Manual 07504208 Model 4208
Page 1
Operation Manual
Model 4208
6(1x8) 2-wire Multiplexer
90900050

Manual 07504208 Model 4208
Page 2
Operation Manual
All technical data and specifications in this publication are subject to change without prior notice and do
not represent a commitment on the part of Giga-tronics, Incorporated.
© 2011 Giga-tronics Incorporated. All rights reserved. Printed in the U.S.A.
CONTACT INFORMATION
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]
On the Internet: www.gigatronics.com
Warranty
Giga-tronics Series 3000 Switching Modules are warranted against
defective materials and workmanship for three yearsfrom date of shipment,
or as detailed in the warranty section of this manual. Giga-tronics will, at its
option, repair or replace products that are proven defective during the
warranty period. This warranty DOES NOT cover damage resulting from
improper use, nor workmanship other than Giga-tronics service. There is no
implied warranty of fitness for a particular purpose, nor is Giga-tronics liable
for any consequential damages. Specification and price change privileges are
reserved by Giga-tronics.

Manual 07504208 Model 4208
Page 3
Operation Manual
Regulatory compliance information
This product complies with the essential requirements of the following applicable European
Directives, and carries the CE mark accordingly.
89/336/EEC and 73/23/EEC
EMC Directive and Low Voltage Directive
EN61010-1 (1993)
Electrical Safety
EN61326-1 (1997)
EMC –Emissions and Immunity
Manufacturer’s Name:
Manufacturer’s Address
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
U.S.A.
Type of Equipment:
Model Series Number
Switching Module
4208
Declaration of Conformity on file. Contact Giga-tronics at the following;
Giga-tronics, Incorporated
4650 Norris Canyon Road
San Ramon, California 94583
Telephone: [phone] (only within the United States)
925.328.4650
Fax: [phone]

Manual 07504208 Model 4208
Page 4
Operation Manual
Record of Changes to This Manual
Use the table below to maintain a permanent record of changes to this document. Corrected
replacement pages are issued as Technical Publication Change Instructions (TPCI). When you
are issued a TPCI, do the following:
1. Insert the TPCI at the front of the manual binder.
2. Remove the pages from the manual binder that are noted in the TPCI.
3. Replace the page(s) removed in the previous step with the corrected page(s).
4. Record the changes in the table below.
TPCI
Number
TPCI Issue
Date
Date Entered
Comments

Manual 07504208 Model 4208
Page 5
Operation Manual
Revision History
Revision
Description of Change
Chg Order #
Approved By
A
Initial Release 5/98
JL
B
Updated
C
Reformatted 3/12
RCW

Manual 07504208 Model 4208
Page 6
Operation Manual
Contents
Contents........................................................................................................................................................ 6
Chapter 1 Introduction ................................................................................................................................. 7
1.1 Safety and Manual Conventions.........................................................................................................7
1.1.1 Product Reference....................................................................................................................... 7
1.1.2 Personal Safety Alert...................................................................................................................7
1.1.3 Equipment Safety Alert ...............................................................................................................7
1.1.4 Notes ........................................................................................................................................... 7
1.1.5 Electrical Safety Precautions ....................................................................................................... 7
Chapter 2 Functional Description ................................................................................................................. 8
2.1 Introduction........................................................................................................................................8
2.2 General Description............................................................................................................................8
Chapter 3 Block Diagram .............................................................................................................................. 9
Chapter 4 Specifications .............................................................................................................................10
Chapter 5 Register Map .............................................................................................................................. 11
5.1 Introduction......................................................................................................................................11

Manual 07504208 Model 4208
Page 7
Operation Manual
Chapter 1 Introduction
1.1 Safety and Manual Conventions
This manual contains conventions regarding safety and equipment usage as described below.
1.1.1 Product Reference
Throughout this manual, the term “Common Core Switching Platform, Series 8800” refers to all models
of within the series, unless otherwise specified.
1.1.2 Personal Safety Alert
WARNING: Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
1.1.3 Equipment Safety Alert
CAUTION: Indicates a situation which can damage or adversely affect the product or
associated equipment.
1.1.4 Notes
Notes are denoted and used as follows:
NOTE: Highlights or amplifies an essential operating or maintenance procedure, practice, condition or
statement.
1.1.5 Electrical Safety Precautions
Any servicing instructions are for use by service-trained personnel only. To avoid personal injury, do not
perform any service unless you are qualified to do so.
For continued protections against fire hazard, replace the AC line fuse only with a fuse of the same
current rating and type. Do not use repaired fuses or short circuited fuse holders.
WARNING
!
CAUTION

