Costway ET1379US User manual

www.costway.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Visit us: www.costway.com
Follow Costway
Please give us a chance to make it right and do better！
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!
USER’S MANUAL
Hammer Impact Drill
ET1379US

www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
02

www.costway.com
03
DESCRIPTION OF THE SYMBOLS
Symbols are used in this manual to attract your attention to possible risks. The
safety symbols and the explanations which accompany them must be perfectly
understood. The warnings themselves do not prevent the risks and can not be a
substitute for proper methods of avoiding accidents.
This symbol, before a safety comment, indicates a precaution, a
warning or a danger. Ignoring this warning can lead to an accident for
yourself or for others. To limit the risk of injury, fire, or electric shock
always apply the recommendations indicated.
Before any use, refer to the corresponding paragraph in the present manual.
Conform to relevant safety standards.
This class II symbol indicates that the product is correctly
insulated. Grounding this machine is therefore unnecessary.
This symbol indicates the requirement of wearing ear protection, eye protection,
respirator and gloves when using the product.
Recycle unwanted materials instead of disposing of them as waste. All
tools, hoses and packaging should be sorted, taken to the local
recycling centre and disposed of in an environmentally safe way.

www.costway.com
04
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and instructions.
Failing to follow the warnings and instructions can result in an electric shock,
a fire and/or a serious injury.
Keep all warnings and all instructions to be able to refer to them later on.
The term “tool” in the warnings refers to your electrical mains powered tool (with power
cord) or your battery operated tool (without power cord).
1 – Safety of the work area
a) Keep the work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate electric tools in explosive atmospheres, for example in the presence
of flammable liquids, gases or dust. Electric tools create sparks that can ignite the dust
or fumes.
c) Keep children and bystanders away while operating the tool. Distractions can cause
you to lose control of the tool.
2 – Electrical safety
a) The electric tool plugs must match the outlet. Never modify the plug in any way. Do
not use adapters with earthed (grounded) tools. Unmodified plugs and matching outlets
will reduce the risk of electric shock.
b) Avoid any body contact with earthed or grounded surfaces such as pipes, radiators,
cookers and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose tools to rain or wet conditions. Water entering a tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
tool. Keep the cord away from heat, lubricants, edges and moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When using a tool outside, use an extension cable suitable for outside use. Use of a
cord suitable for outside use reduces the risk of electric shock.
f) If use of a tool in a humid location is unavoidable, use a supply protected by a
residual current differential device (RCD). The use of an RCD reduces the risk of
electric shock.

www.costway.com
05
3 – Personal safety
a) Stay alert, watch what you are doing and use common sense when operating the
tool. Do not use the tool when you are tired or under the influence of drugs, alcohol or
medication. One moment of carelessness while using a tool can result in serious
personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment such as dust
masks, non-slip safety shoes, a hard hat and hearing protection used for appropriate
conditions will reduce personal injuries.
c) Avoid unintentional starting. Make sure that the switch is in the off position before
plugging the tool into the mains and/or fitting the batteries, picking it up or carrying it.
Carrying tools with your finger on the switch or plugging in tools with the switch in the
on position is a cause of accidents.
d) Remove any adjustment key before operating the tool. A key left attached to a
rotating part of the tool can result in personal injury.
e) Do not overreach. Keep a proper position and balance at all times. This enables
better control of the tool in unexpected situations.
f) Dress in a suitable manner. Do not wear loose clothing or jewellery. Keep hair,
clothing and gloves away from moving parts. Loose clothing, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
equipment, make sure that they are connected and used correctly. Using dust
collectors can reduce the dust-related risks.
4 – Use and maintenance of the tool
a) Do not force the tool. Use the correct tool for your application. The correct tool will
do the work better and safer in the conditions for which it was manufactured.
b) Do not use the tool if the switch does not make it possible to change from the
operating condition to stop and vice versa. Any tool which cannot be controlled by the
switch is dangerous and should be repaired.
c) Disconnect the power cord before any adjustment, changing an accessory or before
storing the tool. Such preventive safety measures reduce the risk of starting the tool
accidentally.
d) Keep idle tools out of the reach of children and do not allow persons unfamiliar with
the tool or these instructions to operate it. Tools are dangerous in the hands of
untrained users.
e) Maintain the tool. Check that there is no misalignment or obstruction of the moving
parts, broken parts or any other condition that could affect the operation of the tool. In
the event of damage, have the tool repaired before using it. Many accidents are due to
badly maintained tools.
f) Keep cutting tools sharp and clean. Properly maintained tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the tool, accessories and blades etc., in accordance with these instructions,
while taking into account the work conditions and the work to be done. The use of the
tool for operations other than those intended could result in dangerous situations.
5 – Maintenance and service
a) Have the tool serviced by qualified repair personnel using only identical
replacement parts. This will ensure that the safety of the tool is maintained.

