Cosmo COS-DIC304 Instruction Manual

IMPORTANT: Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Gas Cooktop
COS-DIC304
COS-DIC366
30 in. / 36 in. Gas Cooktop
Installation & User Manual

THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the
most advanced manufacturing philosophy. Each appliance leaves the
factory after thorough quality inspection and testing. Our distributors and
our service partners are ready to answer any questions you may have
regarding how to install, use and care for your products. We hope that this
manual will help you learn to use the product in the safest and most effective
manner.
Before using this product, please read through this manual carefully. Keep this
installation manual in a safe place for future reference. Please ensure that
other persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased it, or contact our Customer Support at:
1-888-784-3108.
2

TABLE OF CONTENTS
SAFETY & WARNINGS ........................................................4-10
General Safety .........................................................................5
Fire Safety .................................................................................6
Gas Safety ................................................................................6
Electrical & Grounding Safety ..................................................7
Installation Safety .....................................................................8
Location Safety ........................................................................9
Cooktop Safety ...................................................................9-10
COOKTOP DIAGRAMS .....................................................11-16
Dimensions ............................................................................11
Clearance ................................................................................12
Burner BTU .............................................................................13
Side / Back Panel ...................................................................14
Circuit Diagram: DIC304 ........................................................15
Circuit Diagram: DIC3366 ......................................................16
Cooktop Parts ........................................................................17
ELECTRICAL REQUIREMENTS .............................................18
OPERATING INSTRUCTIONS ...........................................19-22
Using the Cooktop Burners ..............................................19-20
Cooktop Requirements / Size Limitations .............................21
Grates .....................................................................................21
Wok Ring ................................................................................22
CARE & MAINTENANCE ...................................................23-26
Cleaning the Cooktop surface ...............................................23
Cleaning the Stainless steel surfaces ....................................23
Cleaning the Control Knobs ...................................................24
Cleaning the Burner grates and components ........................24
Cleaning the Burner caps and heads .....................................25
Cleaning the Burner bases .....................................................25
Electrodes ..............................................................................25
Cleaning the Grate and Wok ring ...........................................25
Burner head and Cap Replacement ....................................26
LIQUEFIED PETROLEUM GAS CONVERSION ................27-31
TROUBLESHOOTING ..............................................................32
WARRANTY & SERVICE ....................................................33-34
3

SAFETY & WARNINGS
4
Read all instructions before using this appliance.
All electrical and gas equipment with moving parts can be dangerous.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or death.
• DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
◦DO NOT try to light any appliance.
◦DO NOT touch any electrical switch.
◦DO NOT use any phone in your building.
◦Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
◦If you cannot reach your gas supplier, call the fire department.
•Installation and service must be performed by a qualified installer, service agency, or the
gas supplier.
SYMBOLS USED IN THIS MANUAL
These warning icons and symbols are here to prevent injury to you and others. Please
follow them explicitly. After reading this section, keep it in a safe place for
future reference.
State of California Proposition 65 Warning (US Only)
This product contains chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Gas appliances can cause low-level exposure to
Proposition 65 listed substances, including but not limited to: Benzene, carbon monoxide,
formaldehyde, soot and substances resulting from the incomplete combustion of natural gas
or LP fuels. For more information go to www.P65 warnings.ca.gov.
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas fitter qualified or licensed by the
State of Massachusetts. When using ball-type gas shut-off valves, you must use the T-
handle type. Multiple flexible gas lines must not be connected in series.
WARNING
CAUTION
NOTE
!
!
Hazards or unsafe practices that may result in
severe personal injury or death.
Hazards or unsafe practices that may result in
electric shock, personal injury, or property damage.
Useful tips and instructions.

SAFETY & WARNINGS
5
GENERAL SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Do not touch any part of the cooktop, including but not limited to cooktop burners during or
immediately after cooking.
• Know the location of the gas shut-off valve and how to shut it off.
• Make sure the hold down brackets are properly installed on the cooktop. See the
installation instructions for more information.
• Do not let children near or onto the cooktop.
• Do not let children play with the cooktop or any part(s) of the cooktop. Children climbing on
the cooktop to reach items could be killed or seriously injured.
• Do not leave children unattended in an area where the cooktop is in use.
• Remove all packaging materials from the cooktop before operating to prevent ignition of
these materials. Keep all packaging materials out of children's reach. Properly store or
dispose the packaging materials after the cooktop is unpacked.
• Do not store any object of interest to children on the cooktop or back-guard of the cooktop.
• Do not operate the cooktop if the cooktop or any part of the cooktop is damaged,
malfunctioning, or missing parts.
• Do not use the cooktop as a space heater.
• Use the cooktop for cooking only.
• Use only dry pot holders.
• Do not use the cooktop to heat unopened food containers.
• Unplug or disconnect the power cord before servicing.
• Never store combustible materials (dishtowels, paper products, etc.) or packaged or
canned food under the cooktop in a way that would let them come in contact with the
underside of the cooktop. The combustible material could catch fire and the packaged or
canned food could explode.
• Make sure the gas line is not compressed or bent by heavy objects. Otherwise, gas leaks
or incomplete combustion may occur.
!

