Costway Stakol EP23796 User manual

www.costway.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Visit us: www.costway.com
Follow Costway
Please give us a chance to make it right and do better！
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!
USER’S MANUAL
EN
HOUSEHOULD FREEZER
EP23796

2
www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: [e-mail]
UK: [e-mail]
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near tothe
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.

3
www.costway.com
NOTE: If the freezer has been placed in a horizontal or tilted position for any
period of time wait 24 hours before plugging the unit in.
1. Use this appliance only for its intended purpose as described in
this use and care guide.
2. This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding
instructions in the installation section.
3. Never unplug your freezer by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
4. Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that
shows cracks or abrasion damage along its length, the plug or the
connector end.
5. Unplug your freezer before cleaning or before making any repairs.
6. Do not use any electrical device or any sharp instrument in
defrosting your freezer.
7. If your old freezer is not being used, we recommend that you
remove the doors. This will reduce the possibility of danger to
children.
8.
WARNING: After your freezer is in operation, do not touch the
cold surfaces in the freezer compartment, particularly when
hands are damp or wet. Skin may adhere to these extremely cold
surfaces.
9. Do not refreeze foods, which have been thawed completely. The
United States Department of Agriculture in Home and Garden
Bulletin No. 69 reads: “…You may safely refreeze frozen foods that
Read all of the instructions before using this appliance. When using this
appliance, always exercise basic safety precautions, including the following:
WARNING
IMPORTANT SAFETY INSTRUCTIONS

4
www.costway.com
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves in
place so that children may not easily climb inside.
DANGER
IMPORTANT SAFETY INSTRUCTIONS
have thawed if they still contain ice crystals or if they are still
cold-below 40˚F”.
“…Thawed ground meats, poultry, or fish that have any off-odor
or off-color should not be refrozen and should not be eaten.
Thawed ice cream should be discarded. If the odor or color of
any food is poor or questionable, discard it. The food may be
dangerous to eat.”
“…Even partial thawing and re-freezing reduce the eating quality
of foods, particularly fruits, vegetables, and prepared foods. The
eating quality of red meats is affected less than that of many
other foods. Use refrozen foods as soon as possible, to save as
much of its eating quality as you can.
10. This freezer should not be recessed or built-in an enclosed
cabinet. It is designed for freestanding installation only.
11. Do not operate your freezer in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

5
www.costway.com
PARTS & FEATURES
Adjustable Temperature Control
Full Width Fixed
Shelves (2)
Leveling Legs

6
www.costway.com
INSTALLING YOUR FREEZER
UNPACKING YOUR FREEZER
1. Remove all packaging material. This includes the foam base and all adhesive
tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the freezer.
ADJUSTING YOUR FREEZER
• Your freezer is designed for freestanding installation only. It should not be
recessed or built-in.
• Place the freezer on a surface strong enough to support it fully loaded.
• When moving the freezer, never tilt it more than a 45-degree angle.
This could damage the compressor and the sealed system.
• If the freezer is tilted let it stand in an upright position for at least 24 hours
prior to plugging in. This is to allow the refrigerant to settle.
PROPER AIR CIRCULATION
• To assure your freezer works at the maximum efficiency it was designed for,
you should install it in a location where there is proper air circulation, plumbing
and electrical connections.
• The following are recommended clearances around the freezer:
Sides……………4” (102mm)
Back..................4” (102mm)
Top....................4” (102mm)

7
www.costway.com
INSTALLING YOUR FREEZER CONT.
ELECTRICAL REQUIREMENT
• Make sure there is a suitable power Outlet (115 volts, 15 amps
outlet) with proper grounding to power the freezer.
• Avoid the use of three plug adapters or cutting off the third grounding in order to
accommodate a two plug outlet. This is a dangerous
practice since it provides no effective grounding for the freezer and may result in
shock hazard.
USE OF EXTENSION CORD
• Avoid the use of an extension cord because of potential safety hazards under
certain conditions. If it is necessary to use an extension cord, use only a 3-wire
extension cord that has a 3-blade grounding plug and a 3-slot outlet that will
accept the plug. The marked rating of the extension cord must be equal to or
greater than the electrical rating of the appliance. DO NOT USE EXTENSION
CORD LONGER THAN 12 FT.
INSTALL LIMITATIONS
• Do not install your freezer in any location not properly insulated or heated e.g.
garage etc. Your freezer was not designed to operate in temperature settings
below 55˚ Fahrenheit.
• Select a suitable location for the freezer on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness should be
corrected.
ELECTRICAL REQUIREMENT - SHOCK HAZARD
WARNING
WARNING
USE OF EXTENSION CORDS- POTENTIAL SAFETY HAZARD

