Conductor DC Resistance: 28.6 ohms / 1000 ft maximum;
DC Resistance Unbalance: 3% maximum
JJaacckkeett::Color: Yellow;
Material: PVC;
Ripcord: yes;
Thickness: 0.018 inch;
Outer Diameter: 0.185 inch nominal
‘DMNet’ Control & Power
CCoonnssttrruuccttiioonn::(1) 22 AWG shielded pair (control) and (1) 18 AWG pair
(power) w/overall jacket
CCoonnttrroollPPaaiirr::Colors: Gray/orange;
Conductors: 22 AWG x2 stranded copper;
Insulation: 0.025 inch thick foam Polyolefin;
Shield: Aluminum/Polyester (100% coverage) w/aluminum on the inside;
Drain: 24 AWG tinned stranded copper;
Capacitance: 12.5 pF / ft, nominal;
Impedance: 100 ohms, nominal
PPoowweerrPPaaiirr::Colors: Red/black;
Conductors: 18 AWG x2 stranded copper;
Insulation: 0.01 inch thick PVC;
Shield: none
JJaacckkeett::Color: Gray;
Material: PVC;
Ripcord: yes;
Thickness: 0.0325 inch;
Outer Diameter: 0.25 inch nominal
Outer Jacket
CCoommppoossiitteeCCoonnssttrruuccttiioonn::All wires contained in a Mylar wrap w/overall outer jacket
MMaatteerriiaall::PVC, flexible, flame retardant
RRiippccoorrdd::yes
OOuutteerrDDiiaammeetteerr::0.58 inch (14.73 mm) nominal
CCoolloorr::Blue w/red stripe
Rating
NEC Article 800; UL Subject 444, Type CM; CSA Type CMG
AVAILABLE ACCESSORIES
DDMM--CCOONNNN
DigitalMedia™Cable Connector
* The maximum allowable cable length depends on multiple factors. One or more
DM Repeaters (Model DM-DR) may be required. Refer to the Crestron DigitalMedia
Design Guide, Doc. #4789 for complete wiring guidelines.
CCrreessttrroonnDDMM--CCBBLL--NNPP
Crestron DM-CBL-NP cable provides a high-performance, single-cable wiring
solution for DigitalMedia (DM) systems. Within a single jacket, DM-CBL-NP
contains one high-bandwidth/low-crosstalk shielded 4-twisted pair (STP) cable,
one CAT5e unshielded 4-twisted pair (UTP) cable, and one DMNet cable.
The STP “Video Data” cable, which connects to the ‘D’ port of a DigitalMedia
device, is of a specialized construction designed to allow the longest possible
cable lengths* for transporting high-definition digital video and audio. The Cat5e
“Data Management” cable, which connects to the ‘M’ port, carries high-speed
Ethernet and other data, plus 5V DC power. Finally, the DMNet cable carries
additional proprietary control signals and 24V DC power.
Wiring a DigitalMedia system using DM-CBL-NP is simple, requiring just one cable
to be run to each DM receiver (i.e. Room Controller) and transmitter location*.
Foot markers are printed on the outer jacket making it easy to determine the
exact length of each cable run when commissioning the installed system.
Termination of a DM cable is accomplished using one standard RJ45 (not
provided) for ‘M’, one detachable terminal block (provided with each DM device)
for DMNet, and one Crestron DM-CONN shielded RJ45 (sold separately) for ‘D’.
The DM-CONN connector enables fast and reliable termination of the shielded
twisted-pair cable without requiring any special tools.
AVAILABLE MODELS
DDMM--CCBBLL--NNPP--SSPP550000
DigitalMedia™Cable, non-plenum, 500 ft spool
SPECIFICATIONS
‘D’ Video Data
CCoonnssttrruuccttiioonn::Four twisted pair, each pair isolated by an internal spline within an inner jacket,
shield, braid, and overall jacket
((44))TTwwiisstteeddPPaaiirrss::Colors: Blue/white, orange/white, green/white, brown/white;
Conductors: 24 AWG x8 solid copper;
Insulation: 0.0055 inch thick HDPE;
Outer Diameter (per conductor): 1.028 ±0.02 mm;
Shield: Aluminum/Mylar tape w/aluminum on the outside;
Braid: Tin/copper (45% coverage);
Mutual Capacitance: 5600 pF / 100 m;
Capacitance Unbalance: 330 pF / 100 m;
Characteristic Impedance: 100 ohms ±15% (1-250 MHz)
IInnnneerrJJaacckkeett::Color: Natural;
Material: PVC;
Thickness: 0.015 inch
JJaacckkeett::Color: Blue;
Material: PVC;
Thickness: 0.018 inch;
Outer Diameter: 7.62 ±0.38 mm
‘M’ Data Management (CAT5E)
((44))TTwwiisstteeddPPaaiirrss::Colors: Blue/white, orange/white, green/white, brown/white;
Conductors: 24 AWG x8 solid copper;
Insulation: 0.0077 inch thick Polyethylene;
Shield: none;
Mutual Capacitance: 14 pF / ft nominal;
Capacitance Unbalance: 330 pF / 100 m maximum;
Characteristic Impedance: 100 ohms ±15% (0.772 to 100 MHz);
Velocity of Propagation: 70%;
www.crestron.com
|
800.237.2041
Crestron Electronics, Inc. 15 Volvo Drive
l
Rockleigh, NJ 07647
Tel: [phone]
l
Fax: [phone]
DigitalMedia™Cable, non-plenum
Specifications subject to change without notice. Doc.4764 01/09
