Chest Freezer
FP10001US-WH FP10002US-WH
USER’S MANUAL
US office: Fontana UK office: Ipswich AU office: Truganina
DE office: Hamburg FR office: Saint Vigor d'Ymonville PL office: Gdańsk

02 03
GENERAL SAFETY RULES
SAVE THESE INSTRUCTIONS
DANGER
WARNING: Read all of the instructions before using this
appliance. When using this appliance, always exercise basic
safety precautions, including the following:
NOTE: If the freezer has been placed in a horizontal or tilted
position for any period of time, wait 24 hours before plugging the
unit in.
1. Use this appliance only for its intended purpose as described in
this use and care guide.
2. This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding
instructions in the installation section.
3. Never unplug your freezer by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
4. Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that
shows cracks or abrasion damage along its length, the plug or the
connector end.
5. Unplug your freezer before cleaning or before making any
repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6. Do not use any electrical device or any sharp instrument in
defrosting your freezer.
7. WARNING: After your freezer is in operation, do not touch the
cold surfaces in the freezer compartment, particularly when hands
are damp or wet. Skin may adhere to these extremely cold
surfaces.
8. Do not refreeze foods, which have been thawed completely. The
United States Department of Agriculture in Home and Garden
Bulletin No.69 reads: “...You may safely refreeze frozen foods that
have thawed if they still contain ice crystals or if they are still
cold-below 40 ℉.”
“...Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed
ice cream should be discarded. If the odor or color of any food is
poor or questionable, discard it. The food may be dangerous to
eat.”
“...Even partial thawing and re-freezing reduce the eating quality of
foods,particularly fruits, vegetables,and prepared foods. The eating
quality of red meats is affected less than that of many other foods.
Use refrozen foods as soon as possible, to save as much of its
eating quality as you can.”
9. This freezer should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
10. Do not operate your freezer in the presence of explosive fumes.
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves in place
so that children may not easily climb inside.
This appliance is not intended for use by persons including children
with reduced physical sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
Do not use extension cords or ungrounded (two prong) adapters.
If the supply cord is damaged, it must be replaced by the qualified
person in order to avoid hazard.
WARNING: Keep ventilation openings, in the appliance enclosure or
in the built-in structure, clear of obstruction.

04 05
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
This appliance is intended to be used in household and similar
applications such as
· Staff kitchen areas in shops,offices and other working
environments;
· Farm houses and by clients in hotels,motels and other residential
type environments;
· Bed and breakfast type environments;
· Catering and similar non-retail applications
1. Exterior Drain Plug
2. Temperature Control
3. Compressor On Indicator
4. Power on Indicator
5. Vinyl-Coated Steel Wire Removable Storage Basket
Parts And Features
Installing Your Freezer
Unpacking Your Freezer
1. Remove all packaging material. This includes the foam base and
all adhesive tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the freezer.
Adjusting Your Freezer
· Your freezer is designed for freestanding installation only. It
should not be recessed or built-in.
· Place the freezer on a floor strong enough to support it full
loaded.
· When moving the freezer, never tilt it more than a 45-degree
angle.This could damage the compressor and the sealed system.
· If the freezer is tilted, let it stand in an upright position for at
least 24hours prior to plugging. This is to allow the refrigerant to
settle.
Proper Air Circulation
· To assure your freezer works at the maximum efficiency it was
designed for, you should install it in a location where there is
proper air circulation, plumbing and electrical connections.
The following are recommended clearances around the freezer:
Sides..........4"(102mm)
Back.....4" (102mm)
Top.........Do not block
WARNING: ELECTRICAL REQUIREMENT-SHOCK HAZARD
Electrical Requirement
· Make sure there is a suitable power Outlet (115 volts,15 amps
outlet) with proper grounding to power the freezer.

