CPR Guardian II Assembly instructions

3CPRGUARDIAN.COMCPR GUARDIAN II
Advanced User Guide

4CPRGUARDIAN.COMCPR GUARDIAN II
1. Set Up & Getting Started
> 1.1 Getting To Know Your Guardian II
> 1.2 Syncing Your Watch With The App
2. Using The Guardian App
> 2.1 Add Contacts
> 2.2 Call The Watch
> 2.3 Measure The Wearer’s Heart Rate
> 2.4 Locate The Wearer
> 2.5 Set Pedometer Goals
> 2.6 Unpair The Watch From The App
> 2.7 Add Another Watch To The App
3. Using The Guardian Watch
> 3.1 Make A Phone Call
> 3.2 Make An SOS Call
> 3.3 Send A Voice Message
> 3.4 Test Your Heart Rate
> 3.5 Change The Clock Face
> 3.6 Charge The Watch
4. Additional Information
> 4.1 Functions & Usage
> 4.2 Cautions & Warranty
CPR Guardian II User Guide

5CPRGUARDIAN.COMCPR GUARDIAN II
The CPR Guardian II
The CPR Guardian is designed to keep the wearer safe,
independent and active at all times with a built-in
emergency assist button, a heart rate monitor,
mobile phone and GPS tracking.
The GUARDIAN II provides you and your loved ones with peace
of mind and reassurance knowing you can always be there
for them whenever they need you.
SOS Button Phone Calls GPS Tracking HR Monitor

6CPRGUARDIAN.COMCPR GUARDIAN II
Introduction
1.1 Getting To Know Your Guardian II
Accessing The SIM Portal
SIM Details
Use the SIM number and PIN printed on the SIM Information
Card to access the CPR SIM portal.
Step 1
To manage your SIM, please visit:
https://www.cprguardian.com/simlogin
Step 2
Sign into the portal using your SIM number
starting with ‘44’ followed by the PIN Code.
Step 3
When you login, sign up as a new user and then
select your SIM plan.
Box Contents
• 1X Guardian II Watch Phone
• 1X USB Cable
• 1X SIM card (already inside the watch)
• 1X SIM Information Card
• 1X Quick Start Guide
Battery Care & Charging
To protect and optimize your battery performance. We
recommend you charge the watch for at least 12 Hours for
the 1st charge and over 8 Hours for the 2nd and 3rd charge.
Always use the USB cable provided and a CE approved USB
charger plug to avoid irreparable damage.
Please align the magnetic charging cable connector to the 4
pin metal contacts on the watch backplate, and make sure it
is properly connected (the magnetic charging cable will not
charge if it’s reversed). When the watch starts to charge, the
charging icon will appear on the watch display screen.

7CPRGUARDIAN.COMCPR GUARDIAN II
Introduction
1.1 Getting To Know Your Guardian II
Power On/Off Button
Date
Time
Steps
Heart Rate
Microphone
Battery
SOS Button
SIM Card Port
Charging Port
Heart Rate
Monitor
Speaker

8CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
132
Next, familiarise yourself with
the app’s functions by
swiping right through
the app summary
Once the app has
downloaded, you need to
allow notifications by pressing
‘Ok’
1
Download the CPR Guardian
App from the App Store /
Google Play store
4

9CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
45 6
Next, press ‘Get Code’Choose your country code and
then enter your mobile
phone number
Once the login page is
reached, proceed by
selecting ‘New User’

10 CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
78 9
Next, create a secure
6-16 letter password
Proceed by entering
your unique code
You will receive an SMS text
message with a
unique code

11 CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
10 11
12
Then select
‘scan device QR code ‘
Proceed by pressing
‘Add Device’
After creating your password,
you can proceed to login

12 CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
13
14
15
Enter the watch user’s details,
ensuring that the watch SIM
number begins with ‘0’
Once scanned proceed by
adding your relationship
to the wearer
To reveal your watch’s QR
Code, swipe up on the
watch face.

13 CPRGUARDIAN.COMCPR GUARDIAN II
Set Up & Getting Started
1.2 Syncing Your Watch With The App
16
Once you’re done, press back
button to save your details
17
Once watch has been added
press [ ] for the watch
to update, this can take
up to 5 minutes

14 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.1 Add Contacts
1
Press the [ ] icon on home
screen of the app
2
Next, select
‘Add Contact’
from the Command List
3
Continue to fill out the fields such
as name, number and then
press ‘Save’

15 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.2 Call The Watch
1
To call the watch, go to the
home screen and then press
the [ ] icon to call the watch
2
You may be prompted to press
‘Call’ before the call
can begin

16 CPRGUARDIAN.COMCPR GUARDIAN IIPAGE NAME
Using The Guardian App
2.3 Measure The Wearer’s Heart Rate
1
To measure wearer’s heart rate,
select the Heart Rate section at
the bottom of the homescreen
3
Press ‘Measure Now’ – the data
will then be available on the
home screen of the app
*This Can Take Up To 3 Minutes

17 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.4 Locate The Wearer
1
2
To locate the wearer, begin by
pressing the icon [ ] on the
app home screen
In real-time the app will locate
the wearer’s location

18 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.5 Set Pedometer Goals
1
Begin by pressing the icon [ ] on
the app homescreen
2
Select Pedometer Goals from
the features list
3
Enter the amount of steps you
would like to reach daily

19 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.6 Add Another Watch To The App
1
Begin by pressing ‘Switch Device’
on the home screen
2
Next, press the [ ] icon located
at the bottom of the screen
3
Next, scan the device QR
Code to add the new device

20 CPRGUARDIAN.COMCPR GUARDIAN II
Using The Guardian App
2.7 Unpair The Watch From The App
1
Begin by pressing ‘Switch Device’
on the home screen
2
Next, press ‘Unpair’ to remove the
watch from the app

21 CPRGUARDIAN.COMCPR GUARDIAN II
Using The CPR Guardian II
3.1 Make A Phone Call
Select who you wish to
call & hold down on
the contact to call
Next, tap the
‘Phonebook’
icon
To make a normal call,
swipe right to left on
the watch face
12 3
John
07000000000
Jane
07000000000
Greg
07000000000
Phonebook

22 CPRGUARDIAN.COMCPR GUARDIAN II
Using The CPR Guardian II
3.2 Make An SOS Call
To make SOS calls from the watch
hold down the red SOS button
for 3 seconds
The watch will the begin to
repeatedly call the SOS contacts
until the call is answered
1
SOS
