Overview
The IV-CAMA3-20-N-W-1B,IV-CAMA3-20-N-SLVR-1B,IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-1B
AutoTracker™ 3 series cameras are high-quality PTZ cameras that automatically track and frame a
presenter based on facial and motion detection. Ideal for lecture capture or conferences, the
IV-CAMA3-20-N-W-1B camera can automate camera operations with no personnel present and still
have the viewing experience of a manned camera. All the tracking intelligence is built into the camera –
no external system is needed. In addition, the IV-CAMA3-20-N-W-1B and IV-CAMA3-20-N-SLVR-1B
NDI®|HXenabled cameras allow for monitoring, control, power, and video output on a single Ethernet
connection.
NOTE:The IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-
20-SLVR-1B are functionally similar. For simplicity within this manual, the term "AutoTracker" is
used except where otherwise noted.

7 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
AutoTracker Features
Key features for the AutoTracker series cameras include:
lAutomatically pans, tilts, and zooms to smoothly follow and frame the presenter
lAI-enabled tracking with dual camera technology
lSmooth tracking and quiet operation
lCompatible with popular conferencing platforms such as Microsoft Teams® and Zoom Rooms™
software
lConnects directly to a codec or recording/streaming device with no external computer required
lHigh quality video supporting resolutions up to 1080p60
lSingle Ethernet connection provides power (PoE+), monitoring, control, and NDI®|HX compatible
video2(only supported on the IV-CAMA3-20-N-W-1B and IV-CAMA3-20-N-SLVR-1B)
lCompatible with Automate™ multicamera systems
lSupports 20x optical zoom for tracking distances up to 50ft from the participants
NOTE:The IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-
20-SLVR-1B AutoTracker cameras include integrated circuits produced by HiSilicon (part numbers
HI3516ARBCV100 and HI3516ARFCV200), a subsidiary of Huawei® Technologies Company.
Intelligent Tracking Technology
Intelligent tracking1automatically detects the presenter and keeps them in the optimal part of the
frame. It is easily set up to prevent tracking other subjects or displays. The AutoTracker is two cameras
in one: a wide-angle camera that continually monitors the room for motion and a PTZ camera that
follows the presenter. This dual camera approach allows the camera to adjust more quickly and never
lose the presenter.
Conferencing Compatibility
Optimize video conferencing, recording, or streaming by using the AutoTracker 3 series cameras with
Microsoft Teams®, Zoom Rooms™, Cisco WebEx®, MediaSite®, or Panopto® software. The AutoTracker
camera includes 3G-SDI video output for use with popular video conferencing codecs and capture
appliances. The IV-CAMA3-20-N-W-1B and IV-CAMA3-20-N-SLVR-1B also support NDI|HX video
output.

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 8
High Quality Video
A high quality Sony Exmor® CMOS sensor enables the camera to output up to 1080p60 resolution video
via the 3G-SDI port. The AutoTracker works well in low light and in front of bright screens.
Manual Control Options
Use VISCA over IP to control the camera with a Crestron® control system. 1B Cam Manager Software is
included for easy configuration from a computer on the network.
Networked Power, Stream, and Control
Connect a single Ethernet cable to power (PoE+), monitor, set up, and control the AutoTracker camera.
Quiet, Fast Switching Between Presets
Up to 256 pan, tilt, and zoom combination presets can be configured. The camera will move to the
selected preset point. A quiet, fast motor (120°/s pan speed) sets camera angles quickly.
Multicamera Capability with Automate Systems
Add the AutoTracker camera to an Automate multicamera system. Automate can be set to autoswitch
between multiple 1 Beyond cameras to focus on the active speaking participant. Incorporate popular
microphones and DSPs to switch between the presenter and audience.
Mounting Options
Standard mounting holes make it easy to mount the camera to a wall mount (included) or a J-Mount
ceiling bracket (sold separately).
NDI|HX for High Quality Network Video
NDI|HX supports efficient and flexible IP configuration with other networked NDI-enabled devices.
NDI|HX allows for easy installation and scalability with a single network pull (only supported on the IV-
CAMA3-20-N-W-1B and IV-CAMA3-20-N-SLVR-1B).
NOTE:NDI|HX is only supported on the IV-CAMA3-20-N-W-1B and IV-CAMA3-20-N-SLVR-1B
AutoTracker cameras.

