CRISTAL MNBX4 User manual

INSTRUCTION
MANUAL
MNBX4

2
Safety information
Important - Please read these instructions fully before
installing or operating
Power source
• The appliance can be connected to a 220-240 volt 50/60Hz AC supply by means
of a three pin socket (mains adaptor sold separately).
• When using the 12V in-car adaptor the compact fridge should not be left
connected for long periods of time when the engine is not running.
• DO NOT connect directly to a 24V lighter socket of a heavy duty vehicle.
• Unplug this apparatus during lightning storms or when unused for long periods
of time - to prevent damage to this product.
• Opening or removing covers may expose you to dangerous voltages or other
hazards.
• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
• Use suitable power sources - Plug the product into a suitable power source, as
described in the operating instructions or as marked on the product.
• The supply voltage should be the same as that indicated in the technical
specifications and the appliance rating plate.
• In order to disconnect the apparatus from the mains completely switch off the
outlet and remove the mains plug completely.
• Do not bend, stretch or pull the supply cable in order to avoid electric shock.
• When installed, the power socket must be within easy reach.
Moisture and water
• Do not use this apparatus near water or moisture.
• Do not use this product near a bathtub, wash-bowl, kitchen sink, and laundry tub, in a
wet basement, near a swimming pool, outdoors, or anywhere else that water or moisture
is present.

3
Safety information
Important - Please read these instructions fully before
installing or operating
Heat sources and flames
• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
Ventilation and location
• Avoid using locations where dust or other airborne contamination may be drawn
into the fan.
• Allow at least 10cm distance from the back and sides of the compact fridge to
allow the withdrawn heat to disperse.
• Never leave the fridge running in poorly ventilated areas e.g. a car boot.
Servicing and repairs
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has been damaged in any way: such as liquid
has been spilled or objects have fallen into the apparatus; the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped
General
• This item cools to 15-20oC below room temperature. If left in a cool room this may freeze
contents.
• DO NOT use your compact fridge to store medication or anything that must be stored at a
constant temperature.
• Allow 30 minutes for the compact fridge to return to room temperature before
attempting to switch from heating to cooling mode, or visa versa.
• Do not sit on the fridge.

4
4 litre compact fridge
Introduction
Please read these instructions carefully. They contain important information which will help
you get the best from your product and ensure safe and correct installation and operation.
Accessories
1. 4L compact fridge
2. In-car mains adaptor
Features
1. Door handle
2. Carry handle
3. Air vent
4. Fan
5. Door catch
6. Internal shelf
7. HOT LED indicator (RED)
8. MODE switch
9. COLD LED indicator (GREEN)
10. POWER DC socket
HOT COLD
OFF
12V
DC
HOT COLD
OFF
12V
DC
1 2 3
310
6 97 854

5
4 litre compact fridge
Operating instructions
Connecting the power (in-car only)
Set the MODE switch (8) to the OFF position before connecting to the car power supply.
1. Insert the smaller end of the power cable into the POWER DC input (10) on the rear of the
fridge.
2. Secure the fridge in place and insert the larger end of the power cable into the cigarette
lighter socket of the vehicle.
WARNING:You risk running the car battery flat if you leave the fridge connected for a long
period of time.
NOTE:The mains AC adaptor is available separately.
Operating the fridge
1. Switch to COLD mode (cooling begins and the green LED
illuminates). Switch to HOT mode (the warming function begins and
the red LED illuminates).
2. When the switch is set to OFF neither function is active (no LED is
illuminated).
HOT COLD
OFF
12V
DC
Car cigarette
lighter socket
HOT COLD
OFF
HOT COLD
OFF
WARNING:DO NOT connect to a
24V power socket.

6
Cooling tips
• To achieve the quickest cooling operation, fill the fridge with beverages which have
already been refrigerated. They will then stay cool and become even cooler providing the
fridge remains switched on.
• The temperature at which the fridge operates depends on the surrounding ambient
temperature. Cooling will be more efficient in a colder environment.
Warming tips
• The box is designed and used for the purpose of keeping warm items warm. And not for
warming up items.
• Hot items stays hot for a number of hours after the fridge has been switched off,
providing the door is closed properly.
Care and maintenance
• Ensure you disconnect the plug fully before performing regular maintenance.
• Use a vacuum cleaner or brush to clean the fan monthly.
• Clean the case with a wet cloth and neutral cleanser.
• Ensure the inside is fully dry before storing when not in use.
Please note:
• Cool air from inside the compact fridge draws moisture out of nearby warmer air, which
condenses on the inner surface. Wipe away any moisture build up with a soft cloth and
avoid opening the fridge door regularly to reduce excessive condensation build-up.
• If the mini fridge is powered off after an extended period then condensation may collect
underneath the unit. This is normal, so steps should be taken to protect the surface the
mini fridge is placed on.
4 litre compact fridge
Product support

