Fiberlink®
3X3X Series
Models 3134/3135 & 3334/3335
10 Channel Video Multiplexer/Demultiplexer
World Headquarters
55 Cabot Court
Hauppauge, New York 11788 USA
Tel: [phone]
Fax: [phone]
[email protected]
Asia
Communications Specialties Pte Ltd
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Tel: [phone]
Fax: [phone]
[email protected]
commspecial.com
Communications Specialties’ Fiberlink® 3X3X User’s Manual
The all-digital Fiberlink® 3X3X
series allows you to multiplex
up to 10 video channels along
with optional RS-Type data onto
a single ber optic core oering
unsurpassed signal distribution
eciency. Fiberlink 3134 is
compatible with Fiberlink Matrix
oering you the ability to route
up to 320 video signals.

Page 2 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Contents
Welcome .................................................................3
Features ..................................................................3
Package Contents .........................................................3
Technical Specications
Model Part Number Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General Specications ................................................4
Video Specications ..................................................4
Data Specications ...................................................5
Optical Loss Budgets .................................................5
Maximum Useable Distance ..........................................5
Installation Instructions ...................................................6
Alarm Switch Settings .....................................................7
Alarm Output Settings ....................................................7
Data Conguration Procedure .............................................8
Data DIP Switch Settings ..................................................9
Data Terminal Block Wiring ...............................................10
Operating Pointers .......................................................12
Troubleshooting .........................................................12
Maintenance and Repairs ................................................13
Certications ............................................................13
Warranty ................................................................14
Accessories and Related Products ........................................15
Contents

Page 3Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Welcome
Thank you for purchasing Communications Specialties, Inc.’s Fiberlink® 3X3X Series.
The all-digital Fiberlink® 3134 series allows you to multiplex up to 10 video channels onto a
single ber optic core oering unsurpassed signal distribution eciency. Fiberlink 3134 is
compatible with Fiberlink Matrix oering you the ability to route up to 320 video signals.
Fiberlink® 3334 adds RS-Type Data to the same ber optic cable.
Features
• No adjustments; pure digital processing and transmission
• Full color, uncompressed, real-time transmission in NTSC, PAL or SECAM
• Optional RS-Type Data
• Built-in diagnostic LEDs for each channel and a loss of signal/broken ber alarm
• Internal, universal power supply with AC line cord
• Fiberlink Matrix Compatible
• One rack unit high (1.75 inches).
• Rackmount ears included with unit
Package Contents
• One Fiberlink® 3134, 3135, 3334 or 3335
• This User’s Manual
• AC Line Cord
• Rackmount Ears
• Accessories Pack (fuses, rubber feet, etc)
Welcome | Features | Package Contents

Page 4 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Model Part Number Specication
Unit Type Part Number
Transmitter Box (No Data) 3134-S7 or 3134-F9
Receiver Box (No Data) 3135-S7 or 3135-F9
Transmitter Box (With Data) 3334-S7 or 3334-F9
Receiver Box (With Data) 3335-S7 or 3335-F9
General Specications
Operating Wavelength 1310 nm (S Version)
1550 nm (F Version)
Optical Connectors ST (S Version)
FCPC (F Version)
Operating Temperature 0 to +55 degrees C
Relative Humidity 10% - 90% (non-condensing)
Operating Power 95-250 VAC, 47-63 Hz
Size 1.75 H x 16.75 W x 10 D (inches)
44 H x 425 W x 254 D (mm)
Weight Approx. 5.5 lbs; 2.5 kg
Fiberlink Matrix Compatibe Models 3134 & 3135
Video Specications
Number of Channels 10
Number of Fibers 1
Video Bandwidth
(all channels at rated distance) 10 Hz - 6.5 MHz (-3 dB)
Video Input 1 volt p-p
Input/Outut Impedance 75 Ohms
Dierential Gain <1.5% typical
Dierential Phase <1 degree typical
Signal-to-Noise Ratio >63 dB (CCIR weighting)
Video Connectors BNC
Video Connector BNC; 4-Pin Mini-DIN for S-Video
Technical Specications
Technical Specications

Page 5Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Data Specication
Number of Channels 1 (bi-directional)
Interfaces Supported RS-232, RS-424, RS-485
2 Wire & 4 Wire
Switch Selectable
Maximum Data Rate 100 Kbps
Protocols NRZ, NRZI, RZ, Manchester, Bi-phase
Data Connectors Screw Terminal Block
Data Specications
Optical Loss Budgets and Maximum Useable Distance
Data Specications | Loss Budgets | Maximum Distance
1310 nm (S Version)
Fiber Type Loss Budget Distance
Single Mode Fiber 0-20 dB 55km
Multimode Fiber (62.5u) 0-20 dB 1.3km
Multimode Fiber (50u) 0-20 dB 1.0km
1550 nm (F Version)
Fiber Type Loss Budget Distance
Single Mode Fiber 5-23 dB 80km
*Note: A minimum attenuation of 5dB is required between the transmitter and
receiver for this version.
Distance specications are only approximate and are not guaranteed.
Operating loss budget must not be exceeded.