9 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
Physical Description
Front
Rear
Bottom
No. Description
1 PTZ Tracking Camera
2 Wide-Angle Camera
3 Audio Input (Only for IP video stream)
4 Ethernet (Supports PoE+)
5 SDI 2 (PTZ camera video output)
6 SDI 1 (Wide-angle camera video output)
7 EXT Port (RS485 / RS 232 serial control)
8 12V DC Power Input
9 1/4 in. Screw Mounting Hole (standard tripod screw)
10 Locating Hole
1 Beyond Camera Manager Software
The 1 Beyond Camera Manager software is a central hub for configuring, monitoring, and controlling 1
Beyond IP cameras. The software enables 1 Beyond AutoTracker 3 camera configuration and
simultaneous monitoring of up to 4 video streams.

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 10
The 1 BeyondCamera Manager software provides the following features for the 1 Beyond AutoTracker 3
camera.
lDiscover 1 Beyond cameras on the network
lUpgrade camera firmware
lModify camera network settings
lModify camera RTMP(Real-Time Messaging Protocol)settings
lSet authentication credentials for the camera
lModify general settings, such as the camera name
lSet a secondary connection to the camera from a control device(such as a touch screen)
lView up to 4 camera video streams (close-up or panorama)simultaneously
lUse the PTZLens controls to adjust the camera's pan, tilt, zoom, focus, and iris levels
lCreate, recall, and delete camera presets
lUse the OSD(on-screen display)menu to adjust advanced settings
lStart and stop tracking for the camera
lDefine tracking and blocking zones and adjust tracking parameters for the camera
CAUTION:The 1 Beyond Camera Manager software enables changing of critical camera settings
that impact the camera's functionality and effectiveness. Ensure that all procedures in this
document are followed carefully for optimal camera performance.

11 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
Specifications
Product specifications for the AutoTracker 3 series cameras.
Optics and Processing
Image Sensor Tracking Camera: 1/2.8 in. Sony Exmor CMOS, 2.14MP;
Reference Camera: 1/2.8 in. CMOS, f=3.4 mm, Horz: 92°, Vert: 50°
Recommended Range 15-50 ft from subject, 7-12 ft from ground
Focal Lens & Iris f=4.7-94 mm, F1.6 - F3.5
Field of View 59.5° - 2.9°
Focus System Auto, Manual, One Push
Minimum Illumination 0.5 Lux (30FPS), 0.1 Lux (60FPS)
Shutter Speed 1/1 - 1/10,000 sec
Gain Auto, Manual
White Balance Auto, Indoor, Outdoor, One Push, Manual
Exposure Auto, Manual, Shutter Priority, Iris Priority
Number of Presets Up to 256
Serial Control RS-485, RS-232 (VISCA, PELCO-D)
Protocol HTTP, RTP, TCP, UDP, ONVIF
Pan, Tilt, Zoom
Tilt/Pan Angle Tilt: 30° - 90°, Pan: 170° - 170°
Tilt/Pan Speed Tilt: 0.1° - 90° /s, Pan: 0.1° - 120° /s
Zoom 20x Optical, 20x Digital
Connectivity
Ethernet RJ-45, 100Mb
Video
Video Outputs13G-SDI (Tracking and Reference);
NDI|HX over Ethernet (only supported on the IV-CAMA3-20-N-W-1B and IV-CAMA3-
20-N-SLVR-1B)
Signal Formats (HD) 1080p60/50/30/25, 1080i60/50, 720p60/50
IP Video Compression H.265, H.264 (Four streams) (IP Stream Only)
Streaming RTSP, RTMP
Streaming Resolution Up to 1080p60, User-selectable framesize/framerate/bitrate
Audio
IP Audio Compression AAC (IP Stream Only)

