Culitek Mbc-25 User manual

This manual contains important information regarding your Culitek unit. Please read this manual

thoroughly prior to equipment set-up, operation and maintenance. Failure to comply with regular

maintenance guidelines outlined in this manual may void the warranty.

Instruction Manual

BOTTLE COOLERS

MBC-25, MBC-50, MBC-65, MBC-95

May 2020

MANUAL

Bootle Coolers

WARNING

DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED

SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING.

PELIGRO - RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARASER REPARADO

SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO. NO PINCHAR LA TUBERÍA REFRIGERANTE.

DANGER – RISQUE DE FEU OU D’EXPLOSION. LE FRIGORIGÈNE EST INFLAMMABLE. CONFIER LESRÉPARATIONS

À UN TECHNICIEN SPÉCIALISÉ. NE PAS PERFORER LA TUBULURE CONTENANT LE FRIGORIGENE.

CAUTION – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. CONSULT REPAIR MANUAL/OWNER’S

GUIDE BEFORE ATTEMPTING TO SERVICE THIS PRODUCT. ALL SAFETY PRECAUTIONS MUST BE FOLLOWED.

ATENCION - RIESGO DE INCENDIO O EXPLOSIÓN. REFRIGERANTE INFLAMABLE UTILIZADO. CONSULTE EL MANUAL DE

REPARACIÓN / GUÍA DEL PROPIETARIO ANTES DE INTENTAR DAR SERVICIO A ESTE PRODUCTO. DEBEN CUMPLIR CON

TODAS LAS PRECAUCIONES DE SEGURIDAD.

ATTENTION – RISQUE DE FEU OU D’EXPLOSION. LE FRIGORIGÈNE EST INFLAMMABLE. CONSULTER LE MANUEL DU

PROPRIÉTAIRE/GUIDE DE RÉPARATION AVANT DE TENTER UNE RÉPARATION. TOUTES LE MESURES DE SÉCURITÉ

DOIVENT ÊTRE RESPECTÉES.

CAUTION – RISK OF FIRE OR EXPLOSION DUE TO PUNCTURE OF REFRIGERANT TUBING; FOLLOW HANDLING

INSTRUCTIONS CAREFULLY. FLAMMABLE REFRIGERANT USED.

ATENCION - RIESGO DE INCENDIO O EXPLOSIÓN DEBIDO A LA PERFORACION DE LA TUBERÍA REFRIGERANTE; SIGA

LAS INSTRUCCIONES DE MANIPULACIÓN CON CUIDADO. REFRIGERANTE INFLAMABLE UTILIZADO.

ATTENTION – RISQUE DE FEU OU D’EXPLOSION SI LA TUBULURE CONTENTANT LE FRIGORIGÈNE EST PERFORÉE;

SUIVRE LES INSTRUCTIONS DE MANUTENTION AVEC SOIN. LE FRIGORIGÈNE EST INFLAMMABLE.

CAUTION – RISK OF FIRE OR EXPLOSION DUE TO FLAMMABLE REFRIGERANT USED. FOLLOW HANDLING INSTRUCTIONS

CAREFULLY IN COMPLIANCE WITH LOCAL GOVERNMENT REGULATIONS.

ATENCIÓN – RIESGO DE INCENDIO O EXPLOSIÓN DEBIDO A REFRIGERANTE INFLAMABLE UTILIZADO. SIGA LAS

INSTRUCCIONES DE MANIPULACIÓN CON CUIDADO CONFORME A LAS REGLAS DE LA MUNICIPALIDAD.

ATTENTION – RISQUE DE FEU OU D’EXPLOSION SI LE FRIGORIGÈNE EST INFLAMMABLE. SUIVRE LES INSTRUCTIONS DE

MANUTENTION AVEC SOIN CONFORMÉMENT AUX RÈGLEMENTATION GOUVERNEMENTALE LOCAUX.

May 2020

MANUAL

Bootle Coolers

BEFORE INSTALLING, PLEASE MAKE SURE:

• If the unit has recently been transported do not use for a minimum of 24 hours before installing.

