Craftsman 3One 917.380542 User manual

®
MODEL NUMBER 917.380542 OWNER'SMANUAL
Convertible
oAssembly
oOperation
oCustomer
Responsibilities
oService
oAdjustments
oRepair Parts
Caution:
Read and Follow
all Safety Rules
and Instructions
Before Operating
This Equipment
IIIIlllIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII
,,, ........ _.............,,,,, ,,,,,............... _

SAFETY RULES
CAUTION: ALWAYSDISCONNECTSPARK PLUGWlRE ANDPLACEWIREWHEREtTCANNOT CONTACTSPARK
PLUG TO PREVENT ACCIDENTAL STARTINGWHENSETTING UP,TRANSPORTING, ADJUSTING OR MAKING
REPAIRS.. IMPORTANT
SAFETY STANDARDS REQUIRE OPERATOR PRESENCE CONTROLS TO MINIMIZE THE RISK OF INJURY,. YOUR UNiT IS EQUIPPED WITH
SUCH CONTROLS. DO NOT ATTEMPT TO DEFEAT THE FUNCTION OF THE OPERATOR PRESENCE CONTROLS UNDER ANY CIRCUM*
STANCES°
TRAINING:
• Read this operator's manual carefully Become familiar with
the controls and know how to operate your mower properly
Learn how to quickly stop mower
• Do not altow children to use your mower Never allow adults
to use mower without proper instructions
• Keep the area of operation clear of all persons, especially
small children and pets
*Use mower onfy as the manufacturer intended and as de-
scribed in this manual
Do not operate mower if it has been dropped or damaged in
any manner Always have damage repaired before using
your mower
Do not use accessory attachments that are not recommended
by the manufacturer Use of such attachments may be
hazardous,
Be aware that the mower blade turns when the engine is
running
PREPARATION:
'. Always thoroughly check the area to be mowed and clear it of
all stones, sticks, wires, bones, and other foreign objects
These objects will be thrown by the blade and can cause
severe injury.
• Always wear safety glasses or eye shields when starting and
while using your mower
,, Dress properIy Do not operate mower when barefoot or
wearing open sandals Wear only solid shoes with good
traction when mowing
•Check fuel tank before starting engine Do not fill gas tank
indoors, when the engine is running or when the engine is hot,
Allow the engine to cool for several minutes before filling the
gas tank_ Clean off any spilled gasoline before starting the
engine
• Always make wheel height adjustments before starting your
mower Never attempt to do this while the engine is running
. Mow only in daylight or good artificial light
OPERATION:
" Keep your eyes and mind on your mower and the area being
cut, Do not let other interests distract you
• Do not mow wet or slippery grass Never run while operating
your mower. Always be sure of your fooling -keep a firm hold
on the handles and walk
Do not put hands or feet near or under rotating parts Keep
clear of the discharge opening al all times
• Always stop the engine whenever you leave or are not using
you rmower, or befo re crossing ddveways, walks, roads, and
any gravel-covered areas,,
* Never direct discharge of material toward bystanders nor
allow anyone near the mower while you are operating it
. Before cleaning, inspecting, or repairing your mower, stop
the engine and make absolutely sure the blade and all
moving parts have stopped. Then disconnect the spark plug
wire and keep it away from the spark plug to prevent
accidental starting
. Do not continue to run yourmower if you hit a foreign object
FoFIowthe procedure outlined above, then repair any dam-
age before restarting and operating you mower.
• Do not chang ethe governor settings or overspeed the
engine Engine damage or personal injury may resutt_
• Do notoperate your mower ifit vibrates abnormally Exces-
sive vibration is an indication of damage; stop the engine,
safely check for the cause of vibration and repair as required
Do not run the engine indoors. Exhaust fumes are danger-
ous
Never cut grass by pulling the mower towards you Mow
across the face of slopes, never up and down or you might
lose your footing Do not mow excessively steep slopes.
Use caution when operating the mower on uneven terrain or
when changing directions -maintain good footing
Never operate your mower without proper guards, plates,
grass catcher or other safety devices in place
MAINTENANCE ANDSTORAGE:
• Check the blade and the engine mounting bolts often to be
sure they are tightened properly
•Check all bolts, nuts and screws at frequent intervals for
proper tightness to be sure mower isin safe working condi-
tion,
* Keep all safety devices in place and working
* To reduce fire hazard, keep the engine free of grass, leaves
or excessive grease and oil
• Check grass catcher often for deterioration and wear and
replace worn bags Use onty repEacement bags that are
recommended by and comply with specifications of the
manufacturer of your mower
• Always keep a sharp blade on your mower
• Allow engine to cool before storing in any enclosure
. Never store mower with fuel in the tank inside a building
where fumes may reach an open flame or an ignition source
such as a hot water heater, space heater, clothes dryer, etc
i
LOOK FOR THIS SYMBOL TO POINT OUT IMPORTANT SAFETY PRECAUTIONS. I
E
IT MEANS -ATTENTION!!! BECOME ALERT!!! YOUR SAFETY IS INVOLVED, !
2