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 12
Power
Power 12VDC, <30 W, PoE+
PoE+ Rating 25.5 W
NOTE: To comply with the European Directive (CE), shielded CAT5e cable must be used as a
minimum for PoE power.
Environmental
Temperature 32° to 104°F (0° to 40°C)
Construction
Mounting 1/4 in. threaded mount hole, compatible with Wall Mount and J-Mount ceiling bracket
Color Silver;
White
S/N ≥50dB
Dimensions
Dimensions 8.9 in. x 8.3 in. x 6.4 in. (226 mm x 211 mm x 163 mm)
Weight
4.3 lb (1.96 kg)
Note:
1. The IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B camera includes integrated circuits produced by HiSilicon (part numbers
HI3516ARBCV100 and HI3516ARFCV200), a subsidiary of Huawei Technologies Company.

13 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
Dimension Drawings

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 14
Installation
Use the following procedures to install the Automate cameras.
NOTES: To avoid damage and ensure optimum performance of the camera, exercise the following
cautions:
lCheck the source power before powering on the camera. The AutoFramer can be powered via
a 30W PoE+ switch or with 12VDC. Under or overpowering the camera will cause damage
and poor performance that may not be immediately visible. If using PoE+ switch, be sure the
port is properly configured for 30W. If using DC power and connecting to a network switch,
be sure the port is not set for PoE.
lDo not power the camera with PoE+ and a power supply at the same time. Doing so may
cause it to malfunction.
lDo not operate the camera beyond the specified temperature and humidity limits. Operating
range of the camera is between 32°F - 104°F (0°C -40°C). Ambient humidity should be less
than 95%RH.
lDo not remove any screws from the camera. There are no user-serviceable parts inside.
Contact Crestron's True Blue Support Team if the camera is damaged or malfunctioning.
lDo not aim the camera lens at the sun or extremely bright lights. Doing so can cause damage
to the image sensor.
lDo not move the camera head manually. Doing so can cause damage to the camera and inner
gear systems. Do not carry the camera by the head; always handle the camera by the base.
lDo not directly expose the camera to rain, water, or high moisture.
lThis camera is for indoor use only.
In the Box
Qty. Description
1 1 Beyond AutoTracker Intelligent Camera
Additional Items
1 Power Supply
1 Serial Control Breakout
1 Wall Mount

15 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
Mounting Requirements
For the optimum tracking performance:
lMount the camera upright with a clear view of the area where the subject will be tracked.
lThe camera should be mounted 15-50ft (5-15m)from the subject and at a height of 7-12ft (2-
4m).
lThe fixed wide-angle camera lens must be able to see the entire area that the subject will be
tracked in as it is used by the tracking algorithm for motion detection.
lThe area in which the subject will be tracked in must be in the top half (ideally in the top third) of
the wide-angle camera’s field of view. Positioning the camera where the wide-angle covers
predominately the ceiling will result in sub-optimal tracking performance. If the room slants down,
the camera should be positioned at a slant as well.
lMount the camera as close as possible to the central axis of the area where the subject will be
tracked. This is commonly the center of the back wall.
Mounting Options
The AutoTracker camera can be mounted on a wall using the included wall mount kit or suspended from
the ceiling using the J-mount kit (sold separately).
NOTE: Do not tilt the camera more than 15° to maintain optimum tilt and pan accuracy.

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 16
Wall Mount
Use the 1Beyond Wall Mount Bracket to mount the camera for video conferencing.
To mount the camera to a wall:
1. Using the following diagram, position the four installation holes on the mount and drill 4 holes in
the wall.
2. Attach the mount onto the wall using four screws (not included). Choose the length of the screws
in accordance with building specifications.
3. Use the included screw to fix the camera on the wall mount.
Caution: This camera cannot be inverted.

