Crosley CR32CD User manual

910-255500-0020-100
CR32CD
PROGRAM
PHONES
VOLUME
AM
FM
ON/OFF
PAUSE
PLAY /
STOP
MAX.
REPEAT
TUNING
CLOSE
OPEN/
B.SKIP F.SKIP CD/RADIO
www.crosleyradio.com
CATHERDRAL CD
Instruction Manual

The exclamation point
within an equilateral
triangle is intended to
alert user to the
presence of important
operating and
maintenance (servicing)
instruction in the
literature accompanying
the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lighting flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert user to
the presence of uninsulated
"dangerous voltage" within
the product's enclosure
that may be of sufficient
magnitude to constitute
risk of electric shock
to persons.
CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE
COVER (OR BACK). NO
USER - SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Specification
Frequency Range : AM 520 - 1710 KHz
: FM 87.5 - 108 MHz
Power Supply : AC adapter (DC 12V 1A)(Included)
Power Consumption : 14W
Speaker : 3 8Ohm 3W x 2
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
*DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
9
General
The unit does not operate
1The AC adapter is not connected. Check to
make sure it is plugged in correctly.
2The unit is not turn on rotate the VOLUME
ON/OFF KNOB (2) from the OFF position past
the click to turn on the unit .
There is no Sound
1Check the volume level by turning the VOLUME
KNOB (2).
CD does not play
1Check to make sure CD is inserted correctly
(label side facing up).
2Check that the surface of the CD is clean
3Make sure function switch is set to CD.
2
The sound from all speakers is cut off.
HEADPHONE JACK (5)
Listening through Earphones/Headphones
(not included)
Headphone Jack
Troubleshooting

Repeat Repeat all Normal
Programmed Play
1
2
3
4
5
6
7
8
9
10 12
11 13
14 16
15
17
18
1Turn the unit on by turning the ON/OFF KNOB
(2) located on the front panel to the ON position.
2Press the CD/Radio MODE BUTTON (16) to the
CD position.
3Press the OPEN/CLOSE BUTTON (15) to
open the CD DRAWER(10).
4Load the desired CD into the player with the
labeled side of the CD facing up and close the
CD DRAWER(10).
5The LED DISPLAY (18) will flash ( - - ) for a
second and then display the total number of
tracks on the CD.
Note: The display will read no if there is no
disc in the unit or the disc cannot be read.
6Press the PLAY/PAUSE BUTTON (6) to begin
playing the CD.
7To skip to a different track, press the FORWARD
SKIP BUTTON (14) or BACKWARD SKIP
BUTTON (13) until you reach the desired
track number. Pressing the FORWARD SKIP
BUTTON (14) will advance forward from track
to track. Pressing the BACKWARD SKIP
BUTTON (13) will skip backwards from track to
track.
8To fast forward through part of a particular track,
press and hold the FORWARD SKIP BUTTON
(14). Playback will resume at the point that
you release the button. To reverse playback,
press and hold the BACKWARD SKIP BUTTON
(13).
9To pause during playback, press the
PLAY/PAUSE BUTTON (6). To resume play,
press the button again.
10 To Stop playback, press the STOP BUTTON (7).
3In Normal mode, the CD will play from track 1 or
the first selected track till the end of the CD and
stop.
4When in Repeat 1, the repeat light will flash and
only the selected song will be repeated. You can
select the song to repeat before you press play
or during playback.
5When in Repeat all, the repeat light will stay on
continuously. In this mode, once the CD is
finished, it will start over from the beginning.
6Pushing STOP BUTTON(7) will clear the Random
and Repeat functions and the unit will return to
Normal Mode.
You can program up to 20 tracks that will play in the
order that you program them.
1In CD Mode with a CD inserted and play stopped,
press the PROGRAM BUTTON (11).
2Select a track you would like to program in
memory by using the Forward or Backward skip
buttons.
3Once you have selected a track, press the
PROGRAM BUTTON (11) again. That track is
now stored.
4Repeat steps 2-3 to store up to 20 tracks.
5When all desired tracks are programmed, press
the PLAY/PAUSE BUTTON (6) to begin playback
of the selected tracks. The tracks will play in the
order in which they were programmed.
6To clear programming, press the stop button.
Programmed tracks will also be cleared if the
CD Drawer is opened or the power is
disconnected.
1There are three modes in which you can listen
to your CD :
Normal, Repeat 1, Repeat all.
2To change between these options, press the
REPEAT BUTTON (16). The play mode will
change in the following sequence.
7
CD Player
Playing a CD
Control Locators
4
Unit Controls
1 Tuner Dial
2Volume On/Off Knob
3Play/Pause Indicator
4 AM/FM Button
5 Headphone Jack
6Play/Pause Button
7Stop Button
8 Repeat Indicator
9 Repeat Button
10 CD Drawer
11 Program Button
12 Program Indicator
13 Backward Skip Button
14 Forward Skip Button
15 Open/Close Button
16 CD/RADIO Mode Button
17 Tuning Knob
18 LED Display
Play Mode
PROGRAM
PHONES
VOLUME
AM
FM
ON/OFF
PAUSE
PLAY/
STOP
MAX.
REPEAT
TUNING
CLOSE
OPEN/
B.SKIPF.SKIPCD/RADIO
PROGRAM
PHONES
VOLUME
AM
FM
ON/OFF
PAUSE
PLAY /
STOP
MAX.
REPEAT
TUNING
CLOSE
OPEN/
B.SKIP F.SKIPCD/RADIO