Page 6 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Installation Instructions
The Fiberlink® 3X3X Series of ber optic transmission systems are ready for
immediate use and do not require any special tools or equipment. However, an Optical
Power Meter, such as the Fiberlink® 6615, can be useful in determining optical loss budgets
during your systems design and maintenance.
The following instructions describe the typical installation procedure:
1) Connect the video source(s) to the video input(s) on the transmitter unit.
2) Connect your video output cable(s) to the video output connector(s) on the
receiver unit.
3) Connect the ber optic cable to the transmitter and receiver units.
4) Connect the power cables to the transmitter and receiver units.
5) When power is applied, the green POWER LED should illuminate, indicating the
presence of operating power. The Video LEDs will give an indication
as described in the Indicator LED’s and Alarm Circuitry section of this manual.
Installation Instructions
The transmitting element in the Fiberlink® 3134 transmitter
unit contains a solid state Laser Diode located in the optical
connector. This device emits invisible infrared electromagnetic
radiation which can be harmful to human eyes. The radiation
from this optical connector, if viewed at close range with no
ber optic cable connected to the optical connector, may be
sucient intensity to cause instantaneous damage to the
retina of the eye. Direct viewing of this radiation should be
avoided at all times!
CAUTION: RISK OF ELECTRICAL SHOCK
To reduce the risk of electrical shock, do not remove the
cover. No user serviceable parts inside. Refer servicing to
qualied service personnel.

Page 7Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series Alarm Switch Settings
Alarm Switch Settings (Transmitter)
Switch Position Alarm Indication Up Down
1 thru 10 Loss of Video Enabled Disabled
(Channel 1 thru 10)
11 N/A N/A N/A
12 N/A N/A N/A
1 thru 10 Loss of Video Enabled Disabled
11 Loss of optical signal Enabled Disabled
12 N/A N/A N/A
Alarm Output Settings
Pin Position Operation
Pin 7 N/A
Pin 8 Closed for no alarm condition
Open for alarm conditions
Pin 9 Common
Pin 10 Closed for no alarm condition
Open for alarm conditions
Alarm Switch Settings & Options
When an alarm condition occurs, the red Alarm LED on the front panel will blink, the inter-
nal piezo sounder will beep and the external contacts will be activated (see Alarm Output
Settings). Switches on the front panel allow you to turn o the sounder, but the Alarm LED
will continue to blink and the external contacts will remain open until the fault is corrected.
Alarm Condition Output
Note that when the alarm is triggered, a set of isolated SPDT contacts (rated at 0.4A,
115VAC 50/60 Hz or 2A, 32 VDC resistive) will be activated. These contacts are available at
the rear panel ALARM terminal block and may be used for remote signaling applications.
Connections to this block are as follows:
Alarm Switch Settings (Receiver)

Page 8 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Data Congration Procedure.
The following instructions describe the typical data conguration procedure:
1) Set the rear panel DIP switches of the transmitter for the desired protocol.
See page 9 for DIP switch conguration settings.
2) Set the rear panel DIP switches of the receiver for the desired protocol.
See page 9 for DIP switch conguration settings.
3) Data terminal block positions 1 through 6 can be used as data inputs or data outputs
depending upon the protocol selected. Refer to page 10 for terminal block
conguration.
4) After the terminal blocks have been wire appropriately, plug them into the rear panel
connectors labels DATA/ALARM on both the transmitter and receiver units.
5) If there is no ber optic cable connecting the transmitter and receiver at this time,
connect an optical cable to both the transmitter and receiver units at this time.
5) Turn on the power for both the transmitter and receiver units. When power is applied
the green POWER LED on each unit will illuminate.
If data is present, the transmitter’s TX LED and the receiver’s RX LED will illuminate.
If a ber optic cable is connected to both the transmitter and receiver but there is no
data present, both the transmitter’s TX LED and the receiver’s RX LED will remain o.
If you feel this is in error check the data SIP switch settings for your desired protocal
on both the receiver and the transmitter units then verify the wiring of the data
terminal blocks.
Data Conguration Procedure