www.costway.com
06
Special safety warning
Intended use
TECHNICAL SPECIFICATIONS
Wear ear protectors with impact drills. Exposure to noise can cause hearing loss.
Use auxiliary handles supplied with the tool. Loss of control can cause personal injury.
Hold power tool by insulated gripping surfaces, when performing an operation where
the cutting accessory may contact hidden wiring or its own cord. Cutting accessory
contacting a “live” wire may make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
- lead from lead-based paints,
- crystalline silica from bricks and cement and other masonry products, and
- arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
The machine is intended for impact drilling in brick, concrete and stone as well as
for drilling in wood, metal and plastic. Machines with electronic control and right/left
rotation are also suitable for screwdriving and thread-cutting.
Model
Voltage
Input current
No-load speed
Chuck size
Max. Drilling Capacity
Steel
Concrete
Wood
Wd60281
120V～60Hz
810 W
0-3000 minˉ¹
1.5 - 13 mm
Ø 10 mm
Ø 13 mm
Ø 25 mm

www.costway.com
07
LIST OF MAIN PART
NOISE/VIBRATION INFORMATION
Measured sound values determined according to EN 60745.
Wear hearing protection!
Vibration total values (triax vector sum) determined according to EN 60745:
The vibration emission level given in this information sheet has been measured in
accordance with a standardised test given in EN 60745 and may be used to compare
one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool.
However if the tool is used for different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the
times when the tool is switched off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration
such as: maintain the tool and the accessories, keep the hands warm, organisation of
work patterns.
1. On/off switch
3. Reverse-rotation lever (forwards/reverse)
5. Auxiliary handle
7. Depth gauge
2. Locking button
4. Hammer drill switch
6. Chuck
8. Maximum speed control knob

www.costway.com
08
Operation
Before use
Before making assembly, changing and adjustment for any accessory, disconnect the
tool from the mains supply to avoid any unintentional starting.
Please always check the mains supply voltage before use! It must correspond with the
rating label on the appliance.
Remove any packing material and loose parts from unit.
Check the accessories before use. It should be fit with the machine and your purpose.
Auxiliary Handle
The auxiliary handle can be mounted on the left or right side of the chuck. Mount the
handle at the flange behind the chuck and tighten it firmly in its desired position.
Depending on the working method, the auxiliary handle can be adjusted in different
positions.
CAUTION!
The machine should be used only with both handles.
Do not continue to use an auxiliary handle if it is damaged.
Depth Gauge
The drilling depth can be set with the depth gauge.
Insert a drill bit into the chuck and clamp it. Loosen the auxiliary handle and insert the
depth gauge into the intended hole. Move the depth gauge until the distance between
the tips of drilling bit and depth gauge corresponds with the required drilling depth.
Tighten the auxiliary handle firmly in its desired position.
Inserting Tool Bits
The impact drill has a key chuck so you need a key to lock the tool bit in place. Make
sure that the drill or screw bit is not skew when it is inserted and the chuck tightened.
Before inserting drill/screw bits open the jaws of the chuck.
Open the chuck until you can insert the tool bit. Insert the tool bit in the chuck and
fasten the chuck by hand. Fasten the chuck firmly by inserting the chuck key in one of
the holes in the side of the chuck and turning it clockwise.
To remove the tool bit, you proceed in reverse order. Open the chuck until you can
remove the tool bit.