8
www.costway.com
FREEZER FEATURES AND USE
OPERATING YOUR FREEZER
• Once the freezer is in its proper place, plug it in an electrical outlet
having 115 volts and 15 amps.
• Set the temperature, on the temperature control knob. “1” being the warmest
and “7” being the coldest. Initially set the temperature on “4”. Place food inside
the freezer. After using the freezer for 24 hours set the freezer to your desired
setting.
• In case you unplug your freezer or experience an electrical outage, allow 5
minutes before plugging it back in.
GENERAL FEATURES
Adjustable temperature dial:
Your freezer will automatically maintain the temperature level you select. The
temperature control dial has 7 settings plus OFF. “1” is the warmest, “7” is the
coldest. Turning the dial to OFF stops cooling the freezer. Set the dial to “4” and
allow 24 hours to pass before adjusting the temperature to your needs.
NOTE: If the freezer has been placed in a horizontal or tilted position for any period
of time wait 24 hours before plugging the unit in.
NORMAL OPERATING SOUNDS YOU MAY HEAR
• Boiling water, gurgling sounds or slight vibrations that are the result of the
refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
Control Panel
Varies by Model

9
www.costway.com
FREEZER FEATURES AND USE CONT.
DEFROSTING
• For most efficient operation and minimum energy consumption, defrost
whenever the frost becomes 1/4” thick. Never use a sharp or
metallic instrument to remove the frost, as it may damage the cooling coils.
(A punctured coil will void the warranty). Use only a plastic scraper. Do not use
boiling water as it may damage the unit.
• Remove frozen food from the freezer and place it in a cooler to
protect the food.
• Turn the temperature control to OFF position and unplug the unit. Defrosting
usually takes a few hours. To defrost faster keep the freezer door open.
DEFROST DRAIN
Place a narrow defrost pan (not included) in front of the freezer, gently slide the
defrost drain outward. Water that has accumulated at the bottom of the freezer
during defrosting will drain into the pan.
NOTE: Monitor the defrost pan to avoid overflow.
• When defrosting is complete, wipe the interior of the freezer with a soft cloth.
Plug in power cord back into the electrical outlet.
• Reset the temperature control to the desired setting.
• Return the food into the freezer.

10
www.costway.com
FREEZER FEATURES AND USE CONT.
LEVELING YOUR FREEZER
• Your freezer has two leveling legs which are located in the front bottom
corners of your freezer. After properly placing your freezer in its final
position, you can level your freezer.
• Leveling legs can be adjusted by turning them counterclockwise to raise your
freezer or by turning them clockwise to lower your freezer. The freezer door
will close easier when leveling legs are extended.
DOOR ALIGNMENT
1. Remove the top hinge cover using a flat
head screw driver. Gently lift from the
rear of the hinge and slide forward.
2. Lossen the top hinge screws using a Phillips
head screwdriver.
3. Adjust the door or put a spacer in between
and then tighten the screws.
4. Replace the top hinge cover by aligning
the rear of the cover with the rear of the
hinge. Press firmly on the front of the cover
until it snaps in place.