Manual 07504208 Model 4208
Page 8
Operation Manual
Chapter 2 Functional Description
2.1 Introduction
This manual provides the necessary information for the Model 4208 card assembly.
2.2 General Description
This card assembly contains six 1x8 dual wire switch multiplexers (trees). This card assembly fits in an
ASCOR’s series 4000 VXI host modules which can be a 3 wide to 8 wide VXI module with the capacity for
six to 17 card assemblies. This allows of ease in design of complex switch systems. The Series 4000 host
VXI module contains sixteen 2-wire analog back plane to allow connections between card assemblies
without the need of external cabling. This architecture produces a high performance switch system
without the usual custom designs or external wiring and integration efforts. The interface and
mechanical construction of the Series 4000 VXI module and card assemblies meets the specification of
the VXIbus System Specification, rev. 1.2 and 1.3.
note: This card assembly requires a ASCOR Series 4000 host VXI module. It is not a stand alone VXI
module.

Manual 07504208 Model 4208
Page 9
Operation Manual
Chapter 3 Block Diagram
Analog Groundplane
Typical 1x8 Multiplexer (1 of 6)

Manual 07504208 Model 4208
Page 10
Operation Manual
Chapter 4 Specifications
Electrical:
Switching Voltage (DC/Peak, AC, Resistive): 220VDC, 250VACpk
Switching Current (DC/Peak, AC, Resistive): 2 Amps
Max Switching Power: 60 W
Life expectancy @ Signal < 1.0V, 0.010A) 1,000,000
Contact resistance <0.05 ohm
Mechanical:
Thickness: 0.6 inches
Width: 7.825 inches
Length: 10.75 inches
Weight: 1 lbs.
Connectors:
Connector: Airborn type WTB56PR
Environmental Specifications
Temperature:
Operating: 0º to 55ºC
Storage: - 40º to 75ºC
Relative Humidity:
Operating: 0 to 90% non-condensing
Storage: 0 to 95% non-condensing

Manual 07504208 Model 4208
Page 11
Operation Manual
Chapter 5 Register Map
5.1 Introduction
The Model 4208 is a VXI register based card assembly design to be used with the ASCOR Series 4000
host VXI module. The switch paths are controlled by a high speed interface called VXImax™ is a 16/32
bit data controller. The Model 4208 can be programmed in 16 bit or 32 bit wide data format. Through
your VXI controller, write the data to the appropriate register as shown on the register map for the relay
or relays in the register that is being closed. When the data bit is true, the relay chosen will be closed.
The state of the relays in a register can be determined by reading the desired register. The data read
back represents the value at the coil of the relay. This allows verification that the program register has
correctly controlled the relay coil.
The following register maps are shown in two configurations: 16 bit mode and 32 bit mode. In each
section, 16 bit and 32 bit, the register map is organized to show the relay designation in each register. It
is followed by the register’s functionality and the path connections to the front panel.

Manual 07504208 Model 4208
Page 12
Operation Manual
Register Map
A16 Register
Offset Value
00h 7Fb5h
7= Register Based, A16/A24 Module
FB5=VXI Manufacturer ID, ASCOR
02h 7xxxh
7=A24 space requirement
xxx= Model Number for this module (see host module)
04h FFFCh
06h (assigned by Resource Manager)
Control Bit
3Eh 0 Low true output to enable coil driver IC’s
1 When low enables readback of coil state
2 High true EEPROM write enable (factory only)
3-15 Don’t care
MSB LSB
REG
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
8000h
K16
K15
K14
K13
K12
K11
K10
K9
K8
K7
K6
K5
K4
K3
K2
K1
8002h
K32
K31
K30
K29
K28
K27
K26
K25
K24
K23
K22
K21
K20
K19
K18
K17
8004h
K48
K47
K46
K45
K44
K43
K42
K41
K40
K39
K38
K37
K36
K35
K34
K33

