Cosmo ECC Series User manual

IMPORTANT SAFETY INSTRUCTIONS
Carefully and completely read the following installation instructions. Observe all
governing codes and ordinances. NOTE TO INSTALLER:Leave these instructions
with Consumer. NOTE TO CONSUMER:Keep these instructions in a safe place for
future reference. Product failure due to improper installation is not covered under
warranty agreement.
ECC SERIES INSTALLATION MANUAL
ECC SERIES
ELECTRICCOOKTOP
I N S P I R I N G T H E W O R L D ’ S K I T C H E N
INSTALLATION MANUAL

THANK YOU FOR YOUR PURCHASE! TABLE OF CONTENTS
COOKTOP SAFETY ......................................................................4
INSTALLATION REQUIREMENTS...........................................5-7
Tools and Parts...........................................................................5
Location Requirements...............................................................5
Product Dimensions ...............................................................5
Cabinet Dimensions ................................................................6
Electrical Requirements..........................................................6-7
INSTALLATION INSTRUCTIONS ..........................................8-11
Prepare Cooktop for Installation.................................................8
Install Cooktop........................................................................8-9
Make Electrical Connection...............................................10-11
Complete Installation ................................................................11
WARRANTY & SERVICE......................................................12-13

COOKTOP SAFETY INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools Required
Parts Included
Parts Required
■A UL listed or CSA approved connector for ½" (1.3 cm)
diameter conduit
■UL-listed wire connectors
Check local codes. Check existing electrical supply. See the
“Electrical Requirements” section.
It is recommended that all electrical connections be made by a
licensed, qualified electrical installer.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
When installing cooktop, use minimum dimensions given.
■To eliminate the risk of burns or fire by reaching over the
heated surface units, cabinet storage space located above
the surface units should be avoided. If cabinet storage is to
be provided, the risk can be reduced by installing a range
hood that projects horizontally a minimum of 5" (12.7 cm)
beyond the bottom of the cabinets.
■The cooktop must be a specified cooktop that is approved to
be installed either alone or over an undercounter built-in
oven. Check the cooktop base for an approved installation
label. If you do not find this label, contact your dealer to
confirm that your cooktop is approved.
■The cooktop must be installed in a level countertop.
■The cooktop should be installed away from strong draft
areas, such as windows, doors, fans or strong heating vents.
The cooktop should be located for convenient use in the
kitchen.
■Use the countertop opening dimensions that are given with
these Installation Instructions. Given dimensions are
minimum clearances and provide 0" (0 cm) clearance.
■Grounded electrical supply is required. See “Electrical
Requirements” section.
IMPORTANT: To avoid damage, check with your builder or
cabinet supplier to make sure that the materials used will not
discolor, delaminate or sustain other damage.
■Tape mea sure
■¼" (6.35 mm) nut driver
■Marker or pencil
■Pliers
■Flat-blade screwdriver
■Foam strip roll
■Clamping brackets (2)
■2½" (6.4 cm) clamping
screws (2)
A. Glass depth - 21 ¹⁄ ₂ " ( 54.6 cm)
B. Glass width -
24 "( 61.0 cm) models - 24 "( 61.0 cm)
Glass width - 30" (76.2 cm)
models -3 0 "( 76.2 cm)
Glass width - 36" (91.4 cm) models - 36" (
91.4 cm)
C. Frame depth -
19 ¹⁄
8" (
48.6 cm)
D. Frame width -
24 "( 61.0 cm) models - 2 1 7 ⁄
8" (
55.6 cm)
Frame width -
30 "( 76.2 cm) models - 27
13
⁄₁₆ " ( 70.6 cm)
E. Cooktop height -
213 ⁄
16"
(5.6 cm)
F. Cooktop height including conduit (located at rear of cooktop, right
side) -
3
3
⁄₄ " ( 9.5 cm)
A
B
D
F
E
C
Frame width - 36" (91.4 cm) models -
33
11
⁄₁₆ " ( 85.6 cm)
Product Dimensions
IMPORTANT:
Save for local electrical inspector's use.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING

INSTALLATION REQUIREMENTS
IMPORTANT: If installing a range hood or microwave hood
combination above the cooktop, follow the range hood or
microwave hood combination installation instructions for
dimensional clearances above the cooktop surface.
NOTES: After making the countertop cutout, some installations
may require notching down the base cabinet side walls to clear
the cooktop base. To avoid this modification, use a base cabinet
with sidewalls wider than the cutout.
If cabinet has a drawer, a 5¹⁄₂" (14.0 cm) depth clearance from the
top of the countertop to the top of the drawer (or other
obstruction) in base cabinet is required.
If codes permit and a separate ground wire is used, it is
recommended that a qualified electrical installer determine that
the ground path and wire gauge are in accordance with local
codes.
Check with a qualified electrical installer if you are not sure the
cooktop is properly grounded.
Make sure that the electrical connection and wire size are
adequate and in conformance with the National Electrical Code,
ANSI/NFPA 70-latest edition or CSA Standards C22.1-94,
Canadian Electrical Code, Part 1 and C22.2 No. O-M91-latest
edition, and all local codes and ordinances.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
Before You Make the Electrical Connection:
To properly install your cooktop, you must determine the type of
electrical connection you will be using and follow the instructions
provided for it here.
■A 3-wire or 4-wire, single phase, 120/240 volt, 60-Hz., AC
only electrical supply is required on a separate, 40-amp
circuit fused on both sides of the line. The model/serial
number rating plate is located on the metal cabinet
underneath the cooktop. See the following illustration.
The cooktop is rated 120/240 volt. Some models have a
neutral (white) wire.
A. 24" (61.0 cm) on 24" models; 30"(76.2 cm) on 30"models;
36"(91.4 cm) on 36"models
B. Combustible areaabove countertop (shown by dashed box above)
C. 30"(76.2 cm) minimum clearance between top of cooktop platform
and bottom of uncovered wood or metal cabinet (24"[61 cm]
minimum clearance if bottom of wood or metal cabinet is covered
by not less than
¹⁄₄ " [0.6 cm] flame retardant millboard covered with
not less than No. 28 MSG sheet steel, 0.015"[0.04 cm] stainless
steel, or 0.024"[0.06 cm] aluminum or 0.020"[0.05 cm] copper)
D. 13"(33 cm) recommended upper cabinet depth
E. 2"(5.1 cm)
F. 19 1
⁄
4"(
49.0 cm) recommended cutout.
Will fit in cutout from
19
1
⁄₈ "- 19
5
⁄₁₆ " ( 48.6 - 49.0 cm).
G. 18" (45.7 cm) minimum clearance from upper cabinet to countertop
within minimum horizontal clearances to cooktop
H. Junction box or outlet: 7" (17.8 cm) minimum from top of countertop
I. Junction box or outlet: 9" (23.0 cm) maximum from right side of
cabinet
27
15
⁄
16"(
71.0 cm) recommended cutout on 30" (76.2 cm) models.
Will fitin cutout from
27
13
⁄₁₆ "- 2 8" ( 70.6 - 71.2 cm) on 30" (76.2 cm)
models.
33
7
⁄
8" (
86.0 cm) recommended cutout on 36" (91.4 cm) models.
Will fit in cutout from
33
11
⁄₁₆ "- 33
15
⁄₁₆ " ( 85.6 - 86.2 cm) on 36" (91.4
cm) models.
K.
2" (5.1 cm) minimum distance to nearest left and right side
combustible surface above cooktop
L.
2" (5.1 cm) minimum clearance between back wall and countertop
D
A
E
I
J
K
G
H
L
C
F
B
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Use 8 gauge copper wire.
Electrically ground cooktop.
Failure to follow these instructions can result in death,
fire, or electrical shock.
J. 22" (
56.0 cm) recommended cutout on 24 " ( 61.0 cm) models.
Will fitin cutout from
21
7
⁄
8"-2
2
1
⁄
8" (
55.6 - 56.2 cm) on 24 "( 61.0 cm)
models.
■The cooktop should be connected directly to the junction box
through flexible, armored or nonmetallic sheathed, copper
cable. The flexible, armored cable extending from the fuse
box or circuit breaker box should be connected directly to the
junction box.
■Locate the junction box to allow as much slack as possible
between the junction box and the cooktop so that the
cooktop can be moved if servicing becomes necessary in the
future.
■Do not cut the conduit. Use the length of conduit provided.
■A UL listed or CSA approved conduit connector must be
provided at each end of the power supply cable (at the
cooktop and at the junction box). A listed conduit connector
is already provided at the cooktop.
■If the house has aluminum wiring, follow the procedure
below:
1. Connect a section of solid copper wire to the pigtail
leads.
2. Connect the aluminum wiring to the added section of
copper wire using special connectors and/or tools
designed and UL listed for joining copper to aluminum.
Follow the electrical connector manufacturer's recommended
procedure. Aluminum/copper connection must conform with
local codes and industry accepted wiring practices.
INSTALLATION REQUIREMENTS
Cabinet Dimensions
■
Electrical Requirements Electrical Requirements
A. Model/serial number plate
A

INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
1. Using 2 or more people, place cooktop right side up into the
cutout.
NOTE: Make sure that the front edge of the cooktop is
parallel to the front edge of the countertop. If repositioning is
needed, lift entire cooktop up from cutout to avoid scratching
the countertop.
2. Remove the selected bracket locations from the bottom of
the cooktop base.
3. Select bracket mounting location that will allow the bracket to
extend far enough out from the cooktop for the installation of
clamping screws.
4. Attach brackets to cooktop base bottom with bracket
clamping screws using the bracket mounting holes .
Securely tighten screws.
A. Cooktop
B. Cooktop base
C.
Clamping screw
D. Clamping bracket (extends far enough beyond
cooktop base to allow installation of clamping screws)
E.
Countertop
F.
Foam seal
A
B
CD
A
B
CD
F
1 1/8''
1 9/16 ''
(2)
(1) E
F
E
A
B
CD
F
E
Prepare Cooktop for Installation
Decide on the final location for the cooktop. Avoid drilling into or
severing existing wiring during installation.
1. Using 2 or more people, place the cooktop upside down on a
covered surface using the foam end posts from the
packaging. Make sure that the knobs are not resting on the
foam.
2. Remove foam strip roll from the package containing literature.
Remove the strip at a time and apply foam strip adhesive-
side down around bottom of the cooktop glass.
NOTE: The foam strip helps avoid damage to the underside
of the cooktop glass from debris and helps the cooktop sit
flat on uneven counters.
Install Cooktop
Style 1: Cooktop over undercounter built-in oven
IMPORTANT: Clamping brackets should not be used.
1. Using 2 or more people, place cooktop right side up into the
cutout.
NOTE: Make sure that the front edge of the cooktop is
parallel to the front edge of the countertop. If repositioning is
needed, lift entire cooktop up from cutout to avoid scratching
the countertop.
Style 2: Cooktop over cabinets
1. Determine whether your cabinet construction provides
clearance for installing clamping brackets at cooktop base
ends.
2. The clamping brackets must be installed after the cooktop
is placed into the cutout. Complete the following steps for
the option .
WARNING
Excessive Weight Hazard
Use two or more people to move and install cooktop.
Failure to do so can result in back or other injury.
Traditional knob models
A. Cooktop base bottom
B.
Clamping screw
C. Clamping bracket
Installing Brackets After Placing
Cooktop in Cutout
A. Cooktop base
B.
1⁄₁₆"
X 3⁄₁₆" ( 0.2X0.5 cm) Foam strip
C. Cooktop
A
B
C