6
SAFETY & WARNINGS
FIRE SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Do not store, place, or use flammable or combustible materials such as paper, plastic, pot
holders, linens curtains, gasoline or other flammable vapors or liquids near the cooktop.
• Do not wear loose fitting or hanging garments while using the cooktop.
• To avoid grease buildup, regularly clean the vents.
• Do not let pot holders or other flammable materials touch a heating element. Do not use a
towel or other bulky items made out of cloth in place of a pot holder.
• Do not use water on a grease fire. To put out a grease fire, turn off the heat source and
smother the fire with a tight-fitting lid or use a multipurpose dry chemical or foam-type fire
extinguisher.
• Do not heat unopened food containers. The buildup of pressure may cause the container to
burst and result in injury.
• Always check if the burners are combusting normally.
• Overheating may cause a fire, and incomplete combustion may cause carbon-monoxide
poisoning.
GAS SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
Checking for gas leaks
Leak testing of the appliance must be conducted according to the manufacturer's
instructions. Do not use a flame to check for gas leaks. Use a brush to spread a soapy water
mixture around the area you are checking. If there is a gas leak, you will see small bubbles
in the soapy water mixture at the leak point.
If you smell gas:
• Close the valve and do not use the cooktop.
• Do not light a match, candle, or cigarette.
• Do not turn on any gas or electric appliances.
• Do not touch any electrical switches or plug a power cord into an outlet.
• Do not use any phone in your building.
• Evacuate the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
!
!

7
SAFETY & WARNINGS
ELECTRICAL & GROUNDING SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Plug the power cord into a grounded 3-prong outlet.
• Do not remove the grounding prong.
• Do not use an adapter or an extension cord.
• Do not use a damaged power plug, power cord, or loose power outlet.
• Do not modify the power plug, power cord, or power outlet in any way.
• Do not put a fuse in a neutral or ground circuit.
• Use a dedicated 120-volt, 60-Hz, 20-amp, AC, fused electrical circuit for this cooktop. A
time-delay fuse or circuit breaker is recommended.
• Do not plug more than one appliance into this circuit.
• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
• This cooktop must be Earth grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of electrical shock by providing a path for the electric current.
This cooktop is equipped with a cord having a grounding plug. The plug must be firmly
plugged into an outlet that is properly installed and grounded in accordance with the local
codes and ordinances. If you are unsure whether your electrical outlet is properly grounded,
have it checked by a licensed electrician.
• The cooktop is supplied with a 3-pronged grounded plug. This cord must be plugged into a
matching, grounded 3-prong outlet that meets all local codes and ordinances. If codes permit
the use of a separate ground wire, we recommend that a qualified electrician determine the
proper path for this ground wire.
• Electrical service to the cooktop must conform to local codes. Barring local codes, it should
meet the latest ANSI/NFPA No. 70 – Latest Revision (for the U.S.), or the Canadian
Electrical Code CSA C22.1 – Latest Revisions.
•It is the personal responsibility of the cooktop owner to provide the correct electrical
service for this cooktop.
!

8
SAFETY & WARNINGS
INSTALLATION SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Have your cooktop installed and properly grounded by a qualified installer, in accordance
with the installation instructions. Any adjustment and service should be performed only by
qualified gas cooktop installers or service technicians.
• Do not attempt to service, modify, or replace your cooktop or any part of your cooktop
unless it is specifically recommended in this manual.
• All other service should be referred to a qualified technician.
• Always use new flexible connectors when installing a gas appliance. Do not use old flexible
connectors.
• Make sure the hold down brackets are properly installed on the cooktop. See the
installation instructions for more information.
• Remove all tape and packaging materials.
• Remove all accessories from the cooktop; grates and griddles are heavy. Use caution
when handling them.
• Make sure no parts came loose during shipping.
• Make sure your cooktop is correctly installed and adjusted by a qualified service technician
or installer for the type of gas (natural or LP) you will use. For your cooktop to utilize LP gas,
the installer must replace the 4 or 6 surface burner orifices with the provided LP orifice set,
and reverse the GPR adapter. Furthermore, the bypass in burner valve will need to be
adjusted. These adjustments must be made by a qualified service technician in accordance
with the manufacturer's instructions and all codes and requirements of the authority having
jurisdiction.
• The qualified agency performing this work assumes the gas conversion responsibility.
• Installation of this cooktop must conform with local codes or, in the absence of local codes,
with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada,
installation must conform with the current Natural Gas Installation Code, CAN/CGA-B149.1,
or the current Propane Installation Code, CAN/CGA-B149.2, and with local codes where
applicable. This cooktop has been design-certified by ETL according to ANSI Z21.1, latest
edition, and Canadian Gas Association according to CAN/CGA-1.1, latest edition.
• Make sure the middle valve has adequate capacity and is not clogged.
•This cooktop must be installed by a qualified technician. Otherwise, gas leaks, fire,
or defective ignition may occur.
!