Manual 07504208 Model 4208
Page 13
Operation Manual
REGISTER: 8000h
MODE: 16 bit
FUNCTION: Control Matrix K1 through K16, note shield is on J1-29 and J1-1
BIT
FUNCTION
CONNECTION
RELAY
Chapter 6 COMMENT
0
K1
J1-56,28 TO J1-48,20
K1
Group 1 1x8
1
K2
J1-55,27 TO J1-48,20
K2
Group 1 1x8
2
K3
J1-54,26 TO J1-48,20
K3
Group 1 1x8
3
K4
J1-53,25 TO J1-48,20
K4
Group 1 1x8
4
K5
J1-52,24 TO J1-48,20
K5
Group 1 1x8
5
K6
J1-51,23 TO J1-48,20
K6
Group 1 1x8
6
K7
J1-50,22 TO J1-48,20
K7
Group 1 1x8
7
K8
J1-47,19 TO J1-39,11
K8
Group 1 1x8
8
K9
J1-46,18 TO J1-39,11
K9
Group 2 1x8
9
K10
J1-45,17 TO J1-39,11
K10
Group 2 1x8
10
K11
J1-44,16 TO J1-39,11
K11
Group 2 1x8
11
K12
J1-43,15 TO J1-39,11
K12
Group 2 1x8
12
K13
J1-42,14 TO J1-39,11
K13
Group 2 1x8
13
K14
J1-41,13 TO J1-39,11
K14
Group 2 1x8
14
K15
J1-40,12 TO J1-39,11
K15
Group 2 1x8
15
K16
J1-39,11 TO J1-39,11
K16
Group 2 1x8
REGISTER: 8002h
MODE: 16 bit
FUNCTION: Control Matrix K17 through K32, note shield is on J1-29 and J2-29
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
K17
J1-38,10 TO J1-30,2
K17
Group 3 1x8
1
K18
J1-37,9 TO J1-30,2
K18
Group 3 1x8
2
K19
J1-36,8 TO J1-30,2
K19
Group 3 1x8
3
K20
J1-35,7 TO J1-30,2
K20
Group 3 1x8
4
K21
J1-34,6 TO J1-30,2
K21
Group 3 1x8
5
K22
J1-33,5 TO J1-30,2
K22
Group 3 1x8
6
K23
J1-32,4 TO J1-30,2
K23
Group 3 1x8
7
K24
J1-31,3 TO J1-30,2
K24
Group 3 1x8
8
K25
J2-56,28 TO J2-48,20
K25
Group 4 1x8
9
K26
J2-55,27 TO J2-48,20
K26
Group 4 1x8
10
K27
J2-54,26 TO J2-48,20
K27
Group 4 1x8
11
K28
J2-53,25 TO J2-48,20
K28
Group 4 1x8
12
K29
J2-52,24 TO J2-48,20
K29
Group 4 1x8
13
K30
J2-51,23 TO J2-48,20
K30
Group 4 1x8
14
K31
J2-50,22 TO J2-48,20
K31
Group 4 1x8
15
K32
J2-49,21 TO J2-48,20
K32
Group 4 1x8
REGISTER: 8004h
MODE: 16 bit
FUNCTION: Control Matrix K33 through K48, note shield is on J2-29 and J2-1
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
K33
J2-47,19 TO J2-39,11
K33
Group 5 1x8
1
K34
J2-46,18 TO J2-39,11
K34
Group 5 1x8
2
K35
J2-45,17 TO J2-39,11
K35
Group 5 1x8
3
K36
J2-44,16 TO J2-39,11
K36
Group 5 1x8
4
K37
J2-43,15 TO J2-39,11
K37
Group 5 1x8
5
K38
J2-42,14 TO J2-39,11
K38
Group 5 1x8
6
K39
J2-41,13 TO J2-39,11
K39
Group 5 1x8
7
K40
J2-40,12 TO J2-39,11
K40
Group 5 1x8
8
K41
J2-38,10 TO J2-39,11
K41
Group 6 1x8
9
K42
J2-37,9 TO J2-30,2
K42
Group 6 1x8
10
K43
J2-36,8 TO J2-30,2
K43
Group 6 1x8
11
K44
J2-35,7 TO J2-30,2
K44
Group 6 1x8
12
K45
J2-34,6 TO J2-30,2
K45
Group 6 1x8
13
K46
J2-33,5 TO J2-30,2
K46
Group 6 1x8
14
K47
J2-32,4 TO J2-30,2
K47
Group 6 1x8
15
K48
J2-31,3 TO J2-30,2
K48
Group 6 1x8

Manual 07504208 Model 4208
Page 14
Operation Manual
REGISTER MAP - 32 BIT CONFIGURATION
DESCRIPTION: Model 4208
PART NUMBER: 85002670
PCB NUMBER: 85002670
MODE: 32 BIT
MSB
REG
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
8000h
K32
K31
K30
K29
K28
K27
K26
K25
K24
K23
K22
K21
K20
K19
K18
K17
LSB
REG
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
8000h
K16
K15
K14
K13
K12
K11
K10
K9
K8
K7
K6
K5
K4
K3
K2
K1
MSB
REG
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
LSB
REG
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
8004h
K48
K47
K46
K45
K44
K43
K42
K41
K40
K39
K38
K37
K36
K35
K34
K33