06 07
· Avoid the use of three plug adapters or cutting off the third
grounding, in order to accommodate a two plug outlet. This is a
dangerous practice since it provides no effective grounding for the
freezer and may result in shock hazard.
Install Limitations
· Do not install your freezer in any location not properly insulated
or heated e.g. garage etc. Your freezer was not designed to operate
in temperature settings below 55°Fahrenheit.
· Select a suitable location for the freezer on a hard even surface
away from direct sunlight or heat source e.g. radiators, baseboard
heaters,cooking appliances etc.Any floor unevenness should be
corrected.
Disposal
· This appliance may not be treated as regular household waste. It
should be taken to the appropriate waste collection point for
recycling of electrical components. For information on local waste
collection points, contact your local waste removal agency or
government office.
· Disposal of this appliance should be in accordance with federal
and local regulations.
Operating Your Freezer
· Once the freezer is in its proper place, plug it in an electrical
outlet having 115 volts and 15 amps.
· Set the temperature, on the temperature control knob. "1" being
the warmest and "7" being the coldest. Initially set the
temperature on "4". Place food inside the freezer. After using the
freezer for 24 hours set the freezer to your desired setting.
· In case you unplug your freezer or experience an electrical
outage, allow 5 minutes before plugging it back in.
Freezer Features and Use
General Features
Adjustable temperature dial: (see fig. #1)
Your freezer will automatically maintain the temperature level you
select. The temperature control dial has 7 settings plus ON."1" is
the warmest, “7”is the coldest. Set the dial to "4" and allow 24
hours to pass before adjusting the temperature to your needs.
For faster freezing capability: The first time you turn the unit on,
turn the temperature control dial to “ON” and run for at least 2
hours, then turn dial to “4”.
Normal Operating Sounds You May Hear
· Boiling water, gurgling sounds or slight vibrations that are the
result of the refrigerant circulating through the cooling coils.
· The thermostat control will click when it cycles on and off.
Note: If the temperature control knob sets to 7, the compressor
may run continuously. It's a quick-frozen mode.Please do not set to
7 frequently.
Food Storage Basket
Your freezer has a basket. Removable basket allows you to store
food more accessibly or you can remove it if not needed.

08 09
Defrosting and Draining
· For most efficient operation and minimum energy consumption,
defrost whenever the frost becomes 1/4"thick. Never use a sharp
or metallic instrument to remove the frost, as it may damage the
cooling coils. Do not use boiling water as it may damage the unit.
It is advisable to let ice and frost melt
· Remove frozen food from the freezer and place it in a cooler to
protect the food.
· Unplug the unit. Defrosting usually takes a few hours. To
defrost faster keep the freezer door open.
· For draining, place a tray beneath the outer drain plug. Unscrew
and remove drain plug. This will let the water flow out in the tray.
When done, screw on the drain plug in place.
Note: monitor the container under the drain to avoid overflow.
· When draining is complete, wipe the interior of the freezer with
a soft cloth, plug in power cord back into the electrical outlet.
· Reset the temperature control to the desired setting.
· Return the food into the freezer.
· Do not refreeze defrosted/thawed foods.
· It is recommended that the freezing date be marked on the
packaging.
These are some suggestions for safe storage:
· TV Dinners 3-4 Months
· Fresh Shrimp, scallops, crawfish 3-6 Months
· Hamburger & stew meats 3-4 Months
· Ground Turkey, veal, pork 3-4 Months
· Chops 4-6 Months
· Steaks 6-12 Months
· Chicken or turkey whole 1 year
For detailed storage chart visit FDA website:
www.cfsan.fda.gov/~dms/fttstore.html
Food Storage Information
Frozen Food:
· Wipe containers before storing to avoid needless spills.
· Hot food should be allowed to cool before storing in the freezer.
This will prevent unnecessary energy use.
· When storing meats, keep in the original packaging as necessary.
· Proper freezer storage requires correct packaging. All foods must
be in packages, which do not allow the flow of air or moisture in,or
out. Improper storage will result in odor and taste transfer and will
result in the drying out of the improperly packaged food.
· Follow package or container instructions for proper storage.
· Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film Self-sealing plastic bags
Proper Freezer Care and Cleaning
Cleaning and Maintenance
WARNING: To avoid electric shock always unplug your
freezer before cleaning. Ignoring this warning may result in
death or injury.
CAUTION: Before using cleaning products, always read and
follow manufacturer's instructions and warnings to avoid
personal injury or product damage.
General:
· Prepare a cleaning solution of 3-4 tablespoons of baking soda
mixed with warm water. Use sponge or soft cloth, dampened with
the cleaning solution, to wipe down your freezer.
· Rinse with clean warm water and dry with a soft cloth.
· Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,
concentrated detergents, solvents or metal scouring pads. SOME of
these chemicals may dissolve, damage and/or discolor your freezer.