Page 9Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series Data DIP Switch Settings
Data DIP Switch Settings
Switch Position 1-3, 7-10 are used to select the desired protocol. Switch positions 4-6 are
used to set the desired Baud Rate.
Protocols:
Baud Rates
1 2 3 4 5 6 7 8 9 10 11 12
Sets Protocol
1 2 3 4 5 6 7 8 9 10 11 12
RS-232
1 2 3 4 5 6 7 8 9 10 11 12
2400 (4.73ms)
1 2 3 4 5 6 7 8 9 10 11 12
19.2k (620μsec)
1 2 3 4 5 6 7 8 9 10 11 12
76.8k (150μsec)
1 2 3 4 5 6 7 8 9 10 11 12
9600 (1.10ms)
1 2 3 4 5 6 7 8 9 10 11 12
57.6k (180μsec)
1 2 3 4 5 6 7 8 9 10 11 12
4800 (2.20ms)
1 2 3 4 5 6 7 8 9 10 11 12
38.4k (300μsec)
1 2 3 4 5 6 7 8 9 10 11 12
RS-485 4 Wire
Multidrop w/ Tristate
1 2 3 4 5 6 7 8 9 10 11 12
RS-422/485 4 Wire
Point to Point
1 2 3 4 5 6 7 8 9 10 11 12
RS-485 2 Wire
Zero Tx/Rx
1 2 3 4 5 6 7 8 9 10 11 12
RS-485 2 Wire
Auto Tx/Rx
1 2 3 4 5 6 7 8 9 10 11 12
Sets Baud Rate

Page 10 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Data Terminal Block Wiring
Pins 1 through 6 are used for data. Pins 7 through 10 are used for the Alarm (see page 7).
RS-232
RS-422
Data Terminal Block Wiring
1 2 3 4 5 6 7 8 9 10
DATA ALARM
1 2 3 4 5 6 7 8 9 10
DATA ALARM
Terminal Block
Receptacle on Unit
Terminal Block
Receptacle on Unit
PIN 1: Signal Common
PIN 2: Signal to be transmitted over ber
PIN 4: Signal being received from ber
PIN 1: Shield Ground
PIN 2: Signal to be transmitted (+) over ber
PIN 3: Signal to be transmitted (–) over ber
PIN 4: Signal being received (+) from ber
PIN 5: Signal being received (–) from ber
Terminal Block
Terminal Block

Page 11Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
RS-485 2 Wire
RS-485 4 Wire
Data Terminal Block Wiring
1 2 3 4 5 6 7 8 9 10
DATA ALARM
1 2 3 4 5 6 7 8 9 10
DATA ALARM
Terminal Block
Receptacle on Unit
Terminal Block
Receptacle on Unit
PIN 1: Shield Ground
PIN 2: Signal to be transmitted/received (+) over/from ber
PIN 3: Signal to be transmitted/received(–) over/from ber
PIN 1: Shield Ground
PIN 2: Signal to be transmitted (+) over ber
PIN 3: Signal to be transmitted (–) over ber
PIN 4: Signal being received (+) from ber
PIN 5: Signal being received (–) from ber
Terminal Block
Terminal Block

Page 12 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Operating Pointers
Remember to check attenuation of the ber optic cable. The system will only operate
properly if these specications fall within the range of the system’s loss budget.
Troubleshooting
Multimode ber optic cable contains an optical ber with a light carrying “core” that is
only .0025 inches (62.5 microns) in diameter. Single mode ber optic cable has an even
smaller “core,” only .00032 to .0004 inches (8-10 microns). This is smaller than a human hair!
Therefore, any minute particles of dirt or dust can easily block the ber from accepting or
radiating light. To prevent this from happening, always use the provided dust caps when
ever optical connectors are exposed to air. It is also a good idea to gently clean the tip of an
optical connector with a lint-free cloth moistened with alcohol whenever dust is suspected.
The status of the LEDs should provide the rst clue as to the origin of any operational
failure. If these are o, it usually means that the ber is broken or has too much attenuation.
Next, be certain that the input and output signal connections are correct.
An optical power meter, such as the Fiberlink® 6615, a visible light source, such as the
Fiberlink® 6610, and a Three Wavelength Light Source, such as the Fiberlink® 6620, can
greatly assist and expedite troubleshooting of ber optic transmission systems and are
recommended tools all installers should have available.
Finally, although multimode and single mode devices may look the same, they will not
operate properly together. Using the wrong device or ber can easily add more attenuation
than specied, resulting in poor overall performance. It should be noted that some of our
ber optic products support both single mode and multimode ber in the same unit.
If, after reviewing the above possibilities, the system is still not operating, please contact
the Customer Service Department for further assistance. If you suspect your problem is
caused by the optics or the ber optic cable, and you have an optical power meter, please
take the appropriate measurements prior to contacting support.
Operating Pointers | Troubleshooting