Manual 07504208 Model 4208
Page 15
Operation Manual
REGISTER: 8000h
MODE: 32 bit
FUNCTION: Control Matrix K1 through 32
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
K1
J1-56,28 TO J1-48,20
K1
Group 1 1x8
1
K2
J1-55,27 TO J1-48,20
K2
Group 1 1x8
2
K3
J1-54,26 TO J1-48,20
K3
Group 1 1x8
3
K4
J1-53,25 TO J1-48,20
K4
Group 1 1x8
4
K5
J1-52,24 TO J1-48,20
K5
Group 1 1x8
5
K6
J1-51,23 TO J1-48,20
K6
Group 1 1x8
6
K7
J1-50,22 TO J1-48,20
K7
Group 1 1x8
7
K8
J1-47,19 TO J1-39,11
K8
Group 1 1x8
8
K9
J1-46,18 TO J1-39,11
K9
Group 2 1x8
9
K10
J1-45,17 TO J1-39,11
K10
Group 2 1x8
10
K11
J1-44,16 TO J1-39,11
K11
Group 2 1x8
11
K12
J1-43,15 TO J1-39,11
K12
Group 2 1x8
12
K13
J1-42,14 TO J1-39,11
K13
Group 2 1x8
13
K14
J1-41,13 TO J1-39,11
K14
Group 2 1x8
14
K15
J1-40,12 TO J1-39,11
K15
Group 2 1x8
15
K16
J1-39,11 TO J1-39,11
K16
Group 2 1x8
16
K17
J1-38,10 TO J1-30,2
K17
Group 3 1x8
17
K18
J1-37,9 TO J1-30,2
K18
Group 3 1x8
18
K19
J1-36,8 TO J1-30,2
K19
Group 3 1x8
19
K20
J1-35,7 TO J1-30,2
K20
Group 3 1x8
20
K21
J1-34,6 TO J1-30,2
K21
Group 3 1x8
21
K22
J1-33,5 TO J1-30,2
K22
Group 3 1x8
22
K23
J1-32,4 TO J1-30,2
K23
Group 3 1x8
23
K24
J1-31,3 TO J1-30,2
K24
Group 3 1x8
24
K25
J2-56,28 TO J2-48,20
K25
Group 4 1x8
25
K26
J2-55,27 TO J2-48,20
K26
Group 4 1x8
26
K27
J2-54,26 TO J2-48,20
K27
Group 4 1x8
27
K28
J2-53,25 TO J2-48,20
K28
Group 4 1x8
28
K29
J2-52,24 TO J2-48,20
K29
Group 4 1x8
29
K30
J2-51,23 TO J2-48,20
K30
Group 4 1x8
30
K31
J2-50,22 TO J2-48,20
K31
Group 4 1x8
31
K32
J2-49,21 TO J2-48,20
K32
Group 4 1x8

Manual 07504208 Model 4208
Page 16
Operation Manual
REGISTER: 8004h
MODE: 32 bit
FUNCTION: Control Matrix K33 through K48
BIT
FUNCTION
CONNECTION
RELAY
COMMENT
0
K33
J2-47,19 TO J2-39,11
K33
Group 5 1x8
1
K34
J2-46,18 TO J2-39,11
K34
Group 5 1x8
2
K35
J2-45,17 TO J2-39,11
K35
Group 5 1x8
3
K36
J2-44,16 TO J2-39,11
K36
Group 5 1x8
4
K37
J2-43,15 TO J2-39,11
K37
Group 5 1x8
5
K38
J2-42,14 TO J2-39,11
K38
Group 5 1x8
6
K39
J2-41,13 TO J2-39,11
K39
Group 5 1x8
7
K40
J2-40,12 TO J2-39,11
K40
Group 5 1x8
8
K41
J2-38,10 TO J2-39,11
K41
Group 6 1x8
9
K42
J2-37,9 TO J2-30,2
K42
Group 6 1x8
10
K43
J2-36,8 TO J2-30,2
K43
Group 6 1x8
11
K44
J2-35,7 TO J2-30,2
K44
Group 6 1x8
12
K45
J2-34,6 TO J2-30,2
K45
Group 6 1x8
13
K46
J2-33,5 TO J2-30,2
K46
Group 6 1x8
14
K47
J2-32,4 TO J2-30,2
K47
Group 6 1x8
15
K48
J2-31,3 TO J2-30,2
K48
Group 6 1x8
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31

Manual 07504208 Model 4208
Page 17
Operation Manual
ASCOR 4208 VXI Card Assembly Module Programming Guide
The base offset address for the Model 4208 is 8000h. The total offset of the card is dependent
on the location of the card in the host VXI module, Series 4000. The offset is x8000h where x is
the card location number in hexidecimal.
refer to the program guide in the Series 4000 host VXI module manual for programing this card
