Crestron TSW-770-FP User manual

The Crestron® TSW-770-FP is a face plate for TSW-770 and TSS-770
series touch screens that can be used when replacing a TSW-760 or
TSS-7 series touch screen. The TSW-770-FP installs over an electrical box
or existing mounting cutout to ensure no part of the installation is
exposed. The TSW-770-FP comes in white or black variants to match the
touch screen color.
In the Box
1 TSW-770-FP, Face Plate for TSW-770 Series
TSW-770-FP-B-S Only
1 Cover Plate, Plastic, Black (2055393)
TSW-770-FP-W-S Only
1 Cover Plate, Plastic, White (2055392)
Install the Face Plate
To install the face plate in existing TSW-760 or TSS-7 installations:
1. Pull the TSW-760 or TSS-7 carefully out its mounting bracket and
disconnect all cables from the rear of the touch screen.
NOTE:If the touch screen is secured to the mounting bracket
with a security bracket, refer to the removal procedure described
in the TSW-560/TSW-760/TSW-1060 QuickStart (Doc. 7926) or
the TSS-7/TSS-10 Quick Start (Doc. 8326).
2. Remove the TSW-760/1060 mounting bracket from the electrical box
or mounting cutout.
3. Attach the face plate to the TSW-770/1070 mounting bracketand
electrical box or mounting cutout with the appropriate screws. The
mounting bracket and screws are included with the TSW-770 or
TSS-770 touch screen.
lFor U.S.-style installations, use the four 6-32 x 3/4 in. screws.
lFor European-style installations, use the four M3 x 16 mm
screws.
lFor U.K.-style installations, use the two M3 x 25 mm screws.
1
TSW-770-FP QuickStart
Face Plate for TSW-770 Series

Refer to the following illustration depicting a U.S.-style installation.
U.S.-Style Installation
4. Connect all cables to their appropriate ports on the touch screen.
5. Push the touch screen into its mounting bracket.
Complete the Installation
2
TSW-770-FP QuickStart
Face Plate for TSW-770 Series

Visit the Product Page
Scan the QR code to visit the product page.
TSW-770-FP
www.crestron.com/model/6511457
Additional Information
Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
Crestron product development software is licensed to Crestron dealers and Crestron
Service Providers (CSPs) under a limited nonexclusive, nontransferable Software
Development Tools License Agreement. Crestron product operating system software is
licensed to Crestron dealers, CSPs, and end-users under a separate End-User License
Agreement. Both of these Agreements can be found on the Crestron website at
www.crestron.com/legal/software_license_agreement.
The product warranty can be found at www.crestron.com/warranty.
The specific patents that cover Crestron products are listed at
www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, visit
www.crestron.com/opensource.
Crestron and the Crestron logo are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Other trademarks,
registered trademarks, and trade names may be used in this document to refer to either
the entities claiming the marks and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others. Crestron is not responsible for
errors in typography or photography.
©2020 Crestron Electronics, Inc.
Doc. 8742A
07/29/20
3
TSW-770-FP QuickStart
Face Plate for TSW-770 Series