www.costway.com
09
On/Off Switch
Use the On/Off switch to start the machine and keep holding it for continuous operation.
The rotation speed can be varied by depressing the On/Off switch. The more the trigger is
depressed, the faster the rotation speeds.
To switch the machine off, release the On/Off switch.
Locking button
The locking button can hold the switch on position for continuous drilling.
Please follow below step:
To lock the on/off switch, turn on the on/off switch and press the locking button, release the
trigger.
The drill will continue to operate until the locking button is released.
To release the on/off switch, just press it again and then release it to stop.
Maximum speed control knob
The maximum speed control knob can adjust the running speed from low to high.
Please follow below step:
1. Switch on the tool
2. Lock the switch
3. Turn the knob clockwise to increase and anti-clockwise to reduce the maximum speed.
Forward/reverse switch
Important!
The machine has to come to a complete stop before the
forward/reverse switch can be used; otherwise the machine
may be damaged.
Use the forward/reverse switch to switch between clockwise
and anticlockwise rotation.
Hammer/drill switch
The hammer/drill switch can switch the drill and hammer/ drill functions.
Select to the hammer icon side to operate as hammer drill. And select the drill icon side to
operate as drilling operation.
When drilling into Concrete, it is recommended to use the hammer drill operation.
Don’t use the hammer drill function for ceramic tile or others material can not withstand
impact energy.
When drilling into metal and wood, it is recommended to use the drill operation only.

www.costway.com
10
MAINTENANCE
STORING
DISPOSAL
WARNING
Don’t apply big pressure to the machine.
The hammer mechanism is activated by applying a slight pressure on the
tool when the drill bit is in contact with the workpiece.
Best hammer drilling results can be obtained by only a slight pressure on
the tool needed to keep the automatic clutch engaged; drilling performance
will not improve by applying more pressure on the tool.
APPLICATION ADVICE
Always use the auxiliary handles provided with this tool. Well controlled machine may
increase the working precision greatly.
The depth gauge can make sure the user drill precisely to a preset depth.
When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
When turning in a screw at/near the cross cut end or an edge of wood, pre-drill a hole in
order to avoid cracking of the wood.
Keep the ventilation openings clear and clean the product regularly.
If something unusual occurs during use, switch off the supply and disconnect the plug.
Inspect and repair the tool before using it again. The repairs must be carried out by a
qualified technician.
Repair of the tool must only be carried out by a qualified repair technician.
Repair or maintenance by unqualified personnel can lead to a risk of injury.
Use only identical spare parts for repairing a tool. Follow the instructions in the
maintenance section of this user manual.
Caution!
If the supply cord of this power tool is damaged, it must be replaced by a specially
prepared cord available through the service organization.
Care and cleaning
Clean the housing only with a damp cloth-do not uses any solvents! Dry thoroughly
afterwards.
Store the machine, operating instructions and where necessary the accessories in the
original packaging. In this way you will always have all the information and parts ready to
hand.
Pack the device well or use the original packaging in order to avoid transit damage.
Always keep the machine in dry place.
Do not dispose of power tools into household waste! According the European
Guideline 2002/96/EC for Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that are no longer usable must
be collected separately and disposed of in an environmentally correct manner.

Welcome to visit our website and purchase our quality products!
Reward Points
Exclusive Customer Service
Personalized Recommendaons
Permanent Shopping Cart
Order History
We would like to extend our hearelt thanks to
all of our customers for taking me to assemble
this product and giving us valuable feedbacks.
www.costway.com
Your suggestions and comments for COSTWAY are really important to us!
We sincerely solicit you to go back to our shop and leave a good rating in just a
simple click. It would be quite encouraging if you could kindly do so like below:
February 24, 2019
Great products so far. Fast delivery, easy setup, and working without any issues.
Great products so far
With your inspiring rating, COSTWAY will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
US office: Fontana, California
UK office: Ipswich
www.costway.com
11
