CRISTAL MNBX18 User manual

INSTRUCTION
MANUAL
MNBX18

2
Safety information
Important - Please read these instructions fully before
installing or operating
Power source
• The appliance can be connected to a 220-240 volt 50Hz AC supply by means of
the supplied mains adaptor.
• When using the 12V in-car adaptor the compact fridge should not be left
connected for long periods of time when the engine is not running.
• DO NOT connect directly to a 24V lighter socket of a heavy duty vehicle.
• Unplug this apparatus during lightning storms or when unused for long periods
of time - to prevent damage to this product.
• Opening or removing covers may expose you to dangerous voltages or other
hazards.
• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
• Use suitable power sources - Plug the product into a suitable power source, as
described in the operating instructions or as marked on the product.
• The supply voltage should be the same as that indicated in the technical
specifications and the appliance rating plate.
• In order to disconnect the apparatus from the mains completely switch off the
outlet and remove the mains plug completely.
• Do not bend, stretch or pull the supply cable in order to avoid electric shock.
• When installed, the power socket must be within easy reach.
Moisture and water
• Do not use this apparatus near water or moisture.
• Do not use this product near a bathtub, wash-bowl, kitchen sink, and laundry tub, in a
wet basement, near a swimming pool, outdoors, or anywhere else that water or moisture
is present.

3
Safety information
Important - Please read these instructions fully before
installing or operating
Heat sources and flames
• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
Ventilation and location
• Avoid using locations where dust or other airborne contamination may be drawn
into the fan.
• Allow at least 10cm distance from the back and sides of the compact fridge to
allow the withdrawn heat to disperse.
• Never leave the fridge running in poorly ventilated areas e.g. a car boot.
Servicing and repairs
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has been damaged in any way: such as liquid
has been spilled or objects have fallen into the apparatus; the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped
General
• This item cools to 12-18oC below room temperature. If left in a cool room this may freeze
contents.
• DO NOT use your compact fridge to store medication or anything that must be stored at a
constant temperature.
• Allow 30 minutes for the compact fridge to return to room temperature before
attempting to switch from heating to cooling mode, or visa versa.
• Do not sit on the fridge.

4
16 litre compact fridge
Introduction
Please read these instructions carefully. They contain important information which will help
you get the best from your product and ensure safe and correct installation and operation.
Accessories
1. 16L compact fridge
2. In-car power adaptor
3. Mains power cable
Features
1. Door handle
2. Air vent
3. Carry handle
4. Fan
5. HOT LED indicator (RED)
6. MODE switch
7. COLD LED indicator
(GREEN)
8. Adjustable internal shelf
9. Door shelves
10. MAINS power AC socket
11. IN-CAR power DC 12V
socket
12. POWER MODE switch
13. Door catch
HOT COLD
OFF
MAX
AC220-240V~50Hz
ECO
DC 12V
HOT COLD
OFF
MAX
AC220-240V~50Hz
ECO
DC 12V
1 5 7 8 9
6
432
913
11
10 12

5
16 litre compact fridge
Operating instructions
Connecting the power (in-car only)
Set the MODE switch (12) to the OFF position before connecting to the car power supply.
1. Insert the smaller end of the IN-CAR power cable into the IN-CAR POWER DC input (11)
on the rear of the fridge.
2. Secure the fridge in place and insert the larger end of the power cable into the cigarette
lighter socket of the vehicle.
WARNING:You risk running the car battery flat if you leave the fridge connected for a long
period of time.
Connecting the power (mains only)
1. Connect the mains plug to a wall socket, but do not switch on yet.
2. Insert the other end of the mains power cable into the AC power input socket (10) on the
rear of the fridge.
3. Switch the mains socket on.
HOT COLD
OFF
MAX
AC220-240V~50Hz
ECO
DC 12V
Car cigarette
lighter socket
HOT COLD
OFF
MAX
AC220-240V~50Hz
ECO
DC 12V
Mains socket
WARNING: DO NOT
connect to a 24V power
socket.

6
Operating the fridge
1. Switch to COLD using the MODE switch (6) (cooling begins and the
green LED illuminates). Switch to HOT mode using the MODE switch
(6) (the warming function begins and the red LED illuminates).
2. When the MODE switch (6) is set to OFF neither function is active (no
LED is illuminated).
3. Set the POWER MODE switch (12) to the MAX setting for full power
usage or MIN setting for economy power usage (This mode is AC
power only.)
Cooling tips
• To achieve the quickest cooling operation, fill the fridge with beverages which have
already been refrigerated. They will then stay cool and become even cooler providing the
fridge remains switched on.
• The temperature at which the fridge operates depends on the surrounding ambient
temperature. Cooling will be more efficient in a colder environment.
Warming tips
• The box is designed and used for the purpose of keeping warm items warm. And not for
warming up items.
• Hot items stays hot for a number of hours after the fridge has been switched off,
providing the door is closed properly.
Care and maintenance
• Ensure you disconnect the plug fully before performing regular maintenance.
• Use a vacuum cleaner or brush to clean the fan monthly.
• Clean the case with a wet cloth and neutral cleanser.
• Ensure the inside is fully dry before storing when not in use.
HOT COLD
OFF
HOT COLD
OFF
HOT COLD
OFF
MAX ECO
16 litre compact fridge
Product support

