wwwstaublicom/electrical
Note:
Operating instructions MA270,
www.staubli.com/electrical
（图 3）
压接钳 PV-CZM包括定位块和压接模
具。
(ill. 3)
Crimping pliers PV-CZM... incl. locator
and crimping die.
注意: 操作说明 MA251，
wwwstaublicom/electrical
Note:
Operating instructions MA251,
www.staubli.com/electrical
型号 Type 导线截面积 Conductor cross section
压接钳
Crimping pliers
PV-CZM-19100 32.6020-19100 PV-CZM-22100 32.6020-22100 PV-CZM-23100 32.6020-23100 PV-CZM-20100 32.6020-20100 PV-CZM-21100 32.6020-21100
PV-KBT4/2,5...-UR,
PV-KST4/2,5...-UR
2.5 mm2•
14 AWG •
PV-KBT4/6...-UR,
PV-KST4/6...-UR
4 mm2• • •
12 AWG • • •
6 mm2• • •
10 AWG • • •
PV-KBT4/5...-UR,
PV-KST4/5...-UR
14 AWG •
12 AWG •
10 AWG •
PV-KBT4/8II-UR,
PV-KST4/8II-UR 8 AWG • •
PV-KBT4/10II,
PV-KST4/10II 10 mm2• •
选择压接钳 Assign the crimping pliers die and locator accor-
ding to the connector chosen
注意： 有关定位块和压接模具的相关信息，请查看操作说明 MA251,
wwwstaublicom/electrical
Note:
For crimping die and locator information, please see the ope-
rating instructions MA251, www.staubli.com/electrical
表1

4/12
5
6
7
4
8
（图 4）
PV-WZ-Torque-Set,
订货号 32.0065
(ill. 4)
PV-WZ-Torque-Set,
Order No. 32.0065
（图 5）
测试棒 PV-PST
订货号 326028
(ill. 5)
Test plug PV-PST
Order No. 32.6028
（图 6）
开口扳手 15 mm
(ill. 6)
Open-end spanner wrench 15mm
（图 7）
扭矩扳手 12 mm（1/2" 驱动尺寸）
(ill. 7)
Torque wrench 12mm (1/2” drive)
（图 8）
电缆钳PV-WZ-KS,
订货号 326080
(ill. 8)
Cable cutter PV-WZ-KS,
Order No. 32.6080
注意: 操作说明 MA705，
wwwstaublicom/electrical
Note:
Operating instructions MA705,
www.staubli.com/electrical
存放注意事项 Notes on connectors and components storage
史陶比尔建议将连接器部件存放在温度-30°C 至 60°C，相对湿度
小于70%的恒温环境中。
部件不能暴露在因降雨、霜降等造成的潮湿环境中。
确保单个部件不与酸、碱、汽油、丙酮或其他任何可能影响材质性
能的腐蚀性化学物质接触。
满足以上条件，则部件自出厂之日起最多可存放两年。
Stäubli recommends to store connector components at a pref-
erably constant temperature range between -30 °C and +60 °C
and relative humidity of less than 70 %.
The components must not be exposed to moisture due to direct
rainfall, condensation, etc.
Ensure that individual components do not get into contact with
acids, alkalis, gases, acetone or any other aggressive chemical
substances, which might impact the material performance.
Once all these storage conditions are met the components could
be stored up to two years behind manufacturing.

5/12
连接器选型指南 Guideline for connector configuration
注意： 如果所用电缆直径位于两个规格的临界值，请使用较小的密
封圈。
Note:
Please use the smaller sealing if the cable diameter used is
between two limits.
电缆准备 Cable preparation
对于 IEC 应用，可以连接符合 IEC 60228 5 类或 6 类的柔性电缆。
对于 UL 应用，务必应用 B 类或以上的电力电缆。
For IEC applications cables with flexible conductors of class 5
or 6 according to IEC 60228 shall be connected. For the UL ap-
proved range applications power cables of class B or higher shall
be connected.