LIMITED MANUFACTURERS WARRANTY
10
IMPORTANT SAFETY INSTRUCTION
PLEASE READ CAREFULLY ALL THE FOLLOWING IMPORTANT SAFEGUARDS
THAT ARE APPLICABLE TO YOUR EQUIPMENT
1. Read Instructions - All the safety and operating instructions should be read before the product is operated.
2. Retain instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating Instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
8. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
9. Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered, The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in a built - in installation such as a bookcase
or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.
10. Power Sources - This product should be operated only from the type of power source indicated on the marking label,
if you are not sure of the type of power supply to your home. Consult your product dealer or local power company.
For products intended to operate from battery power, or other sources, refer to the operating instructions.
11. Grounding or Polarization - This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet try reversing the plug, If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12. Power - Cord Protection - Power - supply cords should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
13. Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage
to the product due to lightning and power - line surges.
14. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short - out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
17. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions;
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance - this indicates a need for service.
19. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
20. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
21. Wall or ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat - The product should be situated away from heat sources such as radiators. Heat registers, stoves, or other
products (including amplifiers) that produce heat.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the users authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful intereference to radio or
television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio TV technician for help.
Crosley Radio, Inc. warrants the product to be free from defects in material and
workmanship under normal use for a period of one year from the original date of
purchase. This warranty is not transferable. If the product is determined to be defective
during the warranty period, the unit will be repaired or replaced at Crosley Radios sole
discretion. This warranty covers manufacturing defects and normal consumer use and
does NOT cover damage or failure as a result of abuse, accident, alterations, misuse,
neglect, abnormal wear and tear, inadequate maintenance, commercial or unreasonable
use, damage caused by power surges, mishandling, accident, acts of God or attempted
repair by an unauthorized service agent. Also not covered are cosmetic damages,
cords and antennas.
Should this product fail to function in a satisfactory manner, it is best to first return it
to the store or retailer where it was originally purchased. If additional service is still
needed, the original purchaser must FIRST contact our offices to obtain an RA (Return
Authorization) Number.
TO OBTAIN AN RA NUMBER
CALL: 1.888.CROSLEY
(1.888.276.7539)
Send the unit prepaid to the address below in the original packaging (or reasonable
substitute to prevent damage). Clearly mark your RA number on the outside packaging
and include the original sales receipt (or a copy) indicating date of purchase, amount
paid, and place of purchase. You must also include your full name, shipping address
and daytime contact number. Please include a check or money order in the amount
of $19.95, made payable to Crosley Radio, to cover handling and return shipping
charges. Returned products will not be shipped to PO Boxes. Crosley Radio will not
be responsible for delays or unprocessed claims resulting from a purchasers failure
to provide any or all of the necessary information.
CROSLEY RADIO
ATTN: RETURNS DEPT
2001 PRODUCTION DRIVE
Louisville, KY 40299
For additional support: Crosley Radio Consumer Service Department
24 hours a day / 7 days a week
Telephone: 1.888.CROSLEY (1.888.276.7539)
There are no express warranties except as listed above.
The purchasers bill of sale is the only proof of warranty entitlement.
This warranty gives the purchaser specified legal rights in addition to any rights which
may vary from state to state.
In accordance with the Moss-Magnuson Warranty Act of July 10, 1975, this is termed
a limited warranty which in no way compromises Crosley Radios high standards of
quality and workmanship.

FM  Make sure the FM WIRE ANTENNA (20) is
fully extended in a straight line.
AM  This radio is equipped with an internal AM
antenna. Try rotating the unit slightly to one
side or the other to improve AM reception.
3
Radio Operation
1Press the CD/RADIO MODE BUTTON (16) to
the Radio position.
2Press the AM/FM BUTTON (4) to the desired
radio band (AM or FM ).
3Select the desired radio station by rotating
TUNING KNOB (17).
4Adjust the VOLUME KNOB (2) to the desired
sound level.
Antenna: for FM reception, the unit is provided with
a FM WIRE ANTENNA (20) , move the wire until
the reception is clear and with no interferences. For
AM reception, the unit is provided with a directional
build-in ferrite antenna. Rotate the set to find the
position in which the best reception is obtained. Do
not connect the FM WIRE ANTENNA (20) to any
outside antenna.
8
Antenna
Hints For Better Reception
Radio Operation
About This Manual
Thank you for purchasing the Crosley Catherdral
CD (CR32CD). Before operating this unit, please
read this manual thoroughly and retain it for future
reference.
Instructions in this manual describe the control
functions of the CR32CD.
Welcome Table of Contents
Control Locators
Control Locators....................... 4 - 5
Getting Started
Unpacking ................................ 6
Set up ....................................... 6
CD Player
Playing a CD ............................ 7
Play Mode ............................... 7
Programmed Play ................... 7
Radio Operation
Radio Operation ..................... 8
Hints For Better Reception....... 8
Antenna ................................... 8
General
Headphone Jack ..................... 9
Troubleshooting Guide ............. 9
Warranty ................................... 10

1Unwind the A/C power adapter (located in a
white box inside the packaging foam). Connect
the small end of the adapter to the back of the
turntable. Connect the other end to an A/C power
outlet.
19
20 21
22
Control Locators
Unit Controls
19 Speaker
20 Antenna
21 AC Adapter
22 12V AC Adapter Jack
5
Power Source
Getting Started
6
Unpacking
Set Up
A/C adapter(21)
1Pull the packing materials off the unit.
2Remove the plastic bag covering the radio.
3Press OPEN/CLOSE BUTTON (15) to open the
CD DRAWER (10).
4Unwind FM Antenna (20) and allow it to hang
straight down.
5Remove tie from A/C adapter(21).
Note: Save all packing materials.
1Plug A/C adapter into appropriate outlet.
Note: This product may be equipped with a
polarized alternating-current line plug (a
plug having one blade wider than the other.)
This plug will fit into the power outlet only
one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet
try reversing the plug, if the plug should still
fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