Page 13Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Certications
Maintenance and Repairs
The Fiberlink® 3X3X Series has been manufactured using the latest semiconductor devices
and techniques that electronic technology has to oer. They have been designed for long,
reliable and trouble-free service and are not normally eld repairable.
Should diculty be encountered, Communications Specialties maintains a complete
service facility to render accurate, timely and reliable service of all products.
The only maintenance that can be provided by the user is to ascertain that optical
connectors are free of dust or dirt that could interfere with light transmission and that
electrical connections are secure and accurate. Please see the Troubleshooting section of
this manual for additional information.
An optical power meter, such as the Fiberlink® 6615, a visible light source, such as the
Fiberlink® 6610, and a Three Wavelength Light Source, such as the Fiberlink® 6620, can
greatly assist and expedite troubleshooting of ber optic transmission systems and are
recommended tools all installers should have available.
All other questions or comments should be directed to our Customer Service Department.
It should be noted that many “problems” can easily be solved by a simple telephone call.
If you suspect your problem is caused by the optics or the ber optic cable, and you have
an optical power meter, please take the appropriate measurements prior to contacting
support.
Maintenance and Repairs | Certications

Page 14 Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series
Communications Specialties, Inc. (CSI) warrants that, for a period of three years after
purchase by the Buyer, this product will be free from defects in material and workmanship
under normal use and service. A Return Material Authorization (RMA) number must be
obtained from CSI before any equipment is returned by the Buyer. All materials must be
shipped to CSI at the expense and risk of the Buyer.
CSI’s obligation under this warranty will be limited, at its option, to either the repair or
replacement of defective units, including free materials and labor. In no event shall CSI be
responsible for any incidental or consequential damages or loss of profits or goodwill.
CSI shall not be obligated to replace or repair equipment that has been damaged by fire,
war, acts of God, or similar causes, or equipment that has been serviced by unauthorized
personnel, altered, improperly installed, or abused.
RMA numbers and repairs can be obtained from:
Communications Specialties, Inc.
55 Cabot Court
Hauppauge, NY 11788 USA
Tel: [phone]
Fax: [phone]
or, in the Asia Pacific Region:
Communications Specialties Pte Ltd
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Tel: [phone]
Fax: [phone]
RMA numbers can also be obtained from our web site: commspecial.com
Please have your serial number available.
Warranty

Page 15Fiberlink® 3X3X Series User’s Manual
Fiberlink® 3X3X Series Accessories and Related Products
Fiberlink® 6610 Visible Light Source
The Fiberlink® Visible Light Source provides a
visible 650 nm laser output that can be used for
identifying ber breaks and individual bers within
ber bundles, allowing for convenient, on-site
testing of ber networks during construction
and maintenance procedures.
Fiberlink® 6615 Optical Power Meter
The Fiberlink® Optical Power Meter measures the
power of optical signals at 850, 980, 1310 and 1550
nm wavelengths, allowing for convenient, on-site
testing of ber networks during construction and
maintenance procedures. It can be used to measure
the power of an optical signal reaching the receiving
end of a ber optic cable, as generated either by a
transmitter unit or by a light source such as the 6620.
Fiberlink® 6620
Three Wavelength Light Source
The Fiberlink® Three Wavelength Light Source oers a
laser output at wavelengths of 1310 and 1550 nm and
VCSEL output at 850 nm, allowing for convenient,
on-site testing of ber networks during construction
and maintenance procedures.

Fiberlink®
3X3X Series
Models 3134/3135 & 3334/3335
10 Channel Video Multiplexer/Demultiplexer
World Headquarters
55 Cabot Court
Hauppauge, New York 11788 USA
Tel: [phone]
Fax: [phone]
[email protected]
Asia
Communications Specialties Pte Ltd
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Tel: [phone]
Fax: [phone]
[email protected]
commspecial.com
©2010 Communications Specialties, Inc.
All Rights Reserved.
Fiberlink and the starburst logo are
registered trademarks of
Communications Specialties, Inc.
CSI and the triangle designs are trademarks
of Communications Specialties, Inc.
P/N 128729 Rev B
Single Color (Black)
Single Color (Black)
on Black Background
If you need to use the CSI logo on a non-solid
background use the Photoshop Layered Files.
©2005 Spectra Vision Productions, Inc.
Communications Specialties’ Fiberlink® 3X3X User’s Manual