注意：
建议使用镀锡导线。切勿使用无保护（外露*）或已生锈的导
线。 所有史陶比尔光伏电缆均具有高品质的镀锡导线。出于
安全考虑，史陶比尔禁止使用 PVC 电缆或 H07RN-F 型号的未
镀锡电缆。
Attention:
Used tinned copper conductors. Do not use uncoated
(bare*) nor already oxidized conductors. All Staubli solar
cables have high-quality, tinned conductors. For safety rea-
sons, Stäubli prohibits the use of PVC cables and the use of
non-tinned cables of type H07RN-F.
* 以下产品可以接受使用外露的铜电缆（B 类或以上）：
PV-KBT4/5…-UR, PV-KST4/5…-UR, PV-KBT4/8II-UR 和
PV-KST4/8II-UR
* It is acceptable to use bare copper conductors, class B or high-
er with the following products: PV-KBT4/5…-UR, PV-KST4/5…-
UR, PV-KBT4/8II-UR and PV-KST4/8II-UR
(图 9)
检查尺寸 A 和 b，参见第 5 页的表 2 和第 6 页的表 3。
(ill. 9)
Check dimensions A and b, see Tab. 2 on page 5 and tab. 3 on
page 6.
注意： 若有使用表2和表3未提及直径的电缆，请联系史陶比尔。
Note:
In case that other diameters than those mentioned in Tab. 2
and Tab. 3 are used contact Stäubli.
9
表2/Tab. 2
A: ø 电缆直径范围 [mm]
A: ø range of the cable [mm]
导线截面积
Conductor cross section
2.5 mm24 mm26 mm210 mm2
5.0 – 6.0 PV-KxT4/2,5I-UR PV-KxT4/6I-UR PV-KxT4/6I-UR PV-KxT4/10I
5.5 – 7.4 PV-KxT4/2,5X-UR PV-KxT4/6X-UR PV-KxT4/6X-UR PV-KxT4/10X
7.0 – 8.8 PV-KxT4/2,5II-UR PV-KxT4/6II-UR PV-KxT4/6II-UR PV-KxT4/10II
b: 控制尺寸
b: control dimension ~4 mm ~5.8 mm ~6.5 mm
TÜV-Rheinland认证的连接器选型 Choose connector configuration verified by TÜV-
Rheinland
连接到连接器的电缆应适用于光伏系统且应符合 IEC 62930 的要
求。
Cables connected to the connector shall be suitable for use in
photovoltaic systems and shall comply with the requirements of
IEC 62930.
注意： 在选择光伏电缆时需要考虑以下事项：
- 光伏电缆的护套材料必须符合 IEC 60664-1 中 1 级绝缘标准的
规定。
Note:
Following topic needs to be considered when selecting the PV
cable:
- The sheath material of the PV cable has to meet insulation
class 1 according to IEC 60664-1.

6/12
10
L
表4/Tab. 4
使用UL认证电缆时的连接器选型 Selection of connector configuration when using
cables certified at UL
连接到连接器的电缆应适用于光伏系统且应符合 ZKLA（PV-线）或
TYLZ (USE-2) 的要求
Cables connected to the connectors shall be suitable for use in
photovoltaic systems and shall comply with the requirements of
ZKLA (PV-wire) or TYLZ (USE-2).
* 首选导线铜丝：19-65 * preferred conductor stranding: 19-65
注意: 如果您选择的电缆同时适用于表2和表3列出的选型并且符合
第12页的技术参数，您可以将其作为双认证电缆（TÜV Rheinland
和UL）来使用。
Note:
If your chosen cable is suitable for both configurations listed in
Tab. 2 and 3 as well as in the technical data on page 12, it can
be used as a double certified cable according TÜV Rheinland
and UL.