• Make sure that the unit is at the desired temperature before loading it with product.

• Ensure that the unit will have proper ventilation in the area that it will operate.

• Inspect the unit to verify all accessories (shelves, shelf clips, casters) are equipped with the unit before proceeding with

installation.

• Review the entire manual in its entirety. Lack of maintenance or misuse of the unit will void the warranty.

• To minimize shock and re hazards, be sure not to over load the outlet. One outlet should be designated to the unit only.

• Do not use extension cords.

• Do not put hands under the unit when moving.

• When the unit is not being used for an extended period of time, unplug the unit from the outlet.

• After unplugging the unit, wait at least 10 minutes before re-plugging it. Failure to wait the allotted time may cause damage

to the compressor.

• To minimize shock and/or re hazards, be sure not to plug or unplug the unit with wet hands.

• Before any maintenance or cleaning, unplug the unit as a precaution.

• To minimize shock and re hazards, make sure that the unit is properly grounded.

• Do not attempt to remove or repair any component.

• Make sure that the unit is not resting on or against the electrical cord or plug.

• Do not hang or lean against door as this may cause personal injury or damage to the door hinge.

• Do not store any ammable and/or explosive gas or liquids inside the unit.

• Do not attempt to alter or tamper with the electrical cord.

• Do not set the desired temperature out of the recommended temperature range:

(REFRIGERATOR:33°F–55°F) (FREEZER:-8°F – 20°F)

CABINET LOCATION GUIDELINES

Install the unit on a at sturdy surface

• Unit may make abnormal noises if surface is uneven

• Unit may malfunction if surface is uneven

Install the unit in an indoor, well-ventilated area

• Unit performs more e󰀩ciently in a well-ventilated area

• For optimal performance, maintain a clearance of at least 6” around all sides

• Outdoor use may cause decreased performance and may damage the unit

Avoid installing the unit in a high humidity and/or dusty area

• Exposure to humidity may cause the unit to rust and/or decrease the e󰀩ciency of the unit.

• Dust build up on the condenser coil will cause the unit to malfunction. Clean the condenser at least once a month

with a brush or clean cloth. Neglect of maintenance will void the warranty.

Select a location away from heat and moisture generating equipment

• High ambient temperatures will cause the compressor to overcompensate, leading to higher energy bills and

eventual break down of the unit.

• Malfunction due to high temperatures will void the warranty.

ELECTRICAL

Please ensure that the required voltage of the compressor is constant at all times. Low or high voltage can detrimentally

a󰀨ect the unit and there by void its warranty.

All units should be plugged into a grounded and properly-sized electrical outlet with an appropriate over current

protection. Please refer to the electrical requirements on the serial tag located inside the unit. Please make sure that the

unit has its own dedicated outlet. Do not use an extension cord.

WARNINGS

INSTALLATION

May 2020

MANUAL

Bootle Coolers

TEMPERATURE CONTROLS

The temperature controls are factory set to maintain an average temperature of 38F.

Regulating the Temperature

Your new refrigerator is now manufactured to run at ideal temperatures for food quality and should

not require any alterations.

Refrigerators are set to cycle between a base temperature of 33° Fahrenheit and a temperature maximum

of 41° Fahrenheit.

Altering the temperature changes the base temperature your unit will keep running at. Your unit won’t run always at

this setting. To change it, follow these instructions:

• Hold “SET” for 1 sec. The display will ash the temperature that the refrigerator is currently set to.

• Use the arrow buttons to adjust the temperature.

• Press “SET” to save your settings.

mute

set

REFRIGERATOR CONTROL

RUNNING A MANUAL DEFROST CYCLE

This unit is pre-programmed to run automatic defrost cycles at preset intervals. However, if you would like to run a

manual defrost cycle at any time, please follow the steps below:

Refrigerators: Press the defrost button (snowake symbol and down arrow) for approximately 3 seconds. Repeat

to stop the defrost cycle.