10 11
· Allow time for recently added warm food to reach freezer
temperature.
· Check gaskets for proper seal.
· Adjust temperature control to colder setting.
Too much frost build-up inside unit:
· Make sure temperature control is not set to "ON" setting for
extended period of time.
Food temperature is too cold:
· If temperature control setting is too cold, adjust to a warmer
setting and allow several hours for temperature to adjust.
Compressor runs too frequently:
· This may be normal to maintain constant temperature during high
temperature and humid days.
· Doors may have been opened frequently or for an extended
period of time.
· Check gasket for proper seal.
· Check to see if doors are completely closed.
· Check freezer compartment for blockage from frozen food
packages, containers, etc.
Freezer has an odor:
· Interior needs cleaning.
· Foods improperly wrapped or sealed are giving off odors.
Freezer Does Not Operate
· Check if freezer is plugged in.
· Check if there is power at the ac outlet, by checking the circuit
breaker.
· Wait for 30-40 minutes to see whether freezer will start.
Compressor cycle must be complete to operate.
Food temperature appears too warm:
· Frequent door openings.
WARNING: IF OUTAGE IS FOR A PROLONGED PERIOD,
INSPECT AND DISCARD SPOILED OR THAWED FOOD IN
FREEZER. CLEAN FREEZER BEFORE REUSING.
Door Gaskets:
· Clean door gaskets every three months according to general
instructions. Gaskets must be kept clean and pliable to assure a
proper seal.
· Petroleum jelly applied lightly on the hinge side of gaskets will
keep the gasket pliable and assure a good seal.
Power Interruptions
· Occasionally there may be power interruptions due to
thunderstorms or other causes. Remove the power cord from AC
outlet when a power outage occurs. When power has been
restored, replug power cord to AC outlet. If outage is for a
prolonged period, inspect and discard spoiled or thawed food in
freezer. Clean freezer before reusing.
Vacation and Moving Care
· For long vacations or absences,empty food from freezer,unplug
the unit and clean the door gaskets according to "General cleaning"
section. Prop doors open, so air can circulate inside. When moving
always move the freezer vertically. Do not move with the unit lying
down. Possible damage to the sealed system could occur.
Troubleshooting Model No.
PRODUCT SPECIFICATIONS
CAPACITY OF CHEST FREEZER IN CU FT
TEMPERATURE CONTROL TYPE
TEMPERATURE RANGE
WHEN DOOR IS OPENED 45 DEGREES,
THE HEIGHT(IN)：WHEN DOOR IS OPENED 45 DEGREES,
THE HEIGHT (IN)：PRODUCT WIDTH (IN.)：PRODUCT DEPTH (IN.)：PRODUCT HEIGHT (IN.)：FP10002US-WH
5.0
MECHANICAL
FP10001US-WH
3.3
MECHANICAL
10℉~ -11℉
/-12 ℃~ -24℃
10℉~ -11℉
/-12 ℃~ -24℃
48.31
53.72
29.69
22.20
33.27
48.31
53.72
22.60
22.20
33.27