表3/Tab. 3
额定电压 [V] DC
Rated voltage [V] DC 导线截面积/Conductor cross section
AWG (stranding)
A: ø 电缆直径范围 [mm]
A: ø range of the cable [mm]
ZKLA (PV-wire) TYLZ (USE-2) 14 12 10 8
600/1000/1500 600 19-49 7-49 7-65 * 7-65 7-78 * 7-78 7-168
5.60 – 6.20 4.80 – 6.20 PV-KxT4/2,5I-UR PV-KxT4/5I-UR PV-KxT4/6I-UR PV-KxT4/5I-UR PV-KxT4/6I-UR PV-KxT4/5I-UR
6.20 – 7.00 6.20 – 7.00 PV-KxT4/2,5X-UR PV-KxT4/5X-UR PV-KxT4/6X-UR PV-KxT4/5X-UR PV-KxT4/6X-UR PV-KxT4/5X-UR
7.00 – 8.60 7.00 – 8.60 PV-KxT4/2,5II-UR PV-KxT4/5II-UR PV-KxT4/6II-UR PV-KxT4/5II-UR PV-KxT4/6II-UR PV-KxT4/5II-UR
5.95 – 8.00 8.30 – 8.56 PV-KxT4/8II-UR
b: 控制尺寸
b: control dimension 4 mm ~3 mm 5.8 mm ~3 mm 5.8 mm ~3 mm ~4.4 mm
型号/Type 长度/Length “L“
PV-KxT4/2,5... 6 mm – 7.5mm
PV-KxT4/6... 6 mm – 7.5mm
PV-KxT4/5... 8.5 mm – 10mm
PV-KxT4/8... 8.5 mm – 10mm
PV-KxT4/10... 6 mm – 7.5mm
（图 10）
根据表 4 提及的范围，剥掉电缆的绝缘层
（长度 L），并检查。
(ill. 10)
Strip cable insulation (length L) accord-
ing to ranges mentioned in Tab. 4 and
check.
注意：
剥离电缆时切勿切断单股铜丝！
Attention:
Do not cut single strands when
stripping the cable!

7/12
11
C
12
K
B-Crimp
O-Crimp
压接 Crimping
（图 11）
用于压接开口压接式插针 (B-Crimp)
PV-KT4/2.5...-UR；PV-KXT4/6...-UR
或 PV-KXT4/10...
• 打开并握住夹钳 (K)。
• 将插针置于适当的截面积范围内。
• 向上旋转压接片 (C)。
• 松开夹钳 (K)。
• 压接完成。
(ill. 11)
For crimping open crimp contacts
(B-Crimp)
PV-KxT4/2.5...-UR; PV-KxT4/6...-UR
or PV-KxT4/10...
•Open clamp (K) and hold tight.
•Insert the contact in the appropriate
cross-section range.
•Turn the crimping flaps (C) upwards.
•Release clamp (K).
•The contact is locked.
（图 12）
用于压接闭合压接式插针 (O-Crimp)
PV-KxT4/5...-UR oder PV-KxT4/8II-UR
将插针置于适当的截面积范围内。
(ill. 12)
For crimping closed crimp contacts
(O-Crimp)
PV-KxT4/5...-UR or PV-KxT4/8II-UR
Place the contact in the appropriate
cross-section range.
对于 PV-KxT4/5... 和PV-KxT4/8...:
将插针置于合适的定位块位置，根据导
线截面积进行压接。
For PV-KxT4/5... and PV-KxT4/8...:
Place contact into the appropriate
locator position, based on conductor
cross-section to be crimped.

8/12
13
14
15
16
B-Crimp
O-Crimp
（图 13）
在压接前，确保插针完全插入进定位块。
(ill. 13)
Make sure the contact is fully inserted
into the locator before crimping.
（图 14）
放置插针并固定到正确位置。
(ill. 14)
Press the pliers gently together until
the crimping flaps are properly located
within the crimping die.
（图 15）
插入剥皮后的电缆末端，使电缆铜丝与
插针的压接套充分接触。再压紧压接钳。
(ill. 15)
Insert the stripped cable end until the
lead strands come up against the
clamp.