9
SAFETY & WARNINGS
LOCATION SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• This cooktop is for indoor, household use only.
• Do not install the cooktop in areas exposed to the weather and/or water.
• Do not install the cooktop in a place which is exposed to a strong draft.
• Select a location where a grounded, 3- prong outlet is easily accessible.
• If the cooktop is located near a window, do not hang long curtains or paper blinds on that
window.
• For the cooktop to ventilate properly, there must be enough clearance at the top, back and
sides of the cooktop, and underneath the cooktop. The vents allow the necessary exhaust
for the cooktop to operate properly with correct combustion.
• Make sure the wall coverings around the cooktop can withstand heat up to 194 °F (90 °C).
• Cabinet storage above the surface of the cooktop should be avoided.
• If cabinet storage above the cooktop is necessary: allow a minimum clearance of 30 inches
(76.2 cm) between the cooking surface and the bottom of the cabinets.
COOKTOP SAFETY
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Select cookware that is designed for range top cooking. Use cookware that is large enough
to cover the burner grates. Adjust the burner flames so that the flames do not extend beyond
the bottom of the cookware.
• Make sure all burners are off when not in use.
• Do not use aluminum foil to line the grates or any part of the cooktop.
• Do not leave burners unattended on medium or high heat settings.
• Before igniting, make sure all burner caps are properly in place and all burners are level.
• Always use the LITE position when igniting the burners and make sure the burners have
ignited. If ignition fails, turn the knob to OFF and wait until the gas has dissipated.
• When you set a burner to simmer, do not turn the knob quickly.
• Make sure the flame stays on.
• Do not place any objects other than cookware on the cooktop.
• This cooktop is designed to cook with a wok or wok ring attachment.
!
!

10
SAFETY & WARNINGS
COOKTOP SAFETY (CONTINUED)
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• If foods are flamed, they should only be flamed under a ventilation hood that is on.
• Before removing or changing cookware, turn off the burners.
• Remove food and cookware immediately after cooking.
• Before removing any parts of the burner for cleaning, make sure the cooktop is off and
completely cool.
• After cleaning the burner spreader, make sure it is completely dry before re-assembling.
• To avoid carbon monoxide poisoning, do not pour water into the cooktop well while
cleaning.
• To avoid cookware discoloration, deformity, and/or carbon monoxide poisoning, do not use
cookware that is substantially larger than the grate.
• Make sure cookware handles are turned to the side or rear of the cooktop and not over
other surface burners.
• Stand away from the cooktop while frying.
• Always heat frying oils slowly, and watch as they heat. If you are frying foods at high heat,
carefully watch during the cooking process. If a combination of fats or oils is to be used
during frying, mix them together before heating.
• Use a deep-fryer thermometer whenever possible. This prevents overheating the fryer
beyond the smoking point.
• Use a minimum amount of oil when shallow pan-frying or deep-frying. Avoid cooking un-
thawed food or food with excessive amounts of ice.
• Before moving cookware full of fats or oils, make sure it has completely cooled.
• To prevent delayed eruptive boiling, always allow heated liquids to stand at least 20
seconds after you have turned off the burner so that the temperature in the liquid can
stabilize.
•In the event of scalding, follow these first aid instructions:
1.) Immerse the scalded area in cool or lukewarm water for at least 10 minutes.
2.) Do not apply any creams, oils, or lotions.
3.) Cover with a clean, dry cloth.
• If a power failure occurs or the electric ignition fails to operate, do not use matches or
lighters to ignite the burners. This may cause a fire or physical burns.
• Do not place and use electric-powered cooking devices such as IH rice cookers or desktop
cooking heaters on top of your cooktop. Electromagnetic forces from these appliances may
cause the cooktop to malfunction.
!