DEFROST SYSTEMS

Refrigerator coils are kept below the freezing point (32°F). During compressor down time, the evaporator fan

continues to circulate air through the evaporator coil. This air circulation raises the coil temperature above the

freezing point, melting any accumulated frost. Run-o󰀨 water is drained in to the evaporator pan and evaporated.

Freezer coils are defrosted electrically. Automatic defrost timers are built in to their refrigeration system and may

not be adjusted. The defrost timers automatically initiate at pre-set intervals and for a pre-determined duration.

NOTE: We strongly reccomend that any servicing be performed by an authorized service technician.

May 2020

MANUAL

Bootle Coolers

LOADING PRODUCT

The bin dividers have been pre-installed. The dividers may be adjusted during initial installation. To remove the bin

dividers, simply push the divider towards the back wall until the front of the divider is removed from the positioning holes.

To install, position the divider to the desired holes, making sure that the pressure spring is installed properly.

DO NOT LOAD PRODUCT ABOVE THE LOAD LIMIT STICKERS OR ABOVE THE TOP CROSS BAR OF THE BIN

DIVIDERS. LOADING PRODUCT ABOVE THE LOAD LIMIT STICKERS WILL HARM THE PERFORMANCE OF THE

UNIT AND WILL VOID THE WARRANTY.

DO NOT LOAD PRODUCT ABOVE

THE TOP CROSSBAR. DOING SO

WILL DAMAGE THE COOLER AND

VOID THE WARRANTY.

REGULAR MAINTENANCE

WARNING: Disconnect power cord before cleaning any parts of the unit.

CLEANING THE CONDENSER COIL

For e󰀩cient operation, it is important that the condenser surface be kept free of dust, dirt, and lint. It is highly

recommended that the condenser coil be cleaned at least once a month. Clean with a commercial condenser coil

cleaner and brush the condenser ns from top to bottom. After cleaning, straighten any bent ns with a ne comb.

CLEANING THE FAN BLADES AND MOTOR

If needed, clean the fan blades and motor with a soft cloth if there is any build up. If it is

necessary to wash the fan blades, cover the fan motor rst to prevent any kind of moisture damage.

CLEANING THE INTERIOR OF THE UNIT

When cleaning the cabinet interior, use a mixture of mild soap and warm water. It is not recommended to use steel wool,

caustic soap, abrasive cleaners, or bleach as this may cause damage to the stainless steel surface.

Wash door gaskets on a weekly basis. Remove the door gasket from the frame of the door, soak

in a mixture of mild soap and warm water for 30 minutes and dry with a soft cloth.

• Place back on the door and check that the gaskets form a proper seal after they are replaced.

• Periodically remove the shelves and pilasters from the unit and clean them with a mild soap and water mixture.

• To remove the pilasters, rst remove the shelves and shelf brackets. Then lift the pilaster up and out.

May 2020

MANUAL

Bootle Coolers

SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION

Compressor not running Blown fuse or circuit breaker

tripped

Unplugged power cord

Thermostat set too high

Cabinet in defrost cycle

Replace or reset circuit breaker

Plug in power cord

Set thermostat to lower

temperature

Wait for defrost cycle to nish

Condenser runs for long

Periods of time

Excessive amount of warm

Products placed in cabinet

Prolonged door opening or

door left open

Door gasket(s) not creating a

proper seal

Dirty condenser coil

Evaporator coil iced over

Allow adequate time for

Product to cool down

Ensure doors are closed.

Avoid leaving the door open

for long periods of time

Ensure gasket is installed

correctly and that it is clean.

Replace gasket if necessary

Clean the condenser coil

Unplug unit and allow coil to

defrost. Ensure that the

thermostat is not set too cold.

Ensure that the door gasket is

creating a proper seal

Cabinet is noisy Loose parts

Tubing vibration

Locate and tighten loose parts

Ensure tubing is free from contact

with other tubing or components.

TROUBLESHOOTING

Before requesting any service on the unit, please check the following chart. Service calls resulting from lack of

maintenance or misuse is not covered under the warranty and may also void the warranty. Please note that this guide

serves only as a reference for solutions to common problems.