Completely close the crimping pliers.
（图 16）
根据 IEC 60352-2 编写标准，目视检查
压接。
(ill. 16)
Visually check the crimp according to
the criteria written in IEC 60352-2.
请确认：
• 所有铜丝均插入压接套
• 压接套没有变形或缺失
• 压接形状对称
• 在连接侧或压接侧，导线可见。
Confirm that:
•all of the strands have been captured
in the crimp sleeve
•the crimp sleeve is not deformed or
missing any portion of the crimp flaps
•that the crimp is symmetrical
•a “brush” of conductor strands are
visible on the contact side of crimp.

9/12
17
18
19
0! >0
安装检查 Assembly check
（图 17）
将压接的插针插进公/母绝缘外壳，直至
啮合。
轻轻拉动导线，检查金属部分是否正确
连接。.
(ill. 17)
Insert the crimped contact into the
insulator of the male or female coupler
until engaged.
You will typically hear a “click” sound
once fully engaged.
Pull gently the cable to verify that the
metal part is correctly engaged.
（图 18）
将测试棒正确的一端最大限度地插入
公/母连接器。如果插针位置正确，测试
棒上的白色标记必须仍然可见。
(ill. 18)
Insert the appropriate end of the test pin
into the male or female coupler as far as
it will go.
If the contact is assembled properly the
white mark on the test pin must still be
visible.
（图 19）
• 使用工具 PV-MS 或 PV-MS-PLS，预先
拧紧电缆格兰头螺母。
• 使用PV-WZ 扳手组合拧紧电缆格兰头
螺母，同时使用 PV-MS 或 PV-MS-PLS
支撑绝缘体前端。
紧固扭矩须与使用的光伏电缆匹配。典
型值在 34 N m 与 35 N m 之间1)。
1) 史陶比尔建议使用校准的扭矩扳手进行组装。 根据 NFPA
国家电气规范 (NEC 2017)章节11014(D)要求使用校准的
扭矩扳手。
(ill. 19)
•Pre-tighten cable gland with tools
PV-MS or PV-MS-PLS.
•tighten cable gland using the
PV-WZ-Torque-Set while supporting
the insulator front with PV-MS or
PV-MS-PLS.
The tightening torque must be appro-
priate for the solar cables used. Typical
values are between 3.4 N m
and 3.5 N m1).
1) Stäubli recommends to use a calibrated torque
wrench for assembly.
The NFPA National Electric Code (NEC 2017)
requires the use of a calibrated torque wrench in
section 110.14(D).
注意 : 关于部件的安装我们建议在-15°C 至
+35°C的环境温度下进行。
Note:
For assembly of components an
ambient temperature between -15 °C
and +35 °C is recommended.
注意： 切勿将螺帽拧到底，需留有间隙。
Note:
Do not bottom out the capnut.

10/12
22
20
21
插入
（图 20）
将电缆耦合器互插直到听到“咔嗒”声为
止。轻轻拉动连接器以便确认是否正确
啮合。(最大拉力：20 N）。
Mating
(ill. 20)
Mate the cable coupler until a „Click“
can be heard. Check correct engage-
ment by lightly pulling on the connector
(maximum pulling force: 20 N).
拔出
（图 21）
将解锁工具 PV-MS 或 PV-MS-PLS 插入
插 座的卡夹（X）中，并解锁。
Disconnecting
(ill. 21)
Push the unlocking pins of PV-MS or
PV-MS-PLS onto the locking clips (X) of
the socket and separate the coupling.
插入
（图 22）
将电缆耦合器互插直到听到“咔嗒”声为
止。轻轻拉动连接器以便确认是否正确
啮合。(最大拉力：20 N）。
Mating
(ill. 22)
Mate the cable coupler until a „Click“
can be heard. Check correct engage-
ment by lightly pulling on the connector
(maximum pulling force: 20 N).