INSTALLATION INSTRUCTIONS
3-Wire Cable from Power Supply to 3-Wire Cable from
Cooktop
IMPORTANT: Use the 3-wire cable from power supply where
local codes permit connecting the frame-ground conductor to
the neutral (white) junction box wire:
1. Disconnect power
2. Remove junction box cover, if present.
3. Connect the flexible cable conduit from the cooktop to the
junction box using a UL listed or CSA approved conduit
connector.
4. Tighten screws on conduit connector if present.
5. Connect the two black wires together using the UL listed wire
connectors.
6. Connect the two red wires together using the UL listed wire
connectors.
7. Connect the green or bare cooktop cable wires to the white
(neutral) wire in the junction box using the UL listed wire
connectors.
8. Install junction box cover.
9. Reconnect power.
1. Check that all parts are now installed. If there is an extra part,
go back through the steps to see which step was skipped.
2. Check that you have all your tools.
3. Dispose of/recycle all packaging materials.
4. Use a mild solution of liquid household cleaner and warm
water to clean cooktop before use. Dry thoroughly with a soft
cloth. For more information, see the “Cooktop Care” section
of the Use and Care Guide.
5. Read the “Cooktop Use” section in the cooktop Use and
Care Guide.
6. Reconnect power.
NOTE: If the cooktop does not work after turning on the power,
check that a circuit breaker has not tripped or a household fuse
has not blown. See “Troubleshooting” section in the Use and
Care Guide for further information.
If You Need Assistance or Service:
Please reference the “Warranty & Service” section of the User
Manual or contact the dealer from whom you purchased your
cooktop.
A. 3-wire cable from power supply
B. Red wires
C. Green or bare ground wire
(from cooktop)
D. 3-wire cable from cooktop
E. Junction box
F. White wire (from power supply)
G. UL listed wire connector
H. Black wires
I. UL listed or CSA approved
conduit connector
INSTALLATION INSTRUCTIONS
This cooktop is manufactured with a frame connected, green or
bare ground wire. Connect the cooktop cable to the junction box
through the UL listed or CSA approved conduit connector.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Use 8 gauge copper wire.
Electrically ground cooktop.
Failure to follow these instructions can result in death,
fire, or electrical shock.
4-Wire Cable from Power Supply to 3-Wire Cable from
Cooktop
IMPORTANT: Use the 4-wire cable from power supply where
local codes do not permit connecting the frame-ground
conductor to the neutral (white) junction box wire:
1. Disconnect power
2. Remove junction box cover if present.
3. Connect the flexible cable conduit from the cooktop to the
junction box using a UL listed or CSA approved conduit
connector.
4. Tighten screws on conduit connector, if present.
5. Connect the two black wires together using the UL listed wire
connectors.
6. Connect the two red wires together using the UL listed wire
connectors.
7. Connect the green or bare ground wire from the cooktop
cable to the green or bare ground wire (in the junction box)
using the UL listed wire connectors.
8. Put a UL listed wire connector on the end of the white wire.
NOTE: Do not connect the bare ground wire to the neutral
(white) wire in the junction box.
9. Install junction box cover.
10. Reconnect power.
A. 4-wire cable from power supply
B. Red wires
C. Green or bare ground wire
(from cooktop)
D. 3-wire cable from cooktop
E. Junction box
F. White wire (from power supply)
G. UL listed wire connector
H. Black wires
I. UL listed or CSA approved
conduit connector
Make Electrical Connection
Complete Installation
Electrical Connection Options
If your home has: And you will be
connecting to: Go to Section:
4-wire direct A fused
disconnect or
circuit breaker
box
3-wire direct A fused
disconnect or
circuit breaker
box
For cooktops with a 3-wire cable:
4-Wire Cable from
Power Supply to
3-Wire Cable from
Cooktop
3-Wire Cable from
Power Supply to
3-Wire Cable from
Cooktop
(12.7 cm)
5"
(8.9 cm)
3¹⁄₂"
A
B
C
D
E
F
H
G
I
H
B
C
D
E
F
G
I
A

13
12