7
Please note:
• Cool air from inside the compact fridge draws moisture out of nearby warmer air, which
condenses on the inner surface. Wipe away any moisture build up with a soft cloth and
avoid opening the fridge door regularly to reduce excessive condensation build-up.
• If the mini fridge is powered off after an extended period then condensation may collect
underneath the unit. This is normal, so steps should be taken to protect the surface the
mini fridge is placed on.
Technical specification
Specification Rating
Dimensions H46.7. W27.4. D30cm
Volume 16L
Net weight 5.17KG (fridge only)
DC voltage
AC
12V DC 4A
220-240V ~50Hz
Power consumption COOL: 58W MAX
HEAT: 45W MAX
Heating capability 55oC - 65oC @ 25oC ambient temp
Cooling capability 12oC - 18oC @ below ambient temp @ 25oC
16 litre compact fridge
Product support

8
Disposal
• Disposal of your old product. Your product is designed and manufactured with
high quality materials and components, which can be recycled and reused
• When this crossed out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
• Please make yourself aware of the local collection system for electrical and
electronic products.
• Please act according to your local rules and do not dispose of your old products
with your normal household waste.
• The correct disposal of your old product will help prevent potential negative
consequences for the environment and human health.
This appliance complies with the following EEC directives: 2014/35/EU Low voltage
directive / 2014/30/EU EMC directive
16 litre compact fridge
Product support

9
16 litre compact fridge
Product support
Troubleshooting
NOTE:The fan will periodically stop when the fridge is in WARM mode. This is normal
operation.
Problem Solution
The fridge is not functioning
and the fan is not spinning.
• Check the power cable is connected correctly and
the MODE switch is set to either HOT or COLD
• The in-car adaptor (cigarette lighter end) may have
debris preventing the contact. If necessary clean
with a non metal brush and solvent.
• The mains power socket is not switched on.
• There may be debris preventing the fan from
spinning. Use a vacuum to remove the dust/debris.
• Check the mains socket with another device.You
may have a faulty socket. If the other device works
try changing the fridge’s plugs fuse.
The fridge is making a whirring
noise
• This is normal when the fridge is cooling down.

10
The compact fridge is not
cooling sufficiently.
• Check the MODE switch is set to COLD (the green
LED is illuminated). ECO mode may not offer
sufficient power to cool in the current environment.
• Check the fan is free of dust and is spinning freely.
(NOTE: cooling is effected by the external ambient
temperature.
• Allow 30 minutes for the compact fridge to return to
room temperature before attempting to switch from
heating to cooling mode, or visa versa.
• Allow at least 10cm distance from the back and
sides of the compact fridge to allow the withdrawn
heat to disperse.
• To achieve the quickest cooling operation, fill the
fridge with beverages which have already been
refrigerated.They will then stay cool and become
even cooler providing the fridge remains switched
on.
• The temperature at which the fridge operates
depends on the surrounding ambient temperature.
Cooling will be more efficient in a colder
environment.
The compact fridge is not
warming sufficiently
• Check the MODE switch is set to HOT (the red LED is
illuminated).
16 litre compact fridge
Product support

16 litre compact fridge
Warranty
This CRISTAL appliance is guaranteed to be free from defects in parts and manufacture for 12 months
from date of purchase, provided that the unit is used under the normal operating conditions shown
within the manual. Please note:
• Clarity Vision Group Ltd. will not accept any liability for damage or injury caused by
improper use.
• Clarity Vision Group Ltd. will not be liable for any damage caused by moving the
appliance; improper power supply;defective wiring or fuses; accident, alteration, abuse
or misuse of the appliance; abnormal operating conditions; commercial or industrial use;
fire; water damage; or customer misuse.
• This warranty is void if service on the unit is performed by any person other than an
approved technician, or if the appliance is used for commercial purposes.
• This warranty does not cover:
1. periodic maintenance and repair or parts replacement due to wear and tear.
2. consumables (components that are expected to require periodic replacement during the
lifetime of a product such as non-rechargeable batteries, bulbs, etc.)
3. damage or changes to the product as a result of : Accidents, fire, liquids, chemicals, other
substances, flooding, vibrations, excessive heat, improper ventilation, power surges,
excess or incorrect supply or input voltage, radiation, electrostatic discharges including
lighting, other external forces and impacts.
This warranty is available only to the original purchaser and is not transferable.
Your legal consumer rights reserved and are not affected.
Consumers have legal (statutory) rights under applicable national laws relating to the sale of consumer
products. This warranty does not affect statutory rights you may have nor those rights that cannot
be excluded or limited, nor rights against the person from whom you purchased the product. You may
assert any rights you have.
If service is required, DO NOT ATTEMPT TO REPAIR UNIT YOURSELF. Please return unit to the store you
purchased it from. Service support is provided by the store. Proof of purchase will be required for any
warranty claims. You must retain your original receipt. If service under warranty is required, you will be
required to produce this. Please also retain the original packaging should the unit need to be returned.
This warranty does not cover transport costs and risks associated with transport of your product to and
from the store.
Please note:As part of our policy of continuous product improvement, Clarity Vision Group Ltd. reserves
the right to amend specifications without notice.

Contact:
Clarity Vision Group Ltd
Unit 9 High March Industrial Estate,Daventry,
Northamptonshire, NN11 4HB
Rev 1.2