7
4 litre compact fridge
Product support
Technical specification
Specification Rating
Dimensions H28.2. W19. D26.8cm
Volume 4L
Net weight 1.86KG (Fridge only)
DC voltage 12V DC 4A
Power consumption COOL: 40W MAX
HEAT: 30W MAX
Heating capability 55oC - 65oC @ 25oC ambient temp
Cooling capability 15oC - 20oC @ below ambient temp @ 25oC
Disposal
• Disposal of your old product. Your product is designed and manufactured with
high quality materials and components, which can be recycled and reused
• When this crossed out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
• Please make yourself aware of the local collection system for electrical and
electronic products.
• Please act according to your local rules and do not dispose of your old products
with your normal household waste.
• The correct disposal of your old product will help prevent potential negative
consequences for the environment and human health.
This appliance complies with the following EEC directive: 2014/30/EU EMC
directive

8
4 litre compact fridge
Product support
Troubleshooting
NOTE:The fan will periodically stop when the fridge is in WARM mode. This is normal
operation.
Problem Solution
The fridge is not functioning
and the fan is not spinning.
• Check the power cable is connected correctly and
the MODE switch is set to either HOT or COLD
• The in-car adaptor (cigarette lighter end) may have
debris preventing the contact. If necessary clean
with a non metal brush and solvent.
• The mains power socket is not switched on (mains
adaptor sold separately).
• There may be debris preventing the fan from
spinning. Use a vacuum to remove the dust/debris.
• Check the mains socket with another device.You
may have a faulty socket.
The fridge is making a whirring
noise
• This is normal when the fridge is cooling down.

9
4 litre compact fridge
Product support
The compact fridge is not
cooling sufficiently.
• Check the MODE switch is set to COLD (the green
LED is illuminated).
• Check the fan is free of dust and is spinning freely.
(NOTE: cooling is effected by the external ambient
temperature.
• Allow 30 minutes for the compact fridge to return to
room temperature before attempting to switch from
heating to cooling mode, or visa versa.
• Allow at least 10cm distance from the back and
sides of the compact fridge to allow the withdrawn
heat to disperse.
• To achieve the quickest cooling operation, fill the
fridge with beverages which have already been
refrigerated.They will then stay cool and become
even cooler providing the fridge remains switched
on.
• The temperature at which the fridge operates
depends on the surrounding ambient temperature.
Cooling will be more efficient in a colder
environment.
The compact fridge is not
warming sufficiently
• Check the MODE switch is set to HOT (the red LED is
illuminated).

10
4 litre compact fridge
Product support
Help and assistance
If you require any technical guidance or find that your compact fridge is not operating as
intended, a simple solution can often be found in the Troubleshooting section of these
instructions or online at www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 600 3021*. To help give
us give you a fast and efficient service please have the following information ready:
Model Ref.
Serial number
Date of purchase
Local call rates applies*
Lines open 8am-7pm Monday to Saturday and
10am-4pm Sunday.
*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines depending on
your call plan/tariff. Mobile and other providers costs may vary, see www.bt.com/pricing for details.
For security and training purposes, telephone calls to and from customer service centres may be
recorded and monitored. Calls from Republic of Ireland will attract international call charges.
You can find these on
the rating plate -
a small information
panel (usually a sticker
or metal plate) on the
rear of your product.
This will be shown on
your receipt
MNBX4

Your Argos Guarantee
This product is guaranteed for twelve months from the date of original purchase. Any defect
that arises due to faulty materials or workmanship will be repaired free of charge (or if
applicable the product will be replaced or the purchase price refunded) where possible
during this period by the dealer from who your purchased the unit.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs or
consumable items.
• The product must be correctly installed and operated in accordance with the
instructions contained in the manual.
• It must be used solely for domestic purposes.The guarantee will be rendered invalid if
the product is re-sold or has been damaged by inexpert repair.
• Specifications are subject to change without notice.
• Alba disclaim any liability for loss or damage arising from the breakdown of the product.
• This guarantee is in addition to and does not diminish your statutory or legal rights.
4 litre compact fridge
Product support

Contact:
www.argos-support.co.uk
Helpline: 0345 600 3021
Rev 1.7