拔出
将解锁工具 PV-MS 或 PV-MS-PLS 推入
PV-SSH4 的开口中，插入插座的卡夹中，
并解锁。
Disconnecting
Push the unlocking pins of PV-MS or
PV-MS-PLS into the openings provided
in PV-SSH4 and onto the locking clips
of the socket and separate the coupling.
插入和拔出（无安全锁扣PV-SSH4） Mating and disconnecting the cable coupler
without safety lock clip PV-SSH4
注意：
不得安装未完全啮合的连接器，因为这可能会导致卡夹永久
偏移，进而丧失锁定功能。 无论何时都必须核实装配情况。
Attention
Assembly of not fully engaged connectors is not permitted
as this could lead to a permanent deflection of clips and thus
to a potential loss of the locking function.
The assembly has to be verified in any case.
配有 PV-MS
with PV-MS
插入和拔出（有安全锁扣PV-SSH4） Mating and disconnecting the cable coupler
when safety lock clip PV-SSH4 is involved

11/12
安装注意事项 Notes on installation
注意： 如果要将本连接器用于光伏阵列以外的低压直流应用，请查阅
《史陶比尔技术说明报告》中的信息。
Link
Note:
If the connector is to be used in low-voltage DC applications
other than those in a photovoltaic array, please consult the infor-
mation as provided in the Stäubli Technical Description Report.
Link
关于安装的一般注意事项
• 必须为未插合的连接器安装保护帽（插座端订购号320716；插
头端订购号 320717）以防止环境影响（湿气、灰尘等）。
• 切勿插合被污染的连接器。
• 连接器不得与任何化学品接触。
General notes on installation
•Unmated connectors must be protected from environmental im-
pact (moisture, dirt, dust, etc.) with sealing caps (socket order
no. 32.0716; plug order no. 32.0717).
•Do not mate contaminated connectors.
•Connectors must not come into contact with any chemicals.
电缆布线
电缆从连接器出来应预留至少20毫米距离再进行弯折。弯折请参
阅电缆制造商规格，获取最小弯曲半径。
Cable routing
Cable management must allow a minimum of 20 mm of cable
that exits directly from the cable seal without bending or stress.
Refer to cable manufacturers specification for minimum bending
radius.
被污染/损坏的连接器：
• 切勿让连接器受到环境污染（如土壤、水、昆虫、灰尘）。
• 切勿让连接器的表面受到污染（如贴纸、油漆、热缩管）。
• 切勿将连接器直接置于屋顶表面。
• 连接器不得位于电缆的最低点，此处会有水聚集。
• 连接器不得位于滞水中。
• 不得将电缆扎带直接安装在连接器本体上。
Contaminated/damaged connectors:
•Do not allow connectors to be contaminated by the environ-
ment (e.g. soil, water, insects, dust).
•Do not allow the connector to be contaminated on its surface
(e.g. stickers, paint, heat shrink tubing).
•Do not allow that the connector is directly on the roofing sur-
face.
•Do not allow that the connector is at the lowest point of cabling
where water can collect.
•Do not allow that the connector is in standing water.
•Do not allow that cable ties to be mounted directly on the
connector body.
机械压力：
• 检查确认连接器没有受到永久性机械拉伸负荷或振动的影响。
• 电缆不得使连接器受到应力。
Mechanical stress:
•Check that the connectors are not subjected to a permanent
mechanical tensile load or vibration.
•Connectors shall not be under strain from cable management.
Min.