17 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
J Ceiling Mount
Use the 1Beyond J-mount kit (sold separately) to suspend the camera from the ceiling to achieve
optimum distance from the presentation area.
To mount the camera:
1. Using the following diagram, position the four installation holes on the mount and drill four holes
in the ceiling.
2. Attach the ceiling mounted bracket onto the ceiling using four screws (not included). Choose the
length of the screws in accordance with building specifications.
3. Screw the J-mount into the ceiling mounted bracket.
4. Use the included screw to fix the camera on the J-mount.

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 18
Wiring
The camera should be properly wired with power, video and control. Please note that the audio input of
the camera only feeds into the encoded IP stream. It is recommended to record/stream audio using a
separate device.
Network Connection
A network connection enables easy configuration, control from any PC connected to the same network,
and access to the camera’s IP video streams for monitoring. Use a CAT5 or CAT6 cable to connect the
camera to the network or directly to the host computer used for configuration.
The camera is shipped with a static IP address. The network connection can also be used to send VISCA
commands over TCP/IP.
Default IP address: 192.168.18.77
Subnet Mask: 255.255.255.0
If an Ethernet cable is connected directly to a computer running the 1BeyondCameraManager
software, the computer’s network port must be set to an address on the same subnet (for example,
192.168.18.77) in order to communicate with the camera.
When configuring multiple cameras, connect them to the network individually and assign them each a
unique IP address that conforms to your overall IP scheme.

19 • IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-
SLVR-1B
Product Manual — Doc.
9323C
PoE+ Power
This camera allows control, monitoring and power input using a single Ethernet cable thanks to PoE+
compatibility. To power the camera from your network switch, make sure that it is a PoE+ certified
switch that can supply 30 W of power for each connected camera. Alternatively, a PoE+ injector can be
used to inject power between the switch and camera.
NOTE: To comply with the European Directive (CE), shielded CAT5e cable must be used as a
minimum for PoE power.
DC Power
Power the camera using 12VDC or PoE+, but not simultaneously. The camera cannot operate properly
with less than 12VDC power. Since voltage drops over distance, the supplied 12V power adapter is not
sufficient if the power source is greater than 10ft (3m) from the camera.
WARNING: Providing too little or too much power can damage the camera. For PoE+, make sure the
network port is configured for 30 W. For DC power, be sure to supply 12V to the camera.
Video Output
For quality video capture, it is recommended to use the 3G-SDI outputs on the camera. The rear of the
camera has two female 3G-SDI ports to use with standard 3G-SDI cabling: RG-6 Coax cable, 75 ohms
with BNC male connectors. Depending on specific building fire codes, cables may need to be plenum
rated.
lSDI 2 – Video output of the PTZ tracking camera
lSDI 1 – Video output of the wide-angle camera (optional connection)
3G-SDI converters are offered to convert the 3G-SDI output of the AutoTracker™ 3 to HDMI. An 3G-SDI
cable is recommended to be run for longer distances and then converted at the capturing / streaming
device to ensure the best possible video quality. For more information on compatible SDI to HDMI
converters, refer to OLH 1001364: Recommended SDI to USB Adapters for use with Automate VX /
Select.
NOTE: For NDI-enabled 1 Beyond cameras, SDI is an optional output.
Serial Control
The AutoTracker supports serial control over RS-485 and RS-232. The serial connection is for sending
remote commands to the camera using the VISCA or PELCO_D protocols from a control system. In
most cases, serial cabling is optional because control of the AutoTracker is done through a network
connection.

Product Manual — Doc.
9323C
IV-CAMA3-20-N-W-1B, IV-CAMA3-20-N-SLVR-1B, IV-CAMA3-20-W-1B, and IV-CAMA3-20-SLVR-
1B • 20
If serial control is required, it is recommended to use RS-485. RS-485 can support cable lengths of up to
4,000 feet while RS-232 is limited to cable distances of 50 feet. Also, RS- 485 can support up to 32
controller devices while RS-232 only supports one.
For control cabling 22 o3 24 Awg twisted pair cable is recommended. Depending on specific building fire
codes, cables may need to be plenum rated.
To wire serial control, connect one of the included standard serial cables to the EXT port on the rear of
the camera and then connect the ends of control cable to the control device you will be using.