May 2020

MANUAL

Bootle Coolers

SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION

Cabinet temperature is too

warm

Thermostat set too warm

Blocked air ow

Excessive amount of warm

products placed in the cabinet

Blown fuse or circuit breaker

tripped

Dirty condenser coil

Prolonged door open

Evaporator coil iced over

Set thermostat to lower

temperature

Re-arrange products to allow

proper air ow. Make sure

there is at least four inches of

clearance from evaporator

Allow adequate time for

products to cool down

Replace fuse or reset circuit

breaker

Clean the condenser coil

Ensure doors are closed.

Avoid leaving the door open

for long periods of time

Unplug unit and allow coil to

defrost. Ensure that the

thermostat is not set to cold.

Ensure that the door gasket is

creating a proper seal

Troubleshooting Continued...

TWO YEAR WARRANTY

Culitek warrants to the original purchaser of this unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal use

and service, for a period of two (2) years from the date of original purchase.

Any parts covered by this warranty that are examined and determined to have been defective within two (2) years of original purchase shall be repaired or

replaced as stated below. Shall be deemed to have fully complied with its obligation under the foregoing warranties by electing either one of the following

procedures

1. Furnishing a replacement part, freight collect, in even exchange for the returned part, freight collect.

2. Receiving the defective part, freight collect; repairing it; and returning it, freight collect.

ADDITIONAL THREE YEAR COMPRESSOR PART WARRANTY

In addition to the (2) two year warranty stated above, Culitek warrants its hermetically and semi-hermetically sealed compressor to be free from defects in

both material and workmanship under normal use and service for a period of three (3) additional years from the date of original purchase but not to exceed

ve (5) years and three (3) months after shipment from manufacturer.

Compressors determined to have been defective within this extended time period will be either repaired or replaced with a compressor or compressor parts

of similar design and capacity.

The three (3) year extended compressor warranty applies only to hermetically and semi-hermetically sealed parts of the compressor and does not apply

to any other parts or components, including, but not limited to, cabinet, paint nish, temperature control, refrigerant, metering device, driers, motor starting

equipment, fan assembly any other electrical component, etc.

R290 COMPRESSOR WARRANTY

The three year compressor warranty detailed above will be voided if the following procedure is not carefully adhered to:

1. This system contains R290 refrigerant and polyester lubricant. The polyester lubricant has rapid moisture absorbing qualities. If long exposure to

ambient conditions occur, the lubricant must be removed and replaced with new lubricant. Failure to comply with recommended lubricant specication

will void the compressor warranty.

2. Dryer replacement is very important and must be changed when a system is opened for servicing. Dryer must be used with XH-9 desiccant.

3. Micron level vacuums must be achieved to insure low moisture levels in the system. 500 microns or lower must be obtained.

WHAT IS NOT COVERED BY THIS WARRANTY

Obligation under warranty is limited to either repair or replacement of parts, subject to the additional limitations below. This warranty neither assumes nor

authorizes any person to assume obligations other than expressly covered by this warranty.

1. WARRANTY IS NOT TRANSFERABLE. This warranty is not assignable and applies in favor of the original purchaser/user to whom delivered. Any such

assignment or transfer shall void the warranties herein made and shall void all warranties, express or implied, including any warranty of merchantability

or tness for a particular purpose.

2. NO CONSEQUENTIAL DAMAGES. Not responsible for economic loss: prot loss or special, indirect, or consequential damages, including without

limitation, losses or damages arising from food or product spoilage claims whether or not on account of refrigeration failure.

3. ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD. Not

responsible for the repair or replacement of any parts that have been subjected after the date of manufacture to alteration, neglect, abuse, misuse,

accident, damage during transit or installation, re, ood, or an Act of God.

4. NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. There are no other warranties, express, implied

or statutory, except the two (2) year warranty and the additional three (3) year compressor warranty as described above. These warranties are exclu-

sive and in lieu of all other warranties, including implied warranty and merchantability or tness for a particular purpose. There are no warranties which

extend beyond the description on the face hereof.