11
www.costway.com
FREEZER FEATURES AND USE CONT.
FOOD STORAGE INFORMATION
Frozen Food:
•Wipe containers before storing to avoid needless spills.
• Hot food should be allowed to cool before storing in the freezer. This will prevent
unnecessary energy use.
• When storing meats, keep in the original packaging or rewrap as necessary.
• Proper freezer storage requires correct packaging. All foods must be in packages,
which do not allow the flow of air or moisture in, or out. Improper storage will
result in odor and taste transfer and will result in the drying out of the improperly
packaged food.
•Follow package or container instructions for proper storage.
•Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
•Do not refreeze defrosted/thawed foods.
• It is recommended that the freezing date be marked on the
packaging.
These are some suggestions for safe storage:
•TV Dinners 3 - 4 Months
•Fresh Shrimp, scallops, crawfish 3 - 6 Months
•Hamburger & stew meats 3 - 4 Months
•Ground Turkey, veal, pork 3 - 4 Months
•Chops 4 - 6 Months
•Steaks 6 - 12 Months
•Chicken or turkey, whole 1 year
For detailed storage chart visit FDA website:
www.cfsan.fda.gov/~dms/fttstore.html

12
www.costway.com
PROPER FREEZER CARE AND CLEANING
CLEANING AND MAINTENANCE
GENERAL:
•Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water. Use sponge or soft cloth, dampened with
the cleaning solution, to wipe down your freezer.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach,concentrated
detergents, solvents or metal scouring pads. SOME of these chemicals may
dissolve, damage and/or discolor your freezer.
DOOR GASKETS:
• Clean door gaskets every three months according to general instructions.
Gaskets must be kept clean and pliable to assure a proper seal.
•Petroleum jelly applied lightly on the hinge side of gaskets will keep the gasket
pliable and assure a good seal.
WARNING
To avoid electric shock always unplug your freezer before cleaning.
Ignoring this warning may result in death or injury.
CAUTION
Before using cleaning products, always read and follow manufacturer’s
instructions and warnings to avoid personal injury or product damage.

13
www.costway.com
PROPER FREEZER CARE AND CLEANING CONT.
POWER INTERRUPTIONS
• Occasionally there may be power interruptions due to thunderstorms or
other causes. Remove the power cord from AC outlet when a power outage
occurs. When power has been restored, replug power cord to AC outlet.
If outage is for a prolonged period, inspect and discard spoiled or thawed
food in freezer. Clean freezer before reusing.
VACATION AND MOVING CARE
• For long vacations or absences, empty food from freezer, move the
temperature DIAL to the OFF position and clean the door gaskets according
to “General cleaning” section. Prop doors open, so air can circulate inside.
When moving always move the freezer vertically. Do not move with the unit
lying down. Possible damage to the sealed system could occur.
WARNING
If outage is for a prolonged period, inspect and discard spoiled
or thawed food in freezer. Clean freezer before reusing.

14
www.costway.com
TROUBLESHOOTING
FREEZER DOES NOT OPERATE:
•Check if thermostat control is not in the “OFF” position.
•Check if freezer is plugged in.
• Check if there is power at the ac outlet, by checking the
circuit breaker.
• Wait for 30-40 minutes to see whether freezer will start. Compressor cycle
must be complete to operate.
FOOD TEMPERATURE APPEARS TOO WARM:
•Frequent door openings.
•Allow time for recently added warm food to reach
freezer temperature.
•Check gaskets for proper seal.
•Clean condenser coils (for models with exposed condenser coils).
•Adjust temperature control to colder setting.
FOOD TEMPERATURE IS TOO COLD:
• If temperature control setting is too cold, adjust to a warmer setting
and allow several hours for temperature to adjust.
COMPRESSOR RUNS TOO FREQUENTLY:
• This may be normal to maintain constant temperature during
high temperature and humid days.
• Doors may have been opened frequently or for an extended
period of time.
•Check gasket for proper seal.
•Check to see if doors are completely closed.
• Check freezer compartment for blockage from
frozen food packages, containers, etc.
FREEZER HAS AN ODOR:
•Interior needs cleaning.
•Foods improperly wrapped or sealed are giving off odors.

16
Welcome to visit our website and purchase our quality products!
Reward Points
Exclusive Customer Service
Permanent Shopping Cart
Order History
this product and giving us valuable feedbacks.
www.costway.com
Your suggestions and comments for COSTWAY are really important to us!
We sincerely solicit you to go back to our shop and leave a good rating in just a
simple click. It would be quite encouraging if you could kindly do so like below:
February 24, 2019
Great products so far. Fast delivery, easy setup, and working without any issues.
Great products so far
With your inspiring rating, COSTWAY will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
US office: Fontana, California
UK office: Ipswich
www.costway.com