CONGRATULATIONS on your purchase of a Sears Lawn
Mower,, It has been designed, engineered and manufac-
tured to give you the best possible dependability and
performance,
Should you experience any problem you cannot easily
remedy, please contact your nearest Sears Authorized
Service Center/DepartmenL We have competent, well-
trained technicians and the proper tools to service or repair
this lawn mower.,
Please read and retain this manual,, The instructions will
enable you to assemble and maintain your lawn mower
properly., Always observe the "SAFETY RULES",
MODEL
NUMBER 917,,380542
SERIAL
NUMBER
DATEOFPURCHASE
THE MODEL AND SERIAL NUMBERS WILL BE FOUND
ON A DECAL ATTACHED TO THE REAR OF THE
LAWN MOWER HOUSING
YOU SHOULD RECORD BOTH SERIAL NUMBER AND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE
FOR FtJTURE REFERENCE_
PRODUCT SPECSRCATDONS
HORSEPOWER: 4.0
DISPLACEMENT: 11,5CU IN
GASOLINE CAPACITY 1,,5QUARTS
AND TYPE: UNLEADED REGULAR
OIL TYPE (API-SG): SAE 30 (ABOVE 32°F)
SAE 5W-30 (BELOW 32°F)
OIL CAPACITY: 20 OZ&
SPARK PLUG: CHAMPION RJ19-LM
(GAP: ,030") STD361458
VALVE CLEARANCE: INTAKE: ..008
EXHAUST: ,B08
SOLID STATE iGNITION
AIR GAP: o0125IN.
BLADE BOLT TORQUE: 35-40 FT_LBS,
MAINTENANCE AGREEMENT
A Sears Maintenance Agreement is available on this product° Contact your nearest Sears store for details,
CUSTOMER RESPONSiBILiTiES
o Read and observe the safety rules,
° Follow a regular schedule in maintaining, caring for and using your lawn mower.
. Follow the instructions under "Customer Responsibilities" and "Storage" sections of this owner's manual.,
LtMITED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER
For two years from date of purchase, when this Craftsman Lawn Mower is maintained, lubricated, and tuned up
according to the operating and maintenance instructionsin the owner's manual, Sears will repair free of charge any
defect in material or workmanship.,
If this Craftsman Lawn Mower is used for commercial or rental purposes, this warranty applies for only 90 days from
the date of purchase..
This Warranty does not cover:
oExpendable items which become worn during normal use, such as rotary mower blades, blade adapters, belts,
air cleaners and spark plug
° Repairs necessary because of operator abuse or negligence, including bent crankshafts and the failure to maintain
the equipment according to the instructions contained in the owner's manuaf,
WARRANTY SERVICE IS AVAILABLE BY RETURNING THE CRAFTSMAN POWER MOWER TO THE NEAREST
SEARS SERVICE CENTER/DEPARTMENT IN THE UNITED STATES,, THIS WARRANTY APPLIES ONLY WHILE
THIS PRODUCT IS IN USE IN THE UNITED STATES,
This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state
SEARS, ROEBUCK AND CO. DI817 WA, HOFFMAN ESTATES, ILLINOIS 60179
3

: .......... I'H I II I ................. :"m IIlll
TABLE OF CONTENTS
SAFETY RULES ............................................................ 2
PRODUCT SPECIFICATIONS ....................................... 3
CUSTOMER RESPONSIBILITIES ..................... 3, 10-12
WARRANTY ................................................................... 3
ASSEMBLY ..................................................................... 5
OPERATION ................................................................... 6
MAINTENANCE SCHEDULE ...................................... 10
SERVICE AND ADJUSTMENTS .....:........................... 13
STORAGE .................................................................... 14
TROUBLESHOOTING .................................................. 15
REPAIR PARTS., LAWN MOWER ........................ 16-17
REPAIR PARTS- ENGINE .................................... 18-20
PARTS ORDERING/SERVICE ................ BACK COVER