20 mm

12/12
生产商/Manufacturer:
Stäubli Electrical Connectors AG
Stockbrunnenrain 8
4123 Allschwil/Switzerland
Tel. [phone]
Fax [phone]
mail [email protected]
www.staubli.com/electrical
© by Stäubli Electrical Connectors AG, Switzerland – MA231 – 01.2022 – Index f Marketing Communications –保留修改权利/Subject to alterations
技术参数 Technical data
型号 名称 Type designation MC4
连接系统 Connector system Ø 4mm
额定电压:
IEC 62852:2014 + Amd1:2020
2 PfG 2330/04.2013
UL 6703
Rated voltage:
IEC 62852:2014 + Amd1:2020
2 PfG 2330/04.2013
UL 6703
DC 1000V 1)
DC 1500V 1), 2)
DC 1500V 3)
额定电流 IEC (85 °C) Rated current IEC (85°C)
22.5A (2.5mm²)
39A (4mm²/6mm²)
45A (10mm2)
额定电流 (UL) Rated current (UL)
30A (14 AWG) 4)
35A (12 AWG) 4)
50A (10 AWG) 4)
70A (8 AWG) 4)
额定脉冲电压 Rated impulse voltage 12kV (DC 1000V)
16kV (DC 1500V)
环境温度范围 Ambient temperature range -40°C...+85°C (IEC)
-40°C...+85°C (UL)
运输/存储温度范围 Transportation/storage temperature range -30°C/+60°C
运输/存储相对湿度 Transportation/storage relative humidity < 70%
温度上限 Upper limiting temperature 105°C (IEC)
最大工作温度 MOT max. operating temperature +85 °C 4)
防护等级， 已插合
未插合
Degree of protection, mated
unmated
IP65/IP68 (1m, 1h)
IP2X
过压类别/污染等级 Overvoltage category/Pollution degree CAT III/3
连接器的接触电阻 Contact resistance of plug connectors 0.25mΩ
连接器公母极性 Polarity of the connectors 插座/Socket = 正极/positive
插头/Plug = 负极/negative
锁紧系统 Locking system Locking type
安全等级 (IEC) Safety class (IEC) II: DC 1000V
0: DC 1500V
连接系统 Contact system MULTILAM
连接类型 Type of termination 压接/Crimping
安全须知 Safety instruction 在负载下请勿断开
Do not disconnect under load
触头材料 Contact material 铜 、镀 锡 /Copper, tin plated
绝缘材料 Insulation material PC/PA
阻燃等级 Flame class UL94-V0
盐雾试验，严酷等级6 Salt mist spray test, degree of severity 6 IEC 60068-2-52
耐氨性（参考DLG） Ammonia resistance (according to DLG) 6076F (1500h, 70°C/70% RH, 750ppm)
获得 TÜV-Rheinland 认证，依据 IEC 62852:2014
+ Amd.1:2020
TÜV-Rheinland certified according to IEC
62852:2014 + Amd.1:2020 R 60127190
获得 TÜV-Rheinland 认证
依据 2 PfG 2330/04.2013
TÜV-Rheinland certified
according to 2 PfG 2330/04.2013 R 60087448
根据UL 6703获得UL认证。 UL certified according to UL 6703 E343181
根据UL 6703获得CSA认证。 CSA certified according to UL 6703 250725
JET 认证符合 IEC 62852:2014 标准 JET certified according to IEC 62852:2014 1625-C43O4-302
CQC 认证 CQC certified 2013003030Z
最高工作海拔高度符合 IEC 62852:2014 +
Amd.1:2020 的规定
Max. operating altitude above sea level accor-
ding to IEC 62852:2014 + Amd.1:2020 5000 m; AK 60159411
温度等级符合 IEC TS 63126:2020 的规定 Temperature Level according to
IEC TS 63126:2020 Level 2; AK 60158515
1) 连接到连接器的电缆应适用于光伏系统且应符合 IEC 62930 的要求。
Cables connected to the connector shall be suitable for use in photovoltaic systems and shall comply with the requirements of IEC 62930.
2) 只能用于配有限制进入通道的 PV 系统/Only for use in PV-systems with restricted access locations
3)有关适用的电缆外径，请参见本安装说明中的表3。/For applicable cable diameter please see table 3 in this assembly instructions.
4) 工程审议：与额定电流相关的应用场景必须经过终端使用产品的验证，且不得超过产品的最大工作温度。
Engineering considerations: Application associated current ratings have to be veri󽗉ed in the products end-use and shall not exceed the maximum operating tempera-
ture
